Draw-Tite Activator III Trailer Brake Controller - 1 to 4 Axles - Time Delayed
Tekonsha Plug-In Wiring Adapter for Electric Brake Controllers - Toyota and Lexus


Part Numbers: 5520,3040-P

Retail:$153.44

Price:$95.94

Shipping Special





Draw-Tite Activator III Trailer Brake Controller - 1 to 4 Axles - Time Delayed
part number: 5520

Electronic controller activates electric trailer brakes with a preset intensity when you apply the brakes in your vehicle. Digital display, manual override, and a simple, plug-in port included. Power output and braking aggressiveness are adjustable.

Features:

  • Brake controller activates trailer brakes with preset intensity
    • Signal is sent to trailer brakes when tow vehicle's brakes are activated
  • Adjustable output control lets you determine the amount of braking force
    • Set to maximum when you travel through hilly terrain with a fully loaded trailer
    • Back off the power output when you tow a lightweight trailer
  • Sync setting lets you adjust the aggressiveness with which the brakes are activated
    • Get full power output faster by moving switch forward to increase activation speed
    • Achieve smoother braking by moving switch in opposite direction to supply power gradually
  • Digital display is easy to read
  • Built-in, slide-bar manual override
  • Quick and easy installation
    • No need to mount level like proportional brake controllers
    • Mounting bracket, wiring harness and hardware included
    • Plug-in port makes it easy to connect to wiring harness
      • Plug-in, vehicle-specific brake-control adapter can be used for certain applications to reduce installation time


Specs:

  • Application: trailers with up to 4 axles (8 brake assemblies)
    • Designed for use with electric brakes only
  • Dimensions: 3-1/4" wide x 4-7/8" long x 1-1/8" tall
  • Limited lifetime warranty


Time-Delayed Braking

The Activator III applies your trailer's brakes when the brake pedal in your tow vehicle is engaged. Every time you apply the brakes in your vehicle, a signal is sent - via the brake switch - to the Activator. The controller then sends power out to your trailer brakes to activate them with an intensity set by you, at a rate determined by you. Both the amount of braking power (output) and rate of application (sync) can be adjusted to suit your preference, the road conditions, type of trailer and size of the load. To determine which levels are best for your application, you must test out your towing setup and choose what feels best.


A time-delay controller is so named because there is a delay between the time that you initially apply the brakes in your tow vehicle and the time that the controller reaches maximum power output. Unlike a proportional brake controller, which activates your trailer's brakes based on the deceleration of your tow vehicle, the Activator sends power out in the same way, with the same gradual delay, no matter the braking situation. Although this delay always exists, it can be adjusted by changing the sync setting.


Sync Settings

To adjust the aggressiveness of your trailer's braking action, use the slide control on the side of the Activator III to change the sync setting. If you want to reach maximum power output faster, move the switch forward. To get smoother braking action, move the switch backward, thus supplying power to the trailer brakes more gradually. You can alter the sync setting to suit your driving preferences or to improve handling based on changing road conditions or varied trailer loads.


Quick, Simple Installation

Because inertia plays no role in the functioning of this controller, you do not have to mount the unit at any particular angle. As a result, mounting options are limitless, so long as you can still easily access the controller. After mounting the unit, hardwire one end of the included pigtail harness directly into your vehicle. The other end plugs into the brake controller.


Installation Accessories

For even easier installation, a vehicle-specific wiring adapter is available for most newer trucks and SUVs. One end of the custom adapter plugs into your vehicle, and the other end plugs into the controller - no hardwiring required.


Note: If a custom brake-control wiring adapter is not available for your vehicle, one of the following will be required:

20-Amp circuit breaker (9506P - sold separately) for 2- to 4-brake applications

30-Amp circuit breaker (38630 - sold separately) for 6- to 8-brake applications


See also etrailer.com's exclusive 7- and 4-way brake-control installation kit (ETBC7 - sold separately) if you don't already have a 7-way plug at the back of your vehicle.



5520 Draw-Tite Act III Time-Delay Trailer Brake Control

Same as Reese Brakeman Ultra - 83520



Tekonsha Plug-In Wiring Adapter for Electric Brake Controllers - Toyota and Lexus
part number: 3040-P

Install your electric brake controller quickly and easily with this custom wiring adapter. Simply plug one end of the adapter into your brake controller and then plug the other end into the built-in harness beneath your vehicle's dash.

Features:

  • Wiring adapter eases installation of your electric brake controller
  • Custom connector end plugs into the built-in port beneath the dash of your vehicle
  • Other end plugs into the back of your electric brake controller
    • Compatible time-delayed brake controllers: Draw-Tite Activator I (5100), Draw-Tite Activator II (5500), Draw-Tite Activator III (5520) and Tekonsha PowerTrac (39523)
    • Compatible proportional brake controllers: Tekonsha Prodigy (90185), Tekonsha P2 (90885), Tekonsha P3 (90195), Tekonsha Primus IQ (TK90160) and Tekonsha Voyager (39510)
  • Wiring length: 32"
  • Limited 1-year warranty


Installation of Tekonsha Brake Controller Adapter

This adapter plugs into the 5-pin connector on your vehicle's built-in brake control wiring harness. The harness is located underneath the dash, to the left of the steering column, taped to another harness near the emergency brake pedal.


To install your electric brake controller you need to connect the wiring of the controller to your vehicle. Certain manufacturers offer pre-wired options, typically known as tow packages, wherein these wires are run for you from the dash to the trailer connector on the back of your vehicle. Often, a brake controller wiring harness is included with your tow package. This harness plugs into a port beneath your dash and connects to the four wires of the brake controller. If, however, you have a brake controller with a plug in place of the four loose wires, you can use the Tekonsha adapter.


This adapter requires no hardwiring. It is designed to plug directly into your electric brake controller for the simplest installation possible. Because there are no wires to connect, installation is not permanent. You can unplug and remove your brake controller at any time and securely stow it away.



3040-P Tekonsha Brake Control Wiring Adapter with 2 Plugs



Video of Demo-Draw-Tite-Brake-Controller-5520


Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.

Video Demo Draw Tite Brake Controller 5520
Draw-Tite Brake Controller 5520 Review
Video Brake Controller Install 2006 Chevrolet 3500
Trailer Brake Controller with Wiring Installation - 2006 Chevrolet Silverado 3500
Video brake controller install 2008 GMC Sierra
Trailer Brake Controller Installation - 2008 GMC Sierra
Video brake controller install 2008 dodge grand caravan
Trailer Brake Controller Installation - 2008 Dodge Grand Caravan
Video install draw tite activator brake controller 2014 jeep grand cherokee 5520
Trailer Brake Controller Installation - 2014 Jeep Grand Cherokee


Video Transcript for Draw-Tite Brake Controller 5520 Review

Today we're going to be taking a look at part number 5520. This is the Draw-Tite Activator III Time Delayed Trailer Brake Controller. This brake controller is going to activate your trailer brakes with a preset intensity. The signal is then going to be sent to the trailer brakes when your tow vehicles brakes are activated. It's got a really nice design to it. Silver finish around the housing, then it's got the black here in the middle, so silver and black two-tone. It looks really good.

It's got a very easy to read digital display here on the front which I'll show you towards the end of the video. We'll plug that in so you can see the displays that it shows and how easy to read that is. It is going to feature adjustable output control that's going to let you determine the amount of braking force. That's going to be the thumb wheel here on top of the controller. You'll want to set it to a maximum when you travel through hilly terrain with a fully loaded trailer. Then you'll want to back off the power output when you tow a lightweight trailer. The sync setting is going to be the slide lever here on the side of the controller.

This is going to let you adjust the agressivness with which the brakes are activated. You can get full output faster by moving the switch forward to increase activation speed. You can achieve smoother braking by moving the switch in the opposite direction to supply power gradually. Here on the front we've got the area for the digital display reading. It's also going to feature the built in slide bar, this is our manual override function. It's a very quick and easy installation.

There is no need to mount this level like proportional brake controllers. You can do it at any angle that's best going to suit your application. It's going to come with the mounting bracket and the screws that you need to get it installed. It's going to have two screws that hold it to the bracket itself. Then it's going to have two more screws that are self-tapping that can go right into the dash of your vehicle. Here on the back it's got a very easy to use port. It's going to come with this plug here, this is your plug-in port.

It's going to make it easy to connect to the wiring harness. This simply connects back here. Push it in until you hear it snap into place. It's got a locking tab on the top. It exposes some wires right here. You're going to have four different wires. The blue is going to be for the trailer brakes. The black is going to be for your power. The white is going to be for your ground. The red is going to be for the stoplight. It exposes these that way you can wire it into your vehicles wiring harness. Here at etrailer.com we do offer plug-in vehicle specific brake controller adapters. They are sold separately and they can be used for certain applications to help reduce your installation time. This is designed for trailers with up to four axles which would be a total of eight brake assemblies. It is designed for use with electric brakes only, so please keep that in mind. The overall dimensions of the actually controller, it's going to give us a width of about three and one quarter of an inch with an overall length of four and seven eighths of an inch. Measuring the overall height it's only about one and one eight of an inch tall, so it's a really nice compact controller. It's going to stay up out of the way and it's not going to take up much space. I'm going to go ahead and hook it up to our external power source that way we can show you what it looks like with power running to it. You could see how it easy that display is to read. Draw-Tite covers this brake controller with a limited lifetime warranty, so they really stand behind their product. I've got it all plugged in, when I press the manual override you can see there it's going to show the reading. We can adjust that output level as well. This is going to adjust in point five increments. You can see that there, all of the way from zero point zero to ten. That's the manual override and then when we apply our brakes to the tow vehicle you can also adjust that and get it preset as you wish. Here on the side you're going to have the sync setting going from zero all of the way up to nine. Again that's just going to adjust the aggressiveness with which the brakes are activated. A very simple system to you use. Again it's got the nice easy to read digital display. It's also going to pop up some error messages. They do include a little handbook, just a little instructional guide. It's going to show you those codes and what they mean and kind of the best response to those to get those resolved. Draw-Tite provides all of that and I believe that's going to do it for today's review of part number 5520. This is the Draw-Tite Activator III Time Delayed Trailer Brake Controller. .




Ask the Experts about this Brake Controller
Do you have a question about this Brake Controller?


  • Installing a Brake Controller on a 2012 Harley Davidson Motorcycle for Towing a Aspen Sentry Trailer
  • I spoke with Aspen trailer to get some details for you, they recommend a time delayed brake controller for their trailers with electric brakes. The representative there said that many of their customers have excellent performance from the Activator III electric trailer brake controller by Draw-Tite, # 5520. The advantage of a time delayed brake controller on a motorcycle is that it can be positioned in any way, so you can easily find a mounting location that is out of the way but still
    view full answer...

  • Troubleshooting OL Error Code On a Draw-Tite Activator III Brake Controller # 5520
  • On the Draw-Tite Activator III Brake Controller, part # 5520, the OL designation on the display will mean overload. The cause of this is most likely a bad ground or a short to the blue brake out put wire. I am including a link to the instructions on the Draw-Tite brake controller. The first thing I would check is the connector on the back of your vehicle. Any dirt or corrosion can be causing a bad ground or a short to the brake output pin. The solution is to clean out the connector and
    view full answer...

  • Constant 12 Volt Power on Brake Output Circuit on 7-Way Trailer Connector
  • You can test your brake controller to determine if it is damaged on the inside or if the problem is from somewhere else. Sever the blue wire a few inches from the back of the controller. Test the blue wire on the brake controller side after you have cut it. If it shows power when not using the manual override, then there is a problem inside the controller and it will need to be replaced. If the controller functions like it should then the problem is further back. A short to the blue
    view full answer...

  • Brake Controller Recommendation for a 1999 Ford F150
  • The Draw-Tite Activator # 5100 that you referenced is basically the first brake controller made in the Activator line. The Draw Tite II # 5500 is the next generation controller with upgrades that include; the ability to handle up to 8 brakes and a digital display. The next controller in the Activator line is the Activator III # 5520. This controller has a brighter display and a quick disconnect feature. The brake controller we recommend is the Tekonsha Prodigy P2 Brake Controller # 90885.
    view full answer...

  • Draw-Tite/Reese Trailer Brake Controller Does Not Light Up or Show a Display
  • It is possible that the act of the plug coming out while driving confused the brake controller. What you will what to do is disconnect the controller for about 15 minutes and then reconnect it. After you do this, before doing anything else, go through the set up process as outlined in the instructions I have linked for you. If there are still issues, make sure that the trailer connectors are intact and that none of the pins are bent or damaged and that the wiring is not damaged. You
    view full answer...

  • Brake Controller Not Working on 2006 Dodge Ram 3500 When Trailer Is Connected
  • If your 2006 Dodge Ram was not equipped with a factory 7-way connector, the brake output and 12-volt accessory circuits are not ran to the rear of the truck. You will need to run a length of 10 gauge wire, like the part # 10-1-1, from the blue lead of the 7-Way connector, under the vehicle, to the engine compartment. Make sure to avoid any moving parts like the suspension and steering components and anything hot like the exhaust. In the engine compartment behind the drivers side wheel
    view full answer...

  • Adding Trailer Wiring and a Brake Controller to a 2012 Harley Davidson TriGlide Trike
  • The first thing you will need to do is install a wiring converter on the trike to add a 4-Way trailer connector, and then add a 7-Way connector. You can use # 119178KIT. You will connect the white wire to a grounding location. Connect the brown wire to the running light wire. Connect the yellow wire to the left turn signal. Connect the red wire to the brake light. And connect the green wire to the right turn signal. After this kit is installed, you will need to add a 7-Way using # 37185.
    view full answer...

  • Brake Controller Recommendation and How To Install it in a 2003 Chrysler Town and Country
  • First let's start with a brake controller. For a brake controller I would recommend the Prodigy P2 Brake Controller part # 90885. This is our best selling brake controller because of how well it works and how easy it is to setup. This is a proportional brake controller that will apply the trailer brakes at the same intensity as the tow vehicle brakes are applied. Unlike a time-delayed controller like the # 5520 that you referenced that always will apply the brakes at the same intensity
    view full answer...

  • Recommendation For a Brake Controller on a 2001 Dodge Ram 3500 Diesel
  • Brake controllers are universal items so most brake controllers will fit on most vehicles by using the correct adapters. The brake controller will have no problem working with your vehicles on board computer. For your 2001 Dodge Ram 3500 Diesel I would recommend the Tekonsha Prodigy P2 Brake Controller, part # 90885. The Prodigy 2 brake controller is our best selling model. It can be mounted in a 360 degree vertical range and will level itself automatically. It is a proportional brake
    view full answer...

  • Parts Needed to Add a 7-Way Trailer Connector and Brake Controller on a 2011 Toyota Sienna
  • On the 2011 Toyota Sienna you will need to hardwire in a brake controller. None of the brake controller wiring harnesses are listed as a fit for the Sienna so I cannot recommend using one. What you will need, since you already have the 4-flat connector, is a 4 and 7-Way installation kit # ETBC7. This will provide the 7-Way and the wiring and parts needed to install a brake controller. I have included some links that will explain the ETBC7 installation. For a brake controller, you could
    view full answer...

  • Brake Controller Wiring Harness to Connect a Brake Controller to a 2012 Honda Pilot
  • You would need to use wiring harness # 20268. This harness has one end that plugs into the factory connection point on the 2012 Honda Pilot. The other end has bare wires that you will need to splice into the brake controller wires. They will connect color for color. Black is power to the controller, white is ground, red is input from the brake switch, and blue is output to the trailer brakes.
    view full answer...

  • Wiring and Display of the Draw tight Activator 2 on a Nissan Titan
  • To attach the Draw-Tite Activator II, item # 5500, electronic brake controller to your vehicles factory connector you will need a Universal Brake Control Wiring Adapter, Nissan, item # 20266. This adapter has four wires that attach color for color to the wires on the brake controller. If you have an adapter that plugs into your vehicle that has five wires then you will have to use a circuit tester, item # 3808 if you need one, and verify the function of each wire once it is plugged in. Attach
    view full answer...

  • Wiring Adapter to Install a Reese Brakeman Brake Controller in a 2014 Ford F150
  • I believe the Reese Brakeman Brake Controller you mention is the same controller as the Activator III Brake Controller, part # 5520. And the correct harness to install this controller in your 2014 Ford F-150 if it has a factory 7-way would be the Tow Ready Plug-In Wiring Adapter # 22292. If you have a 4-way connection you would need the # 22292 as well as a 7-way part # 37185. Check out the FAQ article I attached that shows how to connect the # 37185 to you factory wiring. I attached
    view full answer...

  • What Does it Mean When Draw-Tite Activator III Brake Controller # 5520 Displays Code SH
  • The display code SH on your Draw-Tite Activator III Brake Controller, part # 5520, can indicate that there is a short or overload condition in your trailer brake circuit. This condition may also result in the display showing a flashing OL code. Please refer to the included instructions from Draw-Tite for a description of all error codes. Either of these fault codes points to a need to check the brake circuit on your trailer. I have linked two help articles, one concerning troubleshooting
    view full answer...

  • Act III Brake Controller 5520 Not Recognizing Trailer Connection with 1992 Ford E-350
  • The # 5520 Activator III brake controller will not show a decimal point constantly. You will only see the point when you do not have your trailer connected and you either press the vehicle brake pedal or activate the manual switch. If you do have the trailer hooked up and the controller does not show the brake output, this would indicate a problem on the blue electric brake wire, as you mentioned. To pinpoint where the problem is occurring, use a light tester like part # 3808 to
    view full answer...

  • No Display Of Output Strength And No Brakes When Applied On Draw-Tite Brake Controller, # 5520
  • If the Draw-Tite Brake Controller, # 5520, does not show output strength but it shows the decimal point all the time, then the red wire going to your stoplight switch is connected to the wrong side of the stoplight switch or to a wrong switch (cruise control). You will want to make sure the red wire on your brake controller is connected to the cold side of your stoplight switch, which is the side that will show power only when the brake pedal is pressed. If the brake controller shows
    view full answer...

  • How does the Disply on the Draw-Tite Activator 3 Brake Controller # 5520 Function
  • You asked an excellent question that can be difficult to understand with the included instructions. Without the truck connected to a trailer, the display on the Draw-Tite Activator 3 Brake Controller, # 5520, will show a single red dot when you step on the brake pedal or use the manual override. You will only see numbers, or the power output, if the trailer is connected to the truck. I pulled the Activator 3 from my warehouse and used a bench tester to make a short video for you showing
    view full answer...

  • Does a 1999 Ford F-150 have a Port Under the Dash for Brake Controller Installation
  • If you have a factory 7-way at the rear of your vehicle (it should) there will be a plug under the dash that will let you install a brake controller easily. Check out the FAQ article I attached that shows where it will be. Since you like the Draw Tite Activator III Brake Controller # 5520 you would want to use the brake controller harness part # 3035-P.
    view full answer...

  • Parts Needed to Install a Trailer Brake Controller on a 1997 Dodge Caravan
  • To install a brake controller on your 1997 Dodge Caravan you will need to add a 7-Way trailer connector. In order to install a 7-Way trailer connector the van will either need to already have a 4-Way flat trailer connector or you will need to install one using # 118334. Then you will need 4- and 7-Way installation kit # ETBC7. This provides the 7-Way, retains the 4-Way, and provides the wiring an accessories you will need to install a brake controller. I have included some links that
    view full answer...

  • Activator III Brake Controller Does Not Work with the 2013 Ram 1500 Powernet System
  • In 2013 Chrysler introduced a new electrical system called the Powernet. This new system necessitated a new brake controller wiring harness design, # 3023-P. But there are only certain brake controllers that are compatible with the Powernet system. The Draw-Tite Act III is not one of them but the early models, Act I # 5100 and Act II # 5500 are compatible along with proportional brake controllers # 90885, # 90195, # TK90160, and # 39510. For a brake controller to work properly with the
    view full answer...

  • Installing Brake Controller in 2013 Toyota Tacoma
  • It is not difficult to determine if your Tacoma has the tow package wiring in place. If your Tacoma has the OEM 7-way trailer connector installed, the vehicle is indeed prewired for a brake controller. The # 3040-P wiring harness would plug into the connector located near the emergency brake pedal as shown in the photo I edited for you. Make sure the white ground wire with the ring terminal is grounded under the dash. If you do NOT have the OEM 7-way, the plug for the controller
    view full answer...

  • How to Install an Electric Trailer Brake Controller on a 2011 Toyota Tacoma with Factory Tow Package
  • The installation of the Tekonsha P2 Brake Controller # 90885 and Wiring Harness,# 3040-P, could not be more simple on your 2011 Toyota Tacoma with tow package. The truck will have a wiring harness up under the dash, to the right of the steering column (the plug could also be left of the steering column above the emergency brake pedal). All you have to do is plug in the brake controller wiring harness to it, ground the additional white ground wire to a bare metal surface or existing grounding
    view full answer...

  • ABS and Traction Control Light Stays on After Installing Brake Controller on 2009 Tacoma W/Tow Pkg
  • My first suggestion would be to take your Tacoma back to where you had the controller installed. If you paid them to install the brake controller, I would expect that they should be responsible for correcting the problem for you. According to my contact at Tekonsha, there a few possible causes for what you have occurring. The most likely cause is that your emergency brake is partially engaged. Pull the release handle to make sure the emergency brake is fully disengaged. You might need
    view full answer...

  • Location of Factory Brake Controller Port on a 2006 Toyota Tundra
  • As long as your 2006 Toyota Tundra has the factory tow package that included a 7-Way trailer plug at the rear of the vehicle, you will be able to find the brake controller port under the dash, to the left of the steering column. It should be taped to another harness near the emergency brake pedal. Also note that there is a second ground wire (white) that will need to be connected in order for the brake controller to function properly. I have included a link to the installation details for
    view full answer...

  • Brake Controller Wiring Harness for a 2014 Toyota Tundra
  • If you have a factory installed 7-way trailer connector you can use # 3040-P Tekonsha Plug-In Wiring Adapter for a Tekonsha Brake Controller, such as the P3 # 90195. If your truck has a factory 4-way you will need to add a 7-way using the Universal Installation Kit for Trailer Brake Controller # ETBC7. The # ETBC7 comes with a 7-way trailer connector and the wiring accessories needed to install a brake controller. I have included some links that explain the # ETBC7 installation.
    view full answer...

  • Location of the Electric Brake Control Harness on a 2012 Toyota Tacoma
  • The electric brake control harness on your 2012 Toyota Tacoma will be located underneath the drivers side dash to the left of the steering column. It should be taped to another harness near the emergency brake pedal. It will be a 5-pin connector. I have attached a photo showing the location of this harness as well as the installation instructions for the Plug-In Adapter from Tekonsha, # 3040-P, for you to check out.
    view full answer...

  • Location Of Factory Brake Controller Port On 2007 Toyota Tundra SR5 w/ Tow Package
  • The connector should be located underneath the dash to the left of the steering column. It may be taped to another wire and tucked up and out of the way. I have linked a video installation of brake controller being installed on a 2007 Toyota Tundra using the # 3040-P adapter.
    view full answer...

  • What is the Correct Brake Controller Wiring Harness for a Tekonsha P3 and 2012 Toyota Tundra
  • The brake controller wiring harness for the P3 and your 2012 Toyota Tundra, # 3040-P, does include a separate ground wire that you will need to attach to a bare metal surface on the truck. The factory ground in the Tundra is not sufficient for the needs of the brake controller which is why this additional ground wire is needed. I have included a link to a video showing installation of this harness on a 2010 Tundra which will be similar to your 2012.
    view full answer...

  • Brake Controller Installation Instructions for a 2006 Toyota Tundra with Factory Tow Package
  • You have come to the right place, we have a video showing the installation of a brake controller on a 2007 Toyota Tundra that will be identical to your installation. I have also included a link to the instructions for the Tekonsha Prodigy P2 Brake Controller, # 90885, for you to review. On the 2006 toyota Tundra with factory tow package you will only have to plug harness # 3040-P in under the dash and at the rear of the brake controller to complete the installation. Once installed
    view full answer...

  • Brake Controller and Wiring Recommendations for Towing a R-Pod with a 2011 Toyota Highlander
  • I would recommend using the Brake Controller 7 and 4 Way Installation Kit, item # ETBC7, along with the Tow Ready Harness, # 118449, that you have installed on your vehicle. This kit has all of the wiring, circuit breakers and connectors that are needed to complete a professional looking installation. We also have detailed instructions that guide you through installing this kit, see link. When performing the installation just make sure that the Red wire, from the Brake Controller you
    view full answer...

  • How to Install a Prodigy Brake Controller on a 2010 Toyota Tacoma with Factory Tow Package
  • Since your 2010 Toyota Tacoma has a factory tow package, installation of the Tekonsha Prodigy Proportional Brake Controller P2, # 90885 will be very simple. Your Tacoma has a plug, tucked up under the dash, most likely left of the brake pedal. There are some panels that you will have to remove to gain access to the wiring. Find the plug, it will be the one, probably with a white connector, that is not hooked up to anything. Attach this to the corresponding end of the brake controller harness
    view full answer...

  • Installing a Brake Controller on a 2003 Toyota Tundra with a 7-Way but Not a Tow Package
  • As you probably know, in 2003 Toyota made the Tundra with or with out a factory trailer connector. So if they installed one when you bought it, they might not have run all the wiring for a brake controller. This might be why you only see 4 wires at the 7-Way. I believe this is the case, so you will need to hardwire the brake controller. You will need a brake controller. I recommend the Prodigy, # 90885. It is one of our best selling and highest rated controllers. There are two possible
    view full answer...

  • Availability of a Brake Controller Adapter for a 2015 Toyota Tundra
  • Yes! If you have a factory installed 7-way trailer connector you can use a Tekonsha Plug-In Wiring Adapter # 3017-P. The adapter will plug into your 5-pin connector on your 2015 Toyota Tundra built-in brake control wiring harness. The brake controller I recommend is the Tekonsha Prodigy P3 # 90195. It has 5 storable settings so you can customize multiple trailers and the controller applies the same amount of braking power as the tow vehicle. I have included a couple FAQ's and videos
    view full answer...

  • Installing an Electric Trailer Brake Controller from Scratch on a 2001 Toyota Tacoma
  • The 2001 Toyota Tacoma does not have a port or harness to plug in a brake controller. Instead, the brake controller will need to be hardwired using a 4 and 7 Way Installation Kit, # ETBC7. If the truck does not have a 4-Way trailer connector already, you will first need to add one using T-One Vehicle Wiring Harness, # 118379. I have included links to the installation details and a video showing installation on a 2000 model for reference. To install the ETBC7, you will first plug in the
    view full answer...

  • Installing Tekonsha P3 Brake Controller # 90195 in 2015 Toyota Tundra Crewmax without Tow Package
  • The exact components that are included in a "tow package" can vary by auto maker, by vehicle model and model year. Sometimes the presence of a 7-way socket on the rear bumper means that a tow package is in place, while other times this single feature may not indicate the presence of all of the tow package equipment. Your local dealership can tell you how your truck is equipped based on its VIN number. If your truck has a hitch, tow button and a trailer connector I would expect that
    view full answer...

  • Installing Brake Controller Wiring Harness 3040-P on a 2006 Toyota Sequoia
  • Since your 2006 Toyota Sequoia came with a factory tow package, you can plug in the wiring harness, # 3040-P into the port on the vehicle. It is located under the dash to the left of and above the the emergency brake. You will remove the panel that is there on the far left, and the connector will be tucked up behind some other harnesses. It will have a white connector. I have included a link to a video that shows the installation of this harness on a similar vehicle. Make sure to also
    view full answer...

  • Installing a Trailer Brake Controller on a 2014 Toyota Tacoma
  • If your 2014 Toyota Tacoma came with a factory installed 7-Way trailer connector then the plug-in for a brake controller should be there. Harness # 3040-P is the correct one for your truck and a Tekonsha brake controller. I recommend the P2 # 90885 because it is easy to set up and use and it is reliable. I have linked a video to the right that shows where the controller plugs in. This adapter plugs into the 5-pin connector on your vehicle's built-in brake control wiring harness. The
    view full answer...

  • Wiring a 2008 Toyota Highlander Hybrid with a 7-Way Trailer Connector and Brake Controller
  • If the wiring that was done tied directly into the tail lights of your 2008 Toyota Highlander but did not have a converter, that may be the reason it was throwing codes. In order to install a 7-Way trailer connector on your Highlander, you will first need to install a 4-Way wiring harness, # 118449. I have included links to the installation details and a video showing a typical installation. Next, you will need to install a 4 and 7 Way Installation Kit, # ETBC7. This provides a 7-Way
    view full answer...

  • Trailer Brake Controller Wiring Harness Location on a 2012 Toyota Tacoma with Manual Transmission
  • Manual or automatic the brake controller port on the 2012 Toyota Tacoma should be in the same place. See instruction link for harness # 3040-P. It will only be there if the truck came with a factory 7-Way trailer connector. Otherwise you will need to hardwire in a brake controller and 7-Way. If your truck has the factory 7-Way, sometimes the connector for the wiring harness is actually behind a kick panel on the driver side of the vehicle and you will have to remove it to find the connector. If
    view full answer...

  • Brake Controller Plug In Location for a 2013 Toyota Tacoma
  • It is possible that the brake controller plug on your 2013 Toyota Tacoma is located behind the driver side kick panel like you have indicated. You may be able to reach in and pull it up if you can reach just the wires from the connector. There is also the possibility that it is tucked up under the dash and you cannot see it easily. You would need to fish around under there with your hand and gently push, pull, or otherwise move aside other harnesses to locate it.
    view full answer...

Info for these parts were:


Expert Research:
Michael L

Video Edited:
Zack K

Expert Research:
Sarah L

Expert Research:
Robert G

Expert Research:
Michael H

Expert Research:
Jeff D

Expert Research:
Reno H

Expert Research:
Jameson C

Expert Research:
John H

Expert Research:
Adam R

Written by:
Lindsey S

Expert Research:
DeAnne T

Expert Research:
Patrick B

Video Edited:
Andrew L

Video Edited:
Dustin K

Photos by:
Jim W

Expert Research:
Jeffrey L

Video Edited:
Sue W

At etrailer.com we provide the best information available about the products we sell. We take the quality of our information seriously so that you can get the right part the first time. Let us know if anything is missing or if you have any questions.



Customer Reviews

Draw-Tite Activator III Trailer Brake Controller - 1 to 4 Axles - Time Delayed - 5520

Average Customer Rating:  4.9 out of 5 stars   (10 Customer Reviews)

Electronic controller activates electric trailer brakes with a preset intensity when you apply the brakes in your vehicle. Digital display, manual override, and a simple, plug-in port included. Power output and braking aggressiveness are adjustable.


- 5520

by: Dustin K.08/10/2013


Have this controller in my chevy. Bought it at a local store and paid a fortune for it- But it is a great product. My dad was ready for a quality controller so I looked on etrailer.com. Same great product at almost half the price!! website very easy to operate. Shipping was inexpensive and very fast! 5 stars for etrailer.com 94385






- 5520

by: Bill C.04/21/2014


Works great. Easy to install 126222






- 5520

by: Josh Wood08/19/2013


Product came new in the box with all instructions and plug and play pig tail worked great. Installation took about 10 minutes and 5 of that was figuring out where I wanted it to go. 95859






- 5520

by: John K07/03/2014


Simple to add and effective. I had my wife order it over the phone while I was working. She stated the person helping her was very kind, corteous, and helpful. 138995






- 5520

by: Gary D.08/16/2012


E-trailer quick delivery, easy to follow instructions for the installation, works great. 51860






- 5520

by: Wendell09/20/2012


Came as ordered ................10 minutes and I was ready to tow 55286






- 5520

by: George12/14/2012


If it works as described it will do what I want 61490






- 5520

by: mark a.09/29/2011


Arrived on time and installed no proble m. 24846






- 5520

by: K Wayman04/29/2012


Easy as can be, excellent product 38760






- 5520

by: matt younis04/04/2012


great item install was a snap 36165




10
10

Toyota Tundra Accessories








Stay Connected


Subscribe to email newsletter

Email

privacy - we don't send unsolicited email






etrailer.com reviewsetrailer.com reviews

All images, layout and content copyright etrailer.com
