Kwikee Electric RV Step Complete Assembly - Double - 40 Series - 24" Wide

Kwikee Electric RV Step Complete Assembly - Double - 40 Series - 24" Wide

Item # LC3726892
Our Price: $857.46
RV Steps
Add to cart
In Stock
zoom in icon
slider vertical icon
zoom out icon
Comment field cannot be left empty.
Name field cannot be left empty.

Thank you! Your comment has been submitted successfully. You should be able to view your question/comment here within a few days.

Error submitting comment. Please try again momentarily.

Product Images

In Use/Installed

Need help with installation?
Locate installers near me
Electric step assembly includes everything you need to automatically open and close the steps with your RV door. Motor and control unit extend and retract steps. Switch kit overrides step retraction. Amber light illuminates when steps extend. Great Prices for the best rv steps from Kwikee. Kwikee Electric RV Step Complete Assembly - Double - 40 Series - 24" Wide part number LC3726892 can be ordered online at or call 1-800-940-8924 for expert service.
  • All Info
  • Reviews (20)
  • Q & A (0)
  • Photos
  • Used (1)

Kwikee RV Steps - LC3726892

  • Electric Step
  • Motorhome
  • 2 Steps
  • 24 Inch Wide Step
  • Kwikee
  • 25-3/4 Inch Wide
  • 8 Inch Drop/Rise
  • Steel
  • No Ground Contact

Electric step assembly includes everything you need to automatically open and close the steps with your RV door. Motor and control unit extend and retract steps. Switch kit overrides step retraction. Amber light illuminates when steps extend.


  • Electric RV steps automatically extend when you open the door and retract when you close the door
    • Includes everything you need - motor, control unit, switch kit, and light
  • Motor works with gearbox to extend and retract the steps
  • Control unit wires steps and step light to the opening and closing of the RV door
  • Switch kit allows you to override automatic retraction and lock steps in extended position
    • Keeps the steps out when parked, whether the door is open or closed
  • Amber incandescent light illuminates steps to make them easy to see at night
  • Integrated safety features help prevent damage to the steps
    • Motor retracts the steps if they strike an obstacle during extension
    • Ignition override retracts the steps when the vehicle's engine is started
  • Non-slip tread and easy-to-see reflective strips on step surface
  • Sturdy, powder coated steel construction with weatherproof wiring withstands the elements
    • Solid steel drive rods and stainless steel bushings provide additional durability
    • Air pressed rivets at pivot points ensure long-term strength
  • Simple installation with existing mounting holes and wiring harness
    • Hardware sold separately
  • Made in the USA


  • Extended height: 17-1/4"
    • Folded height: 6-3/4"
  • Overall width: 25-7/8"
  • Mounting plate dimensions: 24-1/4" wide x 14-5/8" deep
  • Bolt pattern: 20-1/2" wide x 12-7/8" deep
  • Step dimensions: 24" wide x 11-1/8" deep
  • Drop/Rise: 8-1/4"
  • Voltage:
    • Motor: 12V
    • Switch kit: 250V
  • Control unit amperage: 10A
  • Light bulb type: C193, incandescent
  • Control unit wire gauge:
    • Green: 12 AWG
    • Purple: 16 AWG
  • Weight capacity: 300 lbs
  • 1-Year warranty

Note: This step assembly includes everything you need to install and use the steps on your RV.

The included 4-way plug fits into the existing wiring harness on your RV. Most vehicles should having this wiring already set up. In the event that your RV is missing the wiring, a 4-way pigtail is included to help you hardwire the unit to your RV.

Safety Features

The Kwikee steps include several safety features in an effort to prevent injury to you or your passengers and damage to the RV steps. If an obstruction is detected while extending, the steps will halt and retract back into the stowed position. The steps will also retract when you turn on the vehicles ignition, even if the automatic retraction override has been activated, in case you forget to stow them before driving away.

Will Kwikee Electric Steps Work for You?

Electric steps are typically installed on RVs and some travel trailers. The electric steps from Kwikee install and fold up underneath the camper for simple storage. To ensure you choose the correct size for your application, there are a few measurements you will need to take.

Kwikee In and Out

The Kwikee electric steps attach to the underside of the camper chassis, directly beneath the doorway. To decide which size you'll need, locate the space available underneath your camper that lines up with the doorframe, and measure the width and depth. You will need a mounting space that is at least 25-7/8" wide and 14-5/8" deep.

If it turns out you have more or less space beneath your doorway, there are other step assemblies available with bracket sizes ranging from 24-3/4" wide to 37-1/4" wide. A full list of the available steps is below.

Outriggers for RV Steps

Outriggers - metal brackets that act as an extension (LC301704 - sold separately) - may be needed for installation depending on the model of your original stairs. These provide extra length if the old steps are longer or wider than the new.

Once you know where the mounting bracket will go and what size mounting bracket you need, that spot will be used as the "mounting point" to determine how many steps you will need.

How Many Steps Do You Need?

Kwikee Entry Height

To decide on how many steps you'll need, measure from the mounting point to the ground. This is called the entry height. The entry height should roughly match the height of the steps when they're fully extended, plus 6" to 8" to account for the drop from the bottom step to the ground. This measurement will also tell you how many steps you need.

The chart below displays mounting bracket widths in the first column and entry height measurements in the second column. The third column shows the corresponding part numbers. Use the mounting bracket width and entry height measurements you took to determine which part number will fit your RV. Choose the bracket size that is closest to your measurements without going over.

This page's step assembly is in bold text.

Mounting Bracket WidthEntry HeightPart Number (Complete Assembly)Part Number (Replacement Assembly)
24-3/4"15-5/8" - 17-5/8"LC3747453LC3747452*, LC3747451**
25"16-3/4" - 18-3/4"LC3724742n/a
25-1/2"27-7/8" - 29-7/8"LC3658373LC369552*, LC365837*
25-1/2"20-1/8" - 22-1/8"LC372261LC3722615*, LC3722617**, LC3722616***
25-1/2"20-1/2" - 22-1/2"n/aLC3725791*
25-1/2"12-1/8" - 14-1/8"LC3723383LC372338**
25-1/4"13" - 15"LC3711363LC371136*, LC3711361**
25-3/4"22-7/8" - 24-7/8"n/aLC372558*
25-5/8"11-7/8" - 13-7/8"LC3691461LC369146*, LC3691462**
25-5/8"13" - 15"n/aLC3726041*
25-7/8"23-1/4" - 25-1/4"LC3726892LC3726891**
26-5/16"27-1/4" - 29-1/4"LC3694042n/a
29-3/8"18" - 20"LC3722661LC372266*, LC3722662**
30-1/4"15-1/4" - 17-1/4"n/aLC372779*
30-3/8"17-1/4" - 19-1/4"n/aLC427247*
30-5/8"20-1/2" - 22-1/2"n/aLC375632*
31-1/2"28-5/8" - 30-5/8"n/aLC375821*
31-1/2"12-3/8" - 14-3/8"LC3756271LC3756272**
32-3/8"20-1/4" - 22-1/4"LC3722862LC3722863**
37-1/4"18" - 20"n/aLC3694112*, LC369411***

*Motor and control unit

**Motor and switch kit

***Motor only

How Do You Install the Steps?

To install the steps:

  1. Hook up the steps to power to verify that all components are in working order
  2. Make sure the camper is level on flat ground
  3. Lift the steps into the mounting space and prop into place
  4. If needed, mark the mounting holes on the camper and drill

    -Set aside steps before drilling

  5. If needed, install the outriggers
  6. Align step mounting holes and secure in place with carriage bots and flange lock nuts

    -Make sure bracket is backed up fully against the I-beam on the chassis

    -Hardware not included

  7. Tighten hardware until snug
  8. Make sure assembly is sitting square and level
  9. Torque the hardware tight
  10. Connect the appropriate writing to your vehicle's source

3726892 Lippert Components (LCI) Quickie 40 Series Motorized Motorhome Entry Steps - 2 Stairs - 8" Drop/Rise - 24" Wide - 300 lbs

Kwikee Part Number 904009025

Customer Satisfaction Score:

Customer Reviews

Kwikee Electric RV Step Complete Assembly - Double - 40 Series - 24" Wide - LC3726892

Average Customer Rating:  5.0 out of 5 stars   (20 Customer Reviews)

Electric step assembly includes everything you need to automatically open and close the steps with your RV door. Motor and control unit extend and retract steps. Switch kit overrides step retraction. Amber light illuminates when steps extend.


These steps will be a perfect match to the original and will be installing them soon. Looking to to replacing the bent up, unrepairable and unsafe steps. Thank you ETRAILER for your expertise.

Robert C.


The steps have been working flawlessly and we love the automatic stow feature when going into gear. Great product!


Great fit, heavy, have a jack and maybe a helping hand or two.


Etrailer was easy to shop online, great price and fast shipping I ordered my kwikee step on Sunday and it was at my house on Tuesday. The installation was easy remove and replace using a small jack to hold the step in position. I did have an issue with the wire going to the motor, the retainer clip somehow was broken on arrival and would not hold the connector to the motor but a zip tie took care of that problem. The steps did not come with new magnetic switch so will have to order one separately the one on my rv was not working. Overall great shopping experience. Will shop here in the future.



The steps have worked perfectly and the installation was straight forward.The steps arrived fast and in like new condition. I look forward to doing business with your company in the future.


Bolt-on replacement. Some splicing required, mostly because whoever installed the last one added some unnecessary lights.

A challenge to lift into place, but I used a hydraulic auto jack to assist.

Only problem, the high current shutoff feature (when current increases, the control system shuts off the motor because increased current should mean the step reached the end of its travel) stops the steps prematurely. I'm hoping that as the steps wear in, this will stop happening. Until then, I need to provide a slight force upward when the steps retract to get them all the way up.



As a follow-up, no change. Step works but still stops prematurely.


After injury and age, getting in and out of a leveled RV is one high step. Having these steps reliably and sturdily come out each and very time needed is a big deal. I installed this on an older RV and for folks that have older RV's please note; the micro-switches in the the door frame are opposite of what are needed for today's control logic. As a result, I added a "Reversing relay" to create the proper signal from the door to have the steps operate as designed.


Salesperson was outstanding


I ordered electric steps in Feb and it was April 5th when I opened the box only to find that it was broken during shipping . I called that day and sent pics of the damage . etrailer said they would send replacement and it arrived today . I've never had such quick response. I want to thank you guys for handling this for me and I'll recommend yall to everyone that I can . Thanks again


I am 78 years old and removed the old step and installed the new one in about 4 hours. I have a 93 Safari that is in great shape and this makes it better.


Easy to find and order. Received in a very timely manner. Very happy with the product.


Good product, it was sometime before I had time to install it but all went well. It is such a relief knowing it is safe to step up or down. Thanks


After one year it has performed perfectly. I installed it myself as a complete unit


Super job guys . I will order again from yall .


Install went great. A direct bolt on for a 2005 Jayco Greyhawk 31SS.



The product came quickly and was just as advertised. Very HAPPY!!







See what our Experts say about this Kwikee RV Steps

  • Will the MORryde StepAbove Work With a Tiny Home That Has An Inward Opening Door?
    Yes, however you won't be able to keep them installed when traveling since the MORryde StepAbove RV Steps for 21-3/4" to 22-1/4" Wide Doorways # MR86RR stows inside when not in-use. These steps would have to be unattached and stored somewhere else anytime you were going to move your home, and then re-attached whenever you arrived. If that doesn't bother you at all, then yes these'll work just fine with your tiny home and would serve as a great upgrade to any current step-situation. I...
    view full answer...
  • What Kwikee Electric RV Step Replaces Coach Steps 725-0043 on 2005 Monaco Monarch
    I spoke with Lippert and they said the Kwikee Electric RV Step Complete Assembly, 40 Series, # LC3726892 will be a direct replacement for the Coach Steps 725-0043. It will be a bolt-on install for replacement of the steps.
    view full answer...
  • Replacement Kwikee Electric Steps for a 2005 Jayco Greyhawk 31SS
    There are and were numerous 2-step Kwikee electric steps available. To ensure we get you the correct replacement I would need to know the series of the steps you have. Check the underside of your steps for any model numbers or other information. The current available models are the 32 Series # LC372261, 42 Series # LC372779, 40 Series # LC3726892, 34 Series # LC3722863, and Platinum Series # LC372558. Any information you can find on your steps will help narrow it down.
    view full answer...
  • What is Overall Height of Kwikee 40 Series RV Steps When Extended Out
    When the Lippert Step part # LC3726892 is installed and extended completely the overall height would be 17-1/4 inches from where it mounts to the RV down to bottom of lower step.
    view full answer...
  • Dimensions Of Kwikee Electric RV Step 40 Series Complete Assembly
    I have the measurements of the Kwikee Electric RV Step Complete Assembly # LC3726892 you are looking for. From the top of the top of the mounting bracket to the bottom of the bottom step is 17-3/8", from the top step to the top of mounting bracket is 7.13", when full extended the overall depth from the back of the mounting step to the front of the bottom step is 33-5/8". I included a diagram of all of the measurements of the Kwikee Electric RV Step # LC3726892 for you to take a look at.
    view full answer...
    Image 1 for Image 2 for
  • Replacement Motor and Control Module For Lippert CoachStep
    You shouldn't need to replace the entire step assembly of your CoachStep, replacement parts should do the trick for you. As for the current replacement step, since CoachStep was discontinued some time ago, there isn't a specific replacement for these steps, you would need to measure the mounting bracket width and entry height. For example, if you had a mounting bracket width of 25-7/8" available and had an entry height of 23-1/4" - 25-1/4" you could install the Kwikee Electric RV Step Complete...
    view full answer...
  • 1-step Electric Steps With 2-Step Electric Steps On Itasca 31T Motorhome
    The motorized steps are designed to have the bottom step 6 to 8 inches off the ground which puts you in a difficult spot. One step is not enough and two steps are too many. The 2-step unit that fits most closely is the Lippert # LC3726892 model. It is 25-7/8" wide so there would be a one inch gap on each side. Then it is designed for an entry height of 17-1/4" where as you have a 14-1/2" entry height. With that in mind, instead of having 6 to 8 inches from the bottom step to the ground,...
    view full answer...
  • How to Determine Correct Replacement Step for 2000 National Sea Breeze Motorhome
    You never mentioned what info you were looking for, but I assume a replacement step, and I can tell you how to determine which one will work for you. What you will need to know is the amount of mounting space you have for the bracket as well as the entry height you need. For example, if you have a mounting space of at least 25-1/2" wide and an entry height of 14-1/8" you will need the Kwikee Electric RV Step Complete Assembly - Double - 32 Series # LC372261. Or if your mounting space...
    view full answer...
  • Replacement Gear Box Solution for Kwikee 40 Series RV Step
    Sounds like your Kwikee 41 series step is in need of a Replacement Gear Box and A Linkage # LC379160 instead of a whole new setup. That said the 40 Series part # LC3726892 would also fit as an easy replacement that uses the same mounting points.
    view full answer...
  • Replacement for Kwikee 40 Series Steps on RV
    The Kwikee Electric RV Step Complete Assembly part # LC3726892 would be a excellent replacement option for the Kwikee 40 Series Steps. It comes with everything you need for a new install such as the step assembly, door magnet, switch, controller, and motor.
    view full answer...
  • Recommended Kwikee Double Electric Step For 2012 Jayco Jayflight
    Lippert Components Kwikee 40 Series Double Electric Step # LC3726892 with mounting bolt pattern of 12.875x 20.5 inches are most likely the steps you are referring to. They have an 8 inch rise and 24 inch tread. They are able to extend and retract with the door opening, but they are also on a switch so you can leave them out if you desire. Kwikee is an OEM replacement, but I can't confirm that it will work on your trailer unless the mounting holes line up. There is not a master list...
    view full answer...
  • Replacement Manual Steps for 40 Series Kwikee Steps
    I have a great suggestion for replacing your powered steps with a manual pull out. But the powered 40 Series Kwikee Electric RV Step, # LC3726892 with a bolt pattern of 20-1/2" wide x 12-7/8" deep is the pattern the manufacturer set for their product; it is not an industry standard bolt pattern that is matched by others. I do not find a manual pull out step listed that can be confirmed to bolt match your existing bolt pattern. But I can recommend an easy to install pull step with great...
    view full answer...
    Image 1 for
  • Dimensions of Lippert Components Kwikee 40 Series Double Electric Step
    When retracted, the Lippert Kwikee 40 Series Double Electric Step # LC3726892 measures 20.5" long and 6.5" high. When the steps are deployed they measure 33.63" long and 17.38" high; the steps have a mounting bolt pattern of 12.875" x 20.5" that would need to match what is on your RV for the steps to work.
    view full answer...
    Image 1 for
  • Difference Between Kwikee 40 Series RV Steps # LC3726892 and # LC3726891
    There is a slight difference between the # LC3726892 and # LC3726891. The # LC3726892 comes with a control switch setup that allows the light and step to come on and off with the opening and closing of the door.
    view full answer...
  • Automatic Deploying RV Step for 1997 Hurricane Motorhome
    We have the Kwikee RV Powered Steps part # LC3726892 that would work well for your motorhome. This is a 2-step RV step that automatically deploys when you open the door. It also has a manual override switch as well so that you could have it stay out at all times if you wanted. If you preferred a triple step solution the part # LC3658373.
    view full answer...
  • Replacements for Kwikee Steps on 1988 Motorhome
    I was unable to find any reference to any of those models or part numbers, unfortunately. For a step of that age, there are very few - if any - replacement parts, and since your wiring is different, that leads me to believe that none of the replacement controllers will work for you. The only option we can offer is an all-new assembly with a motor, control, and switch, such as the Kwikee 40 Series Electric RV 2-Step - Motor, Control, Switch # LC3726892. The right one will depend on the...
    view full answer...
  • Need A Replacement Motor For RV Electric Steps.
    I have your solution, the Replacement Motor for Kwikee Electric RV Steps - 12V # LC379147 will replace your motor on your Kwikee 41 and 40 series steps. Like the Kwikee Electric RV Step Complete Assembly - Double - 40 Series - 24" Wide # LC3726892.
    view full answer...
  • Recommended Steps For 2008 Dodge Durango
    Adding RV steps like the Lippert Components Kwikee 40 Series Double Electric Step with Double Tread # LC3726892 to a 2008 Dodge Durango would require custom welding of brackets as well as enough ground clearance. Although this looks ideal, I assume you'd be looking at a lot of custom fabrication for your vehicle that it isn't intended to handle and could effect other components. My recommendation is to use the Westin Molded, Lighted Running Boards w/ Custom Installation Kit - 6" Wide...
    view full answer...
