Aluminum Viking Series Valhalla Trailer Wheel - 16" x 6-1/2" - 8 on 6-1/2 - Silver Spoke
(150 reviews)
Price: $165.54
In Stock
Aluminum Viking Series Valhalla Trailer Wheel - 16" x 6-1/2" - 8 on 6-1/2 - Silver Spoke
Item # AX02665865HDBMMFL
Our Price: $165.54
This item qualifies for Free Shipping
In Stock
Need help with installation?
Locate installers near me- All Info
- Reviews (150)
- Q & A (8)
- Photos
- Why etrailer?
Taskmaster Trailer Tires and Wheels - AX02665865HDBMMFL
- Wheel Only
- 16 Inch
- 8 on 6-1/2 Inch
- Aluminum Wheels
- Boat Trailer Wheels
- Taskmaster
16" x 6-1/2" Trailer wheel has an 8 on 6-1/2 bolt pattern and a 4.9" pilot diameter. Rustproof aluminum wheel features a bold design in matte black and machined silver. Steel inserts in lug nut wells secure wheel.
Features:
- Aluminum wheel is durable, lightweight, and rustproof
- Viking Series Valhalla design in black with machined silver spokes provides a bold, sleek look
- Front and back of wheel have a matte clear coating
- Steel inserts in lug nut wells help to keep wheel securely in place on trailer hub
- Prevent holes from wearing down
- Eliminate the need for constant retightening of lug nuts
- Center cap and valve stem are included
- Meets SAE J1204 standards
Specs:
- Rim dimensions: 16" diameter x 6-1/2" wide
- Bolt pattern: 8 on 6-1/2"
- Wheel bolt size: 1/2"-20 or 9/16"-18
- Capacity: 4,450 lbs
- Pilot diameter: 4.9"
- Offset: 0
- Lifetime warranty against structural defects
Steel Lug Nut Inserts
This aluminum wheel comes with steel inserts in the lug nut wells. The inserts are pressed into the aluminum, and they help prevent the holes from wearing down over time. This ensures that the wheel stays secured to your trailer hub and that you won't have to constantly retorque the lug nuts.
Determining the Bolt Pattern
The first number in the bolt pattern is the number of bolt holes. The second number denotes the diameter, in inches, of the circle on which the bolt holes sit.
To determine the bolt-circle diameter on wheels with an odd number of bolt holes, measure from the center of any bolt hole to the point halfway between the two bolt holes directly across from the first. (Example: "5 on 4-1/2" means 5 bolt holes with 4-1/2" measured to a point halfway between the opposite bolt holes.)
On wheels with an even number of bolt holes, measure from the center of one bolt hole to the center of the hole directly across from it. (Example: "8 on 6-1/2" means 8 bolt holes with 6-1/2" from the center of one hole to the center of another on the opposite side.)
Measuring the distance from the center of one bolt hole on the wheel to the center of a bolt hole right next to it can also help to determine the bolt pattern.
- If D = 2-5/8", then the bolt pattern is 5 on 4-1/2"
- If D = 2-3/4", then the bolt pattern is 5 on 4-3/4"
- If D = 3", then the bolt pattern is 5 on 5"
- If D = 3-1/4", then the bolt pattern is 5 on 5-1/2"
AX02665865HDBMMFL Taskmaster Viking Series Valhalla 16x6.5 Aluminum Rim - 8 on 6.5 - Black and Machined Silver
Customer Reviews
Aluminum Viking Series Valhalla Trailer Wheel - 16" x 6-1/2" - 8 on 6-1/2 - Silver Spoke - AX02665865HDBMMFL
Average Customer Rating: 4.8 out of 5 stars (150 Customer Reviews)
16" x 6-1/2" Trailer wheel has an 8 on 6-1/2 bolt pattern and a 4.9" pilot diameter. Rustproof aluminum wheel features a bold design in matte black and machined silver. Steel inserts in lug nut wells secure wheel.
- AX02665865HDBMMFL
by: Wayne10/04/2021
i have an 04 Auto Mate 5th wheel. I ordered these rims because they had a 4450 lb ea rating. Timothy helped me with my order. He was great. My experience buying wheels, and lug nuts was stress free. I also ordered wheel studs from Kyle. Shipping was fast. Rims were packaged with great care.and received in perfect condition. You guys were great. Will be buying again.
- AX02665865HDBMMFL
by: Matt08/16/2021
The wheel did well for about a year and then developed a crack. My 2014 Cedar Creek Silverback is a dual axle and probably could use another axle, which may contribute to the crack in the wheel. But the wheel is supposed to be rated for 4,450 lb. of weight. But either way, Taskmaster fulfilled their lifetime warranty and sent me a replacement wheel quickly.
- AX02665865HDBMMFL
by: Roland09/21/2021
wheels showed up 3 days early well packaged, had tires mounted and installed on trailer. so far so good won't be using trailer for a couple weeks but not anticipating any problems.
- AX02665865HDBMMFL
by: Joe10/20/2019
Great service dealing with Donna at etrailer worked with me to find best fit for my needs. Rims arrived on time and in great shape. Had the tires mounted, all went well and looks great only put a few miles(9) on them to get it home. Nice ride and all seems well. Will find out more next spring when start out for 4 month trip
- AX02665865HDBMMFL
by: Charles08/06/2021
These rims look great. They arrived on two different days but were still ahead of schedule. They were well packed and protected. I have always had a good experience with etrailer.
- AX02665865HDBMMFL
by: Kyle03/15/2021
Wheels look really great on my RV. Just what my rig was lacking.
- AX02665865HDBMMFL
by: Johnny06/29/2021
Quick an fast great customer service
- AX02665865HDBMMFL
by: Stephen08/27/2019
They arrive about 11am. I took the wheels and tires to Big O and had them mounted. They look good.
- AX02665865HDBMMFL
by: Ronnie06/26/2021
- AX02665865HDBMMFL
by: Frank09/03/2021
- AX02665865HDBMMFL
by: Scott10/14/2021
- AX02665865HDBMMFL
by: Mcfarling07/19/2021
- AX02665865HDBML
Richard - 05/30/2021
by: Richard05/28/2020
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
A expexted, etrailer sent my order quickly and accurately. These are exactly what I needed, good strong rims to keep my 5th on the road and safe.
Comments
Still rolling! I had a brief break down. Under the loads carried by ANY rim while towing, I have had two completely different brands, one Fuel and one Taskmaster, crack. There were NOT catastrophic but small cracks along the centerline. I believe this is a manufacturing casting process weakness. All that said, both times, for both wheels, they were fully covered under warranty, no problems and quick turnaround. The hardest part was putting on the spare tire. I am confident these wheels are good and have probably proved that. Both times road hazards may have been the true issue. Potholes are hazardous to heavy loads. Although I cannot prove this, I am more vigilant for road hazards. We full time RV and rely upon working wheels. I would buy these anytime. They look good. These Taskmaster wheels have one of the highest load ratings available.
Richard - 05/30/2021
- AX02455545BMFL
by: John04/23/2021
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
etrailer was awesome to work with. Great selection of custom wheels, reasonable pricing, fast delivery and exceptional customer service. My boat trailer loves it's new wheels!
- AX02455545BMFL
by: 07/23/2021
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
helped make my boat trailer look modernized!!! great product!!!
- AX02455545BMFL
by: Victor05/23/2021
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
The quality of these wheels are so good.it just sets my boat off now,thank you so much for the prompt service.
- AX02660655BMMFL
by: Jared05/24/2021
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
Upgraded 27' tongue-pull toy-hauler from factory 15" for one extra ton of tire load and better speed capability. Paired with ST235/80R16 Goodyear Endurance. Center caps did not contact the axle hub which will cause them to float & rattle (a quick mod with pliers to dimple the hub contact area corrects the issue). Packaging was nice & they showed up on time. Trailer manufacturers 15" wheel & tire setup was an Achilles Heel for sure (3 blowouts & a flat last year). Excited to see how they hold up through a season.
- AX02350545BMFL
by: Kevin p.05/16/2021
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
Fits perfect and looks good. The center cap won't go on its not deep enough but other than that they look good.
- AX02350545BMFL
by: Jeffrey08/04/2021
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
Great experience with this company. I received a confirmation email right away after I placed my order. I also received an email when my wheels were shipped with a tracking number for the package. My wheels arrived a day earlier than the expected delivery date which is pretty unheard of these days. Shipping was also free. Win Win Win. I highly recommend etrailer to anyone..
- AX02350545BMFL
by: Michael04/18/2020
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
The wheels made the boat trailer look awesome. Difference is between night and day from the original plain Jane stock wheels and these. Awesome wheels and solid!!
- AX02350545BMFL
by: Patrick08/27/2021
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
Good looking rim, add's some bling to my cycle trailer. Turn around from purchase to curb was great compared to the " BIG chain brand" that was ordered over a month ago and I finally canceled their order. Received these in a couple of days. :-)
- AX02660655BMMFL
by: Michael06/06/2020
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
These wheels are great! mounted on my 2008 Cougar 5er. What a difference! Needed a bit more height so moved up from a 15" steel white wheel to this 16". Made sure whole patterns matched RV before ordering. Had one wheel arrive the wrong size inside the box that was properly labelled, but good customer service got me another one without issue. Two issues... Took a long time to arrive and suspect was still in route from elsewhere, so took a few weeks for me to get. The other is the center cap is still a tiny bit loose after wheel is torqued down... I would purchase again if the need arises...
- AX02350545BMFL
Harv - 03/03/2021
by: Harv03/02/2020
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
What a class operation! I strongly suggest researching the product before ordering by watching the videos on how to measure lug spacing and the like before ordering. If you do, you will receive the right product the first time and your experience will be very pleasant. If buying rims, you will be blown away by the packaging and protection of the rims during shipping. I would 100% buy from etrailer.com again!
Comments
One year with the rims and I couldn’t be happier. They arrived well protected in the shipping boxes. Everything was wonderful.
Harv - 03/03/2021
- AX02350545BMFL
by: Rodney02/23/2020
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
Feel like very high quality looks great package very well. Only complaint is the center cap is about 1/4" to short to fit the cap on with bearing buddies. Doesnt look terrible with it off just disappointing.
- AX02550545BMMFL
by: Shayne10/07/2021
Review from a similar Viking Series Valhalla in Trailer Tires and Wheels
I love the wheels! They fit perfectly, look great, and were received very quickly!
31
162
Show More Reviews
Ask the Experts about this Taskmaster Trailer Tires and Wheels
- Will the 16 Inch Aluminum Viking Series Valhalla Trailer Wheel Hold 110 PSIYes, the Aluminum Viking Series Valhalla Trailer Wheel part # AX02665865HDBMMFL will hold 110 psi if used with the Americana Metal, Bolt-In Valve Stem part # AM20906. The psi capacity of a trailer wheel will always come from the valve stem, not the actual wheel itself. If you don't already have a set of tires picked out, I recommend going with the Provider Radial Trailer Tire part # PRG80235 or part # TTWPRG235R16 which have an 81 mph speed rating and 4,080/4,400 lb weight capacity.
view full answer... - Which Lug Nuts for Taskmaster AX02665865HDBMMFL Viking Valhalla 16x6.5 Trailer WheelBecause the holes for the lug nuts on the # AX02665865HDBMMFL Viking Valhalla wheel are countersunk, a regular lug nut won't work. You'l need a longer lug nut like # 12CLN for a 1/2-20 or # LHLR110 for a 9/16-18. The wheel you specified is compatible with both 1/2 inch or 9/16 wheel studs.
view full answer... - What Size Valve Stem Hole Is On the 16" Aluminum Viking Series Valhalla Trailer WheelThe Aluminum Viking Series Valhalla Trailer Wheel part # AX02665865HDBMMFL has the larger .625" diameter valve stem hole. I recommend using the Metal Bolt-In Valve Stem part # AM20906.
view full answer... - Could Aluminum Viking Series Valhalla Trailer Wheel Replace Wheel with 5 inch Pilot DiameterThe Aluminum Viking Series Valhalla Trailer Wheel # AX02665865HDBMMFL has a 4.9 inch pilot diameter which means the center hole of the wheel is 4.9 inches. This is pretty close to the 5 inch diameter you mentioned so there's a good chance this would fit and work well. Measure the outer diameter of the center bore of your hub and as long as it's less than 4.9 inches this will fit.
view full answer... - 16 Inch by 6-1/2 Inch Wheel Rim Options for ST235/80R16 Load Range G TiresThe Provider ST235/80R16 Radial Trailer Tire - Load Range G # PRG80235 or the Premium Trailer Contender ST235/80R16 Radial Trailer Tire - Load Range G # PTCG80235 is the 14 ply tire you are seeking. These will fit 16x6, 16x6-1/2, and 16x7 inch wheels. We have the following options for the 6-1/2 inch wheels: -Aluminum HWT Series S5 Trailer Wheel - 16" x 6-1/2" Rim - 8 on 6-1/2 - Black # AM22659HWTB -Aluminum Viking Series Valhalla Trailer Wheel - 16" x 6-1/2" - 8 on 6-1/2 - Black...
view full answer... - Recommended 16" Wheels with 6 on 5-1/2 Bolt Pattern for Load Range G TiresIf you were to go with 16" wheels with a 6 on 5-1/2" bolt pattern, the highest capacity wheel we have available would be something like the Aluminum HWT Series S5 Trailer Wheel - 16" x 6-1/2" Rim - 6 on 5-1/2 - Black Item # AM22658HWTB; this wheel has a 3580-lbs capacity, so it's not going to fully maximize the roughly 4000-lbs capacity of a Load Range G wheel like the Provider ST235/80R16 Radial Trailer Tire - Load Range G # PRG80235. However, going up to a wheel with an 8 on 6-1/2"...
view full answer... - Aluminum Trailer Wheel to Use with Goodyear Tire Size ST255/85R16The Goodyear Endurance trailer tire size ST255/85R16 that you referenced # 724862519 needs at least a 6-1/2 inch wide wheel which the Siberian wheel part # LHSB168BMF would not work for since it's only 6 inches wide. So instead you'd want something like the # AX02665865HDBMMFL which is 6-1/2 inch wide or # AX02665865HDGMML for a lighter color version.
view full answer... - Availability of Trailer Wheel that is 16" by 6.5"We have a trailer wheel that matches the dimensions you listed with the HWT Series part # AM22659HWTB that is 16 inch in diameter and 6-1/2 inches wide. We also have the part # AX02665865HDBMMFL as well. Everything else is going to be 6 inched wide or 7 inches wide.
view full answer...
