Kenda 215/60-8 Bias Trailer Tire with 8" White Wheel - 5 on 4-1/2 - Load Range D
Kenda

Kenda 215/60-8 Bias Trailer Tire with 8" White Wheel - 5 on 4-1/2 - Load Range D

Part Number: AM3H323
In Stock
$77.86
Retail:$83.86
You Save: 7%
Trailer Tires and Wheels
zoom in icon
slider vertical icon
zoom out icon
Comment field cannot be left empty.
Name field cannot be left empty.

Thank you! Your comment has been submitted successfully. You should be able to view your question/comment here within a few days.

Error submitting comment. Please try again momentarily.

Product Images

Customer Photos

Need help with installation?
Locate installers near me
Bias tire has a ply rating of 8 and a 1,040-lb maximum load at 70 psi. The 8" diameter x 7" wide steel trailer wheel features a 5 on 4-1/2 bolt pattern and a corrosion-resistant powder coat finish. Great Prices for the best trailer tires and wheels from Kenda. Kenda 215/60-8 Bias Trailer Tire with 8" White Wheel - 5 on 4-1/2 - Load Range D part number AM3H323 can be ordered online at etrailer.com or call 1-800-940-8924 for expert service.
  • All Info
  • Reviews (7194)
  • Q & A (0)
  • Photos

Kenda Trailer Tires and Wheels - AM3H323

  • 8 Inch
  • Tire with Wheel
  • 5 on 4-1/2 Inch
  • 215/60-8
  • Load Range D
  • Steel Wheels - Powder Coat
  • Bias Ply Tire
  • M - 81 mph
  • Kenda

Bias tire has a ply rating of 8 and a 1,040-lb maximum load at 70 psi. The 8" diameter x 7" wide steel trailer wheel features a 5 on 4-1/2 bolt pattern and a corrosion-resistant powder coat finish.


Features:

  • Kenda Loadstar trailer tire offers excellent handling
    • Bias cut provides superior stability
    • Modern tread design reduces rolling resistance for a smooth ride
  • Steel wheel resists rust and corrosion
    • White powder coat finish over e-coat primer
  • Tire-and-wheel assembly meets Department of Transportation specifications


Specs:

  • Rim dimensions: 8" diameter x 7" wide
  • Bolt pattern: 5 on 4-1/2"
  • Wheel capacity: 1,040 lbs
  • Wheel bolt size: 1/2"-20
  • Offset: 0
  • Pilot diameter: 2.8"
  • Tire size: 215/60-8
    • Section width: 8.9"
    • Outer diameter (when inflated): 18.1"
  • Tire capacity:
    • Load range: D
    • Ply rating: 8
    • Maximum load: 1,165 lbs at 70 psi
  • Maximum speed: 81 mph (speed rating M)
  • Limited 5-year warranty on tire
  • Limited 1-year warranty on wheel


1-Year Worry-Free Guarantee

This tire has a 1-year worry-free guarantee. If within the first 12 months the tire is damaged in any way, it will be replaced at no charge.


Bias Tires vs. Radial Tires

Bias vs. radial tire graphic

Bias ply tires are designed for off-road or agricultural applications. They are built with thick, durable nylon cords that are positioned at a 30- to 45-degree angle to the direction of travel. The layers alternate in a crisscross pattern, making the sidewalls stiffer so that the entire tire is able to flex easily. As a result, the tire provides a smooth ride and improved handling when trailering on uneven surfaces.


Determining the Bolt Pattern

The first number in the bolt pattern is the number of bolt holes. The second number denotes the diameter, in inches, of the circle on which the bolt holes sit.

Bolt Pattern - Odd

To determine the bolt-circle diameter on wheels with an odd number of bolt holes, measure from the center of any bolt hole to the point halfway between the two bolt holes directly across from the first. (Example: "5 on 4-1/2" means 5 bolt holes with 4-1/2" measured to a point halfway between the opposite bolt holes.)

Bolt Pattern - Even

On wheels with an even number of bolt holes, measure from the center of one bolt hole to the center of the hole directly across from it. (Example: "8 on 6-1/2" means 8 bolt holes with 6-1/2" from the center of one hole to the center of another on the opposite side.)

Bolt Pattern - Side

Measuring the distance from the center of one bolt hole on the wheel to the center of a bolt hole right next to it can also help to determine the bolt pattern.

  • If D = 2-5/8", then the bolt pattern is 5 on 4-1/2"
  • If D = 2-3/4", then the bolt pattern is 5 on 4-3/4"
  • If D = 3", then the bolt pattern is 5 on 5"
  • If D = 3-1/4", then the bolt pattern is 5 on 5-1/2"




3H323 Solid 8" White Wheel and Kenda Loadstar K399 Bias Tire - LR D





Customer Satisfaction Score:

Ratings & Reviews

4.9

4060 reviews
5 Stars
(3693)
4 Stars
(293)
3 Stars
(29)
2 Stars
(14)
1 Star
(31)
Bias tire has a ply rating of 8 and a 1,040-lb maximum load at 70 psi. The 8" diameter x 7" wide steel trailer wheel features a 5 on 4-1/2 bolt pattern and a corrosion-resistant powder coat finish.

by:

perfect for Apache camper



by:

Good hard rubber, should last a long ti me



by:

Great tire and rim very pleased !!!! Fit was perfect , customer service was Great and shipping fast..Highly recomend this company



by:

Product came in a timely manner and in great shape. No issues here with me.



by:

Wheels and tires are great. Thank you.



by:

Packed well and just a good value



by:

Great product, good communication, I will order from them again..



by:

Complete overall purchase was excellent including delivery time. I bought this tire to replace one that failed from a different manufacture. I now have four of these tires and they have performed very well. Great tires.



by:

Never disappointed



by:

Product is good...but had to purchase bias ply because no radials were available in 12" 145x5x4.5 for 6months...
So I settled on a narrower basis so I can use boat this fall



by:

Fast response fast delivery great product, solid rims great and sturdy looking tries fit like a glove thanks



by:

Work as it should. Would by again.



by:

Placed order and was delivered quickly. P roduct was excellent.
Will be placeing another order in the near future



by:

What can I say the process of ordering was easy, the follow up was complete and delivery was made with no issues.



by:

These tyres are rated 1,100# at an amazing 100 psi. Despite the low price they are almost entirely round. The bolt holes matched up adequately with the existing hub, as well.



by:

Excellent product, well packed, great price, and free shipping...what more could you ask for



by:

Just what I needed and when I sell they wrong one that I ordered on another site, I'll order another one for a spare. TY very much
Gordon



by:

Tires and wheels look good fit was also good and best of all the price was great . Trailer towers nice .



by:

It was easy to find what I wanted on your site , this is the second set I have purchased from you have been satisfied in both cases.



by:

The order was placed and delivered in a timely manner.



by:

The product is as stated. Was shipped very quickly.



by:

Great so far. I'm glad I got them



by:

The price and the service is first class. I will and have promoted the products and supplier on the airport and else where.

Archie



by:

for my 16' duck boat. works perfect



by:

Ordered a trailer tire with normal shipping. Got upgraded and receive my tire in about three days and no additional charges. I've used you company before and received the same excellent service. Parts have always been in stock and the people always willing to provide expert information and data. Thanks again for the wonderful service


25
4060
Show More Reviews

See what our Experts say about this Kenda Trailer Tires and Wheels

  • Distance from Hub Face Surface to Edge of Rim and Tire on Kenda 215/60-8 Bias Trailer Tire # AM3H323
    I pulled a sample of this tire from our warehouse to take the measurements you need. From the rear rim surface that contacts the hub (near the bolt holes) to the innermost edge of the rim the distance is 4-inches. From that same point to the innermost edge of the tire the distance is 4-1/2-inches. The dimensions are noted on the linked photo.
    view full answer...
    Image 1 for
  • Smaller Trailer Tire Than 215/75R14 w/ 5 on 4-1/2" Bolt Pattern To FIt in Garage
    What tire size do you have now? What is your wheel bolt pattern?
    view full answer...
  • Recommended Wheel Tire Combo w/ Less then 18 Inch Diameter for Storing a Trailer
    The closest wheel tire combo we have to 18" in overall diameter without going over is the Kenda 165/65-8 Bias Trailer Tire item # AM3H220. It is 16-1/2", has a 8" white wheel, with a 5 on 4-1/2 lug pattern. This wheel tire combo has a 800 lbs capacity each so two of them will give you plenty of capacity for your 1,400 lbs trailer while sitting in storage.
    view full answer...
  • What Is The Smallest Available Radial Trailer Tire?
    We do have several 215/60-8 tires like the # AM3H323 but nothing in a radial. The smallest radial tire that we stock is a 145/80-12 in part # AM31202. This would be a fairly significant change in tire size. The 215/60-8 measure about 18.1" in diameter and 8.9" wide. The 145/80-12 measure about 21.3" diameter and 5.7" wide. It really comes down to how much clearance you have in your wheel well. Going to larger tires is possible, but we have to have at least 3" of clearance between the...
    view full answer...
  • Offset of 215/60-8 Tires and Wheel Combination
    Harbor Freight trailers have a bolt pattern of 4x101.6 (or 4 on 4 inch) or the 5 on 4-1/2 inch if you have 5 lugs. . The 225 x 8 isn't a size we carry, but we do have the Kenda 215/60-8 Bias Trailer Tire with 8" White Wheel - 4 on 4 - Load Range C # AM3H290 which have a zero offset. This will give you 4.45 inches of backspacing since the tires are 8.9 inches wide. The same is true of the 5 lug wheel and tire # AM3H310.
    view full answer...
    Image 1 for
  • Tire Options To Replace 18.5x8.5-8 Tire On 2004 Floe Trailer
    The best option for your 2004 Floe Trailer made for 18.5/8.5-8 Tires is the Kenda K389 Hole-N-1 Bias Golf Cart Tire - 18x8.50-8 - Load Range B # AM40537. This tire is the exact same width as the tire your trailer was designed for, but will be right at 1/2" an inch shorter. The # AM40537 has a load rating of 815lbs at 22 PSI, and has a speed rating of 65 MPH. I included a video of the # AM40537 for you to take a look at.
    view full answer...
  • Recommended Wheel and Tire Combo w/ a 5 on 4-1/2 Lug Pattern that is 16" Tall
    Hey Don! The closest wheel tire combo we have to 16" tall is the Kenda 165/65-8 Bias Trailer Tire item # AM3H220. It is 16-1/2" tall, has a 8" white wheel, with a 5 on 4-1/2 lug pattern.
    view full answer...
  • Replacement Tire for a 18.5-8.5-8 Tire
    Based on the tire info sticker that you attached it looks like you are looking for a replacement tire for your 18.5-8.5-8 tire size. The 18.5-8.5-8 tire has an overall diameter of 18.5 inches, an overall width of 8.5 inches and fits an 8 inch diameter wheel. The closest size tire I would have is the 215/60-8 bias tire. It will have an overall diameter of 18.1 inches and an overall width of 8.9 inches. You will want to check to make sure you will have the clearance for the extra width. For...
    view full answer...
    Image 1 for
  • Recommended Tires And Wheels To Replace 18.5/8.5-8 Tires On Triton Trailer
    The tire size you can use as a replacement for your triton trailer is a 215/60-8. If you want just the tire, I recommend part # AM1HP28 which is a Load Range D tire. This 8-ply tire has a load capacity of 1,165 lbs at 70 psi. For a Load Range C tire only I recommend part # AM1HP26. This is a 6-ply tire and has a maximum load rating of 935 lbs at 50 psi. Both of these tires are bias-ply tires and will work on the rims you have for your tires. If you are looking for a wheel/tire combo...
    view full answer...
  • Can 5.70-8 Tire/Wheel Combo Be Replaced With 215/60-8 Combo On Small Trailer
    I do not think the diameter of the tire will pose any problem since a 215/60-8 tire is only about .20 of an inch bigger diameter. The problem you may have is the width of the rim. the width of a rim for the 5.70-8 wheel is 3-3/4 inches and the width of a rim for the 215/60-8 tire is 7 inches. The additional 3 plus inches may cause issues for clearance on the fenders and also on the inside of the wheel well. You may want to check the clearance you have with the smaller tires to be sure....
    view full answer...
  • Could the Kenda 215/60-8 Bias Trailer Tire with 8" White Wheel AM3H323 Replace 7.50x8 Wheel/Tire
    That tire size is not a standard trailer tire size so the best solution we can offer would be to replace the wheel and tire with something that would fit. If you can give me the width, diameter and bolt pattern of your current wheels I can get you the closest match we offer. The part # AM3H323 that you referenced has a 5 on 4-1/2 inch bolt pattern, a tire section width of 8.9 inches and an outer diameter of 18.1 inches.
    view full answer...
  • Will an 8 Inch Trailer Wheel Fit on Hubs for a 3,500 Pound Axle
    Are you using hub and drum assemblies or just regular hubs? If you are using hub and drum assemblies then to fit an 8 inch wheel they would have to be very small. We have just one hub and drum assembly that fits 8 inch wheels, # 8-271-7UC3-EZ, and it is for 2,000 pound EZ lube axles. Hub and drum assemblies for 3,500 pound axles are going to require 13 inch or larger wheels. It sounds like you are wanted to use an alternate tire size which requires a smaller wheel than what the hubs are...
    view full answer...
  • Does the Center Pilot Hole of a Trailer Wheel have to be Exact
    Not exactly. A Pilot hole that is 2.80 inches is going to be 0.05 inches larger than a 2-3/4 inch pilot hole. But the only way to get that accurate of a measurement is to use dial or digital calipers. If you measure with a ruler or tape measure you will not be able to get the most accurate measurement. Another issue is that some times the pilot hole dimension does not even matter. If the wheel attaches to the hub using lug nuts then the pilot hole can be larger, just not any smaller. If...
    view full answer...
  • Does 8" Trailer Tire Need to be Upgraded for Safe Travel on a Long Highway Trip
    Hey Scott, thanks for reaching out! A common misconception is that bigger tires/wheels means they are better. While bigger tires can generally handle more weight, as long as a tire isn't being overloaded or the max speed is exceeded then the tire will be perfectly safe to use. We've actually had instances where using a larger tire/wheel just causes a bigger headache because then you might have to deal with a different bolt pattern, larger hub size, or even the tire being too wide for...
    view full answer...
  • Replacement 5.70-8 Tires for a Taylor Dunn B36 Electric Industrial Cart
    If you just wanted to get the tires and not replace the wheels you can use # AM10013. This is a 5.70-8 tire, load range D, with a capacity of 1,075 pounds at 100 psi. Four of these will have a capacity of 4,300 pounds so they can handle the 3500 pound total of the cart when fully loaded. Trailer tires should always be inflated to the maximum psi indicated on the tire. This is because trailer tires are built with a thicker sidewall to handle more vertical load. If the tires were on a trailer...
    view full answer...
  • Recommeded High Load Capacity Tire For Triton 4 Place Snowmobile Trailer
    For your Triton 4 place snowmobile trailer, I recommend using the Kenda 215/60-8 Bias Trailer Tire with 8" White Wheel - 5 on 4-1/2 - Load Range D, # AM3H323. This tire and wheel combination has a maximum load of 1165 lbs at 70 psi. If you just want the tire, I recommend the Loadstar K399 Bias Trailer Tire - 215/60-8 - Load Range C, # AM1HP26, which has a load range c with a maximum load of 935 at 50 psi.
    view full answer...
  • Comparing 215/60-8 Tires to 18.5/8.5-8 Tires for Height and Width
    The 215/60-8 tires like # AM1HP26 should have a diameter of 18.2 inches and a width of 8.5 inches so they should be the same width and yet slightly smaller diameter. If you just go by the definitions these tires should be really similar with the 18.5/8.5-8. There is some variance in sizes depending on manufacturer as some take more liberties than others for instance the Kenda 215/60-8 Bias Trailer Tire with 8" White Wheel - 5 on 4-1/2 - Load Range D # AM3H323 has an outer diameter of...
    view full answer...
  • Recommended Axle with Hubs and Wheel/Tires for Old Trailer
    The pilot hole size is what makes the wheels difficult to match. We have a few options for 5 lug wheels but they all have the 2.81 inch pilot hole in the center. I recommend changing out your axle as you stated to the Dexter Idler Trailer Axle w/ Hubs - EZ-Lube - 5 on 4-1/2 Bolt Pattern - 60" Long - 2,200 lbs # 20545I-EZ-60-10. This has 48 inch on center spring seats. It also has the hub assemblies and spindles with the EZ-Lube for easy maintenance. Then I recommend the Kenda 215/60-8...
    view full answer...
  • How to Determine Clearance of Kenda 215/60-8 Tires on Taylor-Dunn B48 Industrial Cart
    The Kenda 215/60-8 Bias Trailer Tire with 8" White Wheel # AM3H323 has an overall diameter of 18.1" and a section width of 8.9". I'm not sure what kind of clearance you have but the 8" white wheel has a zero offset so you just cut the width in half (4.45") and then measure from where the wheel mounts on your hub to see if you have enough room. I have attached a review video for you to check out as well.
    view full answer...
  • Torque Rating for Trailer Wheel Lug Nuts
    Thanks for ordering with us! I see that you purchased the Kenda 215/60-8 Tire/Wheel Combo, # AM3H323. The torque rating for lug nuts on trailer wheels varies depending on the stud size, lug nut type, wheel size and wheel composition. I've attached a chart that shows standard lug nut torque specs. As you can see on the attached chart, the recommended torque specifications for 1/2" wheel studs and an 8" wheel, like yours, is 75-85 ft-lb. Even though they are starting to feel tight at 60...
    view full answer...
  • Does Maximum Load Listing for Trailer Tire Refer to Individual Tire
    You are correct - the Kenda 215/60-8 Bias Trailer Tire with 8 Inch White Wheel # AM3H323 referenced in your question has a maximum load of 1,165 pounds at 70 psi. This maximum load refers to a single tire. If you have four tires on your trailer, they will have a combined maximum load of 4,660 pounds (1,165 x 4). This will be the same for any trailer tire you look at. To determine the combined capacity of the tires, you will simply multiply its maximum load by the amount of tires you have...
    view full answer...
  • Difference Between Bias Ply And Radial Ply Trailer Tires And What Does Load Range Mean
    The main difference between bias ply and radial ply tire is how the tire is constructed. The cords underneath the tire are run in different directions. On a bias tire, the cords run at a 32 degree angle from the direction of travel and on a radial tire, the cords will run at 90 degrees from direction of travel, or across the tire from wheel lip to wheel lip. Because of the construction of a radial tire, the tire has more flex and will allow for more ground contact. That will improve traction...
    view full answer...
  • What Does Ply Rating Mean on ST Trailer Tires?
    The ply rating has to do with the thickness of the tire and the load capacity will increase based on the ply rating. The information below tells you the ply rating and general load pressure (in psi units) determined by the manufacturer testing: Load Range B: 4 Ply Rating, ~35 psi Load Range C: 6 Ply Rating, ~50 psi Load Range D: 8 Ply Rating, ~65 psi Load Range E: 10 Ply Rating, ~80 psi Load Range F: 12 Ply Rating, ~95 to 110 psi Load Range G: 14 Ply Rating, ~110 psi The Kenda 215/60-8...
    view full answer...
  • Recommended Spare Tire Carrier For 8-Inch Wheel With 5 On 4-1/2 Bolt Pattern
    The spare tire carrier I recommend is the Fulton Hi-Mount Spare Tire Carrier, part # FHDSTC0101. This carrier will work with the 5 on 4-1/2 bolt pattern of the # AM3H323 tire and wheel combo. This carrier will work with trailer frames 3-inch wide x 5-inch high.
    view full answer...
