See what our Experts say about this CURT Trailer Hitch

• Recommended Trailer Hitch for 2017 Lexus RX 350 F-Sport
  Actually, the only trailer hitch currently available that's confirmed to fit the F Sport model of your 2017 Lexus RX 350 is the Stealth Trailer Hitch Receiver; either the part # 391LXRX16T if you ever plan on doing any towing or # 391LXRX16 if you only plan on using it for hitch-mounted accessories like a bike rack or cargo carrier. Both offer a 350 pound tongue weight capacity (along with a 3,500 pound towing limit for the # 391LXRX16T) and feature a completely hidden design when not in...
  view full answer...
• Trailer Hitch for 2018 Lexus RX 350 F-Sport
  Yes we do! For your 2018 Lexus RX 350 F-Sport model we have the Draw-Tite Class III # 75540. It will install by using existing holes in the vehicle's frame for a no-drill installation and it features a 4,500 pound towing weight capacity. I also recommend verifying the towing capacity of your Lexus by checking your copy of the owner's manual. You will simply need to adhere to whichever limit is lower, the vehicle's or the hitch's. I have attached an installation video on the 2017 model...
  view full answer...

• Locking Trailer Hitch Pin for Bike Rack on 2 Inch Trailer Hitch Receiver
  The Curt hitch you purchased is part # C13272 which is a 2 inch receiver so the pin hole is 5/8 inches. A good standard lock to fit is part # e98880. With that being said, a lot of bike racks have threaded hitch pins so you can't use just a standard locking pin. Their threads are usually specific to their own locks so you might need to purchase a specific lock for your specific bike rack. If you let me know which bike rack you have I can help you with a specific locking pin.
  view full answer...
• Complete Towing Setup for 2018 Lexus RX 350 Including Hitch, Wiring and Brake Controller
  I'm happy to help you get your RX 350 ready for pulling your new camping trailer and I wish you many good times in the future. Starting with a hitch, I recommend the USA-made etrailer Class III hitch # e94AR for its simple no-drill installation (it includes all the hardware) and for its substantial 4000-lb towing capacity. It installs as shown in the written instructions, which is linked for reference. I also suggest ball mount kit # 989900 which provides multiple ball mounts and sizes...
  view full answer...
• Trailer Hitch and Tow Capacity of 2018 Lexus RX 350
  I Googled the owner's manual for a 2018 Lexus RX 350 and it said the maximum towing capacity was 3,500 lbs, and the Curt Trailer Hitch Receiver # C13272 has a 4,000 lb towing capacity so you will not have any problems using this hitch for towing less than the 3,000 lbs you mentioned. That said, we do recommend verifying all towing capacity information with vehicle manufacturers as they have the final say on these matters.
  view full answer...
• Recommended Locking Anti-Rattle Hitch Pin For Curt Trailer Hitch C13272 On 2017 Lexus RX 350
  Absoluetly! For the Curt Trailer Hitch Receiver # C13272 you installed on your 2017 Lexus RX 350 I recommend the Anti-Rattle Trailer Hitch Receiver Lock for 2" Hitches # 63232. This will fit perfectly in your 5/8" diameter hitch pin hole and will keep your accessories from rattling while also keeping them secure with the included lock. You will need to make sure your accessories have a hollow shank for this to work. I included videos for both of the products mentioned for you to take...
  view full answer...
• Compatibility of Yakima RidgeBack Bike Carrier on 2016 Lexus RX 350
  The Yakima RidgeBack 2 Bike Rack - 1-1/4" and 2" Hitches - Tilting # Y02457 has a distance from center of hitch pin hole to closest part of rack of 9-1/2 inches. The clearance from your hitch pin hole to the outer bumper will simply need to be less than the 9-1/2 inches. If you use the Curt Trailer Hitch Receiver - Custom Fit - Class III - 2" # C13272 the measurement is 4 inches so you will have 5-1/2 inches of clearance and this bike rack will serve you well.
  view full answer...
• 2020 Lexus RX 350 F Sport Trailer Hitch Option
  The Curt Trailer Hitch Receiver part # C13272 will fit most 2020 Lexus RX 350 F-Sports. This has actually been sort of a complicated issue as many have installed this hitch without issues but some have run into issues. There seems to be a problem with certain options that may come equipped which can create fit issue. Unfortunately, Curt has not been able to narrow down which exact options cause fit issues so to err on the side of caution we have as a whole removed the Curt hitch as a fit...
  view full answer...
• Recommended Trailer Hitch Receiver and Bike Rack to Carry 2 Bikes on a 2017 Lexus RX 350
  When looking for a trailer hitch receiver we always advise people to go with a 2 inch option if it is available for their vehicle as a 2 inch option will give them access to more accessories to use in their hitch. For your 2017 Lexus RX 305 I recommend going with the Curt Trailer Hitch Receiver # C13272 which has a 2 inch receiver and weight ratings of 4,000 lbs for Gross Trailer Weight (GTW) and 600 lbs Tongue Weight (TW). The GTW is increase to 5,000 lbs when using a Weight Distribution...
  view full answer...
• Clearance of Bumper With Curt Cargo Carrier on 2016 Lexus RX 350
  The Curt Aluminum Cargo Carrier # C18100 will fold up without hitting the bumper of your 2016 Lexus RX 350; you will have 1/2" of clearance space when using the Curt # C13272 trailer hitch. It may still be worth it to use the Curt Multipurpose Ball Mount with 2" Receiver for Bike Racks and Cargo Carriers # D210 if you plan on towing or for simple peace of mind. Another option would be Curt Cargo Carrier # C18151, which is not only a bit larger, but offers 4-1/2 more inches of clearance...
  view full answer...
• Will Trailer Hitch Installed on 2021 Lexus RX350 Affect Operation of Hands-Free Liftgate
  As long as your 2021 Lexus RX350 isn't the F-Sport model, the Curt Class III hitch, part # C73DR is a confirmed fit. The Curt # C13272 hitch you'd looked at isn't a confirmed fit. We haven't received any feedback stating that installing the Curt # C73DR hitch has prevented the hands-free liftgate feature on the Lexus RX350 from working, but it will typically block the sensors from reading input right at the center of the vehicle. If you wave your foot several inches to either side of the...
  view full answer...
• Will the Curt Hitch C13272 Fit a 2016 Lexus RX 350 F-Sport
  The Curt Trailer Hitch Receiver part # C13272 will fit most 2016 Lexus RX 350 F-Sports. This has actually been sort of a complicated issue as many have installed this hitch without issues but some have run into issues. There seems to be a problem with certain options that may come equipped which can create fit issue. Unfortunately, Curt has not been able to narrow down which exact options cause fit issues so to error on the side of caution we have as a whole removed the Curt hitch as a...
  view full answer...
• Install Instructions and Video for Curt Hitch # C13272
  We link our install instructions directly from the manufacturer so that we always have the most current install info, the downside to that is that occasionally if they take the link down or modify it we may not have access for a small portion of time. So what I did was attach two pictures that I took from the install instructions for the Curt hitch part # C13272 to this page. The link was working for me when I tried it though. I also attached a link to an install video for this hitch as well.
  view full answer...

• Availability Of Replacement Mounting Hardware For Curt Trailer Hitch Receiver 13272
  We sure do! You will need the Replacement Hardware Kit # RHK. When on the product page of the # RHK you will need to select Curt from the drop down menu, and for the hitch item number you will enter 13272. The Curt Trailer Hitch Receiver # C13272 you mentioned is confirmed to fit the 2016-2019 Lexus RX 350 so as long as the vehicle you are installing the hitch on is one of those model years you will have no issues. I included videos of the products mentioned for you to take a look at.
  view full answer...
• Recommended Trailer Hitch Receiver For 2018 Lexus RX 350 W/ Best Ground Clearance
  You are pretty much right on with the ground clearance. When we installed the Curt Trailer Hitch Receiver # C13272 on a similar 2017 Lexus RX 350 we found that it measured 15-1/2" from the ground to the top inside edge of the receiver. To the bottom of the receiver is about 2-1/4" so you are looking at just over 13" ground clearance with either option. While we have not had an RX 350 in with a factory receiver to measure the ground clearance, based on the pictures I was able to find online...
  view full answer...
• Trailer Hitch, Installation, and Wiring for a 2017 Lexus RX 350
  The manufacturers and installers (like us) have the luxury of lifts to install trailer hitches and other things but they are not required. It makes it easier for sure especially when making an installation video! You could install Curt trailer hitch # C13272 on your 2017 Lexus RX 350 by just lying on the ground but the more space you have the easier it will be. Using a jack, ramps, jack stands, will give you more space should you need it. The wrench you have sounds like a ratchet or...
  view full answer...
• Recommended Trailer Hitch for a 2019 Lexus RX 350
  The trailer hitch I recommend for a 2019 Lexus RX 350 is the Curt Trailer Hitch Receiver part # C13272 which is a fit for all models even the F-Sport. The Curt hitch offers a complete bolt-on installation with no cutting or drilling required. Therefore, the Curt hitch is very easy to install and should only take around thirty minutes or so. The best part of all is that the Curt hitch has a hidden cross tube which you can see in the attached photo and this means that only the receiver tube...
  view full answer...

• Is Rear Damper of 2016 Lexus RX 350 F Sport Removed for Hitch Install
  Since the Curt Hitch part # C13272 installs by simply raising up into position at the rear of your vehicle and then bolting it into place there would be no need for you to remove the rear damper or any body panels to installation. If you wanted to do some towing you might be interested in etrailer ball mount kit # 989900. It comes with 2 ball mounts; one with a 3/4 inch rise or 2 inch drop and one with a 2-3/4 inch rise or 4 inch drop. It also includes a 1-7/8 inch ball, 2 inch ball, hitch...
  view full answer...
• Is Any Trimming Required to Install etrailer Trailer Hitch on a 2016 Lexus RX350
  You should not have to trim anything on your 2016 Lexus RX350 to install etrailer trailer hitch # e94AR. Ther is also no drilling required for installation. If Your Lexus is equipped with the lateral performance damper, the damper will need to be removed to install this hitch. This hitch is an excellent choice for use with a bike rack. There is another hitch that will fit, # C13272. But if it were me I would go with the less expensive etrailer hitch. If you ever plan on doing some towing...
  view full answer...
• Will The Curt Trailer Hitch Receiver # C13272 Fit a 2017 Lexus RX 350 F-Sport?
  Per Curt their Trailer Hitch Receiver # C13272 will not fit the F-Sport package on your 2017 Lexus RX 350. While we have had a number of reviews come back to us saying they were able to bolt it right up without issue there are other issues some have ran into where it would not fit their particular vehicle. The best I can say is you can see the installation video I have linked near the bottom of the page. If you see our particular Lexus has any components in the way of where the receiver...
  view full answer...
• Bolt Won't Thread in to Install a Trailer Hitch
  You definitely want all of the hardware installed for hitch # C13272 or any hitch because how it attaches is part of how it gets its rating. It sounds like the problem you are having is a factory weld nut that is packed with grime and corrosion. Giving it a good, thorough cleaning with a wire brush and some PB Blaster will help. You will apply a good amount of the spray into the weld nut in question and let it soak for a good 15 minutes. Then go at it with a wire brush. Repeat as often...
  view full answer...
• Trailer Hitch Recommendation for a 2016 Lexus RX 350 Sport
  I checked with Curt and the Curt hitch part # C13272 does not have any fit exclusions for Sport models so it would fit your 2016 Lexus RX 350 Sport and work well. If you wanted to do some towing you might be interested in etrailer ball mount kit # 989900. It comes with 2 ball mounts; one with a 3/4 inch rise or 2 inch drop and one with a 2-3/4 inch rise or 4 inch drop. It also includes a 1-7/8 inch ball, 2 inch ball, hitch pin with clip, and a storage bag. If the ball mount kit does not...
  view full answer...
• Recommended Trailer Hitch Receiver For 2017 Lexus RX 350 F-Sport
  The customer service representative you spoke to is correct. We used to list the Curt Trailer Hitch Receiver # C13272 you were looking at as a fit for the 2017 Lexus RX 350 F-Sport, but after multiple fitment issues from customers we changed the fit in our system and do not recommend this hitch for the F-sport models as it may have fitment issues. Instead I recommend going with the Stealth Hitches Hidden Rack Receiver - Custom Fit - 2" # 391LXRX16 if you are planning on using the trailer...
  view full answer...
• Trailer Hitch Fit and Installation Process for 2016 Lexus RX 350
  The 2015 and 2016 model years of the Lexus RX 350 are from different generations of this popular vehicle (AL10 and AL20) and so the hitches that fit the two model years are different. For the 2016 Lexus RX 350 we offer Curt hitch # C13272 which fits both F-Sport and non-F-Sport versions. This is a 2-inch Class III hitch that installs without drilling using the included hardware packet. I have linked the written installation instructions as well as two helpful articles. The tools required...
  view full answer...
