Ultra-Fab Ultra Scissor Jacks - 24" Lift - 6,500 lbs - Qty 2
(647 reviews)
Price: $121.31
Thank you! Your comment has been submitted successfully. You should be able to view your question/comment here within a few days.
Error submitting comment. Please try again momentarily.
- All Info
- Reviews (647)
- Q & A (0)
- Photos
Ultra-Fab Products Camper Jacks
- Fifth Wheel Camper
- Pop Up Camper
- RV Motorhome
- Teardrop Camper
- Travel Trailer
- Stabilizer Jacks
- Scissor Jack
- 6001 - 7000 lbs
- 2 Jacks
- 24 Inch Lift
- Ultra-Fab Products
- Bolt-On
- Weld-On
- Steel
This pair of scissor jacks can be either bolted or welded to the frame of your trailer or RV. Worm-gear mechanisms won't slip. Oversize footplates help to eliminate sinking and tilting.
Features:
- Scissor jacks level and stabilize 5th-wheel, travel, horse and cargo trailers
- Heavy-duty worm-gear jacking mechanisms prevent slippage
- Perfect for stabilizing loads
- Large footplates provide excellent stability
- Bolt-on or weld-on installation
- (2) 3" Wide x 10" long mounting plates have multiple holes to fit most applications
- Mounting hardware not included (3/8" bolt is recommended)
- E-Z crank handle included
- Sturdy steel construction
- Black powder coat finish resists corrosion
Specs:
- Quantity: 2 jacks
- Lift: 24"
- Collapsed height: 4-3/4"
- Collapsed length: 26"
- Support capacity per jack: 6,500 lbs
- Combined support capacity: 13,000 lbs
- Footplate dimensions: 4-1/2" wide x 9" long
- Mounting plates: 3-1/2" x 7-1/4"
- Lifetime warranty
Note: These jacks are designed to stabilize a portion of your trailer's weight, not to support the full GVWR of your trailer. Do not use these jacks to lift your trailer or RV. Doing so will exceed the capacity of these jacks.
48-979002 UltraFab Scissor Jacks - 24" - 2 Pack
Item # UF48-979002
Customer Satisfaction Score:
99% were satisfied with this product
1% of customers were not satisfied
- Wrong item was ordered
- Product did not meet expectations
- Arrived Damaged
Customer Reviews
Ultra-Fab Ultra Scissor Jacks - 24" Lift - 6,500 lbs - Qty 2 - UF48-979002
Average Customer Rating: 4.7 out of 5 stars (647 Customer Reviews)
This pair of scissor jacks can be either bolted or welded to the frame of your trailer or RV. Worm-gear mechanisms won't slip. Oversize footplates help to eliminate sinking and tilting.by: Biro07/03/2023
Great Addition to Flagstaff camper!!!!!Pop up camper came installed with only 2 stabilizers. We added these 2 to the front . We love the extra stability. Easy to install with self drilling/tapping hex head screws.
by: Bill D05/15/2023
I bought these two jacks for the rear of my Keystone Bullet. I had already purchased two and installed them on the front. The trailer seems more stable now, with not so much motion evident when moving about inside the trailer. No drilling was necessary. The jacks bolted on using the existing holes in the trailer (2016 Keystone Bullet 311BHS).
by: Steven11/08/2019
if I had to rate this upgrade in difficulty one being the easiest five being the hardest, it would be a one. Super simple. Take the nuts and bolts off your old hardware and install the upgrade in its place. I read some of the reviews were people were annoyed with the counter clockwise rotation and the bolt sticking out too far. I really didn’t see a problem with either. I know you’re not supposed to use a drill to extend and retract these but I always have. I suppose as long as you’re not torquing the heck out of the adjustment screw you shouldn’t have any problems. I always put a small flat 2 x 6 piece of wood under the foot of each one of these. It seems to add quite a bit of stability.
by: Thomas 06/14/2023
These scissor jacks work well. Installation was relatively easy, just had to drill a few holes. The only reason I'm giving 4 stars instead of 5 is that they turn counterclockwise to extend and all the other jacks of this type I've used turn clockwise. This isn't a huge deal but I didn't see anything in the description that mentioned the reversed threading.
by: Scott D.03/09/2016
The jacks themselves have worked great, they keep the trailer level and solid during our concession events. I just had them mounted to the trailer so I don't have to put them in and out at each event. The jack handles leave a bit to be desired so I use a 20v drill w/ a 3/4" socket to run them up and down.
by: Keith04/03/2023
Was a very simple unbolt old and install new. The mounting hole on the jacks matched up with the pattern on the jacks being replaced so there was no extra drilling required.
by: Brian05/16/2023
Bought these for my 2018 Rockwood Mini Lite 2506s to replace all 4 of my jacks. They were only 5000 lb jacks and were all bent up. These jacks are beefier and hold 1500 more lbs per jack. Bolts up perfectly in the same holes. Also the trailer feels more sturdy when they are all down.
by: Stacey 02/09/2023
Definitely a heavier duty version of our campers stock stabilizers. They bolted right up to the brackets and glad we have new stabilizers. I hope the paint lasts on these as that seems to be an issue with the other, cheaper stabilizers. Time will tell.
by: Bobby F02/02/2023
I have used these scissor jacks on a trailer stand hunting blind. Which is a top heavy situation. The jacks on all 4 corners of the trailer added a tremendous stable platform.
by: weszab01/17/2014
Easy to mount jack
Closes to a very small size
Load and unload without the trailer connected.
Weszab
1/17/2015
The jacks are still working great. Thanks again!
by: Patrick 10/11/2023
These appear to be exactly the same as the jacks on my camper. Very good quality.
by: Dave B.04/23/2014
eTrailer processed the order quickly and I had the jacks within 3 days....thank you eTrailer. They were really easy to install and operate flawlessly. I was concerned that they threading would be too fine and the jacks would take forever to raise and lower, but I was wrong. They operate smooth and fast with no issues.
If you need to stabilize the back end of your trailer I would certainly recommend these.
by: Anthony08/21/2023
Great, get 2 for price of one from local dealer
by: Harry06/03/2019
I purchased these stabilizers to replace the electric stabilizers on my 2017 Jayco. The electric stabilizers were terrible. They rusted in two years and didn’t do much to stabilize the camper. These new ones installed quickly and easily and I immediately noticed the difference. They arrived within 3 days of ordering.
by: Terrance 09/23/2023
Fast delivery and quality product.
by: Gary 08/30/2023
Fit perfect
by: Karen 07/31/2023
Easy to install, and work better than the original jacls
by: Michelle 11/23/2022
We installed the scissor jacks last year. One was in one direction and the other one winds in the opposite direction. Never saw anything like that before ever. Then when lowering the jack for the first time it folded like nothing we have seen before. I work hard for my money and the scissor jacks purchased were not built well at all (they didn’t even make it thru the first use)
by: Bill08/30/2023
One of the 2 jacks is extremely difficult to open.
by: Terry 02/10/2023
Jacks are better than what came on my trailer originally
by: Mark Cornell05/11/2020
The jacks worked excellent and will definitely recommend this company to anyone needing parts for their RV... I will be buying more things for my camper soon
by: Stanley 07/13/2023
Bought 2 sets very sturdy
by: Clyde 03/07/2023
RV came with cheap jacks. These are a great replacement, super heavy duty.
by: Tony06/27/2018
New jacks and tires arrived quickly. Installation was easy since no new drilling was required.
by: Bryan03/03/2023
The Jacks Fit As Advertised But When You Raise The Jacks The Rods Extend Out Board Instead Of Inboard like My Old Ones. Be Careful You Will Scrape Your Shins.
