See what our Experts say about this CURT RV and Camper Hitch

• Receiver Hitch Recommendations For A 2021 Flagstaff E-Pro 19 FBS
  To add a receiver hitch for a bike rack you'll actually connect the hitch to frame of your RV and not use the bumper as most aren't rated to hold the weight of a bike rack and bikes. You'll need to measure from beam to beam to see what frame distance you have. The Multi-Fit Motorhome Trailer Hitch, 24" - 46" wide Item # 5350 you linked to will attach to a frame distance of 24" to 46". We also offer the Curt Adjustable Trailer Hitch Receiver - 18"-51" Wide - 2" Drop - Class III - 2"...
  view full answer...
• Recommended Bike Rack to Use with the Stromberg Carlson Bike Bunk
  I have a great option for you. When using the Stromberg Carlson Bike Bunk Trailer-Mounted Bike Rack Carrier for A-Frame Trailers # CC-275 there are a few parameters you will need to stay within. The bike rack needs to be travel trailer rated, fit a 2" hitch and the combined weight of the bike rack and your bikes needs to be less than 100 lbs. Given these parameters I recommend the Lets Go Aero NEO2 2-Bike Rack # B01748. This 2 bike rack is the lightest weight of the racks that are rated...
  view full answer...
• Can the Curt C13701 Carry a Dirt Bike on the Back of my Grand Design Imagine Trailer
  The Curt # C13701 hitch has a 500-lb tongue weight rating, so it will be able to handle the weight of your dirt bike without issue as long as the carrier is rated for use on the back of a trailer or RV. Any type of carrier - bike, cargo or motorcycle - that will be used on the back of a motorhome or trailer MUST be made specifically for that application; you cannot use something that was designed to be used on a hitch on a passenger vehicle. These accessories, when used on a trailer or...
  view full answer...

• Frame Mounted Trailer Hitch for Travel Trailer
  We do indeed offer some hitches that are designed to bolt to the frame of your travel trailer. If the frame members on your travel trailer are between 18-51 inches apart, the Curt Hitch # C13701 would be an excellent choice, with it's tongue weight capacity of 500 lbs. For frame members between 22-72 inches apart, use the Curt Hitch # 13703, which has a tongue weight capacity of 350 lbs.
  view full answer...
• Can a Trailer Hitch be Installed on the Back of a Trailer
  I am not really sure what you are trying to do but you can install a trailer hitch on the rear of a trailer. There are two different kinds of trailer hitches for trailers, frame mount and bumper mount. The frame mount hitches are much stronger but will require more effort to install whereas bumper mount hitches typically have less of a capacity as they are limited to the bumpers capacity but require less effort to install. Please note that before you install a bumper mount hitch you will...
  view full answer...
• Recommended Trailer Hitch Receiver and Weight Distribution System for 2007 HS M30SFS and Trailer
  For your 2007 HS ADMIRAL SVE, your Hidden Hitch receiver sounds like it is capable of towing your trailer. The rated 5,000 lb capacity is without weight distribution, but from my research it is rated for 6,000 lbs with weight distribution just like the Curt # C13701. If you are needing a weight distribution system for this hitch receiver you likely will need a system rated for 15% of your total trailer weight. That puts you around 540 lbs roughly. You want a system that falls in the...
  view full answer...

• Recommended Frame-Mount Trailer Hitch for Winnebago Motorhome
  We offer two adjustable-width frame-mount hitches for your Winnebago that has a 31-inch frame spread. Curt 2-inch hitch # 13703 can be bolted or welded on a frame from 22- to 72-inches wide. It offers a 350-lb tongue weight capacity. This item fits on box frame, C-channel frame, or I-beam frame RVs. This is a Class III hitch; no class IV hitches are available in this universal-fit type. For a higher-capacity option Curt offers hitch # C13701, also a 2-inch Class III type, that offers...
  view full answer...
• Is It Possible to Install Trailer Hitch on 2006 K-Z Escalade Trailer
  It is absolutely possible to install a trailer hitch on your 2006 K-Z Escalade trailer; it will only require that your trailer have a box frame, C-channel frame, or I-beam frame that is between 22 inches and 72 inches wide. Should your trailer have that you will be able to use the Adjustable Width Trailer Hitch Receiver for RVs # 13703 which will can either bolt or weld onto your trailer's frame. This is a Class III hitch with a 2 inch receiver but please keep in mind it will require the...
  view full answer...
• Parts Needed to Equip 2002 Alfa SeeYa Motorhome for Towing Car Hauler Trailer
  We can help you set up your 2002 Alfa SeeYa motorhome with a hitch receiver and related items for towing a trailer. Towing requires a hitch, ball mount, hitch ball and wiring to activate the trailer's lights. The linked article covers these basic towing items. We have hitches for RVs that are shown on the linked page. You will want to use a frame-mount type since these have the highest capacity. Check your RV frame width to help you choose the best fit. For example, Curt hitch # C13701...
  view full answer...
• Distance Between Mounting Flanges on Draw-Tite Class IV Hitch Part Number 37130
  The distance inside the two mounting flanges that the larger plates attach to on the Draw-Tite # 37130 are 35-1/2" apart.
  view full answer...

• Trailer Hitch Receiver With 2 Inch Receiver for Motorhome on Ford Transit Chassis
  We can help you out with a trailer hitch for your 2019 Coachmen Orion on a Ford Transit chassis, and while there isn't a spec drawing for the Draw-Tite # 75912, I can tell you for certain that it will not fit your chassis, as the manufacturer has directly specified this doesn't fit the chassis versions. What you can use instead is a multi-fit RV hitch made for multiple applications, it will simply depend on the width of your motorhome's frame. For a frame that is between 22" and 66"...
  view full answer...
• Trailer Hitch For A 2013 Prime Time Crusader
  Hey Taylor, Assuming your Prime Time has a standard 4" x 4" or 4" x 4 1/2" bumper we have a great option for you. The etrailer RV Bumper Hitch, # e38HR, is a bolt on hitch for those standard bumpers. It has a 3,500lb towing capacity, but you would want to confirm the capacity of your bumper with the manufacturer before towing. If you do not have a bumper we do have more universal options for trailer hitches. We have something like the Curt # C13701 that would fit certain frame widths....
  view full answer...
• Availbility of Trailer Hitch for RV
  The RV hitches are fairly universal so I can give you some options and you can decide based on dimensions and the style you want. For a frame mounted hitch you will need to know the frame width of your RV. The Curt # C13701 fits frames 18" to 51" wide and the # 13703 fits frames 22" to 72" wide. You could also choose to go with a bumper mount hitch. The Curt # E-100 fits a 4" x 4" bumper and the # C19101 fits a 2" x 4" bumper. You will also need to find the capacity of your RV/bumper...
  view full answer...
• Hitch Reciever For A 2014 Open Range 416 RLS
  Hey Russell, There are a couple options for you to get a hitch on that 5th wheel. We do not currently have a custom fit one for that specific trailer but we have some bumper mount, and frame mount universal options. If your 5th wheel has a bumper I would recommend something like the # e38HR, etrailer RV bumper hitch 3500lbs. This fits bumpers that are 4" x 4" or 4" x 4 1/2", which are fairly standard bumper size. There are other sizes as well so I would need to know your bumper dimensions...
  view full answer...
• Recommended Trailer Hitch for Forest River Geo Pro
  The best option I have to install a trailer hitch on the back of a Forest River Geo Pro to be used for carrying a motorcycle is the Curt Adjustable Trailer Hitch Receiver part # C13701. The Curt hitch features a four bolt installation so it will be easy to install but you do need to make sure your frame width does not exceed 51". It can be used for pretty much anything you wish but will be best for a motorcycle because of its 500 lb tongue weight capacity which is pretty much the limit...
  view full answer...
• Is RV Trailer Hitch Available with 10,000 lb Weight Capacity
  If you are looking for a trailer hitch to mount on your RV then the highest rated capacity is the Curt Trailer Hitches parts # C13702 and # C13701 which are both rated for a max of 6,000 lbs towing when a weight distribution (WD) system is used. These are the same hitch with the only difference being the 13701 has a 2" drop for the receiver. We do have the Ultra Frame Service Body Trailer Hitch Cross Tube # 41991 which has a 16,000 lb towing rating but I'm not sure if it would fit your...
  view full answer...

• Can I Drill Holes in the Brackets of the Trailer Hitch Receiver to Match RV Frame Holes?
  I definitely see the logic in drilling holes in the mounting bracket of the Curt Adjustable Trailer Hitch Receiver - 18"-51" Wide - 2" Drop - Class III - 2" # C13701 versus the frame of your RV, however it isn't that easy. If you were to move the bracket attachment holes, then you would minimize the weight capacity and stability of the trailer hitch receiver as well as void the warranty on the hitch. The installation would be easier for sure, but I can't recommend going this route as...
  view full answer...
• Recommended Hitch for a 2004 Safari Trek Motorhome on a Chevy P32 Workhorse Chassis
  To add a hitch to your 2004 Safari Trek Motorhome you'll want to use the Curt Adjustable Trailer Hitch item # C13701. This is a class III hitch with a 2" receiver that has the requested 5,000 lbs towing capacity. This is a universal hitch that can be bolted or welded onto your Workhorse's frame. There are no custom fit options for your motorhome. Just a heads up. We have a had a similar question related to your 64-6230 Hidden Hitch that we have reached out to Draw-Tite on. According to...
  view full answer...

• Recommended Class III Trailer Hitch Receiver for 2018 Coachman Freelander 20cb on Ford Transit Frame
  For your 2018 Coachman Freelander 20cb I recommend the Curt Adjustable Trailer Hitch Receiver # C13701. This is a Class III hitch that is rated for tongue weights up to 500 lbs. Then you can use a cargo carrier like # FHG69ZR which has an integrated ramp. I've attached a video for you to see this carrier in action. If you were referring to a scooter like a small motorcycle, then I instead recommend the motor bike carrier # UF48-979033. This has a ramp as well and is designed for that...
  view full answer...
• Recommended Front Hitch and Bike Rack for a 2021 ProMaster 1500
  Hey Diana, welcome! We don't have a custom fit front hitch for your ProMaster, unfortunately, but you can use a universal trailer hitch like the Curt Adjustable Trailer Hitch Receiver # C13701. This trailer hitch fits frames 18" to 51" wide, has a 2" class III receiver, and a nice 5,000 lb capacity! If you don't already have a rack, the Saris MHS DUO Bike Rack for 1 Bike # SAR23MR is a great choice and can handle a single bike that weighs up to 80 lbs. If there is something else I can...
  view full answer...
• Recommended 4-Bike Rack Setup For A 2015 Flagstaff Microlite 25BHS
  The Stromberg Carlson Bike Bunk Trailer-Mounted Bike Rack Carrier for A-Frame Trailers - 2"-100lbs Item # CC-275 has a max weight capacity of 100lbs so it wouldn't be able to support the bike rack and 4 bikes. Instead you can install a Curt Adjustable Trailer Hitch Receiver - 18"-51" Wide - 2" Drop - Class III - 2" Item # C13701 if your frame distance falls between 18-51", if not let me know and we can find an alternative. Once you have the hitch installed you can insert the Swagman...
  view full answer...
• Recommended Trailer Hitch for a 2010 Chevrolet Express Box Truck
  Kenneth, since you probably do not need as much drop as most you'd probably best benefit from a hitch that has minimal drop like the Curt Adjustable Trailer Hitch Receiver # C13701 that has 2" of drop or # 15901 for a 3" drop. Both of these hitches are semi-universal so they'll fit a range of frames, both have a 2" receiver opening, and are both assembled in the USA. The main difference other than the drop, is # 15901 is a class V hitch rated at 16K, and # C13701 is a class III hitch,...
  view full answer...
• Recommended Flat Towing Set Up for a 2016 Chevy Traverse
  We'll start out making sure your RV has a hitch and wiring harness in case you don't already have them installed. To add a hitch to your 2000 Newmar Mountain Aire RV, you will want the Curt Adjustable Trailer Hitch Receiver item # C13701. This is a universal hitch that has a 5,000 lbs towing capacity, which is just enough to tow your Traverse. There are no custom fit hitches for your RV. For a 7-way you'll have to hardwire one in using the Universal Wiring Harness w/ ModuLite and Brake...
  view full answer...
• Can Mounting Brackets of Curt Hitch C13701 Attach Vertically to Trailer Frame
  The crosstube of the Curt hitch part # C13701 is perfectly square so if you wanted to mount the brackets vertically like you mentioned you could. This is a universal style hitch that was designed to allow for this type of flexibility.
  view full answer...

Do you have a question about this RV and Camper Hitch?
