What you're going to need is two of the transfer switches in that case. I have attached a diagram from Furrion that shows you how you're going to need to hook the two transfer switches #F30ATS up: -one to the other, then one branching off to…
We have one option that will work for you. The Trailer Hub and Drum Assembly - 4,400-lb E-Z Lube Axles - 10" Diameter - 6 on 5-1/2 #8-407-5UC3-EZ uses inner bearing #L68149 and outer bearing #LM67048 so it would work perfectly on your spindle.…
A cover being installed on your spare tire would not prevent the Swagman Bike Rack part #S80501 from installing. The rack would still fit and work well. You might still compare the dimensions in the picture I attached with you spare tire so that you…
Most critical to trailer tire performance and durability are 1) proper inflation 2) observance of the tire's rated load capacity and 3) observance of the tire's speed rating. If either of these factors is off the mark then the tire will tend…
I wish I could say yes, but as of right now they are not a fit for the 2016 models and we do not have any other suspension enhancement options. If you are trying to fight suspension sag from the tongue weight of a trailer there is a better option. A…
Yes, you are correct. In order to correctly take this measurement you will need to measure from the center of the spindle to the center of the main axle tube. I have included a picture for reference.
Your 265/70R17 size tire is around 31-1/2 inches in diameter. You want to make sure the tire cover you get is large enough and doesn't have to be stretched over the tire. I'd rather have one that's slightly loose than one that tears…
I think you might be talking about diameter but yes, a 215/75-14 trailer tire will have a slightly larger circumference than a 205/75-14 tire. Specifically, the 205 will have a circumference of about 82.582 inches whereas the 2015 will have a…
For your 14 inch wheels, I recommend the Provider ST215/75R14 Radial Trailer Tire - Load Range D #TTWTRTM2157514D. This is a slightly smaller tire, but it is very well made. It is rated for 2,200 lbs at 65 psi and has a max speed rating of 81 mph. It…
The two sizes you mentioned are pretty similar and fit many of the same 15 inch wheels. The 205/75-15 fits rim widths of 5 inch to 6-1/2 inch whereas the 225/75-15 fits widths that are 5 inch to 6 inch. The 205 is 27.1 inches tall and the 225 is 28.4…
The Kenda Karrier ST205/75R14 Radial Trailer Tire #AM10235 (Load Range D) and the Kenda Karrier ST215/75R14 #AM10229 (Load Range C) that you referenced are simply different tire sizes. The ST215/75R14 tire size is larger in diameter/height by just…
Dexter hub #8-174-5UC3 uses the 5-spoke utility bolt pattern so it is uncommon just like the hub you have. If your existing hub uses inner bearing 25580 and outer bearing 15123 with a seal inner diameter of 2-1/8 inches then this hub is a likely fit.…
