Quickly and easily install a 4-way trailer connector on your vehicle with this custom wiring harness. T-One connector plugs directly into existing wiring - no cutting, splicing or tapping required. Powered ModuLite reduces strain on wiring system.
Features:
Specs:
Installation
This custom-fit T-One connector plugs into your vehicle's wiring harness, which is located beneath your vehicle, near the rear driver's-side tire. Once you've plugged in the T-connector, insert the provided fuse into the in-line fuse holder.
Once installation is complete, the 4-way flat connector will be stowed beneath your vehicle, near the trailer hitch. A mounting bracket (sold separately) is recommended to keep the connector secure.
It is recommended that you use a small amount of grease on all electrical connections - the plugs on your automobile and the 4-pole connector itself - to help prevent corrosion.
A ModuLite power module is built into this T-One connector. Because most trailers run on a two-wire system - wherein the brake and turn signals are carried on one wire - the separate brake and turn signals from your vehicle's three-wire system need to be combined so they are compatible with the wiring system of your trailer. This power module functions as a tail light converter to combine the brake and turn signal functions of your automobile so that they run on one wire to properly activate your trailer's tail lights. Note: This will not affect how the tail lights on your vehicle operate.
With a ModuLite, your trailer's lights will be powered without overloading your vehicle's electrical system. Because the module draws power directly from your car's battery and bypasses the electrical routes that are used by a basic wiring harness, there is virtually no draw on your tail light circuits.
Video of T-One Vehicle Wiring Harness with 4-Pole Flat Trailer Connector
Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.
All right today on this 2013 Kia Sorento, we are going to install part number 118541. One quick note before we start, we did do this before installing the hitch to make things a little easier to see. Our first step is to go ahead open up the back hatch and remove the driver side tail light, there will be a couple of screws we have to remove and then we can go ahead and remove the taillight, you pull back, straight back and it will unseat from the other snaps. Alright with our tail light loosened up, we will go ahead and push in a tab right here that will disconnect the wire harness from the taillight. Next we will go ahead and remove the plastic push pin as closest to the tail gate weather strip. Right now we can go ahead and start installing the T-1 harness.
We are going to show it on the outside of the vehicle first. Our wire harness is going to hang from the inside as shown here. The four pole wire will actually get wired closer to the center of the vehicle and then wires the plug into the factory tow ports, underneath it will be wired towards the side of the vehicle. We will go ahead and push them in one side at a time and run wires in as far as possible. Again underneath the vehicle, we will go ahead and pull them out.
To help get the wire pulled out we actually use a piece of stiff wire and with the hook on the end to help pull out. We will pull out a full pull wire first and then we will go ahead and pull out the wires to the other side that will go to the factory port. Alright now we will go back to the top and install the module to the existing reinforcing bracket. The module is going to be mounted to the original place where we had the plastic push pin that we removed. Now we are going to need to pull back the fascia a little bit more to give it some more room to work it in there, so we are going to remove the remaining plastic push pin and the screw that is located behind the taillight.
That will give us enough flexibility to work it into place. We what we need to do is push down behind the plastic, again the module with the built in lug nut, you just catch it on the finger and kind of work it underneath there and then install the new bolt. We will go ahead and tighten down the bolt and then reinstall the plastic push pin and just screw it behind on the taillight. Then we will go ahead and reinstall our taillight. All right now lets go ahead underneath the vehicle and go ahead and run our wires.
We will take our four pole wire, run it to the center of the bumper, and keep it out of the way until the hitch is installed. We will go over to the driver side where the factory tow port is located. Number two plugs, we will go ahead and remove the caps. Again there is a small button that we have to push in the caps will release. Then we will match just match it to the T connectors from the bar harness and plug them back into the ports. With that, it will finish it for install. Now we will go ahead and use a test light to go ahead and check the wires to make sure everything is working. We will go ahead and take our test light, and ground it to the ground pin on the four pole connector, and we will test the ground wire first for running lights, and then green for right turn, and yellow for left turn, and then we will have someone hold the brake down, and we will check for left and right turn for a constant signal. Okay, with that it will finish it for our install of part number, 118541 from Tow Ready on our 2013 Kia Sorento.
2011 - 2013 Kia Sorento EX V6 with factory tow package
2011 - 2013 Kia Sorento LX V6 with factory tow package
2013 - 2013 Hyundai Santa Fe Sport models
2013 - 2013 Hyundai Santa Fe Sport with factory tow package
2011 - 2013 Kia Sorento SX V6 with factory tow package
2011 - 2013 Kia Sorento V6 EX with Factory Tow Prep Package
2012 - 2013 Kia Sorento V6 LX with Factory Tow Prep Package
2011 - 2013 Kia Sorento V6 SX with Factory Tow Prep Package
