Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.
Rating:
24 reviews
Code: 60953
Retail:$238.45
Price:$164.95
Shipping Weight: 21 pounds
Shipping SpecialSpecially designed for light-duty applications, this fully welded Honda Accord trailer hitch receiver features a powder coat finish over an e-coat base to ensure superior corrosion resistance. Drawbar, pin and clip included.
Features:
Specs:
At etrailer.com we're committed to the products we sell, and to our customers. Our experienced and knowledgeable staff are available via both phone and email to address your questions and concerns for the lifetime of your hitch. The technicians at etrailer perform hitch installations on a daily basis, making them a valuable resource for do-it-yourselfers. The one-on-one, personal service you'll receive comes straight from an expert in the towing and automotive field. We've installed it, we've wired it and we've towed with it, so whatever your question, we can answer it.
Video of Hidden Hitch Trailer Hitch Receiver with Drawbar - Custom Fit - Class I - 1-1/4"
Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.
Today we are going to be installing hitch part number 24787 from Draw-Tite on a 2006 Honda Accord. This installation will also apply to Hidden Hitch part number 60953. We are underneath the vehicle. The first thing we want to do to gain access to the frame rail is to go ahead and lower the exhaust down from the passengers side frame rail. There are actually two hangers that we are going to need to remove to lower the exhaust down. The one here on the outboard side, about midway up the muffler here, that is going to need to be pried off. And I definitely recommend to spray it down with some form of spray lubricant, like a WD-40. It makes the removal a lot easier. And the second exhaust hanger that we are going to need to lower is a little bit forward here of the muffler, right dead center of the car.
Before I remove the second exhaust hanger, I am going to go ahead and use a basic tow strap to support the exhaust tube, so that when I remove the second hanger the exhaust does not fall down and damage the exhaust system. OK, with the exhaust lowered, I am going to go ahead and point out the mounting locations for the trailer hitch. The center mounting location will be to the tow loop here that is mounted on the bottom of the trunk well. And you can see on the drivers side frame rail we have got two existing holes we are going to be using the rearmost hole as our attaching point on the frame rail. And we are going to have the same thing here on the passengers side.
In order to get the hardware into the frame, we are going to be using the fish wire that is provided in the installation kit. We are going to take the 7/16 block, which you can see has a few notches cut out in it, and the 7/16 carriage bolt, as well. These are going to up into this hole, and then we are going to pull it back down into place. To do that, we just want to go ahead and feed the fish wire into the block and then wrap the threads of the carriage bolt with the fish wire and feed it up into the hole, followed by the block. And we want to put the notches in first that is going to allow it to go into the frame a little bit easier. And then we just pull it back down into position. And we are going to do that on the passengers side location, as well. And with those two fasteners in place, we can go ahead and put our hitch up into position. I am actually going to attach it to the center tow hook first. We are going to put the 1/2-inch carriage bolt in through.
We are going to take the flat block and place it on the other side. We will come over to the bottom of the frame and go ahead and lift the arm up into position. And again, we are just going to attach this tie with the 7/16 conical-tooth washer and the 7/16 nut. Now that we have got all of the hardware into position, we can go ahead and torque all of our bolts down. We are going to start by torquing the ones at the bottom of the frame on each side first, and then we will come back and torque the one for the center tow hook attaching point last. You want to check with your directions to verify the appropriate torque rating for each individual bolt. And with all of our bolts torqued down, we want to make sure we put our exhaust back up on its hangers, and our installation will be complete. This will conclude the installation of hitch part number 24787 from Draw-Tite on a 2006 Honda Accord.
2006 Honda Accord Owners Who Purchased This Trailer Hitch Also Bought...
Average Customer Rating: 4.8 out of 5 stars (24 Customer Reviews)
by: Jairo P.03/31/2012
Is this review helpful?
Product is of great quality. Installation was not very difficult. Installed on 2004 Honda Accord within 30 minutes.35748
by: Walt K.08/30/2011
Is this review helpful?
The hitch was received quickly and well packaged. It fit my 2005 Honda Accord V6 2-Door perfectly, including your wiring package. I didn't think a trailer hitch could be fitted to my car. Now I can haul my lightweight 1955 HD Model B to near by shows and events.23170
by: Corey R.05/17/2013
Is this review helpful?
Very easy install, even with the muffler still attached on the 4 cylinder.80734
by: Bart V.05/14/2013
Is this review helpful?
I ordered the Hidden Hitch for our Accord V6. The online process was a snap, came within a week with free shipping. Hitch and all parts were as expected. Installation took a little longer since I had to deal with dual mufflers and dual heat shields but overall very straight forward. Check out the etrailers links to YouTube on how to install. Very helpful. Torqued everything down per spec. The Hidden hitch looks great on the car. Thanks!80202
by: Bill01/14/2013
Is this review helpful?
Everything was very good and I had no problem putting the hitch on myself. The only thing I would suggest to make it even easier to put on is if you could have the front mounting bolts 1/2 inch longer that way it would be easier to make use of the washers and getting the nut started. A great product and you gave great service. Thank you ....Bill Keen62972
by: Brenda10/29/2012
Is this review helpful?
Speedy delivery and product looks good so far. Haven't had a chance to put it on my car, will let you know if I find it otherwise. Would recommend your company.58344
by: JohnM09/17/2012
Is this review helpful?
The hitch fit perfectly onto our 2005 Accord. Customer service has been phenomenal. They caught that the hardware was not shipped and had it FedEx'd from the equipment supplier. The experience could not have been better.54911
by: chuck c.09/03/2012
Is this review helpful?
the product was just as advertised and went on my 06 honda great, thanks alot.53817
by: Jared S05/21/2012
Is this review helpful?
Install was straight forward and simple. Order was correct, shipping was fast. Only minor issue was one washer was too small for the bolt that goes through the center loop under the spare tire well. Put on a lock washer we had laying around and solved. Trailer wiring kit was a piece of cake. Would definitely order from here again and recommend you guys to anyone that needs a trailer hitch or accessory. Excellent41084
by: john chehade01/19/2012
Is this review helpful?
great service,very helpful how to do it yourself videos.29961
by: Keith K11/09/2011
Is this review helpful?
This hidden hitch fit my car perfictly. fast delivery too. the install vidieo was great26746
by: Justin10/16/2011
Is this review helpful?
Hitch installed very easily, 25 min tops...but not 100% happy with it. It will do what I need it to do just fine, but the reason I bought the hidden hitch brand for a few more bucks than a drawtite is that in the pictures of it installed on the silver honda accord, the breakaway chain loops were tucked up and rather hidden. This is also the case in the install video for the hidden hitch, it has the flat, tucked up and away style loops. I know it is a nit-picky complaint, but I'm particular with my car and wanted those breakaway chain loops tucked up as much as possible. The hitch pictures (not on a car) are exactly what you get, not what is displayed on the pictures of a hitch installed on the accord. The only other complaint I have is that after one use of the breakaway loop, the finish has already worn off and bare metal is showing. Being particular about my car, I'm not excited at the fact this will likely rust and I'll likely want to take it off and get it stripped and coated in a better quality finish at some point. 25640
by: John B.06/28/2011
Is this review helpful?
Product was delivered on time. Bolted up just as indicated. [At bit of a chore moving the muffler and exhaust system to make the fastener that side--but reasonbable; the instructions were spot on]. In all respects, high marks for a well-designed hitch!18097
by: Chris C.06/21/2011
Is this review helpful?
I am very happy overall. This was an easy product to order, it was shipped promptly, and the install was much easier and quicker than I thought it would be. The video tutorials are indispensable. 17526
by: Bruce M05/09/2011
Is this review helpful?
very pleased with the hitch. Quality of construction is excellent and as advertise easy to install13136
by: Ben R.04/06/2011
Is this review helpful?
Install was straight forward, with very descriptive directions. The video was quite helpful. I was installing it on a V6 model accord, so I had to deal with dual exhaust and heat shields, which made the install take almost 2 hours. Turned out great, though.11196
by: Cameron P.03/22/2011
Is this review helpful?
Received my order quickly. Installation was a snap. Would highly recommend etrailer.com to friends and family. The install videos are extremely helpful too! 10068
by: Paul S.01/28/2011
Is this review helpful?
The receiver was pretty easy to install. The only hard part was getting the muffler off of the back rubber hanger. That probably took half of the time I spent. The rest was just like the installation video showed. 6301
by: Tom01/03/2011
Is this review helpful?
Great Fast Service Ordered on Friday and it was here on Monday.4943
by: Larry07/23/2010
Is this review helpful?
A trip with peace of mind.... Went in easy and didn't make a sound on our trip with 80lbs of bikes on the Hitch bike rake.3260
by: CR05/15/2010
Is this review helpful?
Great experience Easy use web site. Tells exactly what is included and what isn't. (I couldn't tell what I was buying on some of the other sites.) Prompt shipping. Easy install. It might have taken me a couple more minutes than advertised to install the hitch but it was still quick and exactly as described. Great installation videos. I referred to them several times for help in installing hitch and wiring harness.3034
by: Josh L.04/30/2010
Is this review helpful?
Video Intallation helped a lot The video installation guide helped a lot in installing. Made it very easy! Something back there is clinking a little over big bumps, but it appears to have worked itself out. 2985
by: Bob08/25/2008
Is this review helpful?
Problem w muffler hanger I couldn't get the muffler hanger off. Otherwise, everything fit perfect. The instructions didn't say anything about dropping the muffler; this made it very diffucult due to to the limited clearance between muffler and frame. I'm sure there is a simple way to remove the rubber muffler hanger, I just didn't figure it out.1220
by: beechkingd03/27/2007
Is this review helpful?
good hitch, easy to install the center attach point on the car is a little loose and causes some noise. I installed some foam around the bolt and it helped a bit.108
Ask the Experts about this Hidden Hitch Trailer Hitch
Do you have a question about this Trailer Hitch?
Tech Tip
No drilling required for installation, Heat shields require drilling on V6 models, Fits Hybrid models as well
