Diode Dynamics Vehicle Lights - DDY54KV

Upgrade your factory fog lights with these premium 3" LED pod lights. The SAE-compliant fog lights give you brighter light and a more concentrated light pattern to see more clearly in inclement weather. Includes plug-and-play adapters.

Features:

• Custom-fit LED fog lights give you high intensity light in an 80-degree horizontal spread for better visibility in inclement weather
  • TIR optics reduce glare and give you a more concentrated beam pattern that projects light further
  • Street-legal pods are SAE J583 certified for use on all roadways
• Amber backlights act as running lights making you extra visible to other motorists when not using your fog lights
• Plug-and-play adapter makes it easy to switch from your factory fog lights to the SS3
• Rounded bezel gives your fog lights a seamless OEM look
• Pin-fin heatsinks on the back of the housing dissipate heat quickly to increase longevity
• Black powder coated aluminum housing and brackets are corrosion resistant
  • IP69K-rated to protect against moisture and high pressure
• Cool white color matches most factory LED headlights
• Includes 2 LED pods, 2 Type-MS brackets, (2) 5202 2-pin DT adapters, (2) 5202 4-pin DT backlight tap wire kits, mounting hardware, and mounting guide

Specs:

• Quantity: 2 lights
• Light dimensions: 3-5/16" wide x 3-5/16" tall x 2-3/8" deep
• Weight (each): 0.75 lbs
• Operating voltage: 9-30V
• Wattage:
  • Main beam: 36 watts
  • Backlight: 0.4 watts
• Power draw:
  • Main beam: 2.7 amps
  • Backlight: 0.03 amps
• Connector(s): Deutsch DT input
• Lumens:
  • Raw: 5,796
  • Measured: 3,000
• Peak beam intensity: 11,900 candela
• Illuminance: 119 lux @ 10 meters
• Beam angle: 80 degrees wide x 8 degrees vertical
• Color temperature: 6000 K
• IP rating: IP69K
• Operating temperature: -40 F to 185 F
• 8-Year limited warranty

Note:

• When installed as a pair and aimed in accordance with your state's regulations, fog pattern meets SAE J583 standard as a fog lamp, for legal on-road use. Please check your local laws and regulations for aiming, installation, and applicability.
• This kit is a replacement for OEM fog lamps. If your vehicle does not have fog lamps, additional hardware and wiring may be needed for installation.

DD7063 Diode Dynamics Replacement SS3 Pro Upgrade - Type MS Kit - White - SAE Fog Pattern

DDY32VV, DDY59TV

Installation Details

This Product Fits The Following Vehicles

• 2020 - 2023 Jeep Gladiator
• 2018 - 2018 Jeep JL Wrangler
• 2018 - 2018 Jeep JL Wrangler Unlimited
• 2019 - 2025 Jeep Wrangler
• 2020 - 2026 Jeep Wrangler 4xe
• 2019 - 2025 Jeep Wrangler Unlimited
