Fulton 2-Speed Trailer Winch - 10" Long Handle - 20' Strap - Zinc - 3,200 lbs

Fulton 2-Speed Trailer Winch - 10" Long Handle - 20' Strap - Zinc - 3,200 lbs

Item # F142424
lowest price pledge
Retail:$210.22
Our Price: $186.62
You Save: $23.60
Trailer Winch
This item qualifies for Free Shipping
Shipping Weight: 18 lbs
Quantity:
In Stock
F142424 - Extra Heavy Duty Fulton Trailer Winch
zoom in icon
slider vertical icon
zoom out icon
Comment field cannot be left empty.
Name field cannot be left empty.

Thank you! Your comment has been submitted successfully. You should be able to view your question/comment here within a few days.

Error submitting comment. Please try again momentarily.

Product Images

Customer Photos

Videos

Durable winch has 2 speeds - 1 for quick pull in, the other for greater mechanical advantage - and a neutral, freewheeling position for fast line payout. Corrosion-resistant zinc finish is great for marine applications. Includes a 20' strap. Lowest Prices for the best trailer winch from Fulton. Fulton 2-Speed Trailer Winch - 10" Long Handle - 20' Strap - Zinc - 3,200 lbs part number F142424 can be ordered online at etrailer.com or call 800-298-8924 for expert service.
  • All Info
  • Reviews (56)
  • Q & A (27)
  • Photos
  • Why etrailer?

Fulton Trailer Winch - F142424

  • Standard Hand Winch
  • Boat Trailer Winch
  • Utility Winch
  • Polyester Strap
  • Extra Heavy Duty
  • Fulton
  • Two Speed Winch
  • Standard Hand Crank

Durable winch has 2 speeds - 1 for quick pull in, the other for greater mechanical advantage - and a neutral, freewheeling position for fast line payout. Corrosion-resistant zinc finish is great for marine applications. Includes a 20' strap.


Features:

  • Hand winch makes it easier to pull or lift large or heavy items
    • Ideal for boat trailers
  • 2 Speeds to fit your application
    • Fast speed lets you pull in quickly
    • Lower speed offers an increased mechanical advantage
  • Shift lock design lets you change gears without having to move the handle
    • No need to move handle from shaft to shaft - just slide the shaft into desired gear position
    • Shift lock holds the shaft in gear
  • Neutral, freewheel position for quick line payout without handle spinning
  • 20' Strap with safety hook included
  • Clear zinc finish provides superior corrosion resistance


Specs:

  • Handle length: 10"
  • Gear ratios: 5.1:1 and 12.2:1
  • Drum storage: 20' x 2" strap (included)
    • For use with strap only
  • Base dimensions: 5-3/4" wide x 7" long
  • Capacity: 3,200 lbs
  • Limited 5-year warranty


142424 Fulton 2-Speed Boat Trailer Winch with Heavy Duty Strap

Replaces T32ZHD0301

Installation Details F142424 Installation instructions


California residents: click here



Customer Reviews

Fulton 2-Speed Trailer Winch - 10" Long Handle - 20' Strap - Zinc - 3,200 lbs - F142424

Average Customer Rating:  4.7 out of 5 stars   (56 Customer Reviews)

Durable winch has 2 speeds - 1 for quick pull in, the other for greater mechanical advantage - and a neutral, freewheeling position for fast line payout. Corrosion-resistant zinc finish is great for marine applications. Includes a 20' strap.

- F142424
by:

I ordered this two speed Fulton winch because I keep my 18' center console on a trailer and launch and recover it about 60 to 70 times each fishing season and I have a bad shoulder and was tired of fighting the one speed direct drive winch to get the boat up the last couple of feet. This two speed winch makes everything much easier--cranking in the last two feet is very easy now, and the feature that allows you to free spool the strap out without the handle spinning around is awesome. I wish I had bought this winch two years ago, when I bought the boat. 682066


Comments
One year later and the winch is working very well. I have used it hauling out about 70 times now and the two-speed feature makes things easy. Im glad I bought it and recommend it.
Christopher G - 08/09/2020

96747

- F142424
by:

I love this jack! I bought it for my 1984 Ski Nautique single axle trailer. Works great and looks good. 716173



- F142424
by:

The winch has held up great.Would highly recommend etrailer for all your winch and trailer needs.Robert Johnson 659724



- F142424
by:

Replacing a smaller 900# Winch on my Macgregor 26s trailer. While I've not had the pleasure of using it on launch or retrieval yet, it certainly looks to be up to the job. I purchased from Etrailer because the information listed on other sites was incorrect. Etrailer, spelled everything out for me and gave me the confidence that I was getting what I was expecting. Have recommended this site to my friends. 171416


Comments
I use that winch on my 26 foot sailboat trailer. It Winches up that boat with no problem!Id say that it was a great purchase and it has met or exceeded all my expectations.Thanks for the follow up
David F - 02/06/2016

16690

- F142424
by:

Winch worked great pulled up my 87 Formula 242 up on the trailer with no problem. Big improvement over my old cable unit 699207


Comments
Still working great!
JAMES - 10/13/2020

102116

- F142424
by:

Had to replace because of bad gears, that didn't mesh well. My other winch lasted 14 years. Terrible winch. 259330



- F142424
by:

I purchased the Fulton 2-speed trailer winch to use on my Sun Tracker 25 ' pontoon boat. The winch is very well designed and made with excellent quality. The strapping installed on the winch has exactly the strength capacity and durability needed for my large pontoon boat. I sure don't expect to experience any winching problems related to this quality product. 615481



- F142424
by:

When I installed the winch I did have to drill new holes, but that was no problem. There was a problem with the winch. The pinion gear that drives the large gear on the real did not line up properly. It worked fine, but I was afraid over time winching my Four Winns 225 Sundowner boat it might wear the gear prematurely. I contacted etrailer.com and sent some pictures. They had a new winch in the mail the same day, and sent me a shipping label to send the old winch back. The people at etrailer.com are great. And the new winch is great. The neutral position allows the strap to be pulled out easily. It is easy to shift between high and low gear for fast and easy cranking my 5,000 lb. boat onto the trailer. 706600



- F142424
by:

Good website description 871039



- F142424
by:

Arrived ahead of schedule. Winch looks great. Very happy with how this order was handled. 871032



- F142424
by:

Works Great. When I was younger, old winch worked. I wish I had this on my trailer for the last 25 years. At 74 need the extra leverage. 848260



- F142424
by:

I absolutely love this winch! It is big and sturdy and handles my 23' boat very well. I went through 3 different winched trying to find one that I liked and trusted and this one was far superior to ANY of the others! We have even had to crank the boat in by hand once due to mechanical issues and it worked great! I have recommended this winch to all of my boating friends. 837098



- F142424
by:

The product arrived as expected and on time. I will order from etrailer.com in the future! Very Well Done! 822155



- F142424
by:

Exactly what it is. Nice and strong. 820116



- F142424
by:

The boat trailer winch we purchased. It's well-built easy to use holds the weight of our boat with no problem. There site was easy to navigate and within days we got our product 783493



- F142424
by:

The Fulton,F142424, is a tremendous asset for a boat trailer. It’s almost effortless winching my boat back on the trailer now with the two speed winch option. Wish I had bought this winch years ago. I launch and recover my boat on some pretty shallow public ramps sometimes and you have too winch the boat on rather than drive it on. This winch makes that process a whole lot easier. 776565



- F142424
by:

Great turn around! Installed on my boat and very happy! 773680



- F142424
by:

very happy with response i got an the people showed alot of concern to make sure i got treated good an order was processed an shipped in a very quick an timely maner will be ordering produsts from them more offen. 734983



- F142424
by:

Had a tax exempt issue with an online order, called customer service and the issue was resolved. The winch was an exact replacement with a strap (not available most places) and it arrived in 2 day with free shipping! 725703



- F142424
by:

Has worked very well 713154



- F142424
by:

Replaced my old cable winch with a strap type. Mounting was easy. Totally satisfied with this quality product 698526



- F142424
by:

I had just bought a new boat. the winch it came with was brand new. of course the previous owners went cheap and bought a way undersized piece of garbage!! it stripped out on my first use!! The new one from etrailer is a BEAST!! So far it works Awesome!! I have bought from them in the past and always get awesome service and fast delivery! You always get what you pay for!! if you want cheap china junk buy from amazon and ebay.. If you want something well built and built to last then buy here!! 697886



- F142424
by:

Product was exactly as described. Would order again. 682088



- F142424
by:

Came on time and fit my trailer great. Much better than my cable winch and won't cut up my hands from handling an older cable. Glad I made the upgrade. 660565



- F142424
by:

Excellent product works great and did everything it was advertised to do ! 655485


28
59
Show More Reviews

Ask the Experts about this Fulton Trailer Winch

  • Recommended Replacement Hand Winch for a Boat Trailer with a 6,500 Lb Boat
    It is always a good idea to use a winch that is overrated for the purpose you will be using it for. A winch that is used near the bottom end of its capacity will last much longer then a winch used at the top end of its capacity. We do have wire rope options for a hand winch on your boat trailer but I recommend using a winch with a synthetic strap as this will last longer for marine applications in addition to causing less damage if the strap were to break. For your 6,500 lb boat, I...
    view full answer...
  • Recommended Trailer Winch for 25 Foot Pontoon Boat
    The Fulton 2-Speed Trailer Winch with Heavy Duty 20' Strap - Zinc - 3,200 lbs # F142424 will work well with your 25 foot Sun Tracker Pontoon Boat. The only thing to consider is if you desire a longer strap, which for most trailers wouldn't be needed as you'd float more than 5 feet onto the back of the trailer prior to connection and release prior to that for launch to have adequate footing. If you like the enclosed winch with the same two speeds and capacity, then I recommend the Fulton...
    view full answer...
  • How To Install A Strap On the Fulton 2-Speed Trailer Winch F142424
    The instructions for attaching a strap to the Fulton 2-Speed Trailer Winch part # F142424 will be listed for you on the first page of the owner's manual for the winch. I have also attached these for you below just in case you don't have them.
    view full answer...
  • Recommended Hand Winch for 16 Foot Open Car Hauler Trailer
    For your 16 foot open car hauler, I recommend the Fulton 2-Speed Trailer Winch with Heavy Duty 20' Strap # F142424. This is rated for 3,200 lbs and is zinc plated to resist corrosion. It has 2 speeds for quick pull or increased mechanical advantage. It has a free-wheel position and a shift lock to keep the shaft in gear. For a winch stand, we have # CE31013G and bracket # DL24110. Your other option is to consider using an electric utility winch like # BDW15019 and then use wiring...
    view full answer...
  • Fulton T3205 Winch Replacement
    Yes. The Fulton 2 Speed Trailer Winch # F142424 will work as a replacement for your old Fulton T3205 winch. It has the exact same 5.1:1 and 12.2:1 gear ratios as the T3205 and also comes with a 10" handle. I've attached a picture for reference to show some of the measurements-but this is a fairly universally mounted winch. The long holes on the bottom are 1" long and 1/2" from the edges of the plate; the center hole is 2-3/8" from the edge (center of the hole); the long hole at the...
    view full answer...
  • Why Does Winch Handle Rotation Change Direction When changing Speeds
    Fulton 2-speed winch # F142424 DOES have a change in handle rotation direction for each of its two speeds. You can see this in the linked video. This is also true for Dutton-Lainson 2500-lb Hand Winch # DL14825 which uses two separate shafts, one for each speed. This winch does not include the strap but with it you can use # DL24249. I checked many of our 2-speed winches and they all have this reverse-direction cranking.
    view full answer...
  • How to Pick Out Boat Winch for 2,550 lb Boat
    Generally when picking out a winch for a boat trailer the ratio is 2 to 1 meaning you would need a winch with roughly half the capacity as the weight of the boat. With good rollers and a short winching distance the ratio increases to 3 to 1, but with long winching distances and wooden bunks like what you currently have the ratio is 1 to 1. The Fulton Winch # F142424 that you referenced should work well for you although it may be a bit overkill. The Dutton-Lainson Hand Winch # DL14725...
    view full answer...
  • Capacity of Strap on Fulton Winch Part # F142424
    The strap on the Fulton 2-Speed Trailer Winch # F142424 is the part # FWS20HD0200 which has a capacity of 4,000 lbs working load limit and break strength of 10,000 lbs. I attached a review video for the strap for you to check out as well.
    view full answer...
  • Does Fulton 2 Speed Winch part # F142424 Have a Brake
    The Fulton 2 Speed Winch part # F142424 that you referenced will lock with every gear click as you turn the handle. The only way it's going to free wheel is if you pull down on the lever you see in the picture I attached.
    view full answer...
  • Winch Recommendation for Boat Trailer with 6,000 lb Boat
    Generally when picking out a winch for a boat trailer the ratio is 2 to 1 meaning you would need a winch with roughly half the capacity as the weight of the boat. With good rollers and a short winching distance the ratio increases to 3 to 1, but with long winching distances and wooden bunks like what you currently have the ratio is 1 to 1. The Fulton Boat Winch part # F142424 would work well for you. It has a 3,200 lb capacity and would make easy work of your 6,000 boat. I attached a...
    view full answer...
  • Determining Best Replacement Winch for Bryant Ski Boat
    We do have a large selection of hand winches available. The winch that will work best for your Bryant Ski Boat will depend on a few different factors. Generally speaking, a boat-size-to-winch capacity is around 2 to 1, meaning a 3,000 pound capacity winch should be able to handle a 6,000 pound boat. If your boat trailer is equipped with good rollers and you have a short winching distance, this ratio can be increased to 3 to 1. If your trailer has wooden bunks and you have a longer winching...
    view full answer...
  • Recommended Mounting Hardware for Fulton 2-Speed Trailer Winch
    I took a look at the manual for the Fulton 2-Speed Trailer Winch # F142424 and it specifies that to install the winch you will need to use 3/8" diameter grade-5 hardware of the length appropriate to where you are mounting it. You only need to source this hardware locally at any hardware store. I have added a link to a video review of this winch for you to check out as well.
    view full answer...
  • Recommended Hand Winch for 4,600 Lb Boat Trailer
    There are numerous factors in play for selecting a boat trailer winch, one of which is whether or not the trailer has rollers but the number of layers out on the strap and the angle of the boat while retrieved also matter. Without getting too technical, a 2:1 ratio is sufficient so the Fulton 2-Speed Trailer Winch part # F142424 is what I recommend and it will give you room to spare as well.
    view full answer...
  • Recommended Hand Winch for a Pacific Boat Trailer
    For your Pacific boat trailer, I recommend using the Fulton 2-Speed Trailer Winch with Heavy Duty Strap part # F142424. This winch has a zinc plating for extreme corrosion resistance, two speed handle for faster cranking, and a twenty foot strap with included safety hook. It has a 3,200 lb weight capacity which will be more than sufficient for your 4,500 lb boat as you have bunk boards and the boat is a rolling load. It comes with a five year warranty. I have attached a review video for...
    view full answer...
  • Replacement for Fulton Boat Trailer Winch T3205
    The Fulton 2-Speed Trailer Winch part # F142424 will be a direct replacement for your Fulton Boat Trailer Winch T3205 as they use the same mounting plate therefore no drilling will be required.
    view full answer...
  • Picking Out Hand Winch for Trailer with 19 Foot Larson Boat
    I believe your boat is around 3,000 lbs from what I was able to find on it but I'd recommend confirming that if you aren't sure. So to pick out a winch you'd just need to go with one that has at least a 1,500 lb capacity since the ratio for picking out a winch based on a boat weight is 2 to 1. The Fulton you mentioned part # F142424 would be overkill as it has a 3,200 lb capacity but it would work really well and be easy to use. For a lighter duty winch that would still work great but...
    view full answer...
  • Fitting A Wide Winch To A Narrow Frame For A Malibu 2002 Wakesetter Boat Trailer
    After contacting the manufacturer of the Fulton 2-Speed Trailer Winch # F142424, they confirmed what you would need is a custom weld completed to mount a wider plate to your frame in order to then mount this winch. The mounting space needs to equal or exceed the width of the winch so you were correct to identify this as a potential concern.
    view full answer...
  • Is Line Payout Difficult with Fulton F2 2-Speed Trailer Winch # FW32000101
    You are correct that the Fulton F2 2-Speed Trailer Winch # FW32000101 no longer has the neutral feature due to safety reasons. While you can certainly still pull the strap out when needed it does take quite a bit of effort (the handle will turn 16 times to 1 drum revolution when in low speed). Depending on how far away the boat is when this type of operation is needed you might find yourself wishing you had a winch with a neutral position. Because of this I do recommend going with the...
    view full answer...
  • Comparison Between Fulton FW32000101 F2 and Two Speed F142424 Hand Winches
    I'm not sure which winch you're wanting to compare to the # FW32000101 Fulton F2. Could you have meant the Fulton two speed, part # F142424? Both winches have a 3200 lb capacity, both use a 20 foot strap, and both have two speeds. The F2 has an enclosed spool that helps protect the strap from UV exposure while the two speed's spool is is exposed. Other than that, the differences between the two are cosmetic. The ideal ratio between boat weight and winch capacity is 2:1, so either...
    view full answer...
  • Recommended Electric Winch to Replace Fulton 3,200 lb Manual Winch
    We absolutely offer returns on unused items and you can see the details in our return policy under the customer service link on any product page. For your power winch, I recommend the Bulldog Winch Trailer Winch - Wire Rope - Roller Fairlead - 4,400 lbs # BDW15019 or synthetic rope version # BDW15020. To give you the similar strength to the Fulton 2-Speed Trailer Winch with Heavy Duty 20' Strap - Zinc - 3,200 lbs # F142424. If instead you were looking for a boat trailer winch, then...
    view full answer...
  • Recommended Winch That Pulls 800 lbs up Slope
    There are both manual and electric winches which will work for you. For an electric winch, I recommend the Dutton-Lainson StrongArm Electric Winch, AC Powered - 2,700 lbs # DL24965. This winch draws 6 amps at 120 volts, has a full load speed of 7 feet per minute and a cable that is 7/32" diameter x 25' long. It can be mounted using the Mounting Adapter Plate for StrongArm Electric Winches # DL24055 or Angle Mounting Plate for StrongArm Electric Winches # DL24059 and the Quick Mount Kit...
    view full answer...
  • Boat Trailer Winch that Has Capacity for 18,000 lb Boat
    With boat winches you generally only need 50 percent of the boats weight as the winch's weight capacity. So for a 18,000 lb boat like you have you'd need a winch with at least a 9,000 lb capacity. For that we have the Fulton XLT Powered Winch part # F500621 which has a 10,000 lb capacity and would be your best option. The strap is only 15 feet long though so you'd need to make sure you could get the boat within 15 feet from being fully on the trailer.
    view full answer...
  • Strap Winch for Boat Trailer with Rollers
    You can use a strap type winch instead of a cable winch so long as your trailer's rollers are in good shape and the weight of your 28-ft Cuddy is not more than 3-times the winch's rating. Rollers allow you to use a winch rated for as low as 1/3 of the boat weight. I suggest the zinc-plated Fulton 2-Speed model # F142424 which is rated for 3200-lbs and which has a 20-foot strap.
    view full answer...
  • Direct Replacement Winch Fulton Boat Trailer Winch T3205
    Since the Fulton T3205 that you mentioned is not made anymore we do not have very many replacement parts available. In fact the only replacement part we have is the spring part # 4769-28 and handle part # F501108. The only option at this point is to replace the winch with a direct replacement Fulton 2-Speed Trailer Winch - 10" Long Handle - 20' Strap - Zinc - 3,200 lbs part # F142424 which fits the same universal mounting plate so no drilling will be required. I wish there was another...
    view full answer...
  • Can Fulton F2 FW32000101 Boat Trailer Winch Be Mounted Vertically
    According to Fulton, their # FW32000101 wouldn't work very well if mounted vertically because the strap would rub against the opening in the housing which would cause friction and heat that would eventually weaken the strap. Using a more traditionally designed 3200 lb capacity winch such as # F142424 would work much better for you. Other than the adjustable handle and the housing enclosing the winch, mechanically speaking the # F142424 would operate the exact same as the # FW32000101 winch...
    view full answer...
  • Solutions for Fulton T3700 Winch with Broken Cable
    The current version of your Fulton T3700 is the part # F142430 which is a cable-only winch like what you have. Best options I have would be a new cable for yours that is broke like with part # FWC7500100 for a 50 foot cable or to go with a new winch that uses a strap instead like the Fulton part # F142424 which has a similar 3,200 lb capacity. Only downside to the straps is they aren't as long as the cables since the layers add up quicker. This comes with a 20 foot long strap.
    view full answer...
  • Available Replacement Parts for JIF Marine 3200-lb Hand Winch
    The only replacement part available for the Jif 2-Speed Boat Trailer Winch # 315-W3200D is the Hand Winch Strap with Safety Hook # DL24242. If you need to replace your winch and are looking for something that does have replacement parts available, the Fulton 2-Speed Trailer Winch # F142424, which has a ratchet repair kit available with part # F501133 and a replacement strap # FWS20HD0200.
    view full answer...
