Trailer Hitch > 2002 > Buick > LeSabre

2002 Buick LeSabre Hidden Hitch Trailer Hitch Receiver with Drawbar Class II - 1-1/4"

Hidden Hitch Trailer Hitch

Code:   90140



Shipping Special

Shipping Weight: 43.86 pounds


2002 Buick LeSabre - Hidden Hitch Trailer Hitch Receiver with Drawbar - Custom Fit - Class II - 1-1/4"

Specially designed for light-duty applications, this fully welded Buick LeSabre trailer hitch receiver features a powder coat finish over an e-coat base to ensure superior corrosion resistance. Drawbar, pin and clip included.

Confirmed to fit your 2002 Buick LeSabre


  • Custom-fit trailer hitch lets you tow a trailer or carry a bike rack or cargo carrier with your Buick LeSabre
  • Computer-aided, fully welded steel construction ensures strength and durability
  • Easy, bolt-on installation - no welding required
    • Complete hardware kit and installation instructions included
  • Lifetime technical support from the experts at
  • Black powder coat finish covers e-coat base for superior rust protection
  • Sturdy, square-tube design
  • Drawbar, pin, and clip included


  • Receiver opening: 1-1/4" x 1-1/4"
  • Rating: Class II
    • Maximum gross trailer weight: 3,500 lbs
    • Maximum tongue weight: 300 lbs
  • Limited lifetime warranty Technical Support

At we're committed to the products we sell, and to our customers. Our experienced and knowledgeable staff are available via both phone and email to address your questions and concerns for the lifetime of your hitch. The technicians at etrailer perform hitch installations on a daily basis, making them a valuable resource for do-it-yourselfers. The one-on-one, personal service you'll receive comes straight from an expert in the towing and automotive field. We've installed it, we've wired it and we've towed with it, so whatever your question, we can answer it.

90140 Hidden Hitch Class 2 Trailer Hitch Receiver

Video of Hidden Hitch Trailer Hitch Receiver with Drawbar - Custom Fit - Class II - 1-1/4"

Videos are provided As a guide only. Refer To manufacturer
installation instructions And specs For complete information.

Video Transcript for Trailer Hitch Installation - 2002 Buick LeSabre

Today we are going to be installing Draw-Tite hitch part number 36309 on a 2002 Buick LeSabre. This hitch application will also apply to the Hidden Hitch part number 90140. Okay, underneath the vehicle, we are going to go ahead and take a look at the frame rails and point out the mounting location for the trailer hitch. Looking at the passengers side frame rail, you can see we have got the exhaust here that is mounted to this bracket here at the end of the frame. We are going to need to lower that down. The weld nut that this bolt is attached to, which is holding our exhaust bracket on, is going to provide our rear-most attaching point for the trailer hitch. And that is going to be the same on both sides of the vehicle. Our more forward attaching point we are actually going to have to drill. So what we will do is put the hitch up in position with our rear-most attaching point, and then we will use the hitch as a template to drill the hole out on each side.

So the first thing we want to do is go ahead and lower the exhaust down here on the passengers side. Okay, you can see here on the drivers side, our weld nut has a lot of corrosion built up in there, and when we try to install our 10-millimeter bolt, it is not wanting to start at all. In fact, it almost seems like the bolt is too big. It is a common misconception, again, when the weld nut has got a lot of build-up in there. So, to go ahead and clean that out, we are going to use a spray lubricant, like a WD-40, and go ahead and soak that up, let it sit for a second. And then you can take a wire brush I am using actually the top of a battery terminal cleaner here. And just run that in there a few times. What that is going to do is help loosen up all that debris and road grime that is in there. And then you can repeat that process a few times. And then once we have got that all nice and loosened up, we can actually go ahead and take our bolt now, and we just need to get it started - use our ratchet or our air gun, and run it in and out a few times. And that will help to further clean it out. Now that we have got the weld nuts thoroughly cleaned out, we can go ahead and hang the hitch up by those weld nuts using, again, the new 10-millimeter hardware that is provided with our installation kit.

We are just going to snug these bolts up for the time being, just long enough to get our holes drilled out - because, at least here on the passengers side, we are going to need to bring this bolt back down, because our exhaust bracket is going to need to go back up. Next, we are going to go ahead and drill our holes out. I am going to start by using a 1/4-inch drill bit to drill a pilot hole, and then we are going to enlarge them to 1/2 inch. Okay, if you are having trouble over here on the passengers side trying to get your drill bit up around the exhaust, I recommend using an extra-long drill bit. Again, I am going to start off with a 1/4-inch and then use a 1/2-inch one after that. Now that we have got our holes drilled out, we want to fish our 1/2-inch carriage-bolt-and-block assembly in through the frame and down through the hole that we just drilled. To do that, the instructions state to enlarge one of these oblong holes here at the forward side of the frame to get our hardware in place. But on this particular model, we have actually got here on the side of the frame a very large access hole that we can use. Our hardware fits perfectly through there. So I am actually going to be using a 1/2-inch bolt leader here that we do sell here at, and I will feed it through the hole that we just drilled. And we will bring it out the access hole. Next we will take our block and feed in onto our bolt leader here, and then we will take our carriage bolt and wrap the threads of it with our bolt leader. And then we will just take and feed them through the hole. And we will be attaching that bolt with the lock washer and hex nut. Okay, and then we will repeat that procedure for the passengers side, as well.

Okay, next we want to take our exhaust bracket and remove it from the rubber hanger. What we will be using is, again, the new exhaust bracket, which is provided with the installation kit. What we are going to do is, the square hole is going to be fed onto the rubber hanger with the carriage bolt that is provided. We are just going to slide that through here, feed that through. And we will attach that with the locking flange nut that is provided, again, with the installation kit. We are going to tighten that down, but we want to make sure we do not overtighten. It is a lock nut, so it will stay in place. Okay, that should be good enough there. Again, we want it just enough where it is tight, but not too tight where it will not still allow the rubber hanger to rotate on its own. Next, we are going to go ahead and torque down our 1/2-inch carriage bolts. You want to check with your directions to verify the appropriate torque rating for each of the individual bolts. And again, if you do happen to have a model that has dual exhaust, obviously you are going to want to repeat both of these procedures for both sides of the vehicle. Okay, now I am going to go ahead and pull the bolt back out of the rear-most attaching point. And we will go ahead and reinstall our exhaust. And we want the bracket where the carriage bolt is facing up, and then, obviously, this flat piece resting against the bottom of the hitch. What this is going to do is, it is going to provide the additional clearance we need to make sure that the exhaust system does not rattle against the hitch. Okay, and then we can go ahead and torque our 10-millimeter bolts down now. Okay, and now that we have got all our bolts torqued down, our installation is complete. This will conclude the installation of Draw-Tite hitch part number 36309 on a 2002 Buick LeSabre.


Ask the Experts about this Hidden Hitch Trailer Hitch
Do you have a question about this Trailer Hitch?

  • Trailer Hitch, Bike Rack, and Roof Rack Recommendations for a 2000 Buick LeSabre
  • For the 2000 Buick LeSabre, the Draw-Tite, # 36309, and Hidden Hitch, # 90140, trailer hitches are the same as they are made by the same company. The more economical hitch is the Draw-Tite Trailer Hitch, # 36309 because it does not include a drawbar, hitch pin, and clip like the Hidden Hitch. If you need a drawbar, pin, and clip, go with the Hidden Hitch. I have included a link to the installation details and an installation video below. Instead of a trailer hitch, another option would...
    view full answer...

  • Hitch Recommendation for a 2000 Buick LeSabre
  • I have a Hidden Hitch that will work on your 2000 Buick LeSabre, but the Hidden Hitch part # 60832 is not a confirmed fit for that vehicle so I do not recommend it for you. You would want the Hidden Hitch part # 90140. I attached an install video for this product for you to check out also. For a hitch mounted cargo carrier I would recommend the Curt Cargo Carrier part # C18145. This is a highly rated cargo carrier that would work well on the hitch I recommended to carry extra cargo....
    view full answer...

  • Hitch Receiver Size for 2000 Buick LaSabre Trailer Hitch
  • All of the trailer hitches we carry that have been determined to fit the 2000 Buick LeSabre are Class II hitches and have a 1-1/4 inch hitch receiver. We do not have a hitch for the 2000 LeSabre that has a 2 inch hitch receiver. If you are looking to do some light towing, I recommend the Hidden Hitch # 90140. The recommended ball mount for this trailer hitch is # 36063. You will also want a hitch ball, like a 2 inch hitch ball # 19258 or a 1-7/8 inch hitch ball # 19256.
    view full answer...

Do you have a question about this Trailer Hitch?


At we guarantee:

Highest quality trailer hitch for the best price.

Real product know-how.

  • We make sure that the products we sell are what we say they are, and that they work the way they are supposed to work. This helps you get the right product the first time.
  • Every day our teams test, review, assemble and install our products. Our modern installation facilities allow our expert installers and customer service representatives to actually install and use the items we sell, so you can get real advice, from a real person who has the knowledge and expertise needed to solve your problem.

Most detailed, accurate trailer hitch information available.

  • Because we take providing accurate product information seriously, we take our own detailed product photos, demo videos and installation videos, as well as verify measurements, instructions, and vehicle fit information.

Information for this part was:

Video Edited:
Andrew K
Written by:
Lindsey S
Expert Research:
Michael H
Updated by:
Laura H
Test Fit:
Shane T
Video by:
Alan C

Installations, made easy.

  • We love helping people.
  • We have the most highly trained customer service, hands-on experience, step by step videos and installation instructions. We are prepared to answer any question, give advice, or troubleshoot any problem you come across.

Fast shipping.

Personalized service for life.

  • We provide one-on-one, personalized service from the ordering process through the life of your product.

Trusted since 1946.

  • We've been serving customers since our parts store first opened in 1946 and continue to be recognized by our customers, our vendors and third parties for exceptional service.

Weight Carrying Capacity
Gross Towing Weight (GTW):
3,500 lbs.

Tongue Weight (TW):
300 lbs.

Weight Distribution Capacity
Hitch does not allow
use of weight distribution

Trailer Hitch Installation Instructions 90140 Installation instructions 90140 Installation Instructions

Tech Tip
Additional installation time needed for vehicles with heat shield or Load Leveling Control. Drilling required for installation , Exhaust must be temporarily lowered for installation

Manufacturer Estimated Installation Time

Recommended Wiring:
wiring 119179KIT

Recommended Balls:

1-7/8" hitch ball - 19256

2" hitch ball -19258

If you have any questions you can contact our customer service department.
