/Backup Camera Systems
/Standard Camera System
Wireless backup camera uses digital transmission to relay images to the full-color, 3.5" display. Infrared LEDs surround water-resistant camera for night vision. Camera mounts to license plate, and monitor secures to dash with suction cup mount.
Wireless Backup Camera
It's not always easy to spot objects that are right behind your car when you're pulling out of your driveway or parallel parking. This backup camera activates when your vehicle is in reverse to decrease blind spots, thus improving safety and giving you peace of mind. The LCD display secures to your dashboard or windshield with a suction cup mount, and you can adjust the mounting arm to get the perfect viewing angle.
Digital Transmission without Interference
This backup camera system uses digital technology to transmit images from the camera to the monitor. Unlike wireless devices that use analog technology, this camera system does not pick up interference from Bluetooth or other wireless devices. This means that it provides clear, high-quality video that won't be interrupted.
Water-Resistant Camera with Night Vision
The backup camera has an IP66 rating for resistance to water. It is surrounded by 6 infrared LEDs. In dark or dim lighting, a sensor on the camera housing activates the LEDs. This way you can see what's behind you whether it's day or night.
Full-Color LCD Monitor with Parking Guidelines
The 3.5" LCD monitor displays clear, full-color images and is easy to operate. Use the system's parking guidelines to avoid running into objects or other cars as you back down your driveway, pull out of a parking spot, or parallel park. Differently colored lines on the display indicate the distance between your car and the objects behind you. The parking guidelines can be turned on and off using a button on the monitor.
A. Menu button
B. Up button to adjust monitor settings
C. Power button
D. Down button to adjust monitor settings
E. Parking guidelines on/off button
F. Blue power LED
You can adjust the monitor's brightness, color, contrast, and image orientation to customize your view. For additional visibility, this monitor can also be used with a second camera (not included).
Blue LEDs are located on either side of the monitor. These LEDs will blink when the monitor has power and is turned on but the vehicle is not in reverse. This indicates standby mode. When your vehicle is in reverse and there is power to the camera, the LEDs will stop blinking and burn solid blue.
The transmitter is built into the backup camera, which simplifies installation. The camera is attached to a mounting plate that is secured behind your license plate using your existing license plate screws. Customize your view by adjusting the height of the camera or tilting it to any of 6 positions.
The two wires on the camera hardwire to the reverse lights on your vehicle. It may be necessary to drill a small hole to route the camera wire. A plastic grommet is provided.
The monitor attaches to your windshield or dashboard with the included suction cup mount. The adjustable arm on the mount lets you change the position of the monitor to create the perfect viewing angle.
To power the monitor, use the included 12V/24V DC cord, which plugs into the side of the monitor and into your accessory socket. This way you can unplug the cord and remove the display to keep it out of sight of thieves.
Video of Peak Performance Digital Wireless Backup Camera w/ Color LCD Monitor and Night Vision
Videos are provided As a guide only. Refer To manufacturer
installation instructions And specs For complete information.
Today we are going to be taking a look at the Peak Performance Wireless Backup Camera with the color LCD monitor. The wireless backup camera system is going to minimize blind spots, and help avoid accidents. This is perfect for cars, SUV's, and trucks, and it also works great for boats, RV's, and campers. Towards the end of the video we're going to hook it up to power and get a live feed, that way we can see what everything looks like. The unit is going to feature a digital transmitter that is built into the camera, which is going to simplify the initial setup. This type of system really eliminates interference from Bluetooth, and other wireless devices.
It's going to offer high quality, uninterrupted video. the monitor, right here is a three and a half inch full color LCD monitor. It's going to secure to your windshield, or dash with the included suction cup mount. It's going to feature the mounting arms that are able to tilt, that way you can adjust the viewing angle. Now, brightness, color, contrast, and image orientation can all be adjusted. It is going to portray mirror image.
That's going to offer a precise viewing from the drivers perspective, which is exactly what we want in a backup camera system. Now, the three and a half inch measurement is measured from corner to corner across the screen, diagonally. The camera is going to feature a water resistant design. It's going to mount to the same attachment points as your license plate. It's going to offer a hundred and ten degree horizontal viewing angel. Height and vertical angle can be customized, so there is a little bit of give in there.
You can adjust that as necessary, depending on your application. Again, it's going to mount to the license plate attachment points on the vehicle. It's going to feature six infrared LED's on the camera housing, so it will provide night time vision. Once everything is connected on the LCD display, we're going to notice that it's going to have parking guidelines. That's going to be displayed on the monitor, and that's going to let you easily parallel park, or back out of a parking spot. Those parking guidelines, simply indicate that this sense between your vehicle, and other objects. The parking guidelines can be turned off with a simple push of a button, so you can turn those on and off just by pushing the button, and that's all there is to it.
The system is going to automatically activate when you shift into reverse. Pretty simple installation. All the necessary mounting hardware is included. The monitor is going to plug into your vehicle twelve volt, or twenty-four volt DC auxiliary outlet. It's going to come with that power cord. That is going to measure six feet long, so you can easily make the connection. The camera is going to hard wire into the vehicles reverse lights. Six feet of wiring on this side, as well, and you've got your exposed wires there to easily make your connections, and it's going come with equipped splice connectors to get those connected as well. It's going to come with some cable ties, that way you can secure any access, or slacking, or wiring. Making sure your wires are up and out of the way, and they do include a grommet in case your application requires drilling to run the wires through. That way you can install that grommet, and run the wires through there, so the wires don't get damaged. It's going to come with the necessary mounting hardware to get the camera mounted. When it comes to the monitor, we are going to take a look at the overall dimensions, real quick, going in this direction, edge to edge, we are looking at about four and three quarters of an inch. This direction, edge to edge, we are looking about three and one quarter inches. The thickness, just measuring from the back of the unit to the front, we are looking at a thickness of about once inch. So, really nice design. That monitor can easily be detached from that mounting arm, and you can just tighten up everything, once you have the angle set. Again, the LCD display corner to corner is three and a half inches. The power cord length, once again, six feet long. When it comes to the camera, we are looking at a digital transmission distance without interference of six hundred and fifty-six feet. Pretty incredible, for this unit. Frequency is two point four gigahertz. It will work with twelve volt, or twenty-four volt DC systems. It's only going to draw about one amp of power, so that's the power drawl rating on the unit, and it's going to have a water resistant rating of IP66. We are going to go and hook it up to power. That way you can see what it looks like. We are also going to try to turn off our overhead lights, and see if that nighttime vision design, or feature really kicks in. All right. We have that on, now we just need to wire this up. You can see that there, the camera is on. It's working just fine. I'm going to bring it in a little bit closer on this LCD display, so we can get a good look, and everything it has to offer. You can see there, the parking guidelines, and again those can be turned on and off with a push of a button. Just like that. You are going to have a down arrow, and an up arrow, that's going to allow you to navigate through the options. Your going to have a center power button, and then you are going to have your menu button, right here, and again, that's going to allow you to adjust your brightness, contrast, color, and image orientation, and some other options with that. Now, also what I want to do is I want to go ahead and turn off our overhead lights, so now you can see that even in a low light setting, those infrared displays kick on, and you can clearly see the display there on the LCD screen, even with our overhead lights turned off. That's a really neat design. Again, that's going to feature six infrared LED's. I think I said, displays earlier, but that's going to be six infrared LED's on the camera housing. It's going to provide your nighttime vision. Now, I'm going to go ahead and wire this to the reverse function. I just had it running, just straight power. If I want you to be able to see the response time that it has, so when nothing is being connected, so right now, we have power running to the screen, and we have our camera hooked up, but we're not in reverse. You can see there that we have that blue LED flashing, that means that it's receiving power, so when we activate, or go into reverse you can hear that button click, that blue light is going to kick on, and remain on, and then it's going to display the feed from our camera. When we shift out of the reverse gear, that's going to go back into like a hibernation mode. That's a really nice design of the unit. That is going to do it, for today's look at the Peak Performance Wireless Backup Camera System.
Average Customer Rating: 3.9 out of 5 stars (8 Customer Reviews)Wireless backup camera uses digital transmission to relay images to the full-color, 3.5" display. Infrared LEDs surround water-resistant camera for night vision. Camera mounts to license plate, and monitor secures to dash with suction cup mount.
I installed the camera so I could line up the ball on my truck to the hitch on my travel trailer by myself without having to get in and out of the truck 5 or 6 times to see if I’m lined up. The camera works well and I was able to line up the truck with the trailer the first time I tried it out. The image resolution could be sharper and depth perception takes a little getting used to (that depth thing is on me not the camera) but overall the system works very well. I would recommend this product to a friend. 293233
by: Dale R.08/03/2016
I bolted this camera to the license plate on the back of my travel trailer. The power wire connects to the trailer's back-up light. I plugged-in the existing pigtail from the trailer to my tow vehicle. I put the display in the cab, visible to the driver. When I shift into reverse, the display lights-up with a nice bright image of what's behind the trailer like trees, people or big rocks. This installation took about an hour. Testing the system took another half hour. 279092
by: Greg from Arroyo Grande01/04/2017
Great product and very happy. Even I was able to install the device by myself, that is a major accomplishment. I was able to hook up my trailer without assistance and I don't need to jump out of my truck for alignment or distance verification. I really don't know what took me so long to get it, no brainer. Thank you very much etrailer.com 329854
by: Joe D11/20/2016
Keeps playing some sort of recorded video at random times and I cannot find a way to clear it. A real pane 318263
by: jennifer boykin09/30/2016
well it didnt last very long! the back up screen was very fuzzy and worked half the time. 301976
by: waymon p01/21/2017
every was as advertise I had no problems mounting the units and it works great 334340
by: lee g02/23/2012
its not as eazy as it sounds but it can be done. IT work that whats importent 32281
This item works great! It's for the wife's car and she's happy with it. 114146
