This Bluetooth enabled remote display lets you monitor performance and adjust settings on your Go Power MPPT solar charge controller (GP72RR - sold separately). Mounts flush for a clean look.
Features:
California residents: click here
Videos are provided as a guide only. Refer to manufacturer installation instructions and specs for complete information.
Hi everybody, my name is Andy with etrailer.com. Today we're taking a look at this Bluetooth remote display for Go Power MPPT solar charge controllers. Now this Bluetooth-enabled display is going to let you monitor performance and adjust settings on your Go Power GP RVC MPPT series controllers. Now the Bluetooth function lets you monitor statistics and configure settings from your smartphone, and that's gonna require the free Go Power! Connect app. And the LCD display provides information on voltage, current and charge status. Now this is going to mount flush for a nice clean look.
And as you can see, you have your LCD screen. You do have your up button, your down button, your enter button, your back button. And then on the backside, you're gonna have your RJ12 connectors. Now this is going to include the trim piece that you will install over this display once you have it installed. So you can see that, again, it's gonna have a nice clean look when you have this installed and that trim over it.
And it's also going to come with two mounting screws and then a roll of RJ12 cable, and then a quick start guide. Now let me give you some overall measurements here. I'm going to turn this on the back side, it's gonna be a little bit easier here to measure with. So the overall length of this display, we're gonna be sitting right at 4 and about 3/8 inches long. And by the way, the distance between those mounting holes, according to the instruction manual, they report that it is at 4.1 inches, the distance between those mounting holes.
Looking at the width, we're sitting right at about 2 1/2 inches wide. And then in regards to the thickness, I'm gonna lay it on its face and include this connector, we're gonna be sitting right at about an inch and 1/4 thick. Now with the trim piece, this is going to measure 4 1/2 inches long by 2 3/4 inches wide, with that trim piece. Now an external power supply is not required and this does have a five year limited warranty. And if you are interested in the controller that this display will work with, we do have that here at etrailer.com.
That's the Go Power MPPT solar charge controller, 30 amp and 12 volt to 24 volt. You can find that on our website using item number GP72RR. Well, that's going to conclude our look today at this Bluetooth remote display for Go Power MPPT solar charge controllers. Again, my name is Andy. Thank you for joining me..
It is very unfortunate that no-one tells you that you MUST buy this Remote in order to program, or set parameters, in the 30 amp controller to properly pair it with the battery requirements. There is no way to set parameters if you only buy the 30 amp mppt controller, so what good is it? They should have built a screen into the controller, so you don't have to buy an additional unit. The marketers and sellers should inform the buyer of this necessity.
Used this one my houseboat to run separate battery banks... worked great !
The controller is doing it's job up to this point.
E-Trailer kept in touch throughout my whole purchase process from order to my receiving it today 2-3-22. Excellent customer service. GP remote came well packaged and on time. Remote not yet installed, will update.
Overall very good. However the tracking was very poor. It's showed that the package was in customs in NY for over 2 week. When in fact the next day it was delivered to BC. I guess it's not their fault as it wasn't scanned at every location. I would definitely use them again. Good customer service.
Appeared to be an open box item. It had been opened before but unfortunately don’t know the history of it so hoping there is no issue with it. It is operational now just was expecting a new item.
This gives you the on screen and Bluetooth Control needed to understand your solar panels. This is a product I’d recommend and would purchase again.
Always a great experience with ordering and shipment. Thank you.
Do you have a question about this Accessories and Part?
Info for this part was:
At etrailer.com we provide the best information available about the products we sell. We take the quality of our information seriously so that you can get the right part the first time. Let us know if anything is missing or if you have any questions.
Bob
2/4/2023
GP remote working flawlessly
