Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.
Rating:
1 reviews
Code: 41511
Retail:$271.88
Price:$188.95
Shipping Weight: 46 pounds
Shipping SpecialFully welded Chevrolet Tahoe trailer hitch is strong and durable. Draw-Tite's Tested Tough guarantee ensures that this hitch exceeds industry standards. The combination of an e-coat base and a powder coat finish provides excellent rust protection.
Features:
Specs:
Draw-Tite's Tested Tough program provides testing standards far superior to those outlined by the Society of Automotive Engineers (SAE), the go-to source for engineering professionals.
Each Draw-Tite trailer hitch receiver undergoes extensive fatigue testing and static testing with the ball mount that is either supplied or recommended for use with that particular hitch, thus ensuring results that are applicable to real life use. Fatigue testing is also conducted on hitches rated for use with weight-distribution systems.
In addition, Draw-Tite performs static testing on a simulated automobile, as opposed to the rigid fixture used for SAE testing, resulting in a more true-to-life scenario.
At etrailer.com we're committed to the products we sell, and to our customers. Our experienced and knowledgeable staff are available via both phone and email to address your questions and concerns for the lifetime of your hitch. The technicians at etrailer perform hitch installations on a daily basis, making them a valuable resource for do-it-yourselfers. The one-on-one, personal service you'll receive comes straight from an expert in the towing and automotive field. We've installed it, we've wired it and we've towed with it, so whatever your question, we can answer it.
Video of Draw-Tite Max-E-Loader Trailer Hitch Receiver - Custom Fit - Class III - 2"
Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.
Today we are going to be installing hitch part number 41511 from Draw-Tite on a 1993 Chevy Suburban. Looking up under the vehicle now at the frame rail, we are going to go ahead and point out the attaching points for the hitch. As you can see, there are three existing holes at the bottom of the frame that we are going to use as the attaching points. We do need to enlarge these holes before we can put the hardware into place. See the one at the rearmost attaching point, we are going to need to enlarge to a half-inch, and the two forward ones are going to need to be enlarged to nine-sixteenths. So we are going to go ahead and do that now on both sides.
OK, with the holes drilled, we are going to go ahead and put the hardware into place. On the rearmost attaching point we can just set the hardware into place. On the forward-sided holes, we are actually going to have to fish wire the bolts through the framework here and into place. And we are going to use a bolt leader, which we do so here on our Web site. It makes things a lot easier to fish the bolts into place. The access point we are going to use is actually up over the crossmember here. There is a hole that I can fish this through. And with that in place, we can go ahead and put the bolt leader through the block and then wrap the threads of the bolt with the bolt leader. This will allow us to pull the bolt and block through the frame and into position. We are going to do that for both of the forward attachment points on both sides of the vehicle. One thing I do want to note here is that they do offer different blocks here in the hardware kit. You want to make sure you use the correct one in the appropriate positions. The ones on the forward side of the vehicle, you want to use the block with the hole offset to the side. That is going to allow this to not catch inside the frame when you lay it in there. The ones where the hole is actually offset toward the top, you want to put that one in this position here. OK, and again, we want to repeat that procedure for the passengers side, as well.
OK, with the bolts up into position, we can go ahead and put the hitch in place. And we are going to go ahead and use the fasteners that are provided in the kit to attach it. OK, with the hitch up into place, we are going to go ahead and hand tighten all the bolts down. And then after that we are going to go back through and torque them down. The bolts need to be torqued down to 107 foot-pounds. OK, with the bolts torqued down, the installation is complete. And this will conclude the installation of part number 41511 on a 1993 Chevy Suburban.
1998 Tahoe by Chevrolet Owners Who Purchased This Trailer Hitch Also Bought...
Average Customer Rating: 5.0 out of 5 stars (1 Customer Reviews)
by: Nick B06/15/2011
Is this review helpful?
Installation was very simple and painless. All bolts fit perfectly without having to drill the frame out. Took 24 minutes to install. 17057
Ask the Experts about this Draw-Tite Trailer Hitch
Complete Towing Package
1998ChevroletTahoe
Tech Tip
Drilling required for installation
Info for this part was:
At etrailer.com we provide the best information available about the products we sell. We take the quality of our information seriously so that you can get the right part the first time.
