Quickly and easily install a 4-way trailer connector on your vehicle with this custom wiring harness. T-One connector plugs directly into existing wiring - no cutting, splicing or tapping required. Includes tail light converter.
Features:
Specs:
Installation
This custom-fit T-One connector plugs into your vehicle's wiring harness, which is located behind the driver's-side interior trim panel in your rear cargo area. You will need to remove the storage compartment door or trim panel to access the harness.
Once installation is complete, the 4-way flat connector will be stowed in an out-of-the-way location within your cargo area.
It is recommended that you use a small amount of grease on all electrical connections - the plugs on your automobile and the 4-pole connector itself - to help prevent corrosion.
Tail Light Converter
A tail light converter is built into this T-One connector. Because most trailers run on a two-wire system - wherein the brake and turn signals are carried on one wire - the separate brake and turn signals from your vehicle's three-wire system need to be combined so they are compatible with the wiring system of your trailer. The tail light converter combines the brake and turn signal functions of your automobile so that they run on one wire to properly activate your trailer's tail lights. Note: This will not affect how the tail lights on your vehicle operate.
Video of T-One Vehicle Wiring Harness with 4-Pole Flat Trailer Connector
Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.
Today on this 2004 Chevrolet Venture we are going to be installing Tow Ready T-One connector, part number 118355. First we are going to access the rear cargo area. Then we are going to remove the side panel access door. Take it off and set it out of the way. You will see there are two fasteners here holding the black cover on, we are going to remove them now. We will set that out of the way. :23
After you remove the black cover panel you will see the white plug. This will be our new connection point for our Tow Ready connector. Now that we have located our connection point, we will take our Tow Ready connector and plug it in. Next we are going to locate our wire. As you can see it already has a ring terminal on it. We will take the supplied self tapping screw and run it into the sheet metal here behind the trim panel. :45
With our ground wire attached we can go ahead and peel back the double sided adhesive here. What we are looking for is a flat, clean surface to mount our converter box to. We will run our 4-pole connector into the cargo area and reinstall our black cover and the interior trim door. With all of the connections made that completes the install of our new 4-pole connector. To use it, we will route it here, to the outside of the vehicle. The weather seal is thick enough that it will not be harmed when closing the back hatch on it. This completes the install of our Tow Ready T-One connector, part number 118355.
1999 - 2004 Pontiac Montana
1997 - 2004 Oldsmobile Silhouette
1997 - 2004 Oldsmobile Silhouette
1997 - 1998 Pontiac Trans Sport Van
1997 - 2005 Chevrolet Venture
1999 - 2004 Pontiac Montana All Models
2005 - 2005 Pontiac Montana SV6 All Models
1997 - 2005 Chevrolet Venture All Models
1997 - 1998 Pontiac Trans Sport Van All Models, including Montana
