Backup Camera for Edge Color Touch Screen (CTS) Monitors

Backup Camera for Edge Color Touch Screen (CTS) Monitors

Item # EP98201

lowest price pledge

Retail:$207.95

Our Price: $186.95

You Save: $21.00
Accessories and Parts

This item qualifies for Free Shipping

Shipping Weight: 2 lbs

Quantity:
In Stock, Ships Today
EP98201 - Backup Camera Edge Accessories and Parts
zoom in icon
zoom out icon
Comment field cannot be left empty.
Name field cannot be left empty.
Please enter a valid email address.

Thank you! Your comment has been submitted successfully. You should be able to view your question/comment here within a few days.

Error submitting comment. Please try again momentarily.

pop out icon replay 360 icon
horizontal rotate icon

Product Images


  • Performance Chip
  • Backup Camera
  • Edge
Make backing up a snap with this camera, designed specifically for use with your Edge CTS monitor. Sleek, low-profile license plate mount installs quickly and easily. CTS camera mode engages automatically when vehicle is put in reverse. Call 800-298-8924 to order Edge accessories and parts part number EP98201 or order online at etrailer.com. Free expert support on all Edge products. Guaranteed Lowest Price and Fastest Shipping for Backup Camera for Edge Color Touch Screen (CTS) Monitors. Accessories and Parts reviews from real customers.


  • All Info
  • Q & A (17)
  • Videos (2)
  • Photos
  • Why etrailer?

Edge Accessories and Parts - EP98201

Make backing up a snap with this camera, designed specifically for use with your Edge CTS monitor. Sleek, low-profile license plate mount installs quickly and easily. CTS camera mode engages automatically when vehicle is put in reverse.


Features:

  • Backup camera lets you see what's behind you as you drive in reverse
  • Images play on your Edge Attitude, Insight or Evolution color touch screen (CTS) monitor (sold separately)
    • Camera plugs directly into monitor's video input
    • CTS camera mode automatically engages when vehicle shifts into reverse
      • Not available on manual transmission vehicles
  • License plate frame mount installs quickly and easily on your vehicle
    • Low-profile design ensures that camera is virtually invisible
  • Adjustable, customizable camera angle
  • Long-lasting LEDs along the sides of the camera provide superior visibility in the dark
  • Waterproof construction
  • Durable black finish
  • Made in the USA


98202 Edge Back Up Camera for Color Touchscreen (CTS) Monitors

Replaces 98200 Edge Back Up Camera for Evolution CTS Programmer







Video of Backup Camera for Edge Color Touch Screen (CTS) Monitors


Videos are provided as a guide only. Refer to manufacturer installation instructions and specs for complete information.




Video Transcript for Edge Backup Camera for Color Touch Screen Monitors Installation - 2010 Ford F-150

Today, on our 2010 Ford F-150 SuperCrew Cab, we'll be taking a look at and installing the Edge backup camera for Edge color touchscreen monitors, part number EP98201. Backing up is a snap with this camera. If you don't have a monitor, we have plenty of options for Edge Performance tuners and monitors on our website. Our backup camera engages when we put the F-150 in reverse. As you can see, I'm able to safely backup and I can see everything behind me. We can also access the camera manually by going to the main menu and clicking on view camera. It's great for safely backing into tight spots and also for parallel parking or anything else where you need to see behind you. Now that we've got all the features, I'll go ahead and show you how to get it installed.

The first thing we can do, is go ahead and remove our license plate. Now, we can bring in our new Edge license plate bracket. I'm just going to line it up and see where I need to make a hole for my auxiliary cable. I'm basically just going to line it up with my previous holes, then it looks like I need to make it right here. I can go ahead and mark that and then drill it out. Now, it's a good idea to make sure there's no wires or anything behind our bumper here. I've already gone and checked, we're good.

We also want to be sure to drill out a big enough hole so our auxiliary cable can fit through. I'm just using a 3/8 drill bit here. Cool. With our hole drilled out, let's go ahead and bring in our license plate and our Edge backup camera. What we want to do is we want to place it over our bracket but as you can see, our auxiliary cable here, is going to get smashed. What I'm going to do is I'm going to notch the license plate right where it comes out of the back of the camera. I'm just going to be using some tin snips.

I'm going to get it lined up where it needs to be and then just snip a little bit out. Now, with our notch cut out, we can bring back in our license plate and line it up. As you can see, it's going to line up on the backside perfectly and on the front, you can't even see that anything's cut out. Then, we can line it up with the holes on the backside of our bumper here and I'm going to feed the auxiliary cable through our drilled-out hole. I'll bring it in, line it up with the holes, then we'll take our included hardware and put that through. The backside is going to get a flat washer, a lock washer and a nut. Here on the backside, we'll run our hardware just like we said we would. I'm just going to hand-tighten it for now and then I'll repeat the same process for the other three bolts.

With them all hand-tightened, we can come back and tighten them all down with our 10 millimeter wrench. Be sure not to over-tighten. All you want to do is flatten out that lock washer. Now, we can locate our auxiliary cable. We'll bring in our connection, we're going to line up the notches on the cable and push it on in-place until it snaps in, just like that. Then, we can take our adhesive tape and we want to seal up that connection. This is going to help prevent it from coming apart and from getting damaged by the elements. With that sealed up, we can go ahead and begin routing our cable to the front of our F-150. I've gone ahead and routed my auxiliary cable but I'll show you how I did it. I basically just followed my main wiring in the wire loom here, all the way up to the front of my F-150. I started here, I used the included zip ties, I routed it up through here and I kept going. Once I got over the axle, I routed it over, continued along the wiring here, again, using my included zip ties. Just follow along all the way up to the front and this is where I stopped. Now, we can begin routing it up. Please keep in mind, when routing your wire, you want to avoid anything hot or anything sharp. I'll continue routing my wire alongside the main wiring in the wire loom there. I'm just going to come up around the side of the wheel well and then I'm going to grab it from inside the hood. Once we've got a hold of it, we can just pull it up on through. Now we need to run our cable through our firewall. We're going to be going through this large grommet right here. I'm actually going to go on the other side and poke a hole outward through this way. Here it is on the inside and keep in mind, this is the driver's side. You can see it already has a hole through this side but it's a double grommet, so we need to poke it through the other side. Now, I'm just going to be using a screwdriver. Once I actually poke the hole, I can enlarge it. Another option is to use a box cutter and make a small incision on the grommet, so you can get the wire through easily. Now we'll need to pass our wire through our firewall. We're going to be going through this grommet right here, this large one. I'm actually just going to pull it out, pass my wire through and then I can cut a little slit in the grommet and put it back in-place. Here underneath our dash, you can see where my fingers are here. By popping the whole grommet out, it allows me to easily pass all the wires through without using a pull wire or anything like that. With our wires all inside, now I'm going to take my RCA cable, run it up through and trace it up to my monitor here. To make it easier, I'm going to disconnect the trim here. I'm just going to pull out very gently until it pops loose. Once you pop it loose from here, you can circle around, draw it out and then we can tuck our cable behind our weather stripping here. Then, I'll just take my cable, I'm going to come up, grab it through here and I only want to run enough cable up to my monitor. Now, on yours, it may be routed differently. As you can see, this one was fabricated. I'm actually just going to pop it loose, put my cable through here and then put it back where I found it. You can just run yours to your monitor, whichever way works best. Now, I'm just going to plug my cable into the back of my Edge screen here. If you need it, a right angle adapter is included. Once I've got it plugged in, I'm just going to put it back in-place. With my RCA cable plugged in, I'm just going to retract any excess cable that I may have and then I'm just going to zip tie it to my power wire here, for my monitor. We'll cut off the excess of the zip tie and then I'm going to tuck it behind the weather stripping here. With everything tucked in how I want it, I'm going to take my trim, line it back up and just pop it back in place. I've gone ahead and routed and zip tied my wires up underneath the dash here. Now, to route our wires to the passenger side where the fuse box is, we're going to tuck them under this piece of trim here and work our way across. I'm just going to start right here, I'm just tucking it in. I'm just pushing down, making sure it's not going to pop back, working my way across. I'm just pulling out on the trim here and tucking it in. Now, it looks like with the way we've run our wires, we're going to have just enough room to access our fuse box right here. I'm just going to pull it loose and put that to the side for now. Now let's find a place for our ground and that's going to be our black wire here. We're actually going to be connecting it to this bolt back here, so in order to route it that way, I'm going to finish tucking it around the trim here. I'm just going to pull that out a little bit and tuck it to where it's going that way. Then, once I get back here, I'm going to run it up and over the HVAC here and fetch it from the other side and that's going to put us right where we need to be. Then, once we've threaded over the HVAC here, we'll pull it down and then we're right here at this bolt where we need to be. I'll take that loose, put it underneath and tighten it back down. Now, our nut here's just going to be a 10 millimeter. Let's take that loose, put on our ground and then we'll replace it and tighten it back down. When we pull the panel off here, you can see our fuse cover. We're going to go ahead and pull that off. I'm going to squeeze in on both sides and it just pops off. We're going to be using the fuse here. This ties into our instrument panel and it's number 26. Now, you can either use the included tool that comes with your vehicle to pull this loose, or a pair of needle nose. Now, in it's place, we'll put our fuse tap and the hot side of the fuse is going to be on the left side. We'll need to make sure that the wire is on the left side, as you see it here. We can just go ahead and plug that in, just like that. With our fuse tap plugged in, let's go ahead and connect our connecting wire and then test it out. We'll turn our ignition to the on or run position. On a Edge screen, it's going to be just under the main menu. We'll press the view camera button and there you go. Now that we know everything works, I'm going to start cleaning up my mess here. I'm going to route my wire down through that little open section at the bottom of my fuse holder there that way I can put on my cover. I'll just push it in-place until it snaps in on both sides. Then, I'm going to route my wire up and behind my glove box here. With our wire tucked up out of the way, we can go ahead and replace our panel, put it into the tabbed slots here, circle it over and then push it into place. That's it, we're done. That's going to complete our look and installation of the Edge backup camera for Edge color touchscreen CTS monitors, part number EP98201, on our 2010 Ford F-150 SuperCrew Cab.

0
0

Ask the Experts about this Edge Accessories and Parts
Do you have a question about this Accessories and Part?


  • Recommended Performance Kit And Backup Camera For 2016 Ford F-450 Cab And Chassis
  • For your 2016 Ford F-450 Cab and Chassis, the Edge Stage 1 Performance Kit w/ Diesel Evolution CS2 Programmer and Jammer Air Intake, # EP19003, you asked about has 3 settings to increase horsepower and torque. Setting 1 will give you an additional 39 hp and 73 lbs torque to your factory settings. Setting 2 will give you 73 hp and 153 lbs torque. Setting 3 will give you 109 hp and 234 lbs torque. This system is not legal in California. For a dash board mounted backup camera system,...
    view full answer...

  • Compatible Edge Monitors and Display Functions for 2000 Toyota Land Cruiser
  • The Edge monitors offered for your 2000 Toyota Land Cruiser, the Insight CS2 # EP84030 that you referenced and the CTS2 # EP84130, will display up to 8 different engine parameters. These include things like RPMs, coolant temperature, transmission temperature, etc. Exactly which parameters will display is determined by the auto maker who decides on the exact data set that will be routed to the OBD-II port where the monitors connect. You can check with your local dealership using your...
    view full answer...

  • Recommended Backup Camera for Edge Gauge Display on a Travel Trailer
  • I do have an alternative option for you but I spoke to my contact at Edge Products and they informed me that they do not make an extension cable to extend the video cable from the rear of your travel trailer to the cab where your Edge monitor is located. They also stated that they do not recommend cutting and extending the wire in the Backup Camera for Edge Color Touch Screen part # EP98201. In order to use the Edge monitor in your cab with a rear view camera mounted at the back of your...
    view full answer...

  • Will Edge Backup Camera EP98201 Work with the CTS2 Monitor
  • Backup Camera for Edge Color Touch Screen (CTS) Monitors Item # EP98201 is the same as the 98202. It will fit both the CS2 # EP84030 and CTS2 # EP84130 monitors!
    view full answer...

  • Can the EvoHT be Removed After Setting a Tune
  • The Edge EvoHT, # EP36040, can stay plugged in, but it was designed to be able to set the tune and then unplug and throw in your glove box. Unplugging the unit does not reset your tune back to stock. The tune you set will stay on the truck until you use the EvoHT to change the tune. Another programmer that I recommend looking into is the Edge Evolution CTS Programmer, # EP85400, especially if you do not already have gauges to monitor things like boost or coolant temperature. The CTS...
    view full answer...

  • Are Tuning Programs Different In Edge Evolution, Evolution CS, And Evolution CTS For LBZ Duramax
  • I spoke with my contact at Edge and he said that the Edge Evolution tuning program is the same between the Evolution, the Evolution CS, and the Evolution CTS. The only difference is the type of display monitor in each different Evolution model. The display monitor in the Evolution model uses a LCD screen that can display in green, red, and blue or a percentage of each color. The display monitor in the Evolution CS2 uses a full-color, high resolution 2.4 inch screen. The display monitor...
    view full answer...

  • Camera Recommendation for Use with Edge CTS Programmer
  • The only camera we offer for the Edge CTS is the part # EP98201 which is in a license plate frame. You could either mount it where you need with the whole license plate frame or you could pretty easily cut the camera out of the frame and then use the two top mounting holes to secure the camera to your vehicle.
    view full answer...

  • Recommended Programmer for a 2018 Chevy Silverado 1500 with a 5.3L Engine
  • I recommend going with the Edge Gas Evolution CTS2 Performance Tuner # EP85450. This can give your 2018 Chevy Silverado 1500 5.3L up to 18 HP and 27 Torque and includes a monitor with a mount so that you can actually see your vehicle performance. This tuner features 4 preset programs; economy, towing, performance, and extreme so that you can choose the best tune for your application. The Mileage Coach also helps to monitor your MPGs and let you know how to adjust your driving accordingly....
    view full answer...

  • Will Edge Backup Camera Fit a 2006 Dodge Ram with Edge CTS Monitor
  • Since the Edge product you have is a CTS model then you can use the backup camera # EP98201 on your 2006 Dodge Ram diesel. The wiring should be long enough depending on how you route it from the monitor to the camera at the back. If it is not you would have to splice in the required length of wire. We have some 16 gauge wire, # 16-1-1, that is sold by the foot.
    view full answer...

  • Recommended Tuner for a 2012 GMC Yukon XL 1500
  • I have two different recommendations for you that will increase the horsepower, torque, and fuel economy for your 2012 GMC Yukon XL 1500. It all just depends on what type of engine that you have. The Superchips Flashpaq F5 Performance Tuner # SU2845 is my first recommendation. It will work with the 5.3L V8 Engine, the 6.0L V8 Engine, and the 6.2L V8 Engine. This programmer will help you to increase all of the settings on your Yukon XL and has the option to save the factory settings during...
    view full answer...

  • Which Gas Tuner will Help with Fuel Economy on a 2017 GMC Sierra 1500
  • If fuel savings is your number one priority for your 2017 GMC Sierra 1500 with the 5.3L V8, I recommend using the Edge Gas Evolution CTS2 Performance Tuner, # EP85450, for a few reasons. First, this tuner has 4 present programs: Economy, Towing, Performance and Extreme. The Economy tune is what you will want to use to see the fuel benefits in your every day driving. Second, this tuner also has the Mileage Coach which is a program that tracks your driving style and helps you develop...
    view full answer...

  • Edge CTS2 Performance Monitor for 2003 Nissan 350Z
  • The Edge Insight CTS2 monitor that fits your 2003 Nissan 350Z is their part # EP84130. The other monitor option is the CS2, part # EP84030, which does not include the touch screen function. Both of these units are monitors, not tuners, that fit the 3.5L V6 engine. They can read and display information from the car's computer but they do not alter any performance settings. No actual performance tuners are offered for your Nissan, just monitors like these that tell you what is happening inside...
    view full answer...

  • What Does the Edge Insight CTS2 # EP84130 Offer for a 1996 Jeep Cherokee
  • The Edge Insight CTS2 # EP84130 will connect to the OBD-II port in your 1996 Jeep Cherokee and will allow you to monitor the performance of your vehicle. It has an accelerometer that measures G-force and vehicle pitch and roll, does performance tests with logged data, has visual and audible alerts when user-programmed parameters are reached or exceeded and includes some helpful apps. A backup camera # EP98201 can be attached to it so that you can see behind your Jeep as well. This...
    view full answer...

  • OBD-II Data Set Available on 1998 GMC C/K Series 6.5L Diesel Pickup
  • Vehicles produced in the U.S. after January 1996 were req
    view full answer...

  • Can the Edge Evolution Programmer be Used on a 2005 Chevy Kodiak with a 6.6 Liter Diesel Engine
  • I spoke with my contact at Edge and he said that you can use the Evolution CTS2 # EP85400 on your 2005 Chevy Kodiak with the 6.6L diesel. Edge has the following information for the gains when using this programmer on the 6.6: Level 0: Stock Level 1: 30 Horsepower - 60 Foot Pounds of Torque Level 2: 50 Horsepower - 90 Foot Pounds of Torque Level 3: 70 Horsepower - 150 Foot Pounds of Torque Level 4: 100 Horsepower - 210 Foot Pounds of Torque You can add the optional backup camera,...
    view full answer...

  • Comparing Edge CS2 and CTS2 Monitors for a 2017 Ram 1500 with 5.7L HEMI
  • The difference between the Edge Insight CS2 # EP84030 and CTS2 # EP84130 for your 2017 Ram 1500 5.7L HEMI is that the CS2 has a smaller 2.4" screen and you use physical buttons for navigation. The CTS2 has a 5" touch screen that you use for navigation and it can also be paired to work with the backup camera # EP98201 so I recommend going with it over the CS2. Aside from that they both include suction cups for easy mounting and a cord that connects to your OBDII port.
    view full answer...

  • What Type of Camera Connects to Edge Insight CTS2 Monitor
  • For the Edge CTS2 Insight part # EP84130 we only have license plate backup cameras like the part # EP98201 which maybe you could convert into a third brake light camera but honestly would probably be somewhat difficult.
    view full answer...
