119180 Tow Ready Circuit Protected ModuLite Protector with Hardwire Kit
Video of Upgraded Circuit Protected Modulite with 4 Pole Harness and Hardwire Kit - Includes Testers
Videos are provided As a guide only. Refer To manufacturer
installation instructions And specs For complete information.
Today we're going to be taking at look at the Tow Ready upgraded circuit protected ModuLite with the four pole harness and hard wire kit. This unit is going to provide a four way flat trailer connector at the back of your vehicle to power your trailer signal lights, and it's going to include everything that you need for a full installation. It's going to offer short circuit protection which is going to safeguard itself and the tow vehicle against harmful electrical shorts and miswire situations. It's going to virtually eliminate draw on the vehicle tail light circuit, so that's a great advantage to have with this system. The tail light circuit on this unit has been upgraded to work with vehicles using PWM which is pulse width modulation, allowing the converter to turn on fully giving the trailer maximum light brightness. This unit's going to power the trailer stop, turn, tail and running lights directory from the tow vehicle battery. It's going to prevent feedback from trailer to vehicle systems.
It can be used on two and three wire systems. Just keep in mind when used on a two wire system, the thin red wire which is going to be your brake wire, must be grounded. It's going to adapt a three wire system on the towing vehicle to a two wire system on your trailer. It will work on vehicle and trailers with either LED's, incandescent or standard bulb tail lights. It's also going to work with most vehicles that use a multiplex wiring system for lighting. Again, we're going to go over the components that it all includes.
When using this system, you're going to have a maximum amperage of 2.1 amps per side for the stop and turn lights and 5.6 amps for the tail lights. Included with the kit, you're going to get your four way connector. You can see we've got the wire bundled up here so that way you can extend the amount that you need out the back of your vehicle to make your connection to power your trailer signal lights. It's going to have the dust cap. That way we can protect the connection points when the connector is not being used. We can cover those up and that's going to help prevent any type of corrosion from settling into our connection terminals. The black box is going to be a converter box.
This is simply going to help avoid overloading the vehicle's electrical system. Then on this side, you're going to have all your wires. Your green wire is going to be for the passenger side turn signal. Your yellow wire is going to be for the driver's side turn signal. Your brown wire is going to be for your running lights.
The thin red wire is going to be for the brakes. The white wire with the ring terminal attached to it, this is going to be for your ground connection. Some vehicles that this unit will work with is going to have a grounding post in which you can slide this over the post and reinstall the hardware to make the ground connection. Some vehicles with not have that post. They include a self tapping screw so you can make that connection to a nice clean, metal surface. Then you're going to have your thick red wire. This is going to be your 12 volt power wire. It's going to connect to the bundled black wire here. This is going to be 20 feet of 12 gauge wiring. This is going to be the power wire that runs all the way to the vehicle battery. So the red wire is going to connect to the black wire using the included butt connector. It's also going to include a heat strength butt connector. Then you're going to have your fuse holder. Fuse holders are going to get cut right here in the middle. One end is going to connect to the other end of the black wire with the other butt connector. The other end of the wire is going to get one of the two ring terminals attached to it. That's going to connect to the positive post on the vehicle's battery. You're going to have a half inch ring terminal for side terminals and you're going to have a three eighth inch ring terminal for top terminals on the battery. You pick which one works best for your particular situation. You're also going to get the included 10 amp fuse. You're going to get some double sided adhesive tape. It's going to get applied to the back of the converter box here. That way you can stick it to a nice clean surface, keep it up and out of the way. Again, two butt connectors, two ring terminals. You're going to get five quick splice wiring connectors. This makes tapping into the wires quick and easy. Very simple system to use. You're going to get your grounding, self tapping screw and you're going to get your circuit tester. This is going to help find the wire functions behind the vehicle's tail lights to ensure that you are connecting everything correctly. Really nice system. Again, it's going to come complete with everything that you need for a full installation. They're even going to include some zip ties. That way you can secure any excess or slack in your wiring for a nice, clean appearance for your installation. That's going to do it for our review of the Tow Ready upgraded circuit protected Modulite with a four pole harness and hard wire kit.
