6-1/8" Deep x 17" wide steel camper steps expand from 31" to 40" tall and fold up for storage. Steps self-adjust for stability on any terrain. Non-slip tread ensures solid footing. Mounting bracket and hardware included.
Features:
Specs:
Note: These steps are only to be used while your vehicle is stationary and should not be mounted permanently. Use the mounting bracket provided so the steps can be easily removed prior to travel. For recreational use only. Not for commercial applications.
Will Brophy Camper Scissor Steps Work for You?
Scissor steps are typically installed on truck campers, but can be attached to your truck's tailgate using a special mounting bracket (TSSB - sold separately). After the initial installation, they're easy to attach when needed and detach for compact storage. To ensure you choose the correct size for your application, there are a few measurements you will need to take.
The Brophy scissor steps have a single mounting bracket that attaches to either the camper wall or the truck bumper beneath the doorway. To decide which size you'll need, locate the space available for the mounting bracket on your application that lines up with the doorframe, and measure the width and height. You will need a mounting space at least 18-1/4" wide and 1" tall.
If it turns out you have more space beneath your doorway, there are larger step assemblies available with 24" wide brackets. A full list of the available steps is below.
Once you have an approximation of where the mounting bracket will go and what size mounting bracket you need, the spot you chose will be used as the "mounting point" to determine how many steps you will need.
How Many Steps Do You Need?
To decide on how many steps you'll need, measure from the "mounting point" to the ground. This is called the entry height. The entry height should roughly match the height of the steps when they're fully extended, and it will also tell you how many steps you need.
The chart below displays entry height measurement ranges in the first column. If you determined you need an 18-1/4" mounting bracket, the step part numbers with that width are in the second column. If you determined you need a 24" mounting bracket width, the step part numbers with that width are in the third column. Choose the bracket size that is closest to your measurements without going over.
This page's step assembly is in bold text.
| Entry Height | 18-1/4" Mounting Bracket Width | 24" Mounting Bracket Width |
|---|---|---|
| 18" - 23" | AS02, SS02 | Not available |
| 24" - 30" | AS03, SS03 | AS23 |
| 31" - 40" | AS04, SS04 | AS24 |
| 40" - 48" | AS05 | AS25 |
How Do You Install the Steps?
To install the steps:
-Make sure assembly is centered beneath the doorway
-Secure in place with included lag screws
