Curt Double Lock, Flip and Store Underbed Gooseneck Hitch w/ Installation Kit - 30,000 lbs

Curt Double Lock, Flip and Store Underbed Gooseneck Hitch w/ Installation Kit - 30,000 lbs

Item # C615-632

lowest price pledge

Retail:$679.84

Our Price: $438.55

You Save: $241.29
Gooseneck

Will this fit?

To see if this custom-fit item will work for you please tell us what vehicle you'll use it with.

This item qualifies for Free Shipping

Shipping Weight: 122 lbs

Quantity:
C615-632 - 30000 lbs GTW Curt Gooseneck
zoom in icon
zoom out icon
Comment field cannot be left empty.
Name field cannot be left empty.
Please enter a valid email address.

Thank you! Your comment has been submitted successfully. You should be able to view your question/comment here within a few days.

Error submitting comment. Please try again momentarily.

pop out icon replay 360 icon
horizontal rotate icon

Product Images

In Use/Installed

Customer Photos

Videos


  • Curt
  • Below the Bed
  • Removable Ball - Stores in Hitch
  • 2-5/16 Hitch Ball
  • Wheel Well Release
  • 6000 lbs TW
  • 30000 lbs GTW
  • Manual Ball Removal
Get a little extra security when you are towing with Curt's double-lock, gooseneck hitch. Chrome-plated ball locks in place with two pins while towing and flips over for storage inside the hitch when its job is done. Installation kit included. Call 800-298-8924 to order Curt gooseneck part number C615-632 or order online at etrailer.com. Free expert support on all Curt products. Guaranteed Lowest Price and Fastest Shipping for Curt Double Lock, Flip and Store Underbed Gooseneck Hitch w/ Installation Kit - 30,000 lbs. Gooseneck reviews from real customers.


  • All Info
  • Reviews (187)
  • Q & A (18)
  • Videos (1)
  • Photos
  • Why etrailer?

Curt Gooseneck - C615-632

Get a little extra security when you are towing with Curt's double-lock, gooseneck hitch. Chrome-plated ball locks in place with two pins while towing and flips over for storage inside the hitch when its job is done. Installation kit included.


Features:

  • Heavy-duty underbed hitch lets you tow your gooseneck trailer
  • Double-lock system provides added security with 2 pins holding ball in place instead of 1
  • Chrome-plated hitch ball easily removes when you're not towing for complete access to your truck bed
    • Ball flips over and stores upside down in hitch for easy access
  • Chrome ring surrounds the hitch ball hole to provide a tight, low-profile look
  • Comfort-grip handle can be positioned on either side of truck bed
  • Safety-chain hookups are built in
  • Zinc plating provides superior corrosion resistance for locking mechanism
  • Rubber cover keeps grime out of ball hole when ball is stowed
  • Black powder coated steel is durable and corrosion resistant
  • Custom mounting kit with Grade 8 hardware included
    • 4" Hole in bed is required
    • No welding required
  • Adapter plate (C16210 - sold separately) allows for 5th-wheel towing
  • Offset hitch ball (C602 - sold separately) creates additional space between truck cab and trailer


Specs:

  • Ball size: 2-5/16"
  • Gross towing weight: 30,000 lbs
  • Vertical load: 7,500 lbs
  • 7-Year Limited warranty


Curt Double Lock Gooseneck Hitch Operation

Curt Double Lock Gooseneck Trailer Hitch Operation

The Curt Double Lock underbed gooseneck trailer hitch provides a sturdy, secure connection for towing your gooseneck trailer and also allows for a clean, unobtrusive look for your truck bed when you aren't towing. To tow, simply pull the included handle out to unlock the hitch. Then insert the chrome-plated hitch ball into the ball hole. You may need to rotate the ball to line it up with the dual locking pins. When the ball drops into place, rotate the handle counterclockwise until the locking pins snap into position. Because there are 2 locking pins instead of 1, you get extra security for your towing setup.


Get full bed access when you're not towing. Just remove the ball, flip it upside down, drop it back into the ball hole of the hitch, and use the handle to lock the ball in place. A rubber cover is included with the Double Lock. When the ball is stowed upside down in the hitch, place this cover over the ball hole to keep out dirt and grime and create a clean look for your vehicle.



60615 Curt Double Lock Underbed Gooseneck Trailer Hitch - 30,000 lbs

60632 Curt 600 Series Gooseneck Hitch Installation Kit

60711



C615-632 Installation InstructionsInstallation Details C615-632 Installation instructionsC615-632 Installation InstructionsAlternate Instructions C615-632 Installation instructions

This Product Fits The Following Vehicles

2008 - 2013 GMC Sierra 1500 - 5-1/2 Foot Bed

2007 - 2007 GMC Sierra New Body 1500 - 5-1/2 Foot Bed

2008 - 2013 Chevrolet Silverado 1500 - 5-1/2 Foot Bed

2007 - 2007 Chevrolet Silverado New Body 1500 - 5-1/2 Foot Bed

2008 - 2013 GMC Sierra 1500 - 6-1/2 Foot Bed

2007 - 2007 GMC Sierra New Body 1500 - 6-1/2 Foot Bed

2008 - 2013 Chevrolet Silverado 1500 - 6-1/2 Foot Bed

2007 - 2007 Chevrolet Silverado New Body 1500 - 6-1/2 Foot Bed

2008 - 2013 GMC Sierra 1500 - 8 Foot Bed

2007 - 2007 GMC Sierra New Body 1500 - 8 Foot Bed

2008 - 2013 Chevrolet Silverado 1500 - 8 Foot Bed

2007 - 2007 Chevrolet Silverado New Body 1500 - 8 Foot Bed

2014 - 2018 GMC Sierra 1500 5-1/2 Foot Bed

2014 - 2018 Chevrolet Silverado 1500 5-1/2 Foot Bed

2014 - 2018 GMC Sierra 1500 6-1/2 Foot Bed

2019 - 2019 GMC Sierra 1500 Limited 6-1/2 Foot Bed

2014 - 2018 Chevrolet Silverado 1500 6-1/2 Foot Bed

2019 - 2019 Chevrolet Silverado 1500 LD 6-1/2 Foot Bed

2014 - 2018 GMC Sierra 1500 8 Foot Bed

2014 - 2018 Chevrolet Silverado 1500 8 Foot Bed



Video of Curt Double Lock, Flip and Store Underbed Gooseneck Hitch w/ Installation Kit - 30,000 lbs


Videos are provided as a guide only. Refer to manufacturer installation instructions and specs for complete information.




Video Transcript for Gooseneck Trailer Hitch Installation - 2009 Chevrolet Silverado

Today, in our 2009 Chevy Silverado, we'll be installing the CURT Double Lock Gooseneck Hitch, part number C615-632. Next, let's go ahead and go to the operation of our new gooseneck hitch and ball. To release the handle, we'll pull out, rotate it to the unlock position. Then we can install the ball. To install the ball, we'll lineup the groove in the ball with the nipple in the gooseneck cylinder. We'll drop the ball in place and then release the handle locking the ball to the gooseneck.

Again, we can release by pulling out and rotating to unlock it, pull the ball out, turn it over, re-secure the handle and install the gooseneck cylinder cover for the stored position.We'll go ahead and install the gooseneck hitch. To begin our install, we're first going to go ahead and lower remove the spare tire and remove both rear wheels. This will give us more room to make it easier to do the install. Next, we need to remove the heat shield above the exhaust starting at the forward hat channel we'll cut it just behind the hat channel with the rotary cut off wheel. We'll go to the end of the heat shield and cut it just in front of the rear hat channel.

The center section of the heat shield is secured with 2 fasteners. Overtime these fasteners will become very difficult to remove.First, we'll go ahead and attempt to remove them. However, if they strip out, we'll then go ahead and use our cut off wheel to just cut the head of the screw and then remove the heat shield. With our heat shield down all the way, we'll move to the bed. We'll measure for the length per the instructions and then measure for the center width of the bed marking for our pilot hole.

With the bed marked, we'll go ahead and drill out our pilot hole. Next we'll step up to our hole saw and drill out the large hole. Now we've gone through the bed, you'll see that the hat channel covers a small portion of the hole.We can use the hole saw to go ahead and cut out this section of the hat channel. With our hole cut out, we'll move down to the frame rails. Here we'll need to relocate any wiring or brake lines that's secured to the top of the frame rail above the axle.

With the wiring out of the way, we're ready to install the rear rail for our gooseneck hitch. As you put the rail in position, we'll make sure that the pre-drill threaded holes face down. We'll install the forward rail. We'll make sure that the pre-drilled holes in the end that are offset face downward. We'll slide it in between the pickup bed and frame and then rotate it up into place.Using a crescent wrench can make it easier to rotate it into position. With our rails in place, we're ready to install the gooseneck head. To make it easier to do this and hold this head assembly into position we'll be using the CURT install tool for gooseneck hitches, part number C60606. This install tool will sit in the pickup bed with an L bracket that will go down to our cut out hole in the pickup bed we'll lock in the throat the same as a hitch ball. Then we can use the threaded bolt that runs to the L bracket to pull the head up into place and hold it while we install our hardware.This will be the 1/2-inch bolt split lock washer and flat washer. We'll install each fastener finger tight until we have them all in place. Next, we'll move to the wheel wells where we'll install side brackets. The side brackets will get secured to the frame using the 3/4-inch bolt and flat washer that will go through the side bracket. Then we'll add two large round spacers feed it through the manufacturer's hole in the frame. We'll secure it with the large spacer block and then a 3/4-inch flange nut. To secure the side bracket to the frame rail, we'll use a 1/2-inch bolt split lock washer and flat washer.Next, we'll take the U bolt and feed it from the inside around the frame and through the side bracket and secure it with the 2 1/2-inch flange nuts. Now, with all our hardware installed finger tight, we're ready to go ahead and start tightening it down. We'll repeat the same procedure starting with the head units of the rail assembly, side brackets to the frame and then the side bracket to the rail. We're ready to start torque it to the manufacturer's specifications. We'll need to re-secure the brake line bracket. We'll use the extension provided with our install kit.We'll take the extension and manufacturer's fasteners and secure it to the frame. Then we'll take the new 8-milimeter bolt and flange nut and secure the manufacturer's bracket to the CURT bracket. Next, we'll re-secure the wiring. If you're unable to reinstall it into the frame, we'll go ahead and use a couple of zip ties to secure the wire we remove from the frame to the main harness. Then we'll cut off the excess from the zip ties to clean up our install look. Now, we're ready to install our chain holes down. Using the hitch as template we'll pre-drill holes into the bottom corrugation of the bed and then enlarge it to our final size of half inch.Once we have holes drilled out, we'll move to the top of the bed where we'll drop the U bolts down through the holes we just drilled out. Next, we'll move back underneath the bed where we'll install a flat washer spring, second flat washer and then a nylon locking nut. Once we have all the hardware installed for the chain holes down then go ahead and tighten the buts down to where the nut is flushed with the bottom of the U bolt. With our chain holes down in place, we're ready to install the handle and lock. Our double lock will go straight into the head unit.Then our handle will go between the pickup bed and frame past to the two pre-drilled holes in the head assembly where we'll install a flat washer, spring, a second flat washer and the handle will go into the double lock. We'll line up the pre-drilled holes and install the bolt and nylon lock nut and secure the handle to the lock assembly. Note on applications where the handle assembly will hit the bed in order to operate the handle, you may need to make a small cut out. Using a pair of tin snips, we'll cut a small V in the bed to allow more room for a handle assembly to operate.We'll go ahead and reinstall the wheels. And that will complete our install of the CURT Double Lock Gooseneck Hitch, part number C615-632 on our 2009 Chevy Silverado. .


Customer Reviews

Curt Double Lock, Flip and Store Underbed Gooseneck Hitch w/ Installation Kit - 30,000 lbs - C615-632

Average Customer Rating:  4.7 out of 5 stars   (187 Customer Reviews)

Get a little extra security when you are towing with Curt's double-lock, gooseneck hitch. Chrome-plated ball locks in place with two pins while towing and flips over for storage inside the hitch when its job is done. Installation kit included.

- C615-632

by:

Chevrolet


Could be packaged better. The parts are heavy and rub on each other and in some cases the finish was scraped off. Had to chase the holes with a 1/2" tap, because the finish on the hitch was sprayed into the holes. Directions were ok. Hitch fits fine and works well on my 1/2 ton Chevy. The person I worked with at etrailer.com was helpful and the hitch was shipped promptly. 555980



- C615-632

by:


Love the Curt C615-632 under bed kit. It maximizes the use of the bed of my truck, and has a clean 4" cap when not towing 473565



- C615-632

by:

2012 Chevrolet Silverado


I installed this by myself in about 3 1\2 hours. Very good fit. 159680



- C615-632

by:

2004 Dodge Ram Pickup


The hitch fits perfect and was shipped the next day from ordering it. 604769



- C615-632

by:

2004 Dodge Ram Pickup


The springs for the safety loops are to small in diameter. The washers slide over the springs. 602730



- C615-632

by:

2013 GMC Sierra


Worked great. Easy to install. 526127



- C615-632

by:


Great hitch, great price. 398555



- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


We love this hitch. It serves all our needs and then some and would definitely buy from you again 585731



- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


Fast easy installation 519076



- C607-604

by:

Review from a similar Curt Double Lock in Gooseneck


Great product easy to install and good price!!!!! 221771



- C60721

by:

Review from a similar Curt Double Lock in Gooseneck


Very good product! Fit perfectly and works great ! Shipping was very fast also 5* for sure 470751



- C60712

by:

Review from a similar Curt Double Lock in Gooseneck


Easy install very good hitch just as good as my old b&w hitch 434973


Comments

After a year this hitch has held up great gets used daily no complaints good quality hitch and great price will never buy anything else

Eric s - 09/21/2018

43862

- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


Install was a breeze , works excellent. Pulling a 4 horse trailer with no issues, I'll definitely be buying all my future trailer needs from you. 570705



- C60722

by:

Review from a similar Curt Double Lock in Gooseneck


Unit installed and pulled my fifth wheel to provincetowne Mass. Unhooked and pulled the ball out and picked up some firewood. Nice flat surface. Love it. Only way to go. 430919


Comments

Everything is working as it should. Great Equipment

Rick W - 09/11/2018

43456

- C60721

by:

Review from a similar Curt Double Lock in Gooseneck


The site is good, easy to use. My order shipped the same day I ordered it on Saturday And arrived the following Tuesday. The written directions weren't the best but found a YouTube installation video from the manufacturer and it made it seem very simple. 576027



- C60712

by:

Review from a similar Curt Double Lock in Gooseneck


Great product put my under bed 5th wheel hitch in about an hour and a half. The directions could be a lot better. But it was delivered early in great shape and works awesome I will be buying more products from this company hands down the best company to deal with Michelle s was a great lady to deal with up front and honest and takes the extra steps. Thanks etrailer 515008



- C60734

by:

Review from a similar Curt Double Lock in Gooseneck


I order a few hitchs from etrails they always show up fast to my door. I install a curt trailer hitch on my 1996 dodge ram 2500 install was fast and easy took me about 20 mins. Now I have order this curt goose neck hitch for my 1996 haven't got to install it yet but will in the next day. I am sure the install will be fast and clean like the trailer hitch was. Anyone looking to order from etrailers do so. You can not beat there prices and the shipping is fast. Thanks etrailer 444377


Comments

Both hitches that I installed still work great. I hauled a bunch of stuff this year from small lawnmowers to hualing my 25ft pj gooseneck pulling skid steers. Never had a issue they been great

Shawn M - 10/20/2018

44847

- C60751

by:

Review from a similar Curt Double Lock in Gooseneck


No issues with this hitch after one year. I don't have a need to hide the ball so I can't comment on how easy that part works. (I thought I would need to hide the ball - but, have found that I just don't use the truck bed that way very often!) 446178



- C607-604

by:

Review from a similar Curt Double Lock in Gooseneck


Great product, easy install. E-trailer shipped it fast but when I received my hitch UPS destroyed the box in transit and I was missing a lot of stuff. One quick call to customer service and Bryan W had the missing parts shipped out that day! I highly recommend etrailer and will be a future customer 453874



- C607-604

by:

Review from a similar Curt Double Lock in Gooseneck


This company helped me from step 1 on deciding which gooseneck hitch to go with, installation videos and checking up on after receipt of the hitch. The hitch was super easy to install with the template for drilling the hole that was included, this hitch by far exceeds the little extra touches you get with a more expensive hitch, the pull handle is a heavier gage, the double locking pin, and even the dust cover to keep out the dirt and gravel from the turnover ball! Great product 378880



- C607-604

by:

Review from a similar Curt Double Lock in Gooseneck


I ordered my hitch on Tuesday afternoon and received it Friday morning. Saturday morning I put it took about 3 1/2 hours to install which included 45 minutes to get the lock off the spare tire. Struggled to get the bolts in the frame but other than that everything went smooth. It looks real nice in the bed of my 2500 chev. Now to finish lunch and hook onto the trailer and go. 478582



- C607-604

by:

Review from a similar Curt Double Lock in Gooseneck


Very satisfied with hitch . Installation was Easy , except drill template was made improperly and extra measurements were required prior to drilling 4" ball hole. Also would suggest that Curt should clean paint out of all threaded holes prior to shipping. 269832


Comments

Great, have bought and installed one in my 2017, design improvements for drill template and frame flange mounting are great

Norvin M - 07/09/2017

25839

- C60712

by:

Review from a similar Curt Double Lock in Gooseneck


Great value, arrived in just a few days. Looking forward to installation when time permits. Install helps look good. 442950


Comments

All good..no change.

Bob R - 10/16/2018

44713

- C60712

by:

Review from a similar Curt Double Lock in Gooseneck


This is the second Curt gooseneck hitch I've purchased from Etrailer. One for a '15 Chevy 3500 and one for an '05 Chevy 2500. Both arrived in 3-4 days. Both installations went very well. I'm very satisfied with the service and the quality of the hitches and installation kits. Good job, Thanks Guys! 286541



- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


Installation was quick and simple and the instructions where easy to follow! So far the components have yet to deteriorate at all, even with all the abuse I put it through! Great product and highly recommended! 328595



- C607-604

by:

Review from a similar Curt Double Lock in Gooseneck


I got a Curt gooseneck C607-604 and installed it on our '15 Chevy 3500 pick-up. No problems with the installation. It was shipped and arrived quickly. Altogether a very good experience dealing with Etrailer. Great price! Thank you and looking forward to dealing with you again. 230430



- C60751

by:

Review from a similar Curt Double Lock in Gooseneck


Installation was a little difficult, some mods had to be made but once installed all is great. Thanks 479871



- C607-604

by:

Review from a similar Curt Double Lock in Gooseneck


It’s been one year since I installed this gooseneck hitch on my truck. The video was straightforward and I was able to install an afternoon. Since then I have towed my horse trailer several thousand miles in all sorts of climates and conditions with absolutely no issues. Only suggestion , Is make sure every six months or so you lube the height of all lever and mechanism to prevent sticking. I installed this hitch for a fraction of what all the local trailer and towing stores quoted me. 546020



- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


I’m extremely happy with the gooseneck under the bed hitch the service and also the shipping I ordered it on the 15th and got it on the 17th in just two days. I would order from this company again 555753



- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


Might be a good hitch for a single rear wheel gasoline truck but is a nightmare to install on a DRW diesel truck. C-brackets are a pain with fuel tank. No room to get tools in etc.. Lessons learned............. Drop the spare, remove the rear wheels, remove the exhaust from the cab back. The instructions and the video both state that you don't have to any of the above. Yeah right. He also demonstrates removing the ball by turning the release handle to the left to lock it while you remove and replace the ball........... Handle is bolted in rigid and does NOT rotate. I don't see any way to lock it open either. (tarp strap to the fender maybe?) You can put the ball in pretty easily but removing will require 2 people as near as I can figure. Pre sale looked pretty good but........... etrailer on the other hand is still a great company to purchase all trailer needs from. Fast prepaid shipping etc.. Will continue to purchase from etrailer but not too sure about this particular brand of hitch. 572328



- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


Curt Double Lock Flip and store Gooseneck Hitch was a good buy, installation went well, just as the video showed. The only problem was the exhaust pipe clearance. Tweaked the spacer and used only the back half of it and got the clearance I needed 522953



- C607-661

by:

Review from a similar Curt Double Lock in Gooseneck


Fast shipping! Product quality is great. The instructions were adequate but could be better. Would definitely buy from etrailer again. 569607



- C607-649

by:

Review from a similar Curt Double Lock in Gooseneck


Installed easy great product great price I recommend them to anybody fast shipping fit right in my 2018 Ford F150 4-wheel drive 570100



- C60712

by:

Review from a similar Curt Double Lock in Gooseneck


The box was beat up very bad but nothing was missing, just too heavy for UPS to carry. The installation was a little different for me than the videos I watched, on my 2003 Silverado 1500HD the right shock and gas tank was too close to truck bed and it made putting the under bed plate in very difficult, I should have just taken truck bed off. The cross bars that the under bed plate bolted in was very hard to get bolts into even after I cleaned the bolt hole threads out and sprayed WD40 into the bolt holes. It took me by myself almost 5 hours to get it installed but I got it in last Saturday, I will never do this again. 514983



- C60751

by:

Review from a similar Curt Double Lock in Gooseneck


Hitch seems to be working properly. The instructions were a bit hrs to follow, but with the use of a hammer and a little know how everything fit. I have a plastic bedliner, so instead of guessing where to drill the 4" hole, I just removed the liner to drill hole, then replaced it before installing the hitch. 2012 Toyota Tundra Double Cab 6.5 ft. Box. 356540



- C607-604

by:

Review from a similar Curt Double Lock in Gooseneck


Easy to install just follow the video on website. I did it by myself. Took about 2 hours. Thanks. 360894


Comments

After one year the hitch is still working great. I tow my tractor all the time with no issues.

Roy D - 03/31/2018

36619

- C60712

by:

Review from a similar Curt Double Lock in Gooseneck


Easy to install, especially after watching the installation video. Hitch works great with no issues! The flush mount design to the bed allows me to remove the ball and use the space for other cargo without a "bulge" in the center of the bed. I am very happy with the hitch and would suggest it to others! 369798



- C60712

by:

Review from a similar Curt Double Lock in Gooseneck


I took my time it went on very smooth,to me great prouduct. 210413


Comments

VERY GOOD,OUTSTANDING/.

dale m - 07/08/2016

19187

- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


I have installed this hitch and the B&W equivalent on identical trucks. The B&W is about $100 more but took me less than half the time to install. They are very similar but in my opinion the B&W is worth the extra money if you are I talking it yourself. 478729



- C60723

by:

Review from a similar Curt Double Lock in Gooseneck


Hitch showed up sooner than I anticipated. Install was straight forward, everything went together extremely easily. Fit finish, and level of craftsmanship was top quality, install took about 2.5 hours in my driveway, with basic hand tools. Absolutely outstanding American made product, made sold and serviced in the USA. I really believe the top quality finish and engineering of this hitch made it install so easily. 396064



- C60607

by:

Review from a similar Curt Double Lock in Gooseneck


Seems very well built. Fit and finish are great. I installed on a 2015 Sierra with the EZr mounting bracket and the only downfall of the combination was a very difficult installation...think bottle jacks and hammers. 504346



- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


Hitch seems well made, install took about 2.5 hours by myself, will use it to tow stock trailers mostly. Great price and shipped quickly. Thanks 485853



- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


This has been a great hitch so far. I installed it myself with help from a friend and have had no problems. It fit perfectly in my F250. The video had easy to follow instructions. In all it took maybe 2 hours. 400775



- C607-661

by:

Review from a similar Curt Double Lock in Gooseneck


Curt and Pollak make a great product and etrailer is a great site, I come here for all my towing needs now! My only issue is that the instructions for the gooseneck hitch were kind of vague. I got it on in about 3 1/2 hours taking my time and making sure it was right. Other than that I would purchase a Curt and Pollak product again! 454991



- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


The directions could be a little better for the install kit. The kit is for a 99 and newer f250. Mine is a 2016. The fit was questionable. But turned out good. Would be nice if it had a template for the safety chains to use as a guide. Too much stuff in the way under the truck to get a good clear shot at them. All and all I am very happy with it. I don't install this type of stuff all the time. But can be done right. Just take your time. Thanks. 320655



- C607-604

by:

Review from a similar Curt Double Lock in Gooseneck


Haven't installed, but product was shipped extremely fast. Components are very well built and nothing was missing. The installation video said to tap the installation holes with a 1/2-13 tap prior to install to remove overspray from coating. This is very good advice as 1/2 inch bolts will thread in but give resistance the whole way in if coating isn't removed with the tap. Mine was shipped in two boxes making it easier to handle than having all the weight in one box. Overall I believe this is a very good product at a very good price. I also ordered a 7 blade Hopkins wiring kit #47210. This was also well built. The only purchase I had to make was the self tap mounting screws as mounting hardware is not included. 430437



- C607-604

by:

Review from a similar Curt Double Lock in Gooseneck


The video was extremely helpful. All holes lined up and installation went smoothly. 519773



- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


The product looks like it's great and delivery was very prompt but one of the packages was all torn and we still don't know if we have all the parts since we haven't put it together yet. The bag with the nuts and bolts in it was torn and were spilling out of the opened end of the box when it was delivered. We are concerned that some might be missing. 501315



- C60712

by:

Review from a similar Curt Double Lock in Gooseneck


Product came with some packaging damage, and a few things were missing. I called customer service and they were very quick to resolve the problem and send me out new hardware and the missing parts. Overall a great experience and will buy from them again in the future. 494630



- C60720

by:

Review from a similar Curt Double Lock in Gooseneck


Haven't installed yet but I actually received my order the next day! Granted we're only one state away but still impressive! I had originally ordered my hitches on Amazon but received the Wong ones, I decided to go with someone that actually delt with hitches. I Google searched and etrailer came up so far 5 stars 316037


61
222
Show More Reviews

Ask the Experts about this Curt Gooseneck
Do you have a question about this Gooseneck?


  • Recommended Curt Gooseneck Hitch for 2018 Chevy Silverado 1500 with 5-1/2 Foot Bed
  • I do have a solution for you, however the Curt Double Lock Underbed Gooseneck Hitch # C607-604 referenced in your question is only designed to fit the 2018 Silverado 2500 or 3500 that features a longer bed. It will not work on your Silverado 1500 that has the 5-1/2 foot bed. For the Curt Double Lock Gooseneck Hitch that is designed to fit your truck you instead need the part # C615-632. This is confirmed to fit and includes custom brackets that use existing holes in the truck's frame...
    view full answer...

  • How to Determine if a Short Bed Truck Will have Enough Clearance to Make Tight Turns
  • The issue you will run into is that when you go to make tight turns the storage area on your trailer (depending on the dimensions of it), will most likely hit the cab of the truck since your truck bed is so short. Here is a formula you can use to determine if you have the needed clearance. (A + B) - C = Clearance A = Distance from the gooseneck ball to the truck cab B = Offset used, like if you used a Offset Extension Ball # 19308 C = Width of the nose of the trailer divided by 2. I...
    view full answer...

  • Gooseneck Hitch for 2008 Chevy Silverado Crew Cab with 5-1/2 Foot Bed
  • For a 2008 Silverado Crew Cab with the 5-1/2 foot short bed, the Curt Gooseneck Hitch and Install Kit # C615-632 is indeed the correct gooseneck hitch. For install details, click the provided links.
    view full answer...

  • Is Curt Gooseneck Hitch Compatible With Air Bags on 2017 Chevy Silverado 1500 Short Bed?
  • I can confirm for you that yes, the Curt Gooseneck Hitch # C615-632 will work with the Air Lift LoadLifter 5000 # AL57204 as well as # AL88204, with the only difference being the internal jounce bumpers that are on the # AL88204 kit. These kits contain instructions (which are linked for you) for installation on trucks with a gooseneck like your 2017 Chevy Silverado 1500 will have. I also recommend checking out the Air Lift WirelessONE Compressor System for Air Helper Springs # AL25870...
    view full answer...

  • Can a 2008 Chevy Silverado 1500 with a 5-1/2 foot bed Tow a Gooseneck Stock Horse Trailer
  • The Curt gooseneck hitch part # C615-632 that you referenced has been confirmed as a fit for your 2008 Chevy Silverado 1500 with a 5-1/2 foot bed. Since you said the horse trailer is a stock trailer that would typically mean that the nose of it does not have a storage area or living quarters and that the front of the trailer would come to a very narrow point where the coupler installs. I attached a picture that shows the style of gooseneck trailer that would work on a truck with as short...
    view full answer...

  • Can 2018 GMC Sierra 1500 5-1/2 foot Bed Tow Gooseneck Trailer
  • For a truck like your 2018 GMC Sierra 1500 that has a 5-1/2 foot bed it's typically not recommended to try and tow a gooseneck or fifth wheel hitch trailer. Unless the nose is tapered like a stock trailer where there's essentially no nose you'll have turning clearance issues. If the nose is tapered like that we have the Curt gooseneck hitch part # C615-632 as a confirmed fit which will work well. This hitch gives you a setup where you can flip the ball upside down when not needed and is...
    view full answer...

  • Gooseneck Ball Hitch For 2016 Chevorlet Silverado 1500 With 5-1/2 Foot Bed
  • We do have gooseneck hitches that will fit a 2016 Chevorlet Silverado 1500 truck with the 5-1/2 foot bed. However, the Curt hitch model # C61301-52 that you referenced is an over the bed hitch that was not designed to fit in a 5-1/2 bed. If you are looking for an over the bed gooseneck ball hitch the Curt Overbed, Folding Ball Gooseneck Trailer Hitch with Installation Kit, # C61331-52 is designed to fit a 2016 Chevy Silverado with the 5-1/2 foot bed. If you are interested in a below...
    view full answer...

  • What are Determining Factors for Figuring Out if Truck and Gooseneck have Trailer Turning Clearance
  • With a 5-1/2 foot bed you would need all the offset you could get to make a 90 degree turn honestly. There are two determining factors for whether or not you need an offset. The first is the width of the nose of your trailer and then the distance from the center of the gooseneck ball to the truck cab. If the front of your trailer is very narrow you would have your best chance of making a sharp turn. If the trailer has living quarters or a square nose at all then you would be out of...
    view full answer...

  • Recommended Gooseneck Hitch for a 2008 GMC Sierra and Trailer with a Ranch Hitch 5th-Wheel Adapter
  • I would recommend the Curt gooseneck hitch kit # C615-632 for your truck, which will work whether you have a 6-1/2 or 8 foot bed on your 2008 GMC Sierra. Please note that if your truck has a 6-1/2 foot bed, you should be using a fifth wheel to gooseneck adapter that has an offset to give you enough clearance in tight turns. Ranch offers the offset section as a replacement part # AM3140, if needed. It would be a good idea to purchase the Ranch Hitch safety chains, part # AM3109. You may...
    view full answer...

  • Fifth Wheel Towing Setup Recommendation for a 2011 Chevy Silverado 5-1/2 foot Bed
  • Since your truck has a 5-1/2 foot bed the only way you are going to be able to tow a fifth wheel trailer is if you go with a fifth wheel rail kit and hitch plus a Sidewinder pin box on the trailer. There's no offset hitch or adapter for the gooseneck route that would allow this to happen. First you will need to start with a rail kit. For that you would want to go with a custom install kit that will minimize drilling when compared to a universal kit like the part # RP50064-58. For...
    view full answer...

  • Best Gooseneck Trailer Hitch for 2012 GMC Sierra 1500 With 5-1/2 Foot Bed
  • The best gooseneck trailer hitch for your 2012 GMC Sierra 1500 with a 5-1/2 foot bed is the Curt Double Lock, Flip and Store Underbed Gooseneck Hitch w/ Installation Kit # C615-632 because of its completely secure system which locks the hitch ball into place with two locking pins as opposed to the standard single-pin mechanism. This hitch will also install in your '12 Sierra without needing to drill into your frame brackets; I have added a link to a video of this hitch being installed...
    view full answer...

  • Where is Gooseneck Hitch Ball Location for Curt Double Lock # C615-632 on a 2008 Silverado 6-1/2 Bed
  • If you look at the first page of the linked "alternate" installation instructions for the Curt Double Lock, Flip and Store Underbed Gooseneck Hitch w/ Installation Kit # C615-632 you will see that it has a few different bed length options. Since your 2008 Chevrolet Silverado has a 6-1/2 foot bed you will want to look at the measurement for the 78.80 inch bed installation. If you measure from the back of the truck box (not the tailgate) then you will want to measure 42-7/16 inches towards...
    view full answer...

  • Parts Recommendation to Tow a Fifth Wheel Trailer with a 2014 Chevy Silverado 1500 5-1/2 ft Bed
  • You can tow a fifth wheel trailer with your 2014 Chevy Silverado 1500 with a 5-1/2 foot bed. First you will need a rail installation kit. For that you will want the Reese Fifth Whee Installation Kit part # RP50064-58. This is a custom install rail kit that will install in about half the time as a universal kit and will minimize drilling. Since your bed is so short you will need a hitch with a Sidewinder to be able to make 90 degree turns. For a hitch I would recommend the Reese Fifth...
    view full answer...

  • How Does Curt Gooseneck Trailer Hitch and Install Kit C615-632 Attach to a 2009 Chevy Silverado
  • The Curt gooseneck trailer hitch # C615-632 bolts to rails included with the installation kit and the rails are attached to brackets that bolt to the outside of the truck frame rails. I have included a link to the instructions for you and a picture that is basically a diagram showing how it attaches to the truck.
    view full answer...

  • Using Air Lift Air Bags with Curt Gooseneck Trailer Hitch on a 2012 GMC Sierra 1500
  • Yes. If you replace the U-bolts used in Air Lift air bags # AL88204 with the bolt as indicated in the instructions it will be compatible with the Curt Curt Double Lock, Flip and Store Underbed Gooseneck Hitch # C615-632. If your truck is a short bed then the approximate distance from the back of the cab to the center of the ball is 35 inches. On a long bed that distance is 47 inches. At some point you will need to make a 90 degree (or more) turn. If you are towing a 5th wheel trailer...
    view full answer...

  • Can the Air Lift # AL57204 Install on a 2009 Chevrolet Silverado 1500 with a Curt Gooseneck Hitch
  • I did some checking and it looks like the Air Lift LoadLifter 5000 Air Helper Springs # AL57204 are compatbile with both of the Curt gooseneck options, part # C61331-52 and part # C615-632, for your 2009 Chevrolet Silverado 1500 5-1/2 foot bed. A lot of air bag kits install using the same mounting holes along the frame that a 5th wheel or gooseneck hitch would use. This is why you were seeing that most of them say they are not compatible. The Air Lift LoadLifter 5000 Air Helper Springs...
    view full answer...

  • Under Bed 5th Wheel Trailer Hitch Installation Kit for a 2015 GMC Sierra 1500 Short Bed
  • Reese does not offer an under bed 5th wheel installation kit for your 2015 GMC Sierra 1500. The least expensive under bed and hitch option is going to be from Demco using installation kit # DM8551008 and HiJacker hitch # DM8550022 for a short bed. Another option is to use Curt gooseneck hitch # C615-632 and X5 adapter # C16210. The X5 adapter fits in the gooseneck ball hole for this gooseneck hitch and provides standard rails to mount a hitch. If you do not already have a hitch you can...
    view full answer...

  • Does Spray-In Liner Change Measurement When Installing Gooseneck Hitch On 2009 GMC Sierra
  • Since the measurement needed when installing the Underbed Gooseneck Hitch, part # C615-632 requires you to measure from the rear of the truck bed, you will need to make sure you measure the distance taking into account the spray liner if it is on the back edge of the truck bed. If it is 1/8 of an inch you need to add that 1/8 inch to the measurement for the 4 inch hole to be drilled in the truck bed.
    view full answer...


Do you have a question about this Gooseneck?




  • Why etrailer.com?

    At etrailer.com we guarantee:

  • Highest quality gooseneck for the best price.

    Our Lowest Price Pledge ensures you will never overpay for the parts you need.
  • Real product know-how.

    We make sure that the products we sell are what we say they are, and that they work the way they are supposed to work. Get real advice from a real person who has the knowledge and expertise needed to solve your problem.
  • Most detailed, accurate gooseneck information available.

    Because we take providing accurate product information seriously, we take our own detailed product photos, demo videos and installation videos, as well as verify measurements, instructions, and vehicle fit information.
  • Installations, made easy.

    We love helping people and have the most highly-trained customer service, hands-on experience, step by step videos and installation instructions.
  • Fast shipping.

    Your order is automatically routed to get out of our warehouse and to your door as quickly as possible. Receive free shipping on orders over $99.
  • Personalized service for life.

    We provide one-on-one, personalized service from the ordering process through the life of your product.
  • Trusted since 1946.

    We've been serving customers since our parts store first opened in 1946 and continue to be recognized by our customers, our vendors and third parties for exceptional service.
  • Returns Policy

    Satisfaction Guarantee
    Need to return an item? No problem. Please read our Returns Policy for more information.

Info for this part was:

Photos by:
Theodore B
Expert Research:
Michael L
Updated by:
Lindsey S
Expert Research:
Michael H
Expert Research:
Jameson C
Video Edited:
Jacob T
Video Edited:
Chris R
Updated by:
Sarah W

At etrailer.com we provide the best information available about the products we sell. We take the quality of our information seriously so that you can get the right part the first time. Let us know if anything is missing or if you have any questions.



Product Experts Available Now!

Call 800-298-8924


^
About Us
photos and videos
1,056,204 Original Photos & Videos

Produced to make sure you know what you are getting and you get exactly what you need.

installations
35,570 Installations Completed

To make sure products work and fit the way they are supposed to.

etrailer call center
2,476,511 Phone Calls & Emails Answered

1,125,924 phone calls and 1,350,587 emails to help find the right solution.

etrailer training
400+ Average Hours of Product Training

We get to know our products firsthand so experts can better help you.

etrailer service
73 Years of Quality Customer Service

Assisting our neighbors and customers, face to face at the counter.

etrailer experts
193,357 Pages of Expert Information

Created to make sure you have all the answers to your questions, from real experts.
