Curt Q20 5th Wheel Trailer Hitch - Dual Jaw - 20,000 lbs
part number: C16130

Adapter Rails for Curt 5th Wheel Hitch - Ford and Chevy/GMC Towing Prep Package
part number: C88KR

Ask the Experts about this 5th Wheel Hitch
Do you have a question about this 5th Wheel Hitch?

• Solution for Curt Q20 Fifth Wheel Hitch with Loud Clunking from Jaws

• Since the jaws of your Q20 can't be adjusted or replaced your best solution is going to be a new hitch like with the Curt A20 part # C16140 which is the newer version of what you have now which has a much tighter jaw design that will be quieter and last longer. Instead of the two jaw pieces coming together and just touching each other in the middle the A20 jaw has two pieces that lock together.
  view full answer...


• Recommended 20K 5TH Wheel Trailer Hitch For a 2022 Ram 3500 Long Bed With Turnover Ball and Rails

• With already having above bed rails I recommend going with the Curt Q20 # C16130 for your 2022 Ram 3500 long bed.
  view full answer...


• Fifth Wheel Hitch Recommendation to Use with Curt Turning Point King Pin 2021 Ford F-250

• Hey Timothy, basically almost every hitch ASIDE from the Q series Curt hitches like the part # C16130 that you referenced can be used with the Curt Turning Point pin boxes. That's actually one of the reasons Curt updated that line of hitch with the A series. So like the A25 part # C16036 would be a really great option if your 2021 Ford F-250 has the OEM prep package or the part # C77PV for if you do not have the prep package. With either of these you'd need the correct wedge which we
  view full answer...


• Comparing the Curt Q20 and the Curt A20 5th Wheel Hitches.

• As far as height adjustability and weight capacities the Curt Q20 # C16130 and the Curt A20 # C16140 are identical. They both have a Gross Towing Weight of 20,000 lbs, a Vertical Load Limit of 5,000 lbs, and a height range of 13-17 inches. When it comes to choosing which one is better, even though they are both excellent choices, I recommend going with the A20 because it has more features. Right off the bat the A20 has interlocking jaws to secure your king pin as opposed to the Q20 jaw
  view full answer...


• Where Does Curt Q20 Fifth Wheel Hitch Have it's Grease Fittings

• For the Curt Q20 5th Wheel Trailer Hitch # C16130, Curt does recommend that "black graphite grease" be used for the jaw before initial use and every 1,000 miles thereafter. Black graphite grease can usually be obtained at a local auto parts or hardware store and will probably just be labeled as "graphite grease." You can use the grease fitting that is centered in the cast base plate to grease the lower bearing assembly. The fitting is visible while looking down through the jaws in their
  view full answer...


• Recommended 5th Wheel Base Rails for a 2024 GMC Sierra 3500

• To add a set of 5th wheel rails to your 2024 GMC Sierra 3500, I recommend the B&W Custom Installation Kit w/ Base Rails item # BWRVK2505. These are made in the USA and fit both the 6-3/4' and 8' bed models. The B&W item # BWRVK2505 rails are industry standard which means they are compatible with your Curt Q20 item # C16130 along with most 5th wheel hitches on the market. The brackets are custom fit and install in pre-existing holes in your Sierra's frame. I have attached a couple
  view full answer...


• Recommended 5th Wheel Hitch for a 2022 Chevy Silverado 2500

• I would be happy to help you. There are two big differences in options for towing a 5th wheel trailer with your 2022 Chevy Silverado 2500. The first and easiest would be if you have the prep package. What that is is a from the factory option that puts four holes in the bed of your Silverado for mounting a 5th wheel hitch (See picture below). This is a factory option only and there is no way to add this with aftermarket parts. With this system on your truck you have two options to install
  view full answer...


• Will Curt Q20 5th Wheel Hitch Work With Reese Elite Underbed Adapter

• Yes, so long as you have the Reese Elite rails you can keep your Curt Q20 5th Wheel Hitch # C16130 and use the Underbed Rail and Installation Kit for Reese Elite Series 5th Wheel Trailer Hitches # RP30868.
  view full answer...


• Can A Base Rail Mount Curt Q20 5th Wheel Hitch Be Transferred From A GMC Sierra To A Ford F-350

• As long as your Curt Q20 has base rail style feet like part # C16130 and your 2022 Ford F-350 has ISR base rails you'll be able to transfer the hitch over with no issues.
  view full answer...


• Popping Noise Coming From Curt Q20 5th Wheel Trailer Hitch

• There are several parts on the Curt Q20 5th Wheel Trailer Hitch part # C16130 that need greased regularly; one zerk on each side of the head, one zerk in the center of the jaw, and the cam on the locking jaw mechanism. I have attached a photo that shows each of these points for you but also make sure you are using the appropriate grease type as this is important as well. If the issue is still not fixed once you have greased all of the above components then the next thing you will want
  view full answer...


• Will Curt Q20 Work With Lippert Turning Point Pin Box

• There is a great option for a Curt 5th wheel hitch you can use with your Lippert Turning Point pin box, but the Curt Q20 Fifth Wheel Hitch # C16130 is not compatible. The reason is the head of the Q20 has what is called a "spherical axial bearing" which is really a fancy way of saying it pivots 360 degrees. This means it is not stable enough to work with a rotating pin box such as the Turning Point or a Sidewinder. A very similar hitch that will work with your Turning Point pin box is
  view full answer...


• Are Carriage Bolts used In Center Of Rails For Curt Fifth Wheel Installation Kit

• I have attached a drawing from the installation instructions for the rail kit part # C16430-204 you can check out. As you can see in the attached drawing I noted the carriage bolts and where they are located on the rails when installing. Please note the front rail uses 2 longer carriage bolts and the 8 shorter bolts are used in the other rail mounting locations.
  view full answer...


• Will a Curt Q20 5th Wheel Hitch Work with B&W 5th Wheel Rails

• Without knowing exactly what Curt Q20 and what base rails you have, I cannot say for sure that it will fit. But more than likely it will be compatible. The Curt Q20 is available for 5th wheel prep packages (puck system) in newer trucks. It is also available with industry standard mounting points like the Curt Q20 5th Wheel Trailer Hitch # C16130. If you have the Curt Q20 5th Wheel Trailer Hitch # C16130 which uses industry standard mounting points and base rails similar to the B&W
  view full answer...


• Troubleshooting A Curt Q20 Fifth Wheel Hitch That Won't Uncouple

• To uncouple the Curt Q20 5th Wheel Trailer Hitch # C16130 you'll first want to get the trailer as level as possible with the truck in-line with the trailer. Next you'll need to pull off the handle lock (pictured below) to allow the handle to pull out. You may need to lift up your trailer just a bit to take some of the pressure off of the hitch head to prevent it from binding up. Being brand new you shouldn't have any issues with it needing grease already so it's most likely just bound
  view full answer...


• Troubleshooting Jaws On Hitch Being Out Of Alignment

• To fix the jaws of a hitch like the Curt Q20 5th Wheel Dual Jaw Trailer Hitch, Item # C16130, when they are out of alignment, you will start by making sure the flip lock is hanging freely in a clockwise, rotated position. Then pull out the lock bar so that it is in the fully extended position and then release it. This action will reset the jaws. Afterwards, check and make sure jaws are working properly. If the jaws are still out of alignment and the hitch does not seem to be damaged
  view full answer...


• Will Trailair Pin Box Work with Curt Q20 Hitch

• Since I cannot find any info on a Travelair pin box most likely you have a Trailair pin box which would work well with a Curt Q20 hitch like part # C16130.
  view full answer...


• What 5th Wheel Hitches Are Curt 16027 Puck/Rail Adapter Compatible With

• The Curt 16027 which we offer as part # C88KR adapter provides industry standard bed rails that are compatible with Reese, Curt, Demco, B&W, Valley and Husky 5th wheel hitches, among others.
  view full answer...


• Will the Reese 16K Hitch work With the Curt Adapter Rails on a 2024 GMC Sierra 2500

• Yes, the Adapter Rails for Curt 5th Wheel Hitch # C88KR will work with your 2024 GMC Sierra 2500 and your Reese 16K hitch.
  view full answer...


• Can Reese Elite Hitch Install on Curt Adapter Rails for More Height on a 2021 Ford F-450 Puck System

• Hey Bryan, thanks for reaching out! Your Reese Elite Series Hitch (discontinued part 30143) has a height range of 14-1/2" - 17" and is only able to secure to the OEM puck system on your 2021 Ford F-450 Super Duty, so we either need to get you a taller hitch that mounts directly to the pucks or you can use the Curt Adapter Rails # C88KR with a different hitch to gain more height like what you said. The first option I recommend exploring is the B&W Companion # BWRVK3305 because it installs
  view full answer...


• Parts Needed To Use a Curt A20 5TH Wheel Hitch In Bed of a 2017 Ford F-350 With OEM Puck System

• I have 2 options for you Simon to mount your Curt A20 5th Wheel Hitch # C16140 in your 2017 Ford F-350 with the factory puck system. The first and easiest is the Adapter Rails # C88KR which you found. This will mount into your 4 outer factory puck holes and gives you the same mounting points your Curt hitch fits into. Do understand this will add 2-1/2" to the height of your hitch so you may need to adjust your mounting holes. We also have the Legs # C16017 you can mount to your Head #
  view full answer...


• How to Use Andersen Ultimate for Base Rails in 2024 Chevrolet Silverado 2500 With OEM Prep Package

• Hey Brent! It sounds like you have the Andersen Ultimate Connection 5th Wheel Trailer Hitch System # AM3200 which fits industry standard rails. The Adapter Rails for Curt 5th Wheel Hitch # C88KR you were looking at is the solution. This will fit the puck system on your truck and provide you with rails to mount your Andersen hitch. Any big trips planned with your 5th wheel this summer?
  view full answer...


• Can B and W Patriot Hitch be Used in 2025 GMC Sierra 3500 with OEM Hitch Prep

• Hey Bryan, as long as the Patriot hitch you have is the non-slider version you can use the Curt adapter part # C88KR. If you have the slider Patriot there isn't an adapter available and only solution would be a new hitch like the B and W Companion part # BWRVK3715. How do you like the Patriot though? Most of the feedback we have on it is that people really like it.
  view full answer...


• Can I Use the Curt Adapter Rails # C88KR with the Pulrite 2900 SuperGlide?

• It truly depends on what Pulrite SuperGlide 2900 5th-wheel hitch you have. As long as you have the ISR series (which stands for "Industry Standard Rails"), then you can definitely use the Curt Adapter Rails # C88KR (Curt part number 16027) with the hitch. The Curt adapter is compatible with your 2022 GMC Sierra 2500 with a 6-3/4 foot bed and OEM prep. With the # C88KR installed, these serve as your industry standard rails. I went ahead and attached an installation walkthrough to guide
  view full answer...


• What is Needed to Use Curt Slider Fifth Wheel Hitch in Bed of 2022 Ford F-350 OEM Pucks

• Hey Mike, all you need to use your current Curt fifth wheel slider hitch in the bed of your 2022 Ford F-350 with OEM pucks is the correct rail kit adapter which happens to be the part # C88KR.
  view full answer...


• Questions About Turning Clearance With Curt CrossWing On 2025 GMC 3500 AT4

• Hey thanks for reaching out, Craig. We do not have any information stating that the Curt Crosswing cannot be used with the Curt Helux pin box, but if Curt specifically told you not to, then I would have to take their word for it. So unless you can get them to put a different pin box on your 5th wheel, we will need to go in a different direction for the 5th wheel hitch. There are other slider hitches available, but they are going to be considerably heavier than the Crosswing. For example
  view full answer...


• Will Curt E16 Slider Hitch Fit on Curt GM Rail Kit Adapter for 2025 Chevy Silverado 2500

• Hey Jeff, yes the Curt E16 slider hitch is compatible with the GM rail kit adapter part # C88KR you referenced that fits your 2025 Chevy Silverado 2500. What are you towing?
  view full answer...


• Adapter for Curt A16 in 2025 GMC Sierra 3500 With Prep Package

• Hey Keith, congratulations on the new truck! You were right on with what you believed. The # C16560 slider on your Curt A16 fits industry standard rails. The Adapter Rails # C88KR (16027) will fit the puck system on your 2025 Sierra 3500 and provide you with ISR rails to install your Curt 5th wheel hitch. What kind of 5th wheel do you have?
  view full answer...


• Mounting Hole Spacing For the 5th Wheel Adapter Rails C88KR 16027 in a 2021 GMC Sierra 2500

• The Adapter Rails # C88KR (16027) will fit the OEM prep in your 2021 GMC Sierra 2500 and provide you with industry standard mounting points. As long as your Hijacker hitch uses industry standard rails, then it will work with the # C88KR adapter. I have also included a diagram that shows the spacing of the slots in the Adapter Rails # C88KR.
  view full answer...


• Can a Set of 5th Wheel Base Rails Be Installed On a Truck With OEM Pucks

• No, the B&W Custom Installation Kit w/ Base Rails for 5th Wheel Trailer Hitches # BWRVK2402 would not be able to be installed with your OEM prep kit. This is why the Adapter Rails for Curt 5th Wheel Hitch # C88KR exists, so that you can use standard rails with your OEM pucks.
  view full answer...


• Is There A Puck To Base Rail Adapter For The B&W Patriot Sliding 5th Wheel Hitch

• Because the base of the Patriot Slider sits so low in the center there isn't enough clearance for it to be compatible with the Adapter Rails for Curt 5th Wheel Hitch # C88KR. The fixed base Patriot would be a compatible option with # C88KR. Unfortunately there isn't an adapter or a replacement base that you could swap in to be compatible with the puck system in your Sierra so the best option is going to be selling your Patriot and getting the Companion # BWRVK3775, which would fit the puck
  view full answer...


• Recommended 5th Wheel Rail Adapter for the GM Factory Puck System

• To use your Reese 20K 5th wheel hitch in your Silverado's factory puck system, I recommend the Adapter Rails for Curt 5th Wheel Hitch item # C88KR. This adapter has feet that will drop right into the pucks in your bed. It will give you a set of industry standard rails to attach your Reese 5th wheel hitch too. I have linked an installation video below. It will work with almost all hitches that use industry standard rails so don't be concerned that it says only for Curt.
  view full answer...


• Will the Curt Adapter for GM Puck System Work w/ a Curt R20 Slider?

• Congrats on the upgrade! Yes, it will. The Adapter Rails for Curt 5th Wheel Hitch item # C88KR is exactly what you need to use your Curt R20 Slider base item # C16550 in your 2023 Chevy Silverado 3500's factory puck system. This adapter will drop right down into the four pucks and provide you with a industry standard base. The Curt Adapter Rails item # C88KR have a 25,000 lbs capacity and will add 2-1/2" of height to your 5th-wheel hitch when installed.
  view full answer...


• Recommended 5th Wheel Rail Adapter for the GM Puck System

• Congrats on the new truck! You won't have to swap our your Curt Q20 Hitch but you will need to use an adapter because GM changed the puck pattern in 2020. The correct adapter is the Item # C88KR you were looking at. This will mount directly to the puck system in your 2024 Chevy Silverado 3500 and give you a base that works with industry standard 5th wheel hitches like the Q20. I have linked an installation video below so you can see how to get this adapter set up. Please note that
  view full answer...


• 5th Wheel Adapter Rails For a 2024 GMC Sierra 2500 w/ Factory Prep to Use an ISR 5th Wheel Hitch

• It sounds like you have a Reese 16k 5th wheel hitch that mounts in industry standard rails. To use that hitch in your 2024 GMC Sierra with factory prep package, you can use the Curt Adapter Rails # C88KR. This adapter will fit into the puck system in your Sierra and provide you with industry standard mounting points to use your current 5th wheel hitch.
  view full answer...


• Adapter for Industry Standard 5th Wheel Rails on a 2022 Chevy Silverado 2500 HD w/ Factory Pucks

• Thank you so much for the pictures and congrats on the new truck! Yes, the Adapter Rails for Curt 5th Wheel Hitch item # C88KR will fit your 2022 Chevy Silverado 2500's factory puck system. These rails have a 25,000 lbs capacity so they should easily work with your 5th wheel hitch so long as it is compatible with industry standard rails. I have linked a review video below. These will NOT work with a B&W Patriot Slider hitch.
  view full answer...
