The Vanish tonneau delivers a sleek, ultra-low profile and great features at an economical price. It sits only 1/2" above the bed, inside your vehicle's rails. EZ-Dials offer quick tension adjustment, and a trigger latch secures the cover.
Features:
Featuring an ultra-low-profile design, the Vanish tonneau from Access rolls up so that you can haul bulky items and rolls down to shield and secure your vehicle's bed and cargo. The custom-fit cover sits only a 1/2 inch above your truck bed and keeps air from getting caught by the tailgate, thus reducing drag. That can improve your gas mileage by up to 10 percent. Velcro closures on the sides help seal the cover to your truck box and allow you to peel it back quickly for loading.
The tonneau stores neatly behind your cab, secured by two elastic straps with large hooks.
The cover fabric is reinforced polyester mesh coated with UV-blocking vinyl, so it won't fade in the hot sun. The material stays flexible down to -40 F and won't shrink, regardless of the temperature. Aluminum bows act as ribbing to support your cover and make it easy to roll up.
Customize the cover tension using the EZ-Dials at the front of the cover, near your cab. Just dial them up or down to change the fit. A reinforced vinyl weather flap runs along the tailgate to help keep out dirt, rain, snow and ice.
The contoured, black powder coated aluminum tonneau rails resist rust. They sit inside your truck-bed rails so that you can still use stake-pocket-mounted accessories, such as ladder racks and tie-down anchors. Easily install the rails on a truck with an under-the-rail, drop-in bed liner. Over-the-rail liners can be cut to make room for the installation clamps.
The tonneau's rails attach easily to your truck-bed side rails using Tight Bite clamps. The specially designed teeth on these clamps seize the integrated ridges in the rails, ensuring a firm grip.
Once the cover is unrolled and in place, the trigger latch engages automatically to hold the tonneau closed. To release the cover, simply pull the latch for easy, one-hand operation. For added security, lock the cover on both sides using the two slide locks. And locking the tonneau won't interfere with your tailgate - open and close it as usual or add a tailgate lock (sold separately) to get secure storage for your cargo. Cover your assets with this tonneau from Access.
Video of Access Vanish Soft, Roll-Up Tonneau Cover
Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.
Today we are going to install part number 91309 from Agri-Cover, and this is their Vanish low-profile roll-up tonneau cover. And we are going to install this on a 2006 Ford Super Duty long-bed pickup. Our first step involved is go ahead and, we are going to do the side rails first. What is going to happen is the rail is going to fit on the inside edge of the bed, pushed all the way to the front of the box. And you want this edge to match the top edge of your bed rail. Once you have it the way you want it, you go ahead and clamp it into place. Then we will go back with the regular, permanent clamps. Go up as far as you can on the bed. And then the other half is adjustable where it matches the teeth in the rail. Now, you want to install your clamps as evenly as possible across the rail.
Next, we will install the tensioners. And there is a nut that is already in the channel here, so we will just go ahead and put our tensioner in there. And install our bolt - just start it into place. Now, we are not going to tighten it up because we still have to adjust it back and forth. And this part gets attached to the rails, and what that does is it actually moves the tonneau in and out, as needed, to get the tension that you want. We will go ahead and put the tonneau cover itself with the front rail and we will put it on the truck. We will put it up toward the cab. Now put your tensioners to the inside so the attachment can go back to the frame rail right here. And, once you have it in alignment right here, go ahead and run your bolt through. Now, it is not going to be a perfect alignment so the bolt will actually thread its way through. But you will put a nut on the bottom of it also. Once you have this tightened down, you can go ahead and tighten down the nut that holds the crossmember in place up front.
You are probably going to have to take a few test runs of rolling up the tonneau cover and see how it fits in the back. If it is too tight or too loose, then you will have to adjust it up front here. And all you have got to do is spin this dial right here, whichever way you need to go. We did it in 1/4-inch increments until we found out the best way to tighten it down. Once you have it the way you want it, just roll it out, and then it just locks into place. Then you just go ahead and seal down your sides. Next, you want to check for proper clearance on your tailgate. And it is OK if the tailgate kind of pushes it up just a little bit. To unroll it, just undo this latch right here. And you also have an additional, manual latch on the other side, too. And just roll it up when you need access to the truck bed. It also comes with straps to tie it down when you need to use the truck as a truck. It has these little loops they go in two in the front. All right, that covers it for part number 91309 from Agri-Cover, their Vanish low-profile roll-up tonneau cover.
1999 - 2007 Ford F-250 and F-350 Super Duty 8 Foot Bed
