Correct Track Trailer Alignment and Lift Kit - Tandem Axle
(26 reviews)
Price: $455.84
Correct Track Trailer Alignment and Lift Kit - Tandem Axle
Item # RR23QX
Our Price: $455.84
Thank you! Your comment has been submitted successfully. You should be able to view your question/comment here within a few days.
Error submitting comment. Please try again momentarily.
Need help with installation?
Locate installers near meIn-stock alternatives that can ship today
- All Info
- Reviews (26)
- Q & A (0)
- Photos
RV Ride Control Trailer Suspension Parts - RR23QX
- Alignment and Lift Kits
- Boat Trailer
- Camper
- Car Hauler
- Snowmobile Trailer
- Utility Trailer
- Slipper Springs - 2 Inch
- Tandem Axle
- RV Ride Control
Prevent uneven wear on your RV tires and get a smoother, more stable ride by properly aligning your trailer's axles with this kit. This kit also lets you raise your trailer or RV so you can tow with a tall or lifted truck. No-drill installation.
Features:
- Corrects misaligned axles and lifts trailer for level towing
- Improves the life of your tires and creates a more stable ride
- Provides extra clearance so you can tow with your tall or lifted vehicle
- Lets you move axle up to 1/2" forward or 1/2" rearward for proper alignment
- Adjusts in 1/4" increments
- Raises trailer height by 1-1/4" or 2-1/4"
- Works with your existing leaf spring suspension system
- Brackets attach to hangers and supply new, lower mounting point for springs, which results in a taller ride height
- Alignment correction plates mount on either side of hangers to shift axle placement
- Includes 8 suspension plates, 16 alignment correction plates, and the hardware needed for installation
- No drilling required
- Made in the USA
Specs:
- Application: tandem-axle trailers and RVs with leaf spring suspensions
- Minimum required distance from I-beam to spring mounting hole on hanger: 2-5/8"
- Works with 3" wide x 3-3/4" tall hangers or 3" wide x 5" tall hangers and leaf springs up to 2" wide
- 90-Day warranty
Note: This does not work with MORryde CRE3000 equalizers.
Raise Your Trailer's Ride Height
Newer trucks are being built to ride higher. This means that your trailer may have to be raised to match. If the two aren't the same height at the connection point, the nose of your trailer or RV is going to ride too high. This will put too much weight on the rear of your trailer, which can result in poor handling and may eventually cause damage.
The Correct Track helps to solve this problem by lifting your trailer or RV 1-1/4" or 2-1/4", which provides a level towing setup for taller trucks. This added lift is also great for 5th-wheel trailers that might have trouble clearing tall pickup bed side rails.
Correct Misaligned Axles and Suspension
If the tires on your RV or trailer are wearing down quickly and prematurely, there's a good chance your axles are out of alignment. Driving with misaligned axles for long periods of time will shorten the life of your tires, reduce your gas mileage, and can make it difficult to steer your rig. Misaligned axles are often caused by an imbalance of weight, which can result from simply using the slide-out on your 5th wheel or having heavy appliances positioned on one side.
The Correct Track integrates into your trailer's suspension system and shifts the axles back into proper alignment. This kit allows you to adjust the axle alignment by 1/4" increments for a properly aligned suspension. It will correct your RV or trailer's alignment whether the axles need to be moved forward or backward.
9005934 Correct Track Trailer Alignment and 1-1/4" or 2-1/4" Lift Kit - Dual Axle
Installation Details
Customer Satisfaction Score:
91% were satisfied with this product
9% of customers were not satisfied
- Wrong item was ordered
- etrailer mistake
- Product did not meet expectations
Customer Reviews
Correct Track Trailer Alignment and Lift Kit - Tandem Axle - RR23QX
Average Customer Rating: 4.5 out of 5 stars (26 Customer Reviews)
Prevent uneven wear on your RV tires and get a smoother, more stable ride by properly aligning your trailer's axles with this kit. This kit also lets you raise your trailer or RV so you can tow with a tall or lifted truck. No-drill installation.by: Michael 03/26/2023
ETrailer is the best, but these things took TIME to figure out and get the axles aligned correctly! They did the job, lifting the RV up from the tires, and no more tires scraping the fender well on rough/bumpy roads. Have 2 people and a weekend available to get the kit installed correctly and aligned. Tires are running great with even wear. Thank you!
by: Eric05/07/2024
I have not installed the kit yet. The ordering process was easy and had plenty of information to make sure it was what I needed. The delivery date estimated during the order process was not accurate. The delivery date during the order process stated it to be the end of April. A few days after the date had passed I received a notification saying the order was being gathered and was expected to ship May 1. I received the order on May 6. This is not a huge issue, but with porch pirates these days, I make plans based on the stated date when ordering.
*** That being said, I have always had great great experience with eTrailer and is my go to for specialty and towing items. I am grateful for the detailed answers, videos and feedback they have for their customers. ***
by: Daniel 05/08/2023
Well unfortunately I was not able to use this product it was not applicable to my trailer but all I know is the service and the help that I got from the people that e trailer was awesome I will not shop anywhere else if I don't need to
Daniel
5/9/2024
This product has helped us tremendously because of where we live. We are in mountainous country my driveway is hard to get into and this lift kit and the shock absorbing equalizer kit has made our trailer awesome. I would recommend it to everyone that has a bumper pull fifth wheel double or triple axle trailer you will love it
by: Marcel08/16/2023
Horrible product.. from the beginning I had problems with delivery. they changed the delivery date 3 times. when the product arrived at my house I was not present because I expected to use it before. and when using the product I realized that if it would not work. I took it in for installation and the mechanic tried several ways to find a safe position for it but . when I finished the installation and the weight of the trailer came down, the parts with the holes rotated and that brought me a loss of 2 tires. because they started to rotate crooked! In the end, completely dissatisfied with the product. and in the end I never knew what day I received the product and then I never knew when I would have the opportunity to return the product since I felt harmed by the situation! when calling the store they said my refund window closed 2 days ago! very strange. So far completely unsatisfied
Jenny N.
8/31/2023
It is very unusual for the holes to rotate once this is installed. The manufacturer will be in contact to discuss this with you.
by: Thomas05/25/2022
I was having a problem with the brakes on one wheel failing (magnet/actuator), even after replacing the entire brake assembly. Upon measuring the axle alignment to the hitch ball I discovered that the axles were out of alignment. This kit corrected the problem and I am no longer having brake problems, or excessive tire wear. The trailer tracks much better. I am very satisfied with the product. Installation on two axles took about 3-4 hours.
Thomas
5/26/2023
After 2 years and 3300 miles, product is still working as expected. Completely solved the problem of tire wear, and excessive brake heating which lead to brake failure. Very happy with product.
by: David 02/10/2023
This kit made a huge difference in the height of my 5th wheel, it is now level and also gives my rear leveling jack some extra clearance. Pretty easy to install, the first one will take a little bit of time, but the reat will go faster. I also installed the heavy duty shackles and the Road Armor Equalizers. This all made my RV ride so much better!
by: Steve06/09/2023
Price was good and it was in stock.
I was confused why it took four days to ship when it was pulled the second day?
I ended up not being able to use it before I left on a six-week excursion.
Looking forward to getting back home and installing the product.
Jenny N.
6/12/2023
To be honest it looks like there was a hiccup when the order was sent to the warehouse. We did not have the kit on hand to ship right way and needed to wait til our next shipment came in which was just in a few days.
by: 06/11/2022
Used this to lift my fifth wheel 2 inches to reduce the nose height condition that is common with newer trucks. Not as easy as changing a tire though.
by: Francis04/08/2023
Do not purchase. These did not work at all and I had to remove them.
Jenny N.
4/11/2023
I am sorry to hear that this kit did not work out for you. I would like to know more about your experience with them and why it had to be removed.
by: Benjamin 09/23/2022
Product is great. I just wish the instructions addressed tandem and triple axle applications. And some actual pictures of installation would be even better.
by: Ronald 01/29/2023
I can’t review the product since installation is not scheduled until Friday. I have ordered fro eTrailer because I like their service, customer service and quick ship and deliver.
by: Mitchell 09/09/2021
Installing this kit on my travel trailer corrected my dual axle alignment problem which was wearing the inside of the left rear tire. It was easy to install, easy to understand, and very adjustable.
by: Nick 05/26/2023
Pretty simple to do with great benefits down the road.
by: Ryan12/03/2022
The product looks great and seems very well made. I have not been able to install on my own and I have tried with two different shops to install this system on my RV and they will not.
by: Donald 09/08/2022
I have not had a chance to install them yet, but they seem to be exactly what I need.
by: Bryan 04/27/2024
by: Jacques 09/23/2022
by: Greg 10/15/2023
by: Edwin 06/11/2023
by: Kevin 11/09/2023
by: Mark 07/07/2022
by: Don 10/27/2022
by: Mandelke05/24/2024
Built heavy duty ,my axles are in line for once,opted to lift my rig at 2 1/4 " it sits level with my 17 dodge 3500. I like this kit better than the lippert kit. This kit is like it was made for my suspension.
by: Michael05/01/2023
The kit came exactly as described and works as indicated. The shipping was stunningly fast but that might have just been my location. Either way everything was delivered quickly and as described.
I am not sure if I did not read the part about it not working with my Dexter equalizers but I had to modify the kit considerably to get it to fit with my system. The equalizers rubbed on the plates and the plate with the holes extended to far down and rubbed on the rubber of the equalizer. I made it work for me. So far so good.
by: Duane 12/04/2023
I needed to raise the height of my Keystone Laredo because my new truck was too high for a level pull. And it also allowed me to correct a tire wear that I had for years, due to an alignment issue.
25
26
Show More Reviews
See what our Experts say about this RV Ride Control Trailer Suspension Parts
- Lift Kit Recommendation for Trailer with Tandem Lippert 3,500 lb AxlesFor your trailer that has tandem Lippert 3,500 lb axles we have the Correct Track Tandem Axle lift kit part # RR23QX which lifts the trailer by 2-1/4 inches.
view full answer... - Is There A Trailer Equalizer 7-3/4 Long Thats Taller Than 4The Curved Equalizer part # TREQE1 which measures 7-3/4" long is only really offered in one height which is 4-1/4". That said, installing a taller equalizer will not really raise the trailer if that is what you are after. It would only do so marginally at best if any. If you were looking to lift the trailer, the Tandem Axle Lift Kit part # RR23QX would provide a solid 2-1/4" but there aren't really many other options for this.
view full answer... - Solution for Lift Kit for 2009 Forest River Wildcat 27RLI do have a solution, but unfortunately the Lippert Components Tandem Axle Lift Kit LC407131 has been discontinued and is no longer available. Instead, I recommend the Correct Track Trailer Alignment and Lift Kit - Tandem Axle # RR23QX. This kit will allow you to raise your 2009 Forest River Wildcat 27RL 1-1/4" or 2-1/4". It will also ensure proper axle alignment which will improve the life of your tires and create a more stable ride.
view full answer... - How to Lift a Lowboy Car Trailer The MORryde Shock Absorbing Suspension Equalizers item # MR27ZR will be a solid upgrade for your lowboy car trailer however they won't affect the ride height just how much your suspension travels. There are a couple of options to lift your Lowboy car trailer depending on if your axle's sit above or below the leaf springs. If your axles are already below your leaf springs the only option is the Correct Track Trailer Alignment and Lift Kit item # RR23QX. This kit mounts to your spring...
view full answer... - Lift Kit for 2020 Grand Design Imagine 2670MKThe easiest way to raise a trailer like your 2020 Grand Design Imagine 2670K is with an axle flip kit. However, your leaf springs are already sitting on top of the axle. What you can do instead is use the Correct Track Trailer Alignment and Lift Kit - Tandem Axle # RR23QX. This will keep your axles aligned while giving you the option to raise it 1-1/4" or 2-1/4".
view full answer... - Do Both Upper Bolts of Lippert Tandem Axle Lift Kit part # LC407131 go Through SpacerYes both of the upper bolts of the Lippert Tandem Axle Lift Kit part # RR23QX go through the spacer like you mentioned.
view full answer... - Picking Out Lift Kit for Tandem Axle Utility TrailerLook under the trailer at the suspension of it. As long as you see leaf springs you can use the Correct Track Tandem Axle Lift Kit part # RR23QX to give you a lift of 2-1/4 inches. If you see a torsion axle setup instead I would need you to get me the axle brand and capacity off of it to see if we have a torsion lift kit for it.
view full answer... - Parts Needed To Install SumoSprings Trailer Helper Springs With 4-1/2 Inches of Frame ClearanceYou can install the Correct Track Trailer Alignment and Lift Kit # RR23QX which will allow you to raise your trailer 1-1/4". This will move your height to 5-3/4" from your spring plate to the frame. Then you will be able to fit the SumoSprings Trailer Helper Springs # TSS-107-40 which require a 5-5/16" to 6-1/2" clearance.
view full answer... - How To Choose Correct Replacement Leaf Springs for a Keystone Montana 5th WheelIn order to find the correct replacement leaf spring for a trailer you first need to start by noting the type whether that be slipper or double eye. Then, you'll need to measure their unloaded length via jacking up the trailer. If the springs are worn they will measure longer than their replacement. Lastly, you will need to note the axle capacity which is found on the tag in the center of the beam. Please note, the number of leaves does not really denote capacity as leaves have different...
view full answer... - Is There a Lift Kit for a Keystone Montana with MORyde LRE SuspensionI do have a lift kit that is compatible with a Keystone Montana in the Correct Track Trailer Alignment and Lift Kit part # RR23QX. This kit attaches to the leaf spring hangers and extends them to provide lift of 1-1/4" or 2-1/4". This is the only type of trailer lift kit we offer for leaf spring trailers. Unfortunately, the Correct Track Trailer Alignment and Lift Kit is incompatible with the MORryde LRE Suspension System.
view full answer... - Will Lowering Leaf Springs On Hangers Raise The Ride Height Of Trailer?It sounds like you are talking about moving your leaf springs down further on the hangers installed on the frame of your trailer. If that is the case then as long as each end of the spring is moved down the exact same distance, you will get the much lift in your trailers ride height. For example if you move the leaf springs and equalizers 1" lower on all of the hangers, you will get 1" lift. If you need more lift than your current hangers can give you going with the Correct Track Alignment...
view full answer... - Can MORryde X-Factor, Road Armor Equalizers, and Correct Track Lift Kit All Work on TrailerThe Correct Track Trailer Alignment and Lift kit part # RR23QX that you referenced is compatible with the Road Armor equalizers to answer your first question Ryan. Since you have the Correct Track kit installed you would need the MORryde X-Factor Crossmember Adapter part # MR93WR with the X-Factor # MR33WR and you'd be set.
view full answer... - Lift Solutions for 2013 Jayco Eagle HT RLSIf you have 3,500 lb axles on your 2013 Jayco Eagle HT RLS and the springs are currently below the axles yes you can use the part # K71-384-00 and it will give you a lift that equals the diameter of your axles (will be 2-3/8 inch) plus the thickness of your leaf springs. Or you could go with the Correct Track lift kit part # RR23QX which fits regardless of you axle configuration and can give you a lift of 2-1/4 inch.
view full answer... - Lift for Grand Design 295RL That is Towed by 2020 Chevy Silverado 2500 with 3 inch LiftFifth wheel towing with a lifted truck does get a little more challenging since the ride height between the truck and trailer needs to be pretty close to stock. So since your truck has a 3 inch lift the best solution would be a similar lift size installed on your trailer like the Correct Track part # RR23QX. This would lift the trailer 2-1/4 inch which would be pretty close to what you have on your truck and would allow your trailer to be towed level and still have enough clearance between...
view full answer... - Recommended 5TH Wheel Hitch & Determing If Enough Clearance For 5TH Wheel Towing 2020 Ram 2500 6-1/2While I cannot give you a yes or no to verify if you will be able to tow the 2021 Grand Design Momentum 320G with your 2020 Ram 2500, I can give you the information and some options to determine if you will be able to tow level. First for your Ram the only under bed mounted 5th wheel will consist of the B&W Turnover # BWGNRK1320 and B&W Companion # BWRVK3400. The head of the hitch can be adjusted from 17-19" above the bed. You will need to take these measurements on your truck and compare...
view full answer...
- Lift Kit Option for Trailer with Springs Mounted Under AxleWe have the Correct Track lift kits that will give you a 2-1/4 inch lift regardless of whether axles are above or below the leaf springs. If you have a tandem axle trailer you'd need the # RR23QX or if you had a single axle trailer part # LC87120. We also have a triple axle kit with the part # RR55QX.
view full answer... - Install Instructions for Correct Track Alignment Lift Kit RR23QXI attached a link to a page that has install instructions for the Correct Track kit part # RR23QX that you referenced. I'd recommend the shackle bolt kit part # MR58ZR as it comes with the correct size bushings, bolts, and shackle straps.
view full answer... - Availability Of Lift Kit For A 2020 Big Tex 18’ Tandem 7K Axle Utility TrailerI am happy to look into this for you. We will need more information on your trailer in order to recommend the correct parts. Firstly, we will need to know if your trailer uses round tube axle leaf spring suspension, or torsion axles. For 7K leaf spring axles we have the Correct Track Trailer Alignment and Lift Kit # RR23QX, which will lift the trailer either 1-1/4" or 2-1/4". For 7K torsion axles you can use the Torflex Lift Kit # K71-725-02, for a 3-1/8" lift. As far as larger tires,...
view full answer...
- How To Correct Towing Nose High with 5th Wheel Trailer While Hitch Is At Lowest SettingCorrect, if the distance from the ground to the bottom of the skid plate on the pin box is 2" lower than the distance from the ground to the top of the skid plate on the 5th wheel hitch after all adjustments to the pin box and 5th wheel hitch have been made then you will need to raise the trailer. The only option we have to raise the trailer exactly 2" is with the Tandem Axle Lift Kit part # RR23QX. Please note, it is not out of the ordinary to have to lower/raise the trailer in order...
view full answer... - Lift Kit for Cardinal 5th Wheel Mor Ryde SuspensionWe've checked with Lippert in the past and the Correct Track lift kit part # RR23QX does work with the Mor Ryde suspension kits like you have and will give you a 2 inch lift like you are needing.
view full answer... - Solution for Tandem Axle Trailer with Lippert Ground Control that Has Rear Jacks to Close to Ground4 inches of clearance from the ground to the feet of the rear legs of the Lippert Ground Control isn't very much. I could see them scraping at one point but I believe the solution is to get your trailer more level as it looks like it's pretty nose high currently. Since your truck is sitting taller the best way to get the trailer level while still retaining the proper clearance between the trailer overhang and the truck bed rails will be to lift the trailer suspension with a lift kit like...
view full answer... - Tandem Lift Kit and Correct Track ComparisonsThe lift kit part # RR23QX is very similar to the Correct Track you mentioned. Basically they both share the same lift kit components but the Correct Track (no longer available) also had some alignment components that are no longer available at this time.
view full answer... - 10K Car Hauler Lift Kit Recommendation for 1 Inch - 2 Inch Height IncreaseTo lift your tandem axle 10K car hauler an inch or two I recommend the Correct Track Trailer Alignment and Lift Kit # RR23QX. Not only will this kit help to ensure that your trailer is level, it also allows you to increase the height of your trailer 1-1/4" or 2-1/4" to fit your application. To make sure this works for your setup you need at least 2-5/8" from the I-beam to the spring mounting hole on the hanger and then this works with 3" wide x 3-3/4" tall hangers or 3" wide x 5" tall...
view full answer... - How to Lift a 2016 Riverside Retro 199FKS Trailer There are a couple of options to safely lift your 2016 Riverside Retro 199FKS trailer depending on if your axle's sit above or below the leaf springs. All of them will get you within the 2" - 3" range. If your axles are already below your leaf springs the only option is the Correct Track Trailer Alignment and Lift Kit item # RR23QX. This kit mounts to your spring hangers and moves the attachment point down 1-1/4" or 2-1/4". If your springs are below your axles you will want to use one...
view full answer...
