Quickly and easily install a 4-way trailer connector on your Honda Civic with this custom wiring harness. T-One connector plugs directly into existing wiring - no cutting, splicing or tapping required. Circuit-protected converter guards against shorts.
Features:
Specs:
Installation
This custom-fit T-One connector plugs into your Honda Civic's wiring harness, which is located inside your trunk, behind the tail lights on both the driver's side and passenger's side. You will need to remove some interior trim or carpeting to access the harness.
Once installation is complete, the 4-way flat connector will be stowed within your trunk.
It is recommended that you use a small amount of grease on all electrical connections - the plugs on your automobile and the 4-pole connector itself - to help prevent corrosion.
Circuit-Protected Tail Light Converter
A tail light converter is built into this T-One connector. Because most trailers run on a two-wire system - wherein the brake and turn signals are carried on one wire - the separate brake and turn signals from your Honda Civic's three-wire system need to be combined so they are compatible with the wiring system of your trailer. The tail light converter combines the brake and turn signal functions of your automobile so that they run on one wire to properly activate your trailer's tail lights. Note: This will not affect how the tail lights on your Honda Civic operate.
This converter safeguards itself and your vehicle against possible electrical shorts and overloads with integrated short circuit protection. Just install the connector as indicated and rest assured that the wiring system of your vehicle will remain feedback-free.
Video of T-One Vehicle Wiring Harness with 4-Pole Flat Trailer Connector
Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.
Today on this 2008 Honda Civic we are going to install part number 118420 from Tow Ready. This is our T-One wiring harness. First, we are going to get inside the trunk area. We will show you the layout of the T-One connector. The yellow wire goes to the driver side, so does the red and brown wire. The green wire will go all the way to the passenger side. :20
Just use simple clamps to hold the cover up into place. Next, we will remove the threshold panel right here. We will remove the panel right here by removing these two fasteners. You should be able to pull it out enough to get to our connection points. We will then start making our wire connections. :40
The connection for the red and brown wires will fit right here. Make sure they match up so you know you have the right part. Snap this back into the tail light and take your factory harness and plug it back into the T-One. Now we will deal with the yellow wire, it will be your turn signal circuit. Pull this tab out and it comes apart. Plug that into our T-One connector and the T-One connector into the tail light. Next we will install our ground. We will use this factory ground right here. We are done with that side, now lets take our green wire and run that across to the passenger side. Repeat the same process with that wire. This will be our connection point for our green wire. Next we will find a place for our modulite. We will adhear it to the backside of the body work right here. We will take a second here to zip tie our wires up and take care of the slack. Snap our threshold back in place. 2:01
We have our wiring installed, I will show you how to use it. Pull it out, set it on this seal right here because it is thick enough that it will not hurt it when you shut the hatch on it. Just make sure you stay away from the latch right here, and pull out what you need to reach your trailer hitch or trailer. When you are not using it you can keep it safely stored away with the spare tire so it will not be sitting outside all the time getting corroded up. With that, that will finish our install of part number 118420 from Tow Ready.
2008 Civic by Honda Owners Who Purchased This Custom Fit Vehicle Wiring Also Bought...
Average Customer Rating:
4.9 out of 5 stars (76 Customer Reviews)
by: Ron H.09/18/2012
Is this review helpful?
took some time to place hitch and run bolts ,but would be able to do another one a lot faster now that I have done the first. great product worked in drive way with a smaller jack. Took about a hour but a lot of that was jacking up blocking and trying to make the car safe to get under. Holding the hitch, getting bolts centered ,nuts started kind of a pain by myself a second set of hands would have been great help. Just a small helper handing parts or tool while I hold the hitch up would be great55009
by: Allen N.08/24/2011
Is this review helpful?
The product was well designed and a snap to install.22600
by: Eric K.06/20/2011
Is this review helpful?
The Harness itself deserves a 5 star rating. Its Perfect. The hookup instructions, STINK.17320
by: Peter S.03/17/2011
Is this review helpful?
The harness has the appearance of good design, quality manufacture, ruggedness and durability. The connectors fit snugly and securely. The wires are right-sized (length). It works as expected. I installed the wiring harness myself, and initially had problems. I tried to connect to the first two tail light connectors I saw, instead of locating the specified light for a specified harness connector. I thought the wiring harness connectors were misfit. Customer service gently encouraged me to activate the specific light (turn signal or running lights), find that tail light and then connect that harness connection to it. I reluctantly complied, tried it, and found that it worked (as advertised). I called back to thank CS and apologize for being moronic. I was assured that I wasn't a moron. Customer service was patient, tolerant and helpful - a pleasure to deal with.9567
by: Angelo M.12/21/2010
Is this review helpful?
it Works in a 2007 Civic Si Sedan I'm not exactly sure why it says it will not work with the Civic Si models. I researched parts from Honda and found that the tail light wire harness for the 2007 Civic EX and Si are the same. So this past summer I went on a limb and purchased this unit rather than the alternative one which would have required me to spice into wires. I've confirmed that it does work on a 2007 Honda Civic Si Sedan. It may not work for 2008+ Si Sedans, and it may not work for 2006+ Si Coupes, but I know for sure it works on my 2007 Si Sedan without problems. Installation was easy. I read some folks complaining about directions and I don't understand why., I found the directions nearly unnecessary, it's a pretty simple plug-in and go item. If you have a basic understanding of wiring or you've wired up a trailer before, it should be very straight forward where everything needs to plug into and why. I will admit though that you want to layout all the wiring first to decide the best way to mount the harness in your trunk. The process does give you the feeling that you could work for West Coast Customs when you're done.4423
by: ed wyrwas05/22/2010
Is this review helpful?
wire harnis for civic 2007 gave the wire instructions for in car huckup a ZZZZZZZZZZ !!!!!!!! Thanks for your vidio , i gave it A++++ job completed in about 10-15 teen minutes !3055
by: Ralph G04/29/2013
Is this review helpful?
Works just wonderful! Appreciate the movie instructions found on line--very helpful!78251
by: Chris03/06/2013
Is this review helpful?
Plug and play! Great kit. I recommend this product.69304
by: Robert02/21/2013
Is this review helpful?
Quick and easy. Looks professional. 67192
by: Scott W.02/17/2013
Is this review helpful?
This wiring harness fits my 2009 Honda Fit perfectly and installed in minutes.66661
by: Farrell02/13/2013
Is this review helpful?
It was a no-brainer! Less than 5 minutes and up and running!66163
by: Dan01/29/2013
Is this review helpful?
After receiving very good direction for removing the original plugs, installing the harness was simple. Really plug and play. I ordered the wrong harness and received the correct one in just a couple of days. I have purchased several items from etrailer, and their shipping and service have been top rate. I have never before written a review of a purchase; this one stands out so that I do so with pleasure. Dan McBeth64421
by: Richard Z12/17/2012
Is this review helpful?
satisfied with both products do have question how do you remove the rear theshold on 2012 honda so i can wire the rear lights you help would be appreciated 61704
by: Steve D11/17/2012
Is this review helpful?
This wiring installation was as easy at the hitch install. All of your products and service have been great. Thanks for taking care of business (your customers). Now, take the rest of the day off! 59598
by: Scott D.11/12/2012
Is this review helpful?
Product has high quality connectors that matched up perfectly with the connectors in the car. I wish all the wiring harness's availible used T connectors.59299
by: Shawn P.11/09/2012
Is this review helpful?
Install went off without a hitch (no pun intended). I jacked up the car, threaded the fish wire, all in all pretty simple. I actually did it on my own and it went well. I was under the car an braced the bar up, was able to get one of the nuts on and put the other two on to hold it into place while I finagled the other side into place (the passenger side outlet on the muffler was kinda in the way). I was able to get it on easily but tightening the last nut (closest to the back of the car) was a bit tough because the hitch frame gets in the way. Overall, it was simple, it's all tightened down, and now we can tow a trailer/cargo/whatever! Thanks etrailer, your prices beat anyone on the internet and Uhaul by at least 100 bucks.59089
by: JP10/24/2012
Is this review helpful?
Fast service have not installed yet. 58058
by: Trials Warrior10/09/2012
Is this review helpful?
After watching the installation videos I was a little concerned about how to route the power wire to the car battery. It turns out this wiring harness doesn't need a power wire. No need to cut/split wires either. Just unplug the connector from the rear light assembly, plug it into the wiring harness female connector and then plug the wiring harness male connector back into the light assembly. The whole process took me about 45 minutes. This went on a 2012 Mazda 3 hatchback with regular light bulbs.56824
Awesome, im going to grab the same setup for my 2012 Mazda3 S sedan.
comment by: Ed S - 1/17/2013
by: ED10/09/2012
Is this review helpful?
Just wanted to say I'm really happy with the wiring harness for my 2009 Honda Civic. Installation was really easy and thank you to etrailer for the video install. This past year, I've bought a hitch for my civic, for my Fiancee subaru and the wiring harness, and etrailer is an awesome seller. Finally, the wiring harness works great. I was able to install the harness, and then take my trailer to pick up my new living room couch!!! Thank you Etrailer, keep up the great work!!56793
by: Tom C.09/28/2012
Is this review helpful?
Product was very easy to install ( 2011 mazda 3 ). Connections snap tight with ease, and wire appears to be high grade. The instructions were very easy to follow. Took half an hour for toatl install.56043
by: Andrew K.08/20/2012
Is this review helpful?
Does what I need it to do and it's mostly covered up. Though the coverage is an issue with the car not the product. Directions were straight forward and hooking up the plugs was extremely easy.52364
by: Gilbert (Miami)08/06/2012
Is this review helpful?
I purchased this product and received it in less than a week. I was very pleased with this product and the ease of installation. You can't mess this up. It took me longer to pull apart the panels than to install the wires. this is a must for your install. 50713
by: Ben07/28/2012
Is this review helpful?
Excellent customer service via email. Super quick shipment.49639
by: Nick Tedeschi07/24/2012
Is this review helpful?
easy to install 49147
by: Rose D06/26/2012
Is this review helpful?
fast delivery, thanks! 45712
by: jason06/18/2012
Is this review helpful?
Easy to install! Fast Shipping!! Great experience!!!!44654
by: Miljan B06/17/2012
Is this review helpful?
Very easy install. I didn't believe that it was as easy as it said that I did the installation at 12 o'clock at night after work and the hardest part was to get the panels off :) 2011 Mazda 3 hatchback 44487
by: Josh J06/11/2012
Is this review helpful?
Easy to install on a 2009 Honda Fit Sport. Wires tuck behind all the trim panels for a clean look. Plug and wires hide in the spare tire well when not in use.43599
by: Mark05/29/2012
Is this review helpful?
simple installation 41971
by: Tim A.05/17/2012
Is this review helpful?
The item was very easy to install. The directions were also simple to follow. I was done in less than 20 minutes.40794
by: Tom F.05/17/2012
Is this review helpful?
Simple installation, instructions could be worded better, but it is hard to mess up. Nice and simple and could easily be removed without damaging any of the wiring. Installation on an '09 Mazda 3 Sport Touring Wagon (5-door).40770
by: Bruce R.05/14/2012
Is this review helpful?
Product was very good. instructions for the hitch were great. Video was just whatt was needed. Instead of enlarging the frame holes in the car I chose to grind 1/16 inch from sides of rectangular spacers. Please note do not have to remove 10 inches from heat shields only 8 inches. This provides a more professional installation. The wire harness works great as well. Better instructions would have been more helpful in the wiring kit. Overall for the price this is a very good product.40357
by: dan baker05/02/2012
Is this review helpful?
harness is super easy.... instructions stink. It would really help to have a video of a mazda 3 install. It took me much longer to figure out how to remove appropriate panels than it did to complete the wiring.39208
by: diane05/02/2012
Is this review helpful?
easy to install thanks 39121
by: James Delmege04/30/2012
Is this review helpful?
I installed this very quickly and it worked right away. Very well made. My only criticism is that the directions are weak, but frankly there is just not much to the install so it was ok.38860
by: Jon J.04/27/2012
Is this review helpful?
Excellent product- a no brainer to install if you follow video on this site.38625
by: Mardy04/04/2012
Is this review helpful?
Very easy to install. 36159
by: John P.03/14/2012
Is this review helpful?
No wire splicing required! makes installation really easy and simple. Installation took 10 minutes MAX.33843
by: pmurphy02/19/2012
Is this review helpful?
Worked great with instructions provided. Easy to use and simple to install32005
by: Klaus H.02/19/2012
Is this review helpful?
Installation was super easy, everything was there, took 5 minutes including the routing of the cables under the trim pieces.32000
by: Charles W.02/12/2012
Is this review helpful?
This product is as simple and easy to install as one might imagine. Plugs right in with no problems. Coupled with the hitch I also purchased from etrailer.com, I had everything installed in less than 45 mins. Well worth the money.31624
by: Bob H02/06/2012
Is this review helpful?
This was the quickest and easiest wiring job I've ever done! 31231
by: Don - NH01/16/2012
Is this review helpful?
The service was excellent again, this being my third hitch and harness set purchased over a few years from eTrailer. The T-One wiring harness is an excellent product, far superior to cutting and splicing on your vehicle’s wiring, particularly now with the small wires used with the LED lights of modern cars. The installation was straight forward, though the instructions could be greatly improved with some model-specific detail on removing trunk panels, and on identifying the correct vehicle plugs. Ultimately, the number of pins in the connector guides the match-up, but a little more information would speed the process. Overall, an excellent product from an excellent company. Good customer service, prompt delivery, quality products. 29780
by: Chris01/06/2012
Is this review helpful?
The install was easy as pie on a 2005 Mazda3 5 Door. I did buy an M6 bolt to use the existing ground connection on the drivers side instead of using the provided sheet metal screw. Installation takes 5 minutes. It was so easy to install/remove, I chose not to leave it permanently installed. I just install when needed.29167
by: JB G.01/03/2012
Is this review helpful?
Just right. Didn't take long to install. All connections are keyed so you know your doing everything right. Good price, delivery was swift. I would order from them again. 29037
by: Roger S.12/31/2011
Is this review helpful?
The order was prompt and everrything was as described. My third order from eTrailer, I am a fan.28928
by: John H10/02/2011
Is this review helpful?
Super easy to install on a 2010 Honda Fit, easy access to the lights.24966
by: Ed L09/02/2011
Is this review helpful?
Simple, straightforward installation. Easy as pie but not as delicious.23474
by: Dave C.09/02/2011
Is this review helpful?
Super easy to install. This wiring harness is the best way to wire a vehicle for towing.23466
by: Maralee Q.08/31/2011
Is this review helpful?
I loved your service and the product. I asked for it to be shipped right away because I was planning a trip, and my brother was going to install it for me. I recieved an e-mail that said it would ship that day. My brother works in a shop in Montana. I will say he's a gifted mechanic. He installed the product in my 2010 Honda Civic in less then 30 min. with no problems. I am now able to tow my Rack and Roll kayak trailer. Thank You23279
by: Chris M08/24/2011
Is this review helpful?
Easy install. Works. Thanks. 22618
by: Jim C.08/07/2011
Is this review helpful?
Excellent... as easy as stated. 21271
by: Charlie07/22/2011
Is this review helpful?
Product couldn't be much easier to install. Watching the online videos helped a ton - thanks!19949
by: David W.07/22/2011
Is this review helpful?
The T-One wiring harness is an excellent product. It attaches to the original wiring precisely, leaving the job completely reversable should that ever be desired. Making all the connections and routing the wires is quite easy, it's just removal/reinstallation of all the cover panels that takes all the time and care.19875
by: Paul07/18/2011
Is this review helpful?
Exactly what I ordered and was shipped incredibly fast! Will definitely order from Etrailer again!19659
by: Arnold M.07/12/2011
Is this review helpful?
The product was very high quality. Very easy to install. The web page was easy to use. This will be the only place I shop for things for my cars and trailers.19275
by: anonomyous07/05/2011
Is this review helpful?
Good email status and prompt shipment. 18497
by: John D06/12/2011
Is this review helpful?
Easy, easy, easy to install. Enough said. 16780
by: Rick06/11/2011
Is this review helpful?
The installation was easy. The only problem that I had is that the hitch pin was not in the package, just the locking clip. I could not believe that it was missing, but it was, as I carefully went through all the packing material. 16722
by: Adam T.06/06/2011
Is this review helpful?
Simple installation in my Mazda 3. Plugs right into the factory wiring harness. Taking the plastic piece off the trunk took longer than the actual installation.16228
by: Rodg K06/02/2011
Is this review helpful?
Quick easy installation.Perfect fit.Good product.Thank you.15915
by: DBurger05/25/2011
Is this review helpful?
Great service 15392
by: Larry D05/14/2011
Is this review helpful?
Great wiring kit. Easy to install and just worked the first time! Made this all fun.13999
by: Octavio05/12/2011
Is this review helpful?
I received the items as promised. The installation was easy to follow and after some minor modifications was able to install everything as advertised. Looking forward to putting it to use. Thanks!!!!!13668
by: Gil John03/29/2011
Is this review helpful?
High quaility at a great price with super fast shipping. Will buy from again and tell all my friends where to buy hitch supplies etc.10645
by: Tom G.03/25/2011
Is this review helpful?
Wiring harness fit perfectly. Shipping was super fast.10404
by: Eric D.03/09/2011
Is this review helpful?
Quick shipping, well packaged, and good price.8930
by: JR02/11/2011
Is this review helpful?
Installed on a 2007 Mazda 3. The Mazda 3 install was actually easier than the install on the Honda video. The installation video was helpful. This is a high quality product.7021
by: Eris P.01/24/2011
Is this review helpful?
Quickest install I've ever done. 5971
by: Dave S03/31/2010
Is this review helpful?
Real Simple oddly enough I found the instructions easy to follow. But maybe its cos Im a typical bloke, read instructions, get the hang of what it means, chuck 'em away. Open car up and fit them. 20mins later, its done. When I connected it up to the Uhaul, everthing worked perfectly.2887
by: Al from AK02/11/2010
Is this review helpful?
Follow instructions by Jim T. Feed the directions to the dog Jim T, from Harleysville, PA The directions that come with the wiring are general at best, You still have to figure out a few things it's easy but you have to think about what you are doing. 2708
by: Matt W07/06/2009
Is this review helpful?
Special thanks to Jim T!!! I actually owned this for roughly a year before installing the harness. Much like Jim, the hitch went on without a problem, and when I made it to the installation instructions for the harness, I stared at it and my trunk for 15 minutes and put it on the shelf....(yes, i have two engineering degrees.....) I settled for the main intended use of the hitch for carrying bikes :) I decided to following Jims instructions this weekend when I went back to the website to find the "directions" again. Installation was complete within 10-15 minutes thanks to his painstaking instruction writeup. Key is to remove the strip edge piece first. I was able to do the right hookup without removing any panel fasteners, and only had to remove one for the left side (for those of you who try it without, you do have the proper wiring harness, there is a fourth plug above the other three for the missing harness connection (that cost me half of the installation time). A few tie wraps, a few snaps and back in business!! works like a charm. Thanks Jim, there was no need for you to do that but you made the world a better place from your effort!!!2099
by: Clyde T06/02/2009
Is this review helpful?
Good Product Good Product just what was advertised.1931
by: Aaron A10/14/2008
Is this review helpful?
YES FEED DIRECTIONS TO THE DOG The product quality is very good. I gave "Installation" 5 stars because I printed off Jim T's directions (See Below) and followed them step by step. I got the Wiring Harness installed in about 15 minutes. Thanks Etrailer and Jim T1358
by: Jim T,05/22/2008
Is this review helpful?
Feed the directions to the dog While the hitch went on my '06 Civic without a problem, this wiring harness allowed our neighbors to learn some new colorful hyphenated words, fitting to my level of aggravation! While the quality of the product was certainly top-notch, the installation instructions were almost unintelligible, highly generic and ambiguous. I rolled them into a ball after 10 minutes and used them to play fetch with the dog. Here are some tips to make this a 10 minute deal instead of 1-1/2 hours that it cost me. PREPARATION - After the trunk mat is out, remove the plastic interior trunk edge piece (about 2' long and right below the bottom of the trunk opening). To do this, lift up and inward at the same time. There are 4 plastic pins and a location tab that hold this in place. If you simply pull on it from the bottom, you'll break off the plastic locator tab. BE CAREFUL! Once this is off, simply remove the three plastic fasteners from the trunk material so as to gain access to the back of the tailights. It's helpful to have a partner hold this material out of the way while you work. INSTALL - You'll see 4 groupings of wiring coming off the little black logic box, one is for the 4-pin trailer harness and the other three connect to the tailights. 2 of the wire groups (the one with the single yellow wire and the one with the 2 wires) go to the drivers side tailight and the single green wire goes to the passenger side tailight. There are 3 connectors on each tailight, each being different, so it's impossible to make an error connecting. These connectors remove by depressing a tab on the edge of the connector while pulling. For each of the 3 wire groups, simply attach the two connectors in series with the disconnected lead from each tailight. There is a main ground lug just below the drivers side tailight, and this is where you attach the white wire with the eyelett on the end. REASSEMBLY - Get yourself some extra wire ties. Attach all of the excess wire to the factory loom. Now, pull the paper off the double-faced tape on the logic box and attach it to the flat surface just to the outside of the drivers side tailight (between the light and the fender). Reassemble all else, making sure that the interior panels fit into the groove in the trunk weatherstripping or the fasteners won't align. They don't tell you this, but the 4-pin trailer connection stays in the trunk when not in use, and the trunk shuts fine with the lead in use.896
by: kc06/02/2012
Is this review helpful?
Should work will see when I install 42416
