Tekonsha Brake Controller for the Acura TL, 2004

Tekonsha Brake Controller

ratingratingratingratingrating (140 reviews)


Code:   TK90160

Retail:$107.91

Price:$94.95


Shipping Special

Shipping Weight: 1.5 pounds

Quantity:






Tekonsha Primus IQ Trailer Brake Controller - 1 to 3 Axles - Proportional - Acura TL, 2004

Proportional brake controller automatically levels when mounted within a 70-degree vertical range. Includes digital display, 3 boost levels, battery protection and continuous diagnostics. Easily transfer between different automobiles.

Features:

  • Brake controller activates trailer brakes in proportion to your Acura TL's braking action
    • Automatically adjusts trailer's braking based on deceleration of tow vehicle
    • Activates immediately - no pausing like with time-delayed brake controllers
  • Automatic-leveling ability - internal sensor detects deceleration even if controller is not mounted flat
    • Position anywhere from 0 degrees (level) to 70 degrees in the vertical plane
  • 3 Boost levels let you adjust initial braking power and aggressiveness
  • Continuous diagnostic check alerts you to any potential problems
  • Integrated safeguards protect your vehicle and trailer
    • Minimizes drain on car battery when not in use
    • Prevents trailer brakes from overheating by reducing power output to them during prolonged stops
  • Easy-to-read LED display
  • Built-in, slide-bar manual override
  • Quick-disconnect feature lets you easily remove and store the control when not in use
    • Replacement wiring harness (sold separately) and replacement bracket (6927 - sold separately) required to move the controller from one vehicle to another
  • Plug-in, vehicle-specific brake-control adapter (sold separately) can be used for certain applications to reduce installation time


Specs:

  • Application: trailers with up to 3 axles (6 brake assemblies)
    • Designed for use with electric brakes only
  • Dimensions: 4-3/8" wide x 5" long x 2-1/2" tall
  • Mounting: between 0 degrees (level) and 70 degrees in the vertical plane
  • Limited lifetime warranty


Proportional Braking

With a proportional brake controller, you can get heavy-duty emergency braking, general braking or slow-to-an-idle braking for your trailer automatically. The intensity with which your trailer brakes are activated and the rate at which they are applied are dependent on the deceleration of your tow vehicle. This means that, unlike time-delay controllers - which send the same amount of preset power to your trailer brakes every time - proportional controllers are able to adapt to every braking situation differently. So, if you slam on the brakes in your truck, your trailer brakes will activate with that same extreme intensity. And if you merely slow down as you approach a red light, your trailer will gradually brake in the same manner. Just set the initial power level, select a boost setting, and you're good to go.


As long as the Primus IQ controller is properly mounted and is pointed in the direction of travel, it will sense - via an internal inertia sensor - how your tow vehicle brakes. This inertia-based sensor responds to the deceleration of your tow vehicle as you brake by signaling the controller to send out enough power to your trailer brakes so that they are activated with an intensity that matches. The result is uniform braking across your towing setup. No push-pull action - just smooth, proportional braking every time.


Power Boost for Heavy-Duty Towing

Aside from smoother, more efficient braking, Tekonsha's Primus IQ brake controller also offers a boost feature that gives you more initial braking power for those times when you're towing heavy loads. You can switch boost levels so that the power output to your trailer brakes automatically starts out at either 13 percent or 25 percent of the predetermined power setting.


So, if you boost the initial power so that your trailer brakes activate with 25 percent of the overall intensity at the start, the brakes will reach maximum braking faster. This is particularly beneficial if you are towing a heavy load because the intensity required to stop that load may be far greater than that needed to halt your Acura TL. Therefore, sending out more initial power to the trailer brakes - and causing them to reach maximum braking faster - allows you to better control the trailer so that it doesn't push your tow vehicle before coming to a complete stop.


If your trailer weighs less than your tow vehicle, no boost is needed. But if you wish to set the boost so that your trailer leads the braking of your towing setup, you can select level B1. The following table gives an indication of when you might use the different boost levels and the power increases that they offer.


Approximate Gross Trailer WeightBoost LevelIncrease in Initial Power Output
Less than tow vehicle GVWB113%
Equal to tow vehicle GVWB1 or B213% or 25%
Up to 25% more than tow vehicle GVWB2 or B3*25%
Up to 40% more than tow vehicle GVWB3*25%

*Both B2 and B3 offer a 25-percent boost in initial power. But the braking curve for B3 is more aggressive than that of B2. This means that, even though you will start out with the same intensity when using these boost levels, you will get an overall more aggressive braking experience with the higher level. So if you use B3, you will reach maximum braking sooner than if you use B2.


Safety Features

The Primus IQ offers advanced safety features to prevent damage to various components of your towing setup. For example, when it is not in use, this brake controller will be in power-saving mode. In this setting, the power draw falls to minimize drain on your Acura TL's battery.


When you stop at red lights, or any time that your truck and trailer are at a standstill with the brakes applied for more than 5 seconds, the Primus IQ's "hold" feature will activate. When this happens, the power output to your trailer's brakes will be reduced to just 25 percent of the preset power setting so that the brakes will not overheat.


If ever there is a time that you need to brake your trailer separately from your tow vehicle - when traveling down a steep incline, for example - the manual override is easily accessible. Pushing this slide bar engages the brakes on your trailer with full power. In addition, when you activate this override, the brake lights on your trailer will illuminate, properly warning those behind you of the braking action of your rig.


In addition to all of those safety features listed above, the Primus IQ offers diagnostics such as:

  • Open ground
  • Overload
  • Output short
  • Faulty mounting
  • Power loss
  • No trailer connection

Automatic Leveling and Simple Installation

The self-leveling feature of the Primus IQ ensures that the brake controller continues to function even as you drive up steep hills or through the mountains. Simply mount it in your cab at a vertical angle that is between 0 degrees (level) and 70 degrees, and the controller will level itself automatically.


Correct Primus mounting70-Degree Primus mounting

Note: The Primus IQ must be mounted on a level horizontal (side-to-side) plane and must be lined up with the direction of travel for the internal sensor to function properly.


Installation is a snap. After mounting the Primus IQ unit in your cab using the included bracket, hardwire one end of the included pigtail harness directly into your Acura TL. The other end plugs into the brake controller. To transfer the Primus IQ to another vehicle or to remove it for storage, just unplug the unit and snap it out of the bracket.


Installation Accessories

For even easier installation, a vehicle-specific wiring adapter (sold separately) is available for most newer trucks and SUVs. One end of the custom adapter plugs into your Acura TL, and the other end plugs into the controller - no hardwiring required.


Note: If a custom brake-control wiring adapter is not available for your Acura TL, one of the following will be required:

20-Amp circuit breaker (9506P - sold separately) for 2- to 4-brake applications

30-Amp circuit breaker (38630 - sold separately) for 6- to 8-brake applications


See also etrailer.com's exclusive 7- and 4-way brake-control installation kit (ETBC7 - sold separately) if you don't already have a 7-way plug at the back of your Acura TL.



90160 Tekonsha Primus I-Q Proportional Trailer Brake Control

39528 Hidden Hitch Proportional Brake Control

20191 Draw-Tite I-Stop IQ Proportional Brake Control



Video of Tekonsha Primus IQ Trailer Brake Controller - 1 to 3 Axles - Proportional


Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.

Video install brake controller 2005 chevrolet express van tk90160
Trailer Brake Controller Installation - 2005 Chevrolet Express Van
Video install brake controller 2011 chevy silverado tk90160
Trailer Brake Controller Installation - 2011 Chevrolet Silverado
Video install brake controller 2006 chevrolet uplander tk90160
Trailer Brake Controller Installation - 2006 Chevrolet Uplander
Video install brake controller 2009 dodge ram 1500
Trailer Brake Controller Installation - 2009 Dodge Ram 1500
Video install brake controller 2005 ford expedition tk90160
Trailer Brake Controller Installation - 2005 Ford Expedition
Video install brake controller 2004 ford f350 super duty tk90160
Trailer Brake Controller Installation - 2004 Ford F-350 Super Duty
Video install tekonsha trailer brake controller 2004 ford f250 tk90160
Trailer Brake Controller Installation - 2004 Ford F-250
Video install brake controller 2013 toyota highlander tk90160
Trailer Brake Controller Installation - 2013 Toyota Highlander
Video install brake controller 1999 toyota tacoma tk90160
Trailer Brake Controller Installation - 1999 Toyota Tacoma

Video Transcript for Trailer Brake Controller Installation - 2005 Chevrolet Express Van

Today on our 2005 Chevrolet Express van, we'll be installing the Tekonsha Primus IQ trailer brake controller for one to three axels. Part number TK90160. To begin with, we'll go ahead and locate the four wires that are part of the factory tow package on this vehicle. You'll see they're right up here underneath the driver side dash, kind of near where the brake pedal is. On our brake controller, we get a short pigtail and it has four different color wires: a black, a red, a white and a blue. We'll go ahead and connect them using some butt connectors, so we'll be tying the blue wire off of our connector that goes in the back of the brake controller to the large blue wire on our factory wiring harness. The black wire off of our brake controller will tie in with the red wire with the white stripe off of our factory wiring harness.

This is the power wire. The white wire will tie in with the black wire. This is the ground wire. The red wire, which is a stop light or brake light switch, will get tied to the light blue wire on our factory wiring harness. Now that we have all of our connections made as well as being taped up, we need to go ahead and find a location inaudible 01:03 our brake controller. We're going to choose to use the plastic style that'll allow you to adjust the brake controller angle a little, as well as easily remove it if you so choose.

To install this, it's just two simple screws that come with the kit. We'll go ahead and choose our location on the lower dash here, but before we put the bracket into place using the screws, we'll check behind the dash to make sure nothing can be damaged behind the dash when we put the screws in. We'll then take the bracket, line it up on our location on the lower dash and install the two screws that come with the kit. Once we have the bracket in place, we'll take our four flat end that we just made our connections earlier with and connect it to the backside of the brake controller. With that done, we can slide our brake controller up into the bracket, locking the tabs in on each side. As far as the functions of the brake controller, the button on the top left is the boost feature button, the round knob on the left side is your power adjustment knob, there's a digital readout screen, and then there's a slide mounted on the right front; this is the manual override button. You've noticed once you've plugged the wiring harness into the back of the brake controller the brake controller was powered up, as well as having an NC which means there's no trailer connected.

We'll go ahead and hook up our trailer and we'll go through some of the other features. Showing how once you plug the trailer in, you get a C, which means the trailer is connected. When we push the manual override button, we can adjust the power level as well as the boost feature. With that, that'll conclude our installation of the Tekonsha Primus IQ trailer brake controller for one to three axels. Part number TK90160 on our 2005 Chevrolet Express van.

.
