Loadstar 4.80-12 Bias Trailer Tire with 12" Galvanized Wheel - 5 on 4-1/2 - Load Range C

Loadstar 4.80-12 Bias Trailer Tire with 12" Galvanized Wheel - 5 on 4-1/2 - Load Range C

Item # AM30670
lowest price pledge
Retail:$122.08
Our Price: $94.37
You Save: 23%
Trailer Tires and Wheels
Orders above $99 qualify for Free Shipping
Shipping Weight: 18 lbs
Quantity:
In Stock
AM30670 - Steel Wheels - Galvanized,Boat Trailer Wheels Kenda Tire with Wheel
zoom in icon
slider vertical icon
zoom out icon
Comment field cannot be left empty.
Name field cannot be left empty.

Thank you! Your comment has been submitted successfully. You should be able to view your question/comment here within a few days.

Error submitting comment. Please try again momentarily.

Product Images

Customer Photos

Videos

Is this right for you? Product Expert Mary E says:

Yes, if you:

  • Have a boat trailer and need a rust-resistant finish
  • Tow off-road most of the time or for shorter distances

No, if you:

  • Travel long distances on the highway
Bias tire has a ply rating of 6 and a 990-lb maximum load at 90 psi. The 12" diameter x 4" wide steel trailer wheel features a 5 on 4-1/2 bolt pattern and a corrosion-resistant galvanized finish. Lowest Prices for the best trailer tires and wheels from Kenda. Loadstar 4.80-12 Bias Trailer Tire with 12" Galvanized Wheel - 5 on 4-1/2 - Load Range C part number AM30670 can be ordered online at etrailer.com or call 800-298-8924 for expert service.
  • All Info
  • Reviews (2838)
  • Q & A (45)
  • Photos
  • Why etrailer?

Kenda Trailer Tires and Wheels - AM30670

  • Tire with Wheel
  • 12 Inch
  • 5 on 4-1/2 Inch
  • 4.80-12
  • Load Range C
  • Steel Wheels - Galvanized
  • Boat Trailer Wheels
  • Bias Ply Tire
  • Kenda
  • Good Rust Resistance

Bias tire has a ply rating of 6 and a 990-lb maximum load at 90 psi. The 12" diameter x 4" wide steel trailer wheel features a 5 on 4-1/2 bolt pattern and a corrosion-resistant galvanized finish.


Features:

  • The Loadstar trailer tire is designed for excellent handling at high speeds
  • 8-Spoke steel wheel is galvanized to resist rust
  • Tire-and-wheel assembly meets Department of Transportation specifications


Specs:

  • Rim dimensions: 12" diameter x 4" wide
  • Bolt pattern: 5 on 4-1/2"
  • Wheel capacity: 1,250 lbs
  • Wheel bolt size: 1/2"-20
  • Pilot diameter: 3.19"
  • Tire size: 4.80-12
    • Section width: 4.9"
    • Outer diameter (when inflated): 20.7"
  • Tire capacity:
    • Load range: C
    • Ply rating: 6
    • Maximum load: 990 lbs at 90 psi
  • Warranty:
    • 5-Year on tire
    • Limited 2-year on wheel


1-Year Worry-Free Guarantee

This tire has a 1-year worry-free guarantee. If within the first 12 months the tire is damaged in any way, it will be replaced at no charge.


Bias Tires vs. Radial Tires

Bias vs. radial tire graphic

Bias ply tires are designed for off-road or agricultural applications. They are built with thick, durable nylon cords that are positioned at a 30- to 45-degree angle to the direction of travel. The layers alternate in a crisscross pattern, making the sidewalls stiffer so that the entire tire is able to flex easily. As a result, the tire provides a smooth ride and improved handling when trailering on uneven surfaces.


Determining the Bolt Pattern

The first number in the bolt pattern is the number of bolt holes. The second number denotes the diameter, in inches, of the circle on which the bolt holes sit.

Bolt Pattern - Odd

To determine the bolt-circle diameter on wheels with an odd number of bolt holes, measure from the center of any bolt hole to the point halfway between the two bolt holes directly across from the first. (Example: "5 on 4-1/2" means 5 bolt holes with 4-1/2" measured to a point halfway between the opposite bolt holes.)

Bolt Pattern - Even

On wheels with an even number of bolt holes, measure from the center of one bolt hole to the center of the hole directly across from it. (Example: "8 on 6-1/2" means 8 bolt holes with 6-1/2" from the center of one hole to the center of another on the opposite side.)

Bolt Pattern - Side

Measuring the distance from the center of one bolt hole on the wheel to the center of a bolt hole right next to it can also help to determine the bolt pattern.

  • If D = 2-5/8", then the bolt pattern is 5 on 4-1/2"
  • If D = 2-3/4", then the bolt pattern is 5 on 4-3/4"
  • If D = 3", then the bolt pattern is 5 on 5"
  • If D = 3-1/4", then the bolt pattern is 5 on 5-1/2"




30670 8-Spoke 12" Galvanized Wheel and Loadstar K353 Bias Tire - LR C






Customer Reviews

Loadstar 4.80-12 Bias Trailer Tire with 12" Galvanized Wheel - 5 on 4-1/2 - Load Range C - AM30670

Average Customer Rating:  4.9 out of 5 stars   (2836 Customer Reviews)

Bias tire has a ply rating of 6 and a 990-lb maximum load at 90 psi. The 12" diameter x 4" wide steel trailer wheel features a 5 on 4-1/2 bolt pattern and a corrosion-resistant galvanized finish.

- AM30670
by:

I bought the spare tire, mount and cover cheaper than I could purchase just the exact same tire somewhere else. I received the tire and it was very easy to mount to my trailer and the cover made it look very professional. Would highly recommend. 275027



- AM30670
by:

etrailer has performed to 110% of everything I have ordered from them. I am so impressed and thankful they do what they say. I bought a hitch and wiring harness for my Acura to tow a jet ski.. possibly a questionable idea... NOPE! super fast install and everything worked exceptionally well. Then I wanted to update my trailer tires and wheels.. value, shipping speed and selection as well as delivery 110% perfect. wheel galvanizing was high quality, tires high quality and inflated properly. Didn't think I would get excited about opening my wheels and tires. Thank you to the team at etrailer. NICE WORK 211322


Comments
After a year, all is very good. no changes in my opinion.
Nick W - 07/12/2016

19327

- AM30670
by:

We ordered 3 boat trailer tires from ETrailer. Quick shipping and free shipping too! Just what we wanted. Great company to deal with. They were not in stock when we ordered. They emailed and called us to let us know. And they were still shipped QUICK! We’ll definitely order from here again 566688



- AM30670
by:

Excellent Service-Easy to install-Looks great. Thanks 609175



- AM30670
by:

Wow. Fast shipping. Awesome products, great prices, and perfect communication. Finally an online store that goes beyond the basics. etrailer.com gives you all the search options needed to make a smart purchase. Was so impressed I made another order for more products. I WILL continue to use etrailer.com for all my needs that they carry/sell. Couldn't be happier. Thanks so much. 575259



- AM30670
by:

I had originally found a wheel/tire option on Amazon but elected to go with eTrailer b/c I was not comfortable with purchasing through a 3rd party merchant -- I have had trouble if any issue is encountered. My wheels from eTrailer showed up in a sturdy box and were ready to mount. Very satisfied with overall purchase experience. The wheels are used for my small Yacht Club trailer that holds my 2006 SeaDoo GTX. For the price, you can't go wrong. Some people have reviewed the wheels as being a bit scuffed (as in not immaculately polished). I kind of chuckled a bit when reading those. Folks - you are getting 2 wheels + tires shipped to your door for ~$100 all-in. That is an insane value. My wheels were also not perfectly polished...but I was 100% ok with that. 358939



- AM30670
by:

The newly purchased Loadstar 4.80-12 tires and Galvanized rims also new fenders from etrailer make my snowmobile trailer pretty sharp.. 714456



- AM30670
by:

I am more than happy with this purchase. The price was unbeatable. I feel much safer and secure towing my boat on the freeway at high speeds for long distances with these tires and wheels. Shipping was extremely fast,and communication was excellent. I highly recommend these as an upgrade to any smaller trailer. Before and after pic's. 14' G3 jon boat 18 hp Nissan/Tohatsu 520901



- AM30670
by:

I needed a spare for my boat trailer. I got exactly what I needed, and on time. Thank you. 875254



- AM30670
by:

I like etrailer, good prices and fast shipping. This time the box was busted and a nut and bolt for the trailer Jack was missing. Luckily I have a bolt bin with spares. 874493



- AM30670
by:

A+++++ Great web page with all products well organized and easy to navigate thru. Excellent tutorials for your products way to go in this digital era. Easy purchase, fast delivery, good products with compatible prices. Your order follow up excellent. I can say enough all pertinent information well displayed and well organized. Other companies should follow you guys as a template. Good doing business with you, I recommend your services to anyone I feel that I got great value for my money, thank you. 864747



- AM30670
by:

Great durability! These wheels and tires work great hauling my trailer with my 1,000 lbs. jet ski. 864520



- AM30670
by:

So far, so good. TIres and wheels bolted onto jetski trailer with no problems. Towed trailer to vacation lake house and back, then from SF Bay Area to Boise, ID. 860941



- AM30670
by:

Great price, fast shipping, tire and rim are in excellent shape. 855862



- AM30670
by:

I bought these wheels to replace the original wheels on my Honda jet ski trailer. They were delivered on time, ready to install. I had both of them on the trailer in about 30 minutes. I bought them because of the stainless steel rims as my old wheels were rusting. I had one question prior to buying, but eTrailer customer service answered it quickly. This is the 3rd time I’ve bought a product from eTrailer and all of them have been exactly what they were advertised to be. Good company to buy from. Fair pricing. Will definitely buy from eTrailer again. 852417



- AM30670
by:

I just received the wheel in the mail and it appears to be just as stated. Good looking, clean and in good condition. 845943



- AM30670
by:

I purchased the Kendra 6ply tires to replace the ones I had been getting at Walmart. manner and fit right on my trailer.. These tires are far superior to those. I am still using them after a year. I expect another year out of them. They arrived in a timely manner. Needless to say, I will be buying more of them in the future. The price is excellent for a set also. 845743



- AM30670
by:

Ordering process was easy, communication was great, and I received my order in 6 business days. Great service! I would definitely order again. Thank you. 840120



- AM30670
by:

Just what I ordered 832786



- AM30670
by:

I recently purchased this spare tire/wheel combo for my new continental trailer that carries my PWC. It matched perfectly however the mounting bracket could include a filler plate for the smaller PWC trailers to mount. I used a small piece of wood as filler and will replace with a metal bracket. 831033



- AM30670
by:

Fast delivery, good quality tire.. Fits perfect. 828709



- AM30670
by:

I bought this tire as a spare and it fit as described. Good quality tire for the price. 828375



- AM30670
by:

I needed to replace the rims/tires for my Triton LT wave runner trailer and had trouble finding what I needed until I found these on etrailer.com. Exactly what I was looking for and needed. Ordering was easy and they were delivered pretty quickly. Overall very pleased with everything and really happy I have a good set of tires now for the trailer now! 818408



- AM30670
by:

Excellent service with no surprises. Product came in as advertised with good fit and hassle free installation; just the air pressure between the two wheels delivered were off by 4 lbs. from each other. 805829



- AM30670
by:

The tires were exactly as described. Received shipment in a very timely manner. Would recommend to anyone. 799162


31
2905
Show More Reviews

Ask the Experts about this Kenda Trailer Tires and Wheels

  • Comparison of Two Kenda Tire and Wheel Combos Part # AM30670 and # AM30790
    Both tires # AM30670 and # AM30790 are Kenda tires but there are a number of differences. For starters they're different sized tires. The # AM30670 is a 4.80-12 sized tire and # AM30790 is a larger 5.30-12 sized tire. The latter being about 3/4 of an inch wider and over an inch larger in diameter. Also, they both have a C Load Range but the larger # AM30790 has a higher weight capacity at 1,045 pounds when inflated to 80 psi. The # AM30670 is rated up to 990 pounds at 90 psi. With...
    view full answer...
  • Spare Tire and Wheel for Trailer with Kenda 4.80-12 Bias Tires
    The Kenda Loadstar 4.80-12 Bias Trailer Tire with 12" Galvanized Wheel # AM30670 that you referenced will work perfectly as a spare for your trailer. The important info you need when picking out a spare or replacement is the tire size, load range, and bolt pattern on the wheel so you can be sure it will fit your hub. This bias tire matches the size (4.80-12), Load Range (Load Range C of 990 pounds at 90 psi) and the 5 on 4-1/2 inch bolt pattern on your current tire/wheel as pictured....
    view full answer...
  • Recommended 4.80-12 Trailer Tire for Higher Speed Driving
    All of our 4.80-12 size trailer tires and tires-with-wheels are shown on the linked page. For higher-speed highway travel I suggest the 81-mph-rated Load Range C Tasksmaster tire # TTWSF48012C which is rated to carry 990-lbs at 90 psi. Always run your trailer tires at the full psi pressure noted on the tire sidewall. It is never appropriate to under- or over-inflate a trailer tire as doing so reduces its load capacity and increases chances for heat-related failure.
    view full answer...
  • Comparing Two Tires of the Same Size For Spare Tire Use
    When comparing two tires, what really matters is the size, bolt pattern of the wheel, speed rating and load range are the same. The DOT code is a date of manufacturer code so that isn't going to matter as much. If both the stock and spare tire are 4.80-12 Load Range C tires then they are the same size so there will not be a difference there. You want to make sure both wheels have the same bolt pattern to fit the trailer. The only Loadstar 4.80-12 Bias Trailer Tire we carry is part #...
    view full answer...
  • What Tire Pressure Should Trailer with 12 inch Wheels be Ran At
    With trailer tires like # AM30670 you have to run the max tire pressure rating that's on the sidewall of the trailer. This ensures you get the full weight capacity of the tire and also that you prevent any heat build up which also leads to premature tire failure. Trailer suspension by nature is a bit bouncier than vehicle suspension since there isn't a shock there to dampen the movement of it.
    view full answer...
  • Can Tire Pressure be Lowered on Motorcycle Trailer to Provide a Better Ride
    You always want to keep your trailer tires psi set to what is recommended. If the psi is higher or lower then the tire will not perform as the manufacturer states. For instance, the Kenda # AM30670 is rated for 990 lbs at 90 psi. If we were to deflate the tires at all then the 990 lbs capacity that Kenda says the tire can handle will not be the case anymore. Underinflated tires are more prone to overheating and tire failure as well. I strongly advise against lowering the psi.
    view full answer...
  • Recommend Replacement Spare Tire and Galvanized Wheel For Karavan Trailer Tire ST 185/80D13
    For a spare tire and wheel in a 13 inch size that matches your tire size, we have the Kenda Tire and Wheel, part # AM3S334, which is a ST 185/80-D13. You will want to measure the bolt pattern of your trailer wheels to make sure part # AM3S334 has the same bolt pattern (see FAQ). Part # AM3S334 has 5 on 4-1/2 bolt pattern. Trailer tires should be inflated to their maximum indicated PSI Rating as stated on the tire, for best performance and longer life of the tire. I have linked...
    view full answer...
  • Can Trailer Tire Size of 20.5x8-10 be Replaced with 4.80-12
    The two sizes you mentioned have the exact same diameter of 20.5 inches. The biggest difference is that the 12 inch size you are considering of 4.80-12 is much narrower at 4.9 inches compared to 8.4. Clearance wise you'd not have any problems at all. If you have a 5 lug bolt pattern you'd need the part # AM30670 or if you have a 4 lug pattern you'd need the # AM30630.
    view full answer...
  • Choosing a Spare Tire and Wheel for a Jet Ski Triton Trailer
    You are on the right track. Either the # AM30660 or the # AM30670 would work fine for you. The AM30660 features a white powder coat finish, while the AM30670 has a galvanized finish. It would be up to your individual preference as to which wheel is better for you. The 3.19 pilot diameter refers to the hole in the center of the wheel that the hub grease cap passes through. The section width refers to the distance from the widest point of the outer sidewall to the widest point of its inner...
    view full answer...
  • Recommend Replacement Spare Tire and Galvanized Wheel For Karavan Trailer Tire ST 175/80D13
    If you have a 5 on 4-1/2 inch bolt pattern you would want a Karrier ST175/80D13 Tire and Wheel part # AM31242, if you have a 4 on 4 inch bolt pattern you would want a Loadstar ST175/80D13 Bias Trailer Tire with 13 inch Galvanized Wheel part # AM3S130.
    view full answer...
  • Kenda LoadStar Tires to Replace OEM Tires on Malone MicroSport Trailer MPG460G
    Malone specifies 12-inch 5-lug galvanized wheels/tires on their MicroSport Trailer # MPG460G. The Kenda LoadStar 4.80-12 bias ply trailer wheel/tire # AM30670 will work fine as a replacement since these have a 990-lb weight capacity per tire at their rated inflation pressure of 90-psi. This is more than enough for the trailer's GVWR.
    view full answer...
  • Galvanized Wheel and Bias Ply Tire Combination for Use on Jet Ski Trailer
    We can offer you many options in a 4.80-12 trailer wheel and tire. All wheel/tire options in this size are shown on the linked page. We have galvanized wheels in two bolt patterns, 4-on-4 and 5-on-4-1/2, and all are mated to a bias ply tire in either Load Range B or Load Range C. Just click on your bolt pattern to see just the wheel/tire items that will work on your hubs. For example, part # AM30670 is a Load Range C tire (that handles up to 990-lbs at 90-psi pressure) mated to a...
    view full answer...
  • Correct Inflation Pressure for Trailer 4.80-12 Trailer Tires
    Tire size 4.80-12 is not found on vehicles, but is a common trailer tire size on smaller utility- and sport-type trailers. In trailer use you do want to inflate them to the maximum cold psi pressure noted on the tire sidewall. Trailer tires should never be under- or over-inflated since they can deliver their rated weight-carrying capacity only when inflated to their specified pressure. Incorrect inflation can lead to excessive heat which is the main cause for tire failure. All of our...
    view full answer...
  • What are Limitations When Upgrading to Larger Tires?
    Should you want to upgrade the size of your wheels and tires you can, you'll only need to determine how much available space you have and pick a wheel and tire combination that will fit. You are also going to need wheels with the same bolt pattern; I've added a link to a help article that explains how to determine bolt pattern. I have also attached a link to each of our available wheels and tires for you to take a look at.
    view full answer...
  • What is the Max Tire Pressure for the Kenda Loadstar Tire
    No matter what trailer tire you are using, including the Kenda Loadstar # AM30670, you need to keep the cold psi rating to the what the manufacturer recommends. When you are over or under the recommended pressure then you can cause excessive heat build-up which results in a blowout. Even if it feels like the 990 lbs at 90 psi weight capacity seems like overkill for your trailer this is the best way to maintain your trailer tires. You should be able to find the 90 psi rating somewhere...
    view full answer...
  • Can Trailer Tire Size 20.5x8-10 Replace Tire Size 5.30-12
    The difference in size is not drastic enough to prevent one from fitting in place of the other. The diameters are within 1.4 inches of being the same so as long as you match the bolt pattern and the frame is rubbing like you mentioned you'd be fine. For the wider 20.5 x 8 -10 we have the part # AM3H490 for if you have a 5 lug bolt pattern or part # AM3H440 for a 4 lug pattern. We don't carry the exact tire you mentioned.
    view full answer...
  • Best 480.12 Boat Trailer Tire and Wheel Combo
    I definitely recommend the Kenda brand because it is a time tested industry leader. I would go with one of the model tires listed below depending on your load range which is listed after the number (12) on your tires. Your load range is either (B or C) for this size tire. When you're ready for some new wheels, you'll need a 5 on 4-1/2 bolt pattern. The only 5 bolt pattern that is offered for this wheel size is 5 on 4-1/2. Kenda K353 Bias Trailer Tire - 4.80-12 - Load Range B # AM10060...
    view full answer...
  • Lug Nut Compatibility with Kenda 4.80-12 Bias Trailer Tire/Wheel AM30670
    Since the Kenda 4.80-12 Bias Trailer Tire with 12-Inch Galvanized Wheel # AM30670 has a steel wheel, you can use standard lug nuts # CE11051 that you referenced. These are 60-dgree coned nuts that fit the same 1/2-inch wheel bolts as those used by the Kenda wheel/tire.
    view full answer...
  • Replacement Tire and Wheel Combo with 175/80-13 Tires on a 1993 StarCraft Starstream
    The 5 on 4-1/2 indicates the bolt pattern of the wheel. It has 5 holes that are centered on a 4-1/2 inch diameter circle. Take a look at the help article I linked that explains bolt pattern. I have also included a link to the tires and tire and wheel combos with ST175/80-13 tires. Check the tires on the trailer or the manual for the load range/capacity that you need to be sure you get some that are rated high enough. Tire and wheel combo # AM32001HWTB would look great on the trailer....
    view full answer...
  • Replacement Trailer Spare for Tire Size 4.80-12
    The tire diameters are very different between the two sizes. The bigger size you have now of 4.80-12 is overall 20.5 inches tall and the older size 4.80-8 is 16.1 inches. Since that difference is split between either side of the spindle you'd have one side of the trailer sitting 2.2 inches taller than the other. In a very short-term emergency situation you could probably limp home with that but I would highly recommend matching the larger tire size for a spare with something like the...
    view full answer...
  • Troubleshooting Tire Wear Down Middle of Tread on Trailer
    Generally speaking, a trailer tire will wear in the middle of the tread when it is over-inflated, however that does not appear to be the case with the tires on your trailer. With that being said, I do not recommend lowering the pressure on the tires to below the maximum psi recommended on the sidewall. Doing this will essentially lower the tire's load capacity to an unknown number, which may lead to you overloading them and causing further damage to the tires and trailer. A trailer tire...
    view full answer...
  • Can 4.8-12 Tire Size Fit on Wheel that Had 4.8-8 Tire
    The numbers at the end of the two trailer tire sizes you mentioned are the wheel size they are intended to fit so what you are wanting to do is not possible. The size 4.8-12 is for a 12 inch wheel and the 4.8-8 is for an 8 inch wheel. So to go to the 4.8-12 size you'd need a wheel and tire combo like the part # AM30670 for if you have a 5 lug bolt pattern or # AM30630 for if you have a 4 lug bolt pattern.
    view full answer...
  • Thinner Replacement Trailer Tires to Replace 20.5 x 8 - 10 Sized Tires
    Your 20.5 x 8-10 sized tires are the same as a 205/65-10 sized tire using new measuring. The rims are 6 inches wide. A replacement size that's the same 20.5 inch diameter are 4.80-12 sized tires but the weight capacity is much lower. For example the Kenda # AM30670 is rated for 990 pounds at 90 psi. Your current tires are likely rated higher. The rim is 4 inches wide. If you have the clearance to go with a larger diameter tire you may be able to use size 145/80-12 which also use...
    view full answer...
  • Can I Use Smaller Tires and Wheels to Lower Trailer for Storage
    I looked at tire options and basically anything that would fit your current rims would have a height of 23 inches or greater. You could change to a 12 inch rim so long as you do not use them for towing (unless they accommodate your weight capacity). Your weight capacity is not as important for storage. Depending on your bolt pattern, you have the following options: 1. Loadstar 4.80-12 Bias Trailer Tire with 12" Galvanized Wheel - 5 on 4-1/2 - Load Range C Item # AM30670. Bias special...
    view full answer...
  • Is It Okay If Trailer Weighs Exactly 2,100 lbs When Loaded and it has Tire Capacity of 2,100
    If you are absolutely certain that your trailer when loaded would not exceed 2,100 lbs then you wouldn't need to worry as you should be fine. I would strongly recommend you keep your tires inflated to their maximum psi though. If a trailer tire is inflated to a lower air pressure than the maximum, the amount of weight that the tire can carry will be reduced. If a heavier load is put on the trailer tire than what is recommended for that air pressure, the sidewall of the tire could...
    view full answer...
  • Recommended PSI for 12x4 Tires
    It is recommended that tires always be inflated to the max psi, which should be listed on the sidewall of the tire. The psi ratings for two tires of the same size will differ based on each tire's load range. For instance, a Kenda 4.80-12 tire, such as Item # AM30670, is a load range C tire with a capacity of 990 lbs at 90 psi. However, the same size tire at load range B, such as Item # AM30590, has a capacity of 785 lbs at 60 psi. Different tire manufacturers may also have different psi...
    view full answer...
  • Rim Size Compatibility for Trailer Tire Size 4.80-12
    A 4.80-12 size tire will only fit on a 12 x 4-inch rim such as the one in wheel/tire part # AM30670 and wheel # AM22319HWTB. The smaller tire size 4.80-8 like item # AM10002 that you referenced will fit an 8 x 3-3/4-inch wide rim but again not a 12 x 3-inch one. You may care to check out the two linked articles on trailer tires for more information about tire and wheel compatibility. Do please note that a trailer wheel is measured from bead seat to bead seat, not edge to edge. You...
    view full answer...
  • How to Determine if ST185/80D13 Trailer Tire Will Fit on Trailer With 4.80-12 Tires
    You have already done most of the work in regards to knowing your bolt pattern and the Loadstar ST185/80D13 Bias Trailer Tire with 13" Galvanized Wheel # AM3S334 does have a 5 on 4-1/2" bolt pattern so the wheel is going to fit. Since you mentioned you have a 4.80-12 tire and wheel - like the Loadstar # # AM30670, for example - I can tell you that tire and wheel measures 20.7" in diameter and 4.9" wide while the trailer tire and wheel you asked about, the # AM3S334, measures 24.4" in...
    view full answer...
  • 4.80-12 Trailer Wheel/Tire Weight Differences Based on Wheel Material
    The Kenda 4.80-12 wheel/tire combination item # AM30679 weighs about 17-lbs while the same tire size on a galvanized steel wheel, part # AM30670, weighs about 2-lbs more. The tire's own weight capacity on both of these products is 990-lbs, but the wheels alone each have higher (but different) weight ratings; 1520-lbs for the aluminum wheel and 1250-lbs for the galvanized steel wheel. With both products the tire's 990-lb rating becomes the overall rating for the combination. I linked...
    view full answer...
  • Best 12 Inch Galvanized Tires and Rims for Small Boat Trailer
    A radial tire flexes more than a bias tire, giving it better ground contact, traction, stability, and tread wear. Radial tires generally run cooler than bias tires, which usually leads to a longer life for radials. I would recommend going with a radial tire if possible, but provided you heed limits such as load range and psi, a bias tire will also work. We currently offer three different tire sizes that have 12 inch diameters and galvanized 5-lug rims. You can check your current tires to...
    view full answer...

Do you have a question about this Trailer Tires and Wheel?




  • Why etrailer.com?

    At etrailer.com we guarantee:
  • Highest quality trailer tires and wheels for the best price.

    Our Lowest Price Pledge ensures you will never overpay for the parts you need.
  • Real product know-how.

    We make sure that the products we sell are what we say they are, and that they work the way they are supposed to work. Get real advice from a real person who has the knowledge and expertise needed to solve your problem.
  • Most detailed, accurate trailer tires and wheel information available.

    Because we take providing accurate product information seriously, we take our own detailed product photos, demo videos and installation videos, as well as verify measurements, instructions, and vehicle fit information.
  • Installations, made easy.

    We love helping people and have the most highly-trained customer service, hands-on experience, step by step videos and installation instructions.
  • Fast shipping.

    Your order is automatically routed to get out of our warehouse and to your door as quickly as possible. Receive free shipping on orders over $99.
  • Personalized service for life.

    We provide one-on-one, personalized service from the ordering process through the life of your product.
  • Trusted since 1946.

    We've been serving customers since our parts store first opened in 1946 and continue to be recognized by our customers, our vendors and third parties for exceptional service.
  • Returns Policy

    Need to return an item? No problem. Please read our Returns Policy for more information.

Info for this part was:

Expert Research:
Mike L
Expert Research:
Michael H
Expert Research:
Reno H
Expert Research:
Jameson C
Expert Research:
Adam R
Installed by:
Jeff D
Updated by:
Laura H
Updated by:
Mary E
Updated by:
Sarah W
Updated by:
Hannah L
Updated by:
Isabelle B

At etrailer.com we provide the best information available about the products we sell. We take the quality of our information seriously so that you can get the right part the first time. Let us know if anything is missing or if you have any questions.
