LED Backup Light for Truck or Trailer - Submersible - 10 Diodes - Oval - Clear Lens - Qty 1
Optronics

LED Backup Light for Truck or Trailer - Submersible - 10 Diodes - Oval - Clear Lens - Qty 1

Part Number: BUL10CB
In Stock
$30.29
Retail:$34.73
You Save: 13%
Trailer Lights
zoom in icon
slider vertical icon
zoom out icon
Comment field cannot be left empty.
Name field cannot be left empty.

Thank you! Your comment has been submitted successfully. You should be able to view your question/comment here within a few days.

Error submitting comment. Please try again momentarily.

Product Images

Customer Photos

Videos

Need help with installation?
Locate installers near me
6-7/16" Oval. Waterproof trailer light is certified for backup light function in a 2-lamp system when a pair of lights is installed. Recessed mount with grommet (sold separately). Accepts 2-prong plug. 10 White LEDs. Clear lens. Great Prices for the best trailer lights from Optronics. LED Backup Light for Truck or Trailer - Submersible - 10 Diodes - Oval - Clear Lens - Qty 1 part number BUL10CB can be ordered online at etrailer.com or call 1-800-940-8924 for expert service.
  • All Info
  • Reviews (267)
  • Q & A (0)
  • Photos

Optronics Trailer Lights - BUL10CB

  • Tail Lights
  • Oval
  • LED Light
  • White
  • 6-7/16L x 2-1/4W Inch
  • Recessed Mount
  • Backup
  • Submersible Lights
  • Optronics

6-7/16" Oval. Waterproof trailer light is certified for backup light function in a 2-lamp system when a pair of lights is installed. Recessed mount with grommet (sold separately). Accepts 2-prong plug. 10 White LEDs. Clear lens.


Features:

  • Oval backup light for trailers and utility trucks
    • Certified for backup light function in a 2-lamp system when a pair of lights is installed (second light sold separately)
  • Sonically sealed, waterproof housing and lens unit is submersible
  • LEDs make great replacements for incandescent lights
    • Last 50 times longer
    • More efficient - provide brighter light with less power output
    • No bulbs to replace - no brittle filaments
  • Polycarbonate lens and housing
  • White LEDs with clear lens
  • Recessed mount with grommet (sold separately)
  • Accepts industry-standard 2-prong plug (sold separately)
  • DOT compliant
    • Meets FMVSS 108 and CMVSS 108 requirements for automotive lighting


Specs:

  • Dimensions: 6-7/16" long x 2-1/4" wide x 1-3/4" deep
  • Diodes: 10
  • Power draw at 12.8 volts: 0.26 amps
  • Lifetime warranty on LEDs


light dimensions

Sonically Sealed, Waterproof Trailer Light

The waterproof construction of this light makes it ideal for use on trailers that may be submerged, like a boat trailer. The housing and lens are sonically sealed together to create a single unit, which means that water will not get into the light and damage the diodes or circuit board.



BUL10CB Optronics 6" Oval LED Reverse Trailer Taillight - 10 Diodes - Clear Lens

Alternate part number: BUL-10CB




California residents: click here


Customer Satisfaction Score:

Ratings & Reviews

4.7

266 reviews
6-7/16" Oval. Waterproof trailer light is certified for backup light function in a 2-lamp system when a pair of lights is installed. Recessed mount with grommet (sold separately). Accepts 2-prong plug. 10 White LEDs. Clear lens.

by:



by:



by:



by:



by:



by:



by:



by:



by:



by:



by:



by:



by:



by:



by:



by:



by:

rugged and bright



by:



by:



by:



by:



by:



by:



by:



by:

just what i was looking for.


25
266
Show More Reviews

See what our Experts say about this Optronics Trailer Lights

  • Looking for Way to Mount Optronics Backup Light # BUL10CB on Ranger Trail Boat Trailer
    In order to mount the Optronics Backup Light, # BUL10CB, on your Ranger Trail Boat Trailer, I recommend using the Rubber Grommet, # a70gb, and Trailer Light Mounting Bracket, # BK70BB. A wiring harness, part # A49PB for a right angle plug and part # A45CB for a straight plug, will also be needed for the Optronics Backup Light, # BUL10CB. I have included a few short videos for you to check out.
    view full answer...
  • Where to Gain Input For a Backup Light For a 2019 Chevrolet Equinox?
    You may be able to get a connection for a backup light in the rear fuse panel on your 2019 Chevy Equinox. I do see there is a circuit for the trailer reverse lights is F8 and K2 positions according to your owners manual. Do understand you may or may not have these circuits wired on your fuse panel and may need to get the signal from the wiring going into the tail light.
    view full answer...
  • What is the Candela Output of Optronics 6-1/2 Inch Incandescent and LED Tail Lights?
    I do recommend you move to LED lights as they are going to last much longer than the incandescent lights on your horse trailer. As far as light output, Optronics generally measures their lights in candelas instead of lumens though at a distance of 1 foot candela is equal to lumens so you should have a good idea of how bright the lights are. I contacted Optronics and the representative was able to give me the candelas of each of the lights you were asking about. The incandescent # BU70CB...
    view full answer...
  • LED Reverse Light Recommendation for 2005 Toyota Prius
    Since you have a Prius I would strongly recommend going with an LED reverse light that will draw considerably less than the Halogen part # PL-807. For that you'd want the LED light part # BUL10CB with the bracket # BK70BB and the grommet # A70GB and you'd have a setup that draws only .28 of an amp per light. You'll also need a wiring pigtail like the part # A49PB. This could be ran to the reverse light circuit of your vehicle without overdrawing it.
    view full answer...
  • What are the Brightest 6.5" Oval Lights for my Motorhome
    Because the GloLight LED Backup Light for Truck or Trailer part # BUL111CB slightly diffuses the light around the outside of the light I recommend using the LED Backup Light for Truck or Trailer part # BUL10CB. This will give you a slightly brighter light than the other. To be honest the difference is minimal and I like the looks of the GloLight better but for maximin brightness the second option is the better of the two.
    view full answer...
  • Connecting New Reverse Lights Wiring At Trailer Electrical Connector For a Dump Trailer
    As long as your trailer has a 7-way you will more than likely have a Junction Box # 3375601101 that all the wiring from the 7-way will go into and connect to the trailer wiring. You will need to locate this box and find the wire for the reverse light circuit. This will typically be either the purple wire or yellow wire if your harness does not have a purple wire. A Test Light # PTW2993 can be used to verify that you are connecting to the correct wire. If your trailer uses a 6-way connector...
    view full answer...
    Image 1 for Image 2 for
  • Comparing Brightness Ratings of Optronics LED Tail Lights
    The Optronics LED Backup Light # BUL22CB is brighter than backup light # BUL10CB although I would not describe it as significant, though that can be subjective. Optronics measures the brightness of their lights using candelas and the # BUL10CB has a candela rating of 125, while the # BUL22CB has a candela rating of 160. There is also the backup light # BUL52CB which has a candela rating of 175. The reason I would not classify the brightness as significantly higher is because these lights...
    view full answer...
  • Recommendation for Submersible LED Backup Lights on a Boat Trailer
    I can help you add reverse lights to your trailer. Yes, It is important to pay attention to DOT compliance when adding lights on your boat trailer. Compliance will be met if you use the Optronics # BUL10CB light as your backup light. The # BUL72CB is purposed for a utility light and will not meet the criteria for reverse lights on the roadway. In order to add reverse lights to your trailer would would need to have a 7-Way on the trailer and a 7-Way on the vehicle. On the vehicle side,...
    view full answer...
    Image 1 for
  • How To Connect Electric Trailer Brake Assemblies To Junction Box On Trailer
    You have a good plan! You are correct that once you have a functional 7-way connector and the Tekonsha Prodigy P3 # 90195 installed in your truck that you will not need any other wiring on the truck. Going with a junction box like the # 38656 to install the 7-way connector is the best way as it gives you a very nice location to make all of the wiring connections. All you will need to do is run the # 10-2-1 like you mentioned from the brake output post on the junction box to one wire...
    view full answer...
    Image 1 for
  • How to Wire LED Reverse Lamps on Enclosed Trailer
    The center pin on the 7-way trailer connector carries the reverse lamp signal. Install your reverse lamps such as # BUL10CB as well as the # A45CB pigtail and the # A70GB grommet and # BK70BB bracket if needed. Then, run a length of # DW02359-1 16 gauge wire from the center pin on the trailer connector back to the running lights. I've linked you to our Trailer Wiring help article.
    view full answer...
  • How to Provide Power to Trailer Reverse Lights
    To connect back up lights you need to have a 7-way trailer connector on both your trailer and tow vehicle. On a 7-way the reverse lights are powered by the center pin. To connect reverse lights to the trailer's 7-way you can use 16 gauge wire # 16-1-1, or 14 gauge # DW07550-1 if you have a longer trailer. Both are sold by the foot. If you need reverse lights a couple of popular options are the Optronics LED Backup Light # BUL10CB for an LED that uses a 2-wire pigtail # A45CB to connect....
    view full answer...
  • Recommended Wiring And Waterproof Lights For 2000 Ranger 620 VDS Boat Trailer
    To completely rewire the trailer you will need to start with a 7-way trailer side wiring harness like part # H20044. You will then need a junction box like part # 38656 to attach to the trailer. You will run the # H20044 harness into the junction box and run the wiring for the brakes and lights off of the posts in the junction box. You will need the appropriate size wire for the lights and for brakes if you have them on the trailer. You will want to run 10 gauge wire like part # 10-1-1...
    view full answer...
  • Do Trailer Reverse Lights Require Two or Three Wires to be Powered
    Reverse lights like the part # STL211RCB only need power and ground to function. You would not need three wires ran to the light assembly. Power would need to come from the reverse light circuit of the tow vehicle but you can ground the lights to the trailer frame or using wire to run back to ground of the trailer wiring. The version of the light I would recommend instead though is the part # BUL10CB since this is just a reverse light. For pigtail harnesses you'd want either the # A45CB...
    view full answer...
  • How Much Amperage Is Required to Add Reverse Lights to Trailer
    If the tow vehicle has a trailer reverse light circuit separate for trailer wiring then you'd be limited by the amperage rating of the fuse that protects it. If you are tapping into the reverse light circuit of your vehicle for the light then it comes down to the amperage rating of the fuse that protects the circuit as well as the amperage rating of the lights and how many amps are left over between those two numbers. Now with that all said if you went with an LED reverse light like the...
    view full answer...
  • Difference in Brightness Between # BUL10CB Backup Light and # BUL72CB Utility Light
    Both the # BUL10CB and the # BUL72CB are 10 diode lamps, and therefore neither lamp would really be brighter than the other. The main difference between the two is how the light is focused. Because the # BUL10CB lamp is DOT compliant as a back-up light, the light would be more diffused over a wider area. By contrast, the # BUL72CB which is NOT certified as a back up light would have the light more focused on a smaller area. Each lamp would output a similar amount of light, but the # BUL72CB...
    view full answer...
  • Can Reverse Light Circuit of Trailer 7-Way be Used to Power Additional Reverse Lights
    If the reverse light circuit of your 7-way is active you can use it to power the reverse lights you bought. It would be a matter of running the power wire of the light to the reverse light circuit of the 7-way and the negative to the ground circuit of it. If the circuit isn't active on your trailer wiring you'd then need to tap into the reverse lights of the truck. For a quick splice connector you could use the # SWC502905-1 to make the connection to the circuits.
    view full answer...
  • Why Would LED Trailer Light Stop Working
    The lifespan of LEDs are typically much longer than what they would ever be needed for. They don't burn out like traditional bulbs which is one of the many advantages to them. Most likely your issue is ground related. Try improving the ground on the right turn signal and you should get the light to work again.
    view full answer...
  • Oval LED Reverse Lights with Grommet for Flatbed Trailer
    We have exactly what you are looking for in terms of an LED reverse light that fits with a grommet for your flatbed trailer. The Optronics LED Backup Light for Truck or Trailer - 6 Diodes # BUL12CB or the same light with 10 Diodes # BUL10CB can be mounted to your trailer with PVC Grommet for 6-1/2" Oval Trailer Tail Lights # A70GB and you will just need a 2-wire pigtail for the lights. For this you can use 2-Wire Pigtail # A45CB or Right Angle 2-Wire Pigtail # A49PB. I have added links...
    view full answer...
    Image 1 for
  • Flush Mount, Submersible LED Back Up Light Recommendation for a Trailer
    The brightest LED light, flush mount, submersible, that can be used as a back up light, is going to be the round light # BUL23C24B. But this is a 24 volt light and it has 27 diodes. For a 12 volt back up light that is flush mount and submersible would be # BUL10CB or # BUL11CB. For the BUL10CB that you have referenced, you will also need grommet # a70gb, and a wiring harness # A49PB. For the round light # BUL11CB, you would need grommet # A45GB. and harness # A45CB.
    view full answer...
  • Is the Custer 4 LED Strobe Light part # STRL4W Waterproof
    In order for something to be considered waterproof it needs to be able to withstand submersion for a certain amount of time without any water leaking in. The Custer 4-LED Strobe Light or Running Light # STRL4W would work well on the exterior of your vehicle and normal amounts of rain wouldn't break it. But I would not recommend it for a boat trailer where the trailer gets submerged. For something like that you would want a LED Backup Light part # BUL10CB.
    view full answer...
  • Reverse Light Wire Color on a 1996 Chevrolet K1500 Pickup to Allow Connection of Back Up Light
    The best way to confirm which wire activates your vehicle reverse lights is to remove one taillight assembly and visually identify which lead goes to the reverse light bulb. To remove the taillight, open the tailgate and locate and remove the two taillight retaining screws. This will allow you to pull out the taillight assembly for access to the wiring. Then, for safety sake, it will be useful to have a helper turn the ignition to the on position without starting the vehicle. Then place...
    view full answer...
  • DOT Approved Trailer LED Reverse Light and an LED Interior Trailer Light
    Optronics light # BUL78CB is a utility light so it is not DOT approved to be used as anything other than that. For the interior of the trailer it will work fine, it doesn't have to be DOT approved since it isn't a tail, marker, reverse, brake, or turn signal light. It is about as tough as any other trailer light that you would find but I would not expose it to repeated impact from cargo. the lens or flange would eventually crack. If you are looking for a DOT approved reverse light with...
    view full answer...
  • Recommended Optronics Assembly for Adding Backup Lights to Sprinter
    I recommend going with the Optronics LED Backup Light # BUL10CB, as it will provide you with a clear, bright LED and it is DOT approved to be used as a backup lamp. The Optronics Sealed Oval LED Light # BUL78CB that you also mentioned is a nice utility light, but it is not actually DOT approved to be used as a backup lamp on a vehicle. To install the light assemblies, you can use the 2-Wire Pigtail # A45CB. The white wire will be attached to a bare metal surface of the frame for ground,...
    view full answer...
  • Reverse Light Recommendations and Difference Between 2 and 3 Wire Pig Tails
    The LED Backup Light # BUL10CB with 10 diodes will fit in the Rubber Grommet # a70gb. Also, the Sealed, 6-1/2 inch Oval LED Trailer Back Up Light # BUL52CB with 36 diodes will fit in the # A70GB. 7/16 of an inch is pretty close to half an inch and honestly it was probably a measuring error as both lights will fit yet they are listed as having different diameters. The 36 diode light will be noticeably brighter than the 10 diode light. It really just depends on how bright of a back up light...
    view full answer...
