Blue Ox High-Low Adapter for Tow Bars - 2" Hitches - 3" Rise/Drop - 12" Long

Blue Ox High-Low Adapter for Tow Bars - 2" Hitches - 3" Rise/Drop - 12" Long

Item # BX88235

lowest price pledge

Retail:$216.25

Our Price: $179.36

You Save: $36.89
Accessories and Parts

This item qualifies for Free Shipping

Shipping Weight: 24 lbs

Quantity:
In Stock, Ships Today
Blue Ox Tow Bars - BX88235
zoom in icon
zoom out icon
Comment field cannot be left empty.
Name field cannot be left empty.
Please enter a valid email address.

Thank you! Your comment has been submitted successfully. You should be able to view your question/comment here within a few days.

Error submitting comment. Please try again momentarily.

pop out icon replay 360 icon
horizontal rotate icon

Product Images

Videos


  • Tow Bars
  • Hitch Adapter
  • High-Low Adapter
  • Blue Ox
  • Fits 2 Inch Hitch
  • 3 Inch Rise/Drop
Achieve the proper height for your tow bar setup with this drop/rise hitch adapter. Provides either a 3" rise or a 3" drop to make up the height difference between your RV and towed vehicle. Rated at 10,000 lbs. Pin and clip included. Call 800-298-8924 to order Blue Ox accessories and parts part number BX88235 or order online at etrailer.com. Free expert support on all Blue Ox products. Guaranteed Lowest Price and Fastest Shipping for Blue Ox High-Low Adapter for Tow Bars - 2" Hitches - 3" Rise/Drop - 12" Long. Accessories and Parts reviews from real customers.


  • All Info
  • Reviews (10)
  • Q & A (11)
  • Videos (1)
  • Photos
  • Why etrailer?

Blue Ox Accessories and Parts - BX88235

Achieve the proper height for your tow bar setup with this drop/rise hitch adapter. Provides either a 3" rise or a 3" drop to make up the height difference between your RV and towed vehicle. Rated at 10,000 lbs. Pin and clip included.


Features:

  • Allows for proper positioning of tow bar
    • Makes up for height difference between RV's hitch and towed vehicle's base plates
  • Can be used in either rise or drop position
  • Constructed of sturdy steel
  • Resists rust and corrosion with durable powder coat finish
  • Includes pin and clip for attachment to trailer hitch
  • Made in the USA


Specs:

  • Application: 2" x 2" trailer hitch receivers
  • Rise/drop: 3"
  • Receiver size: 2" x 2"
  • Maximum weight capacity: 10,000 lbs
  • Overall length: 15-3/4"
  • Length from center of pin hole to center of pin hole: 10-1/8"
  • Length from center of hitch pin hole to end of receiver: 12-3/4"
  • Measurement from center of receiver pin hole to opening of receiver: 2-9/16"
  • Measurement from center of receiver pin hole to end of receiver: 3-7/8"
  • Measurement from center of hitch pin hole to end of shank: 3"
  • Length of receiver portion: 6-3/8"
  • Pin hole diameter: 5/8"
  • 1-Year warranty


Dimensions

Note: Designed for flat towing only. Do not use to tow a trailer.


Many tow systems require some sort of hitch accessory to either raise or lower your tow bar so that it sits level. To determine if your setup needs an adapter, hook the tow bar up to your RV and towed car and measure to see how close to level it is. The "safe zone" for a motor-home-mounted tow bar ranges from 3 inches above level to 3 inches below. Car-mounted models must be absolutely level. This high-low adapter can provide you with the necessary drop or desired rise to achieve a level tow bar setup.



BX88235 Blue Ox Hi-Lo Drop Receiver - 3" Drop/Rise



BX88235 Installation InstructionsInstallation Details BX88235 Installation instructions



Video of Blue Ox High-Low Adapter for Tow Bars - 2" Hitches - 3" Rise/Drop - 12" Long


Videos are provided as a guide only. Refer to manufacturer installation instructions and specs for complete information.




Video Transcript for Blue Ox Tow Bars BX88235 Review

Today we're going to be taking a look at part number BX88235. This is the Blue Ox high low adapter for tow bars. It's going to allow for proper positioning of your tow bar system. Its going to make up the height difference between the RV's hitch and tow vehicle's base plates. It can be used in either the rise or drop position. This would be the rise position.

And then just flipping it over would turn it to the drop position. It's going to be constructed of a sturdy steel construction. It's got a nice solid shank on it, and it's going to resist rust and corrosion because it has a nice durable powder coat finish on it. The receiver is going to be securely bolted onto the shank. It does include your 5/8 inch pin and clip to secure it inside of the trailer hitch. The product's made in the USA and keep in mind that this is designed for flat towing only.

It's not designed to use to tow a trailer. It is designed for 2 inch by 2 inch trailer hitch receivers. It's going to provide us with a rise or drop of 3 inches. That's measuring from the inside top edge of the receiver tube of your hitch to the inside top edge of the receiver that's bolted onto the shank. From the inside corner to inside corner, that's going to measure 3 inches whether it's in the rise or drop position. It's going to feature a maximum capacity of 10,000 pounds. The overall length, we'll take a measurement of that real quick.

Measuring from edge to edge that's going to give us a measurement that looks to be about 15 and 3/4 of an inch. The distance that we have from the center of the hitch pin hole to the center of the pin hole on the receiver is next. That's going to give us a measurement from this pin hole right here, center on center, to this one right here of about 10 and 1/8 of an inch. The length from the center of the hitch pin hole to the front of the receiver opening is going to give us a measurement of about 12 and 3/4 of an inch. And then next the measurement from the center of the receiver pin hole to the end of the receiver, going this direction. We're looking at about 3 and 7/8 of and inch.

And then to the front we're looking at about 2 and 9/16 of an inch. That's from the center hitch pin hole to the front of the receiver. We'll take a measurement from the center of the hitch pin hole that's right here to the end of the shank. That looks like it's going to give us a measurement of right on 3 inches. The length of the receiver portion that's up here from front to back is going to give us a measurement of about 6 and 3/8 of an inch. Now the pin holes on the unit, this one right here and this one right here, are going to measure 5/8 of an inch in diameter. It does have a solid backing right here on the receiver that's mounted to the shank. It has really simple installation though. When it comes to installing this unit all you have to do is slide the shank into the receiver tube of the hitch, line up your pin holes and then secure it with the included hitch pin and clip. That's going to do it for today's look at part number BX88235.


Customer Reviews

Blue Ox High-Low Adapter for Tow Bars - 2" Hitches - 3" Rise/Drop - 12" Long - BX88235

Average Customer Rating:  5.0 out of 5 stars   (10 Customer Reviews)

Achieve the proper height for your tow bar setup with this drop/rise hitch adapter. Provides either a 3" rise or a 3" drop to make up the height difference between your RV and towed vehicle. Rated at 10,000 lbs. Pin and clip included.

- BX88235
by:

Bridget was very helpful in getting our item selected and shipped. The High Low is working great! Thanks again for your great service!! 214495



- BX88235
by:

This item is well built, strong welds solid bar stock. Priced right. 454087



- BX88235
by:

This is the first time that I have purchased from e-trailer. They had an unbeatable price, and my purchase arrived quickly. Our Class C motorhome has a bolt on hitch that sits very low to the ground. Only, the “Blue Ox high/low adaptor” provided our needed 3" height increase, between our MH and our towed SUV. For us, a 2" rise was not enough, and 4" was too much (everyone sells those), this 3” adaptor was exactly what was needed. As usual Blue Ox equipment is top notch! It was bit expensive but their quality is exceptional. The welds were very clean, precise and it was painted like a new car. Thanks e-trailer for making the purchase possible and a pleasant experience. We will be using our new 3” rise adaptor tomorrow. Thanks 179846



- BX88235
by:

Product is very well made, shipping was excellent and Gwen was very courteous and processed the order in a acceptable amount of time. Thank You Again E-Trailer 558672



- BX88235
by:

Best price, and prompt service. I would recommend highly. 403414



- BX88235
by:

Nice drop bar. I needed the longer length for my application and this did it. Not sure why this style drop bar is bolted while most of the other Blue Ox drop bars are all welded. 286735



- BX88235
by:

What makes it great, are the instructional videos that you provide. This aided my service guys in the installation. Thanks!! 271900



- BX88235
by:

Solid, high quality and expensive. Arrived a day ahead of predicted. 228694



- BX88235
by:

Product is available many places, but the best price is etrailer.com. 227143



- BX88235
by:

i dont think you can get anything stronger !! 178010


10
10

Ask the Experts about this Blue Ox Accessories and Parts

Do you have a question about this Accessories and Part?


  • Weight Capacity of Blue Ox 12 Inch and 14 Inch Shanks
  • Are you looking at the Blue Ox SwayPro weight distribution shanks, like part # BXW4002? If so, Blue Ox does not give these shanks a specific class rating. All of their shanks fit 2 inch trailer hitches and have a maximum towing capacity of 15,000 lbs and a maximum tongue weight capacity of 1,500 lbs. If you are looking at the 12 inch Blue Ox High-Low adapter, like part # BX88241 or # BX88235, they have a maximum towing capacity of 10,000 lbs. The high-low adapters are not given a tongue...
    view full answer...

  • Pin Hole to Pin Hole Dimension on RoadMaster High/Low Receiver
  • The pin hole to pin hole distance of the # RM-048-4 is 9-5/8". The Blue Ox # BX88241 has a pin hole to pin hole length of 12 inches, but it also has a rise/drop of 7 inches. This will be crucial to picking out the right adapter for your RV, see attached Help Article. Two adapters that are similar to the Roadmaster one you were looking at are the Blue Ox # BX88235, with the length from center of pin hole to center of pin hole is 10-1/8" and the Roadmaster # RM-076 has a pin hole to...
    view full answer...

  • Parts Needed to Flat Tow 2016 Chevrolet Silverado 3500 High Country
  • When your Silverado 3500 owner's manual refers to the transfer case and its neutral position this refers not to the column shifter but to either a floor-mounted manual shifter or to the dash-mounted electronic transfer case control knob. Both will have 4WD high and low settings indicated by up or down arrows and both will have a neutral position. Flat towing a vehicle like your Silverado 3500 requires a number of components, all of which are outlined in the linked article. These include...
    view full answer...

  • High-Low Tow Bar Adapter for Blue Ox Aventa Tow Bar Towing Chevy Silverado 3500
  • Blue Ox says that as long as the RV receiver height and base plate height are within three inches of each other, no adapter or riser is necessary, so you should be fine. However, if you did feel the need to use a High-Low adapter, they do offer one with a three inch rise/drop that's rated at 10,000 lbs, part # BX88235. To my knowledge, Blue Ox does not offer a riser/adapter like you describe, but Blue Ox offers a hitch immobilizer # BX88225 that might work if the sleeve sticks out...
    view full answer...

  • Availability of Hi-Low Adapter to Lower Receiver Height of Motorhome
  • If you're needing to lower the receiver for a tow bar that you're using to flat tow a vehicle, Roadmaster offers several High-Low Hitch Adapters that would get your towbar within the recommended 3 inches of level. For a 10 inch drop use part # RM-048-10. For an 8 inch drop use # RM-048-8, for a 6 inch drop use # RM-048-6, for a 2 inch drop use # RM-048-4 and for a 2 inch drop use # RM-048-2. These adapters shouldn't be used for towing a trailer. For a bike rack or a cargo carrier, Blue...
    view full answer...

  • How To Measure Correct Rise or Drop of High-Low Adapter
  • Measuring from the ground to the center of your motorhome's hitch receiver and then from the ground to the center of the base plate tabs (or where the base plates attach) is how to find the drop or rise you need for a high-low adapter. If you measured that and found the difference was three inches then the Blue Ox High-Low Adapter for Tow Bars - 2" Hitches - 3" Rise/Drop - 12" Long # BX88235 will work for you.
    view full answer...

  • Option to Raise Cargo Carrier on Rear of 2006 Hyundai Tucson For Better Ground Clearance
  • Blue Ox offers the # BX88235 adapter which would give your 3 inches of rise, and would allow you to retain the 500 lb capacity of your cargo carrier, but it shouldn't be used for towing a trailer. The # BX88241 offers 7 inches of rise, and also the capacity of the adapter mentioned above. The Roadmaster adapter you referenced wouldn't allow you to use the full capacity of your cargo carrier.
    view full answer...

  • How to Lower Front Receiver of 2013 Jeep Wrangler for Use with SnowSport Snow Plow
  • Blue Ox offers a High-Low Adapter, part # BX88235 that might work for you if getting a 3 inch drop in the receiver would put you below the 16 inch maximum receiver height. This isn't an inexpensive solution, but the adapter has a huge weight capacity that will be needed to withstand the battering it will receive when used with a plow. Keep in mind that the adapter cannot be used for towing a trailer.
    view full answer...

  • 4 Inch High/Low Adapter Recommendation for a 2001 Fleedwood Bounder Towing 2013 Honda Fit
  • I would go with the 4 inch drop like the RoadMaster High-Low Adapter part # RM-070 that you referenced for your 2013 Honda Fit being towed by a 2001 Fleetwood Bounder Class A motorhome. That would put you withing a 1/2 of an inch of being perfectly level and I believe would be your best option without breaking the bank on a 3 inch drop adapter like the Blue Ox High-Low Adapter # BX88235.
    view full answer...

  • Distance From Hitch Pin Hole of Blue OX BX88235 to Ball Mount Opening Mounting Plate
  • The distance from the center of the hitch pin hole on the Blue Ox High-Low Adapter for Tow Bars # BX88235 to the plate that holds the ball mount opening is 3 inches. I attached a picture that shows this dimension as well.
    view full answer...

  • Recommended Adjustable Ball Mount For 2014 Jeep Wrangler Using Weight Distribution System
  • The adjustable shank that is included with the # RP66558 has a maximum drop of 2-7/8 inches. The adjustable shank we offer by Reese that has the greatest amount of drop is part # RP3344. This has a minimum 6-3/8 inch drop and a 7-5/8 inch maximum drop when used with a trunnion-bar system like the # RP66558 has, and will work for you. Per the instructions you want to set the ball mount so that the ball height is approximately 1 inch above the coupler when the trailer is sitting...
    view full answer...
