Trailer and Vehicle Electric Winch Wiring Kit, for up to 16.5K Winches

Superwinch Accessories and Parts

ratingratingratingratingrating (4 reviews)


Code:   SW2008

Retail:$267.75

Price:$194.95


Shipping Special

Shipping Weight: 11 pounds

Quantity:






Superwinch Accessories and Parts - SW2008

Features:

  • Includes wire and connectors necessary to install a winch on a trailer or on the back of your vehicle
  • Fits Superwinch Models: S5000, S6000, S9000, LP8500, X6CD, X9, EP6.0, EP9.0, EPi6.0, EPi9.0, EP12.5 and EP16.5
  • Kit Includes:
    • (1) 2 AWG 30" Wire - attaches from battery to vehicle frame to ensure a good ground
    • (1) 2 AWG Double Wire, consists of:
      • 25' wire - runs from the rear of the vehicle to the battery, and
      • 4" wire - ground wire - attaches to vehicle or trailer frame
    • (1) 2 AWG 3' Double Wire - connects to winch and will then plug into the 25' double wire

2008 Superwinch Winch Wiring Kit





Video of Trailer and Vehicle Electric Winch Wiring Kit, for up to 16.5K Winches


Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.

Video install superwinch winch wiring 2004 ford f250 sw2008
Superwinch Electric Winch Wiring Kit Installation - 2004 Ford F-250
Video install superwinch wiring kit 2003 ford f250 sw2008
Superwinch Electric Winch Wiring Kit Installation - 2003 Ford F-250
Video install superwinch talon winch 2003 ford f250 sw1612210
Superwinch Talon Winch Installation - 2003 Ford F-250
Video install superwinch winch wiring 2004 gmc sierra sw2008
Superwinch Electric Winch Wiring Kit Installation - 2004 GMC Sierra

Video Transcript for Superwinch Electric Winch Wiring Kit Installation - 2004 Ford F-250

All right, today in this 2004 Ford F250 were going to install part number SW2008 from Superwinch. This is our wire harness for the back of the truck. Well go ahead and mark the ends of our cable. Well go ahead and pair the end with the gray connector to see which is positive and negative and well go ahead and mark the ends. Well go ahead and take our two 5-ft long wires with the gray connector and well route those from the front of the vehicle to the battery. Weve got one wire in and well go ahead and repeat the same process with the other wire.

All right, now well go ahead and attach our positive wire to the positive turn on our battery. Then well go ahead and attach the negative wire to the negative poles on the battery. Next, well go ahead and route the 19-ft long wire thats supplied. Youll have gray end with one long wire and one short wire. The long wire will run up through the frame and up to the battery in the positive side.

The short wire will run along the edge of the frame and attach to the frame at the back of the truck for ground.First off, well go ahead and put our gray connector up where we want it and then well zip tie it in place. Then well continue on running our wire from the front and well make sure we stay away from anything moving like suspension components or anything hot like the exhaust. In this case, we ran along the frame on the inside using zip ties with some existing holes in the frame to hold everything in place. Theyre rounded up into the front of the vehicle and underneath and up towards the battery. When we get to the battery well go ahead and loosen up the nut on our terminal and go ahead and install it.

Then we can go ahead and tighten it back down.Well stop right here and install our ground wire. Were going to install it to the cross member located here behind the spare tire. Well use number 14 self tapping screw to attach it to the frame. Now we can go ahead and add our cover to the plug and were good to go for installation on the truck.Now this kit does come with extra set of cables for quick attachment for your winch. The part number were working with is SW1698201.

Well start off by marking our wires positive and negative. Now theyre marked at the connector and well go ahead and follow them back and put a mark on the end. All right, to install our wiring for a quick connect, now well go ahead and undo the cover on the winch and well remove the positive wire first, that will be the red one. Then well install our positive cable going inside. Well just go ahead and reassemble it. Next, well go to the bottom of the winch and install the ground wire. We have some bolts on the bottom. Once again, well go ahead and remove the original one which will be a black wire and then install the new cable. Well unbolt it and bolt the new one in place.Now well go ahead and show the two connectors working together. Well simply push them together and our winch is connected and are ready for service. With that, that finishes our installation of all these components for part number SW2008 from Superwinch on our 2004 Ford F250.
