Ask the Experts about this Pro Series Trailer Jack

Do you have a question about this Trailer Jack?

• Can Pin for Drop Leg be Moved on Pro Series Square 10,000 Pound Jack # PS1401010376

• The pin location cannot be changed but we do have Pro Series jack # PS1400950376 or # PS1400980376 which do have the pins on the front (or back depending on how you have the jack positioned). Another option is # TJD-12000SP-F2 or # TJD2SP-12000SP-F.
  view full answer...


• Can Two of the Pro Series Square Jacks # PS1400950376 be Used Together on Trailer

• You can certainly use two of the Pro Series Square Jacks # PS1400950376 that you referenced on your trailer. If you are looking to use two of them in tandem, you will just want to make sure they are both mounted in the same position. This 10,000 pound capacity jack does include a sidewind crank but you will need to obtain a long enough connecting rod if you are wanting to use them together. This is a really nice, heavy-duty square jack that features a weld-on design and a total lift...
  view full answer...


• Difference Between Pro Series Drop Leg Square Jacks PS1400950376 And PS1400960376

• You are correct. There are just two differences between part # PS1400950376 and part # PS1400960376. The crank handle is included with part # PS1400950376, and it is painted black. The # PS1400960376 does not include the crank handle, part # PS1400920383, which is sold separately, and this jack is painted gray. Both jacks have a 12-1/2 inch lift and have a lift capacity of 10,000-lbs. They also feature an extended height of 54-1/4 inches.
  view full answer...


• What is the Diameter of the Crank Input Shaft on Pro Series Drop Leg Trailer Jack # PS1400950376

• The shaft on which the crank attaches to for the Pro Series Square Jack, # PS1400950376, measures 1 inch in diameter. I have also included a dimensional diagram for the jack for you to view.
  view full answer...


• Drop Leg Jacks Needed for Loading Equipment on a 14,000 lb Equipment Trailer

• The Pro Series Square Jack - Drop Leg w/ Spring Return, # PS1400950376, that you referenced would work well for your trailer, but you would most likely have to do some fabrication to install this jack on each side at the rear. The outside dimension of this jack is 4 inches square. I produced a short video showing 3 jacks, the one you mentioned, the same jack without a spring return drop leg, # PS1400990376, and an 8,000 lb jack, # PS1400800383, that would most likely work also. Two...
  view full answer...


• Dimensions for Attachment of the Pro Series Square Drop Leg Jack 12,000 Lbs. # PS1400950376

• I spoke with my contact at Reese and he sent me dimensions of the Pro Series Jack, item # PS14009503676. I have included a drawing containing these dimensions for you to review. There is no owners manual included with these Jacks at this time. The recommended installation for this jack is direct welding to the trailer frame.
  view full answer...


• Does 10k AutoLock Drop Leg Trailer Jack Have a Spring Return for the Pin on the Drop Leg

• I was able to find that the pin for the drop leg on jack # TC10B is not spring loaded. Pro Series jack # PS1400950376 does have a spring return pin. I have included a link to a video review of this jack for you. Bulldog jack # BD182804 also has a spring return.
  view full answer...


• Comparing the Pro Series Jack Part # PS1400950376 and the RAM Jack Part # TJD-12000SP-R2

• Yes, both the Pro Series Square Jack part # PS1400950376 and the Square Direct Weld Jack part # TJD-12000SP-R2 are made of steel. The Pro Series jack has a one year warranty and the RAM jack also has a one year warranty. They both have a 10,000 lb lift and 12,000 lb support capacity although the RAM jack does offer a bit more lift at 13-1/2" compared to the 12-1/2" of the Pro Series jack. Essentially, the jacks are pretty much the same for the exception of brand. I have attached a review...
  view full answer...


• Moving a 2,500 Pound Trailer with a Jack that Doesn't have a Wheel

• All of the jack wheels we have are for round tube jacks but there is an alternative to moving around a trailer other than a wheeled jack. You could use a trailer dolly such as # MT70225. It is rated for 600 pounds tongue weight and since your trailer is 2,500 pounds at most the tongue weight would be around 250 pounds. There isn't a gross trailer weight capacity because it just depends on how much weight the user can pull or push around. Another option that will assist in moving the...
  view full answer...


• Horse Trailer Landing Gear Jack Recommendation

• Since your trailer weighs a total of 10,400 lbs the Pro Series Square Jack # PS1400950376 that you referenced would work well since it has a lifting capacity of 10,000 lbs. Since the jack does not lift the entire weight of the trailer this would be more than enough for you. This also has a spring return feature built into the foot of the jack like you said you wanted as well.
  view full answer...


• What is the Correct Follower Leg for Pro Series 12K Square Drop Leg Trailer Jack

• Yes, Pro Series jack # PS1400960376 can be used as the follower leg to # PS1400950376. Connecting the 2 jacks using a rod will allow you to raise and lower both jacks at the same time. I have included a link to a video review of the master jack for you to view.
  view full answer...


• Availability of 10K Weld-On Side-Wind Trailer Jack

• On the linked page you can view all 10K-rated side-wind weld-on trailer jacks. All come with a jack foot included but they range in lift height from 13-inches of lift up to 26-inches of lift. Pro Series 10K Square Jack # PS1400950376 offers 12-1/2-inches of lift and has an outer tube that is 3-inches wide.
  view full answer...


• Does the Pro Series Jack # PS1400950376 Have a Grease Fitting and Include the Handle

• Yes, the Pro Series 12,000 lb Square Jack, # PS1400950376, does have a grease fitting built into the front of the jack. You can see the grease fittings in the photos on our product page. It will be located between the handle and the warning sticker. I have attached a photo showing where the grease fitting is located. The handle is also included with the jack.
  view full answer...


• Dimensions and Warranty of the Pro Series Square Jack # PS1400950376

• If you check out the diagram that I attached for the Pro Series Square Jack # PS1400950376 you can see that the outside diameter of the outer tube is 4 inches and the outside diameter of the inner tube is 3 inches. This jack comes with a limited 1-year warranty.
  view full answer...


• Replacement Parts Availability for Pro Series Trailer Jack

• Economy jacks like the Pro Series # PSEA20000103 do not have the same availability of replacement parts as the comparable products that are more costly. This is why they cost less. Pro Series does offer a replacement handle # PS1400920383 for their higher-capacity square tube jacks like # PS1400950376 but not for their lower-capacity value-priced jacks. If you wish to select a new jack you can do so using the linked page.
  view full answer...


• Replacement Internal Screw Availability for Bulldog Jacks

• It's hard to say what would be the correct replacement nut and screw for your jack since I do not know what brand or part number you have. But if you have a Bulldog 10k Jack you would want the part # BD500250 and if you have a 12k Bulldog Jack you would want the part # BD500217. Currently these are the only two we carry.
  view full answer...


• Powered Bulldog Jack Recommendation for a 24 ft Flatbed Gooseneck Trailer with Camper

• The best recommendation I can give you would be to replace your current jack with a Bulldog Jack like our part # BD182804 and then get a Bulldog Powered-Drive Kit # BD1824200100. The powered drive kit is only confirmed to fit Bulldog jacks so you would not be able to install the kit on your current jack.
  view full answer...


• Replacement Landing Gear With Drop Leg Recommendation for Trailer with Unknown jacks

• Based on the design of the drop leg and the markings on the side of the jack the picture you submitted is of a Bulldog jack part # BD182400. If you are looking to replace just one of the jacks you would need this part number.
  view full answer...


• Correct Trailer Jack for a Cherokee 2002 3 Horse Trailer with 8 Foot Living Area and 12000 GVW

• For your application I recommend using the Bullydog Square Jack # BD182701. This jack has a lift capacity of 12,500 pounds which is rated more appropriately for your trailer with a Gross Vehicle Weight of 12,000 pounds. The Pro-Series Jack that you mentioned # PS1400950376, only has a lift capacity of 10,000 pounds, and a static capacity of 12,000 pounds. Your trailer exceeds the capacities of the jack. The diameter of the drive for the Pro Series # PS1400950376, and the Bulldog...
  view full answer...


• What are the Dimensions of the Pro Series 12k Square Drop Leg Trailer Jack

• When the Pro Series Square Jack # PS1400950376 is fully retracted it is 28 inches tall. When fully extended it is 54 inches tall. The outer tube is 4 inches square. If you are looking for some specific dimension let me know and I can determine what it is. I have linked a video review of the jack for you.
  view full answer...


• Recommended Square Topwind Jack With 10,000 lb Capacity

• For a Topwind Jack with dropleg, I recommend the Bulldog Square Jack - Drop Leg w/ Non-Spring Return - Topwind - 12-1/2" Lift - 10,000 lbs # BD182304. This is the closest topwind jack we have to the Pro Series # PS1400950376, but it does not have the spring return. Every other aspect is very similar.
  view full answer...


• Can Pro Series Trailer Jack # PS1400950376 Work on 21,000 lb Rated Trailer

• Yes, the Pro Series Square Jack # PS1400950376 that you referenced would work great as it has a 10,000 lb capacity. Pin weight for gooseneck trailer is typically 20 percent total trailer weight. So yours being 21,000 lbs means you'd have a pin weight of right at 4,200 lbs which the Pro Series jack would have no problem with.
  view full answer...


• Powered Landing Gear Jack Recommendation to Replace Pro Series Landing Gear

• There isn't a motor that can be added to the Pro Series Jacks part # PS1400960376. But if you are in the market for a new set of landing gear that has motors you would want the part # BD500161. This set has a 10k capacity and 36 inches of lift so it would be a great choice for your trailer.
  view full answer...


• Available Types and Weight Capacities of Trailer Jacks

• We carry all types of trailer jacks, from powered A-frame tongue jacks like # HT87247 to weld-on side-mount jacks like # PS1400950376 to 5th wheel trailer landing gear like # BD500161. On the linked page you can see all jacks; click on the type you need and then click on the weight capacity required. For instance, in a 12K rating we have side-mount jack # BD182513 and powered jack # BD185400. We also have jacks like the weld-on # BD1823050383 and the bolt-on # BD1839060383, both...
  view full answer...


• 10k Capacity Pro Series Jack Recommendation

• Sounds like you are looking for the Pro Series Square Jack # PS1400950376 as it has a 12-1/2 inch lift and a 10k capacity. This jack is designed to weld directly to the frame of your trailer. Check out the review video I attached for more info.
  view full answer...


• Outer Tube Dimensions of Pro Series Square Tube Drop Leg Jack Part # PS1400950376

• The outer tube dimension of the Pro Series Drop Leg Jack you referenced, part # PS1400950376 is indeed 4 by 4 inches. The jack is a weld-on application, and would work great on your horse trailer.
  view full answer...


• Purpoose of the Shaft that Sticks Out of the Opposite Side of the Crank Handle of Jack PS1400950376

• The shaft that comes out of the other side of the jack on the part # PS1400950376 that you referenced is designed for attaching to a follow leg so that the jack can be used as a landing gear set. It would turn with the crank handle. The closest jack we offer to this one that does not have that shaft would be a topwind jack like the part # BD182304.
  view full answer...


• Recommended Replacement Weld On Jack with 10,000 lb Capacity

• The Pro Series Square Jack - Drop Leg w/ Spring Return - Sidewind - 12-1/2" Lift - 10,000 lbs # PS1400950376 you asked your question from is the best jack for your application. We do not have a 3/4 inch input shaft with any jack, so you will need to do modifications unless you choose to replace both sides. It is recommended to use matching jacks so they will raise and lower at the same exact rate.
  view full answer...


• Can the 10K Pro Series Square Jack be Used in a Dual Setup

• Yes, you can use the Pro Series Square Jack # PS1400950376 in a dual setup as long as it is with the same model Pro Series jack like part # PS1400960376. Just be sure these are installed at the same height and your connecting rod is long enough for your application.
  view full answer...


• How to Determine if Trailer Jack Has Available Wheel or Caster

• It would depend on which jack you're speaking of. The casters used on trailer jacks usually have a fairly low weight capacity, usually limited to 1500 lbs or so. The caster can limit the weight capacity of the jack if its capacity is lower than that of the jack. For instance, the Pro Series A-frame jack # PSEA20000103 has a 2000 lb capacity, but if you add the # PS1400750340 caster to it, the capacity will be lowered to the capacity of the caster. Generally speaking, if a jack we sell...
  view full answer...
