Kodiak Hydraulic Brake Hose - 3/16" Male Fittings w/ Stainless Flares - 1/8" ID - 20'
(39 reviews)
Price: $48.80
In Stock
Kodiak Hydraulic Brake Hose - 3/16" Male Fittings w/ Stainless Flares - 1/8" ID - 20'
Item # bh-3mfs-20
Retail:$52.85
Our Price: $48.80
You Save: 8%
Orders above $99 qualify for Free Shipping
In Stock
- All Info
- Reviews (39)
- Q & A (14)
- Photos
- Why etrailer?
Kodiak Accessories and Parts - bh-3mfs-20
- Trailer Brakes
- Disc Brakes
- Hydraulic Drum Brakes
- Brake Lines
- Kodiak
- Brake Line Components
- 20 Feet Long
- Flexible Brake Hose
This flexible, rubber brake line acts as part of a trailer's hydraulic braking system. Stainless steel flares, brass fittings, and a high thread engagement help prevent splits, corrosion, and leaks. Includes 2 standard male flare nut fittings.
Features:
- Brake line connects hydraulic brake actuator to trailer brakes when used with additional lines, tees, and fittings (sold separately)
- Flexible design makes hose easier to install than a rigid steel brake line
- Stainless steel flares resist corrosion and are stronger than brass to reduce splitting
- Ideal for boat trailers
- Deep threads improve connection to help prevent leaks
- Rubber hose meets DOT and SAE standards
- Brass, male swivel flare nut fittings on both ends
- Swivels allow flare fittings to turn without the hose twisting
- Double-crimped brass ferrules securely clamp fittings to hose
- Open area on flare fittings lets you use a line wrench for better grip
- Minimizes the risk of stripping threads
Specs:
- Hose length: 20'
- With fittings: 20' 3"
- Hose inner diameter: 1/8"
- Fitting size: 3/16"
- Thread size: 3/8"-24
- 3-Year limited warranty
Flexible Rubber Brake Hose
This Kodiak brake hose is made of rubber, making it a practical choice for a variety of applications. Because you can easily bend it, a rubber hose is simpler to work with than a rigid stainless steel brake line. This flexibility makes a rubber hose great for use with foldaway trailer tongues because it is less likely to kink or break when bent. In addition, rubber hoses allow for a wide range of motion so articulating parts can effectively function. These qualities make rubber hoses better suited than steel lines for trailers with torsion axle suspension systems and trailers that have disc brakes.
Stainless steel brake lines have braided exteriors, which can not only wear against exterior surfaces, but also against the interior lining of the hose if dirt gets underneath the steel braid. And if the braid on a stainless steel line tears, it can cut into the hose lining. The exterior surface of this hose is solid rubber, so there are no crevices for debris to enter.
Durable Fittings with Deep Threads
Kodiak brake hoses have corrosion-resistant brass fittings with stainless steel flares. These fittings have a gap built into them that allows room for a line wrench - also called a flare nut wrench - to slide over the line and down to the nut. This type of wrench grips the nut better than a standard open-ended wrench so there is less chance of stripping the threads as you tighten down the nut.
The stainless steel that is used to create the flares on this hose is stronger than brass. As a result, these fittings are more durable than ones made entirely of brass. The stainless flares are primarily designed to keep the fittings from splitting when you tighten them down, but they offer absolute rust protection as well.
Kodiak's fittings have deeper threads than many other fittings on the market to provide a higher thread engagement. Deeper threads offer an advantage when used with fittings that have the same thread depth. These Kodiak fittings will work with most fittings on the market, but when they're used with other Kodiak fittings, the result is a stronger connection with fewer leaks.
BH-3MFS-240 Kodiak 1/8" ID Rubber Brake Hose - 3/16" MFFN with Male Swivels - 240"
Customer Reviews
Kodiak Hydraulic Brake Hose - 3/16" Male Fittings w/ Stainless Flares - 1/8" ID - 20' - bh-3mfs-20
Average Customer Rating: 5.0 out of 5 stars (39 Customer Reviews)
This flexible, rubber brake line acts as part of a trailer's hydraulic braking system. Stainless steel flares, brass fittings, and a high thread engagement help prevent splits, corrosion, and leaks. Includes 2 standard male flare nut fittings.
- bh-3mfs-20
by: Lewis06/07/2020
Continue part of brakes overhaul and line replacement. Very easy install, almost like plug and play, again adding some metal sheathed to shield against rodent possible gnawing. product seems to be well made, much better than my old metal lines.
- bh-3mfs-20
by: Chris07/12/2021
easy ordering and fast shipping.
- bh-3mfs-20
by: Connie12/12/2020
Excellent customer service, fast deliver, items worked as described. This is why we shop only here for all towing and trailer needs. Thanks
- bh-3mfs-20
by: RonA05/29/2017
Ordered a 20" brake line for my trailer and received it quickly and at a very good price. Haven't been able to finish the installation however the ends did fit the master cylinder perfectly, just need some dry weather to get under the trailer and connect the hose to the distribution fitting then bleed the system and away we go.
- BH-3MFS-20
by: Doug P07/22/2015
I like the fact that when ever possible , the products sold are made in the USA. They are reasonably priced and so far, always available. It is vary easy to shop and find all the parts and pieces that I need for my projects at etrailer.com. Even when I may have questions about my project, etrailer.com is just a phone call away with professional help available "immediately". In the future, I will always use etrailer.com for all my trailer needs. This is a top notch company that a person can count on.
- bh-3mfs-20
by: Brian06/30/2019
Great price, fast delivery, I would definitely use etrailer again and recommend them to others. Replaced a broken brake line on surge brakes on boat trailer. We are enjoying the boat at the lake again.
- bh-3mfs-20
by: Art P.08/22/2017
I paid a little extra for priority mail and it was delivered fairly quick. The beak hose is as advertised I installed it within minutes after delivery and it is a perfect fit! I'm happy with this trusted seller and will definitely buy from them again. Art.
- bh-3mfs-20
by: Earl09/10/2020
Everything was as advertised with delivery and shipping as advertised
- bh-3mfs-20
by: Happy Boater06/09/2017
Replaced the steel line on my boat trailer with the rubber hydraulic line. It Worked like a charm. I dreaded having to make up a 20 feet steel line and route it inside the trailer box tubing.
- bh-3mfs-20
by: Jeff06/27/2019
Replaced steel brake line on boat trailer from master cylinder to axle. Worked perfect.
- bh-3mfs-20
by: Daved09/16/2017
Great value. Very well made and a fraction of the cost of the original hose.
- bh-3mfs-20
by: Chuck longwell08/02/2016
All parts were exact fit. I over ordered one of the hoses and I returned it and got a prompt refund.
- BH-3MFS-20
by: Don05/05/2015
this is the best company to find what you need for trailer parts and brake parts. the price is great and the shipping is fast. Dan-- Kona, Hawaii
- bh-3mfs-20
by: Lee08/31/2020
Exactly what i needed. Quality good.
- bh-3mfs-20
by: Dan06/10/2018
Hose worked perfect, buy extra fittings. No matter how you plan putting it together we always wish you had one more elbow or T fitting. Hard to find them In a local store.
- bh-3mfs-20
by: Zach07/17/2017
Great company. Shipped same day to make sure I received products on time for a trip I had planned. Products were great as well.
- bh-3mfs-20
by: Gregory03/20/2018
The brake line worked great on my boat trailer. First class stuff....
- bh-3mfs-20
by: Jeff M04/18/2017
great replacement product for my Tie Down main line on boat trailer.. Fit and ease of install was spot on.
- bh-3mfs-20
by: Mike B05/06/2017
Rebuilding a boat trailer, nice upgrade compared to OEM.
- BH-3MFS-20
by: Don06/29/2015
Great price, quick shipping.
- BH-3MFS-20
by: Ron P10/02/2014
This is the place to shop for trailer p roducts.
- bh-3mfs-20
by: Paul08/26/2018
Received very quickly. Was surprised to see it shipped out as quick as it did. Not an item I can get at the store when I need. Exactly what I wanted. Happy to do business with this company
- bh-3mfs-20
by: Larry W05/02/2017
Product was as ordered, in perfect condition and delivered promptly. Everything fit well and I am super-pleased.
- bh-3mfs-20
by: Darryl05/26/2020
GREAT VALUE
- bh-3mfs-20
by: Ken B.02/26/2019
Performs as designed.
27
41
Show More Reviews
Ask the Experts about this Kodiak Accessories and Parts
- Will Kodiak Brake Line # BH-3MFS-20 Work with UFP A75 ActuatorYes, the Kodiak Hydraulic Brake Hose # BH-3MFS-20 that you referenced is the correct brake line to use with your UFP actuator as it has the same fitting size of 3/16 inch.
view full answer... - Will Kodiak Brake Line # BH-3MFS-20 Fit Tie Down ActuatorI looked up the part number you listed and it's a standard brake line what is used on most surge brake actuators. That means the Kodiak part # BH-3MFS-20 would fit and work well since it uses the same thread size of 3/8"-24.
view full answer... - Replacement Brake Line For 1999 Trailer For Larson 233 Escape BoatThe best way to find a brake line that will work for your trailer is to take a quick measurement. You will want to measure from the actuator at the front of your trailer back to the Tee for the brake lines running to the brakes. From my research I saw that the Larson 233 boats were all on tandem trailers. I have attached a link to the brake lines product page we offer. You can select a line that best matches the length of the line you are wanting to replace or you can go with an easier...
view full answer... - Availability of Rubber Brake Line for 22 foot Continental Boat TrailerWe have rubber brake lines that will work but I don't know exactly what length you need so we have a few options you will need to consider. Part # BH-3MFS-20 is 20 feet long, part # BH-3MFS-24 is 24 feet long, and # BH-3MFS-18 is 18 feet long.
view full answer... - Outer Diameter Dimension of Kodiak Brake Line Rubber HoseI was able to go out to the warehouse and measure the outer diameter of the hose on the # BH-3MFS-20 for you and found that it was .411 inches with a digital caliper like # PTW80157 which is just under 27/64ths of an inch.
view full answer... - Kodiak Brake Line # BH-3MFS-20 Pressure RatingAccording to my contact at Kodiak Trailer, their # BH-3MFS-20 Brake Hose has a maximum psi rating of 3,000 lbs. That's about twice as much as what's normally seen in a disc brake setup.
view full answer... - Shorter Brake Line Recommendation than Kodiak Hydraulic Brake Hose BH-3MFS-20We have the 7 foot section part # BH-3MFS-7 which is the shorter version of the # BH-3MFS-20 that you referenced. Or for just slightly shorter we have the 18 foot long section part # BH-3MFS-18.
view full answer... - Will Kodiak Hydraulic Brake Hose BH-3MFS-20 Work with Surge BrakesYes, the brake line part # BH-3MFS-20 that you referenced is perfectly compatible with trailers that have surge brakes.
view full answer... - Could Kodiak Hydraulic Brake Hose # BH-3MFS-20 be Used on TruckThe Kodiak Hydraulic Brake Hose # BH-3MFS-20 you referenced meet and/or exceeds SAE and DOT standards so there's no reason you couldn't use it on your truck.
view full answer... - Option for Getting 21 Foot Long Flexible Brake Line SectionIf you need a section of flexible brake line that is longer than the # bh-3mfs-20 you would want the part # bh-3mfs-24 which is 24 feet long instead. I wish we had a 21 foot long section but you would either need to use the 24 foot section or add a 1 foot section to the 20 foot section with part # bh-3mfs-1.
view full answer... - Compatibility of Kodiak # BH-3MFS-20 Flex Brake Hose with Disc Braking System on TrailerThe Kodiak 20 foot long flexible brake hose, part # BH-3MFS-20 would work great connecting your brake actuator to the disc brakes on your trailer. Brackets like # T0776300 and tees like # BH-T-3FIF are sold separately. Shorter lengths of hose like # BH-3MFS-3-5 are available to join the tee to the brake calipers.
view full answer... - Replacement Brake Line/Hose for Dexter 8K Disc Brake AxleThere are several brake lines in varying lengths and sizes between your disc brake assembly and the surge brake coupler on your trailer. I am not sure which one you are looking for but if you can pinpoint this for me I may have some better advice for you. In the meantime, I have attached for you a photo that shows what brake lines go to and from a disc brake assembly and surge brake coupler on a tandem axle trailer. A) Kodiak Hydraulic Brake Hose part # BH-3MFS-20 (3/8"-24 x 20') *20'...
view full answer...![Image 1 for]()
- How to Install a Fold-Away Coupler Hinge Kit on a Trailer with Surge BrakesIn order to install a Fulton Fold-Away Coupler Hinge Kit like part # FHDPB230101 on a trailer with surge brakes you are going to want to use a flexible brake line that runs from the actuator to the t-fitting just before it splits to each braking assembly. This hose can been seen as letter A in the attached photo. The hose can actually be ran through the frame rail you will just need to make sure you have enough slack so it does not put too much tension on the line when the tongue is in...
view full answer...![Image 1 for]()
- Can a 20 Foot Brake Hose be Substituted for 18 Foot Hose on Brake Line Kit?Yes for the Kodiak Hydraulic Brake Line Kit - Single Axle # 18SI-BLKIT what you could do is replace the 18 foot hose with the 20 foot Kodiak Hydraulic Brake Hose # BH-3MFS-20. It is the exact same hose that comes with the Kodiak kit except it is 2 feet longer. I've added a link to a video review of this hose for you to take a look at.
view full answer...
