TrailerMate Custom Tail Light Wiring Kit for Towed Vehicles

TrailerMate Tow Bar Wiring - TM780067

Quickly and easily connect your towed car's lighting system to your RV to activate the signal lights required for towing. This custom harness plugs directly into your vehicle's existing wiring - no cutting or splicing required.

Features:

• Lets you connect your RV's tail, brake and turn signal lights to your towed vehicle's lighting system
  • Provides 4-way flat plug at front of towed car to connect to motor home
• Plugs in quickly and easily - no cutting or splicing of wires
  • Connection points are located behind your vehicle's tail lights
• Helps prevent damage to towed car's electrical components caused by electrical feedback
  • Built-in diodes safeguard car's wiring
• Won't interfere with electrical system when towed car is not hooked up to RV
• Provides connection point for 4-pole flat wiring harness (TM85330 - sold separately) at rear of towed car
  • Tow a trailer behind your car when it's not being flat towed
• Custom designed for your vehicle
• Includes wiring harness, mounting bracket and 4-flat extension loop for hookup
  • Brake light relay (RM-88400 - sold separately) may be required if used with supplemental braking system
• Limited lifetime warranty

Wiring Your Vehicle with TrailerMate

Typically, wiring your car for flat towing is a tremendous chore. You have to position and mount multiple diodes beneath your car and then splice into the car's wiring. Before cutting and splicing, though, you have to use a circuit tester to identify each wire. This must be done for the wires carrying signals from your running lights, brake lights, and both turn signal lights. And don't forget to jump the diodes so that the running light signal is sent to both sides of your car.

Or...you could just plug in the TrailerMate wiring harness. This custom-fit system plugs into your vehicle's existing wiring harness, which is located behind your car's tail light assemblies. No cutting, tapping or splicing is required. The wiring around the plugs is encased in durable convoluted tubing, making it easier to handle and safer to route as well.

After plugging in the wiring harness, use the included bracket to mount the 4-way flat connector at the front of your towed car. Then hook up to your RV with the supplied wiring extension, and you're good to tow. Note: The extension included with this system requires that your RV have a 4-wire flat trailer connector. If your RV has a 7-pole round connector, or another type of connector, then an adapter is required.

Do You Need a Brake Light Relay?

Because your vehicle has a combined lighting system - wherein the brake signals and the turn signals are carried on a single wire - a brake light relay (RM-88400 - sold separately) may be required if you use a supplemental braking system with your towing setup. A supplemental braking system depresses the brake pedal in your towed car every time you apply the brakes in your RV. So, if your towed car's brake lights illuminate when the brake pedal is pressed and the engine is off - as is the case when towing - then you need to install a relay to ensure that the lights on your towed car always act in accordance with the signals sent by your RV via the wiring harness. Without a relay, the brake signal from your towed car will override the turn signal sent by your RV when you slow down to make turns, creating a potential hazard.

T-Connector Function for Towing a Trailer

When you're not flat towing your car, the TrailerMate wiring harness can remain on your vehicle; it will not interfere with the electronics. And if you ever tow a trailer with your car, you'll be wired and ready. The TrailerMate system comes ready to accept 4-flat wiring (TM85330 - sold separately) at the rear of your vehicle so that you can hook up a trailer quickly and easily. Just plug in the add-on 4-way trailer connector, and you're good to go.

780067 TES Trailer Mate RV Tow Harness for Towed Vehicles

Video of TrailerMate Custom Tail Light Wiring Kit for Towed Vehicles

Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.

TrailerMate Tail Light Wiring Kit for Towed Vehicles Installation - 2011 Chevrolet Malibu

This Product Fits The Following Vehicles

2008 - 2013 Buick Enclave

2008 - 2012 Chevrolet Malibu

2009 - 2012 Chevrolet Traverse
