Yakima Roof Bike Racks - Y02071
Load a bike built for two all on your own with the SideWinder fork mount. Attach your fork with the bike still on the ground, then simply swing the bike into place in the rear cradle. Carrier mounts on either round or square roof-rack crossbars.
Features:
- 1-Person loading
- Swing-out skewer arm for mounting fork first
- Engages with top-mounted knob
- Adjustable, padded boom cradle holds bike more securely than wheel-tray designs
- Firmly grips bike tube with ratcheting wheel straps
- Protects bottom-mounted cables
- Stainless steel skewer
- Adjusts with 1 hand
- Makes loading fast and effortless
- Locks with 1 Same Key System (SKS) Core (sold separately)
- Locks bike to carrier
- Use 4 Accessory Lock Housings (sold separately) to lock bike carrier to crossbars
- Requires 4 additional SKS Cores
- SKS Cores can be changed out to make all your Yakima locks keyed alike
- Tool-free installation
- Stabilizing handlebar strap included
- Compatible with most disc brakes
Specs:
- Capacity: 1 bike
- Compatible with disc brakes
- Application: Mounts on either round or square crossbars
- Minimum crossbar spread of 24"
- Will not interfere with most hatchbacks or flip-up rear doors
- SKS Cores:
- For enhanced security, install 4 Accessory Lock Housings and 4 additional SKS Cores to lock carrier to crossbars
- Skewer handles any 9-mm/100-mm tandem fork
- Center of skewer to center of cradle: 40"
- Swinger extends 10" from pivot
- Weight: 21 lbs
- Dimensions:
- Overall: 56" long x 12" tall x 8" wide at skewer
- Mounting plates: 4-1/2" wide
- Lifetime warranty
Note: Does not work with Yakima Might Mounts.
The SideWinder fork mount makes loading your tandem bike onto a roof rack an easy, one-man operation. So now that you've done all the pedaling, let your riding partner enjoy stowing the bike.
SideWinder operates with a swing-out skewer arm, allowing you to mount the fork first with the bike still on the ground. The arm engages with a top-mounted knob and rotates away from the vehicle for easy access.
Once the bike fork is secure, all you have to do is lift the frame into the adjustable boom cradle. The swing-out arm reduces the weight of the tandem rack as you load it onto your vehicle. The padded cradle firmly grips your bike frame with ratcheting straps and protects bottom-mounted cables.
SideWinder comes with a strap to hold your handlebars in place during transport, providing added stability.
The SKS-lockable skewer holds your bike firmly in place on the fork block, securing with a quick-release lever. You can adjust the skewer - tighter or looser - with one hand by turning the knob hidden inside the lever cover.
For added security, you can lock the carrier to your crossbars by replacing the hand knobs (hex keys) on the bottom of the mounting brackets with up to four Yakima Accessory Lock Housings (Y07220), which require purchase of additional SKS Cores.
SideWinder installs on your vehicle with no tools and fits both round and square roof-rack crossbars. The carrier will not interfere with most hatchbacks or flip-up rear doors and is compatible with most bikes that have disc brakes.
8002071 Yakima SideWinder Roof Mounted Tandem Bike Carrier - Fork Mount
Video of Yakima SideWinder Roof Mounted Tandem Bike Carrier - Fork Mount
Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.
Video Transcript for Yakima SideWinder Roof Mounted Bike Rack Review
Today we are going to show you part number Y02071 from Yakima. This is their SideWinder Bicycle Rack. It is specially designed for tandem bicycles. It mounts on a normal roof rack - either round bars or square bars. It actually pivots out away from the vehicle, making it a lot easier to load your tandem bicycle on it. At this point, we will go ahead and mount this on a typical roof rack and give you a little bit better idea of how it works.
These adapter clips right here snap onto your bars, and then the hardware for the rack itself bolts in through here and then clamps everything into place. You have two that go onto the rear and then on the front, two of them will actually use a U-bolt to clamp onto the front crossbar. Next we will go ahead and install the strap on the bicycle. What the strap will do is keep the handlebars straight on the bike as you load it up and go down the road. Now, how you attach these is going to be a little bit different for each bicycle, since there are different types of handlebars out there. Basically, on this one you do not want a position where it slides off the handle, so we will loop it around and then back over itself. Then take your third strap, and that will go back to your seat post. And then just tighten up the buckle. All right, and it is ready to be loaded onto the bicycle rack.
All right, now that we have got our bicycle rack installed, we will go ahead and load up our bike. A couple of things you need to take care of first we need to swing out our fork mount so we can put our bike on. This little knob and spring-loaded assembly right here just unscrew it and you can just swing it out away from the vehicle. This is your fork mount right here the forks go in here and here. And what is really nice about this, in some applications you have a nut you have to spin on the other side to tighten it up, actually on this one everything is done on one side. So you put your bike up in there, twist it down, and then lock it into place. It is actually pretty neat. And also, once you have it latched into place, you can a lock core here from Yakimas Same Key System. And then on the back half here, you want to get these clamps out of the way. Just push the red buttons and the whole assembly comes out. All right, now we can load up our bike.
And it is securely latched into place. All right, then you can just pick your bike up and swivel it into place. And when you put it on the cradle, you want to go ahead and get a chain past it on the other side, since it is not sitting in the cradle. Get it centered in the cradle, and then go ahead and put your straps back in. Then go back up to the front and secure the front pivot point. And with that, the bicycle is ready to go down the road. All right, and that covers it for our review of part number Y02071 from Yakima. This is their SideWinder Bicycle Rack.
Replacement parts available for this product
Ask the Experts about this Yakima Roof Bike Racks
Do you have a question about this Roof Bike Racks?
- Need To Carry A Recumbent Bike On A 2010 Jeep Patriot Without Roof Rack Crossbars
- On the 2010 Jeep Patriot with the factory side rails that run front to back, but no crossbars you can use the Yakima Sidewinder Tandem Bike Carrier, # Y02071, but you will need to install the Yakima towers and crossbars.
The towers you will need are the Yakima RailGrab Towers, # Y00138. These will attach to the side rails on your Jeep and accept the Yakima Round 48 Inch Crossbars, # Y00408. This setup will give you the cross bars that are needed to use the Yakima Sidewinder Tandem Bike Carrie
view full answer...
- What Will I Need to Haul a Mountain Bike on the Roof on a 2006 Jeep Liberty with Factory Side Rails
- In order to load a bike on top of your 2006 Jeep Liberty you will first need the Thule Roof Rack For 2006 Jeep Liberty, part #s TH450R, and THARB53. The TH450R railing foot pack allows your factory rails to mount the Thule AeroBlade Aluminum Load Bars, part # THARB53. Once both of these items attached to your roof rails you will be ready to mount a bike rack on your roof.
The roof mounted bike rack that the Thule fit guide recommends for your Jeep Liberty is the Thule Sidearm Wheel-Mount Bike
view full answer...
- Will a Sidewinder Rack Secure my Rans Cruz Bicyle on my 2005 Subaru Outback with Factory Crossbars
- I spoke with our contact at Yakima and he said that the Sidewinder should work well on your Rans Cruz Bike.
In order to mount the Sidewinder Tandem Bike Rack, # Y02071, you will need a couple items because your factory crossbars will not be strong enough to mount the sidewinder rack directly.
First thing you will need to install is a set of Yakima RailGrab Towers for Flat and Raised Side Rails (QTY 4), part # Y00138. Next, you will need to install Round 48 inch CrossBars for Yakima Roof Ra
view full answer...
- Parts Needed for Carrying a Cannondale Tandem Bike on a 2008 Toyota Highlander with Roof Rack
- To be able to use the Yakima SideWinder Roof Mounted Tandem Bike Carrier, item # Y02071, on the factory rack on your 2008 Toyota Highlander, you will need to install the Yakima RailGrab Towers for Flat and Raised Side Rails, item # Y00138, along with the Round 58 inch CrossBars for Yakima Roof Rack System, item # Y00409, on your existing raised side rails.
Your factory cross bars cannot be used with tandem bike carriers because the design of the mounting hardware will only work on Yakima roun
view full answer...
- Using Yakima Sidewinder Tandem Bike Rack # Y02071 with Factory Crossbars on 2008 Volvo XC70
- According to our friends at Yakima, in order to use the Yakima SideWinder, part # Y02071 with your 2008 Volvo XC70 you would need to temporarily remove the factory crossbars, and use a combination of Yakima RailGrab Towers, part # Y00138 and 48 inch CrossBars, part # Y00408. The RailGrab Towers would attach to the existing side rails that run from the front to the rear of the vehicle roof. Yakima does not include end caps with their load bars. They are available separately as part # Y8007026.
view full answer...
- Recommendation for Carrying a Recumbent Bike on a 2012 Jeep Wrangler Sahara
- The best solution would be to use a trailer hitch and hitch mount recumbent bike rack. For a trailer hitch I reocmmend the Draw-Tite, # 75515. The receiver on this hitch is a little longer which will help to clear the spare tire mounted on the back. I have included a link to the installation details for you to view.
If your recumbent bike has 3 wheels, and has the pedals in front of the front tire, (tadpole style), I recommend using the CycleSimplex Tadpole Trike Rack, # R2TK1TAD.
If the b
view full answer...
- Parts Needed to Install Yakima Sidewinder Rack # Y02071 on 2006 Ford Escape With Factory Cross Bars
- To install the Yakima SideWinder Roof Mount Tandem Bike Carrier, part # Y02071, on your 2006 Ford Escape you will first need to remove your factory cross bars from the roof rack. Then, install the Yakima Landing Pads, part # Y00221, to the factory side tracks on your Escape, that run from front to back. These landing pads will provide a mounting point for the Yakima Control Towers, part # Y00214. The last part you will need are the Yakima Cross Bars, part # Y00408. These cross bars will attach t
view full answer...
