Code: 56146KIT
Retail:$72.00
Price:$47.18
Shipping Weight: 2 pounds
Shipping Special
Features:
Specs:
Warning: Overloading circuit can cause fires. Do not exceed lower of towing manufacturer rating
Read Mercedes-Benz E-Class's owners manual and instruction sheet for additional information.
Kit Includes:
Surface Mount Technology (SMT) is a method for constructing electrical circuits where components are mounted onto the surface of printed circuit boards.
56146KIT Circuit Protected Tail light Converter with 4-Flat End, Circuit Tester and Quick splices
Video of Curt Upgraded Circuit Protected Tail Light w Converter Hardwire Kit - 4 Pole End (Includes Tester)
Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.
Today on our 2003 Mercedes M Class, specifically the ML 350, were going to install the Curt Circuit Protected 4-Pole Wiring Kit, part number 56146KIT. To begin our install, well first remove the tail light assembly here on the drivers side. There are two fasteners that well need to remove. Then well go ahead and pop the tail light assembly out of its position and use our circuit tester to identify which wires that well be tapping into to connect our converter box for our 4-pole. The blue wire next to the green wire is going to connect to our brown wire from our converter box. This will be our running light circuit.
The green wire will connect to the yellow wire to our converter box, which will be our left turn signal and the manufacturers orange wire will connect to the red wire to our converter box for our brake signal. Lets go ahead and use a quick connector provided with our install kit and make those connections now. With that done, well go ahead and take some black electrical tape and re-tape up the wires that we stripped back and cover our connection points. Now, well go ahead and take the white wire with a pre-formed ring terminal attached and secure it to the body of the vehicle. This will be the ground wire to our converter box.
Using the self-tapping screw provided, well go ahead and make that connection now. Now, well go ahead and use the two-way adhesive to secure our converter box here to a flat clean surface. Peel back the one side and secure it to the converter box and then the other side and secure it here behind the tail light assembly. Now, we can take the 4-pole wire and our green wire which will be the wire that will carry our turn signal from the passengers side to our converter box down between the bumper fascia and the sheet metal of the vehicle. Next, we can go ahead and take the black wire provided with our install kit and connect it with the black wire from our converter box.
Well feed it up from underneath and using the yellow butt connector provided to secure the two together. Then I'm going to go ahead and take some black electrical tape and wrap up this connection. Now, with all our connections made here behind the drivers side tail light assembly, we can go ahead and reinstall it. Next, Ill go ahead and remove the passengers side tail light assembly so that when we route the green wire, we can feed it up behind it. Now, we can get underneath the vehicle and start routing our wires.
Well take the green wire and route it over to the passengers side and our 4-pole will get routed to the hitch. Keep in mind when youre routing the wires, you need to be especially careful of excessive heat such as the exhaust or moving components such as the steering or suspension. In some cases, the green wire will not be long enough and youll need to add an extra piece to get all the way to the tail light assembly. As in this case, well go ahead and add a piece of green wire. Well strip back both sizes of wire using a blue butt connector, make this connection, and then well wrap it with electrical tape to keep out any dirt, dust, debris, or moisture. Next, we can go ahead and take some black zip ties and secure our wiring. Now, were behind the passengers side tail light assembly. We need to make a connection with the manufacturers turn signal. Well go ahead and strip back enough from the manufacturers tape to make our connection. Our green wire will be connected to the manufacturers pink wire to pick up our passengers side turn signal. Well repeat the same process that we did on the drivers side. Alright, now with the passengers sides tail light assembly connected, taped up and reinstalled, we can go ahead and get back underneath the vehicle and take our black power wire and route it to the engine compartment. Now, weve got our power wire run into the engine compartment, well go ahead and use some zip ties and secure it, and then route it over to the battery. Again, as I route my wire over the battery, well just use some black zip ties to secure our wire. Now that were at the battery, well go ahead and cut off any excess from our power wire. Next, we can go ahead and prepare to add our fuse holder. Well cut the fuse holder in half and strip back both ends. Well strip back our power wire then well add our yellow butt connector to connect the fuse holder to the black power wire and our ring terminal to the other end. Now, we can go ahead and take some black electrical tape and wrap up the butt connection. Now, were ready to go ahead and add the fuse holder terminal to the battery. Here will be a perfect location so well go ahead and add a nut to the positive battery terminal and secure our ring terminal to the battery. Now, we can go ahead and add our fuse to the fuse holder and install the cap. This will complete the install of our Curt 4-Pole Wiring Harness, part number 56416KIT, on our 2003 Mercedes M Class.
