Accessories and Parts > Tow Bar Wiring > Accessories > Diodes > Hopkins


Tail Light Isolating Diodes (Qty 4)

Hopkins Accessories and Parts

ratingratingratingratingrating (26 reviews)


Code:   48955

Price:$20.95


Shipping Special

Shipping Weight: 1 pounds

Quantity:






Hopkins Accessories and Parts - 48955

Allows motorhome or R.V. to power the lights on the towed vehicle without power feedback.

  • Includes 4 Isolating Diodes
  • May also require the 4-pole wiring harness or vehicle to vehicle converter (see related products below)
  • Max amperage: 3 amps
  • Max voltage: 24 volts

Note: If vehicle being towed has amber turn signals (separate turn and brake signals) then the vehicle to vehicle tail light converter (118158) will also be needed.


Tail Light Isolating Diode System by Hopkins Manufacturing





Video of Tail Light Isolating Diodes (Qty 4)


Videos are provided as a guide only. Refer to manufacturer
installation instructions and specs for complete information.

Video base plate wiring 2011 jeep liberty
Tow Bar Wiring Diode Installation - 2011 Jeep Liberty

Video Transcript for Tow Bar Wiring Diode Installation - 2011 Jeep Liberty

Today on this 2011 Jeep Liberty, we are going to install part number 48955. First off, what we are going to do for our wire harness is find a spot where we are going to locate the 4-pole end. And you can do it anywhere you want. We are going to actually run it to the center on this vehicle right here for now. Put it over this pin. And then we will go ahead and start routing our cable from the front of the vehicle all of the way back. Just stay away from anything moving, like the suspension components, or anything hot, like the exhaust. OK, we will take our ground wire with the ring terminal and we will run it straight to the frame. We will go ahead and show you how we routed our wire. Above the sub-frame there is a piece of tubing that goes all of the way across the suspension. So we actually thread it through from the front to the rear. It is actually easier to see from the back side right here. And then we were able to run it through the frame, using the wire pull. We were able to go all of the way out to the back of the vehicle. We were also able to route it through the back cross member. Our green and brown wires go over to the passenger side of our vehicle. And our yellow and brown wires will go over to the driver side. 1:02

Alright, next we will go ahead and remove the taillights of the vehicle. We will start off with the driver side and then do the passenger side. We are going to tape into our wires to install the diodes. So we will go ahead and take away the protective covering right now. We will be looking for two circuits. We will be looking for the brake circuit and the running light circuit. Now the reason we are looking for the break light circuit is that is going to do two functions for us. The break light circuit is going to do the break light, of course, and also the turn signal since it will be combined coming off of the RV. That allows us to use two less diodes and less wire splices. And the running light circuit, of course, will be dedicated to the running light. So we will test our socket. And that looks like white with a light green stripe. So that will be our running light circuit. So we will cut our wires in half, add our connectors to them and then we will install the diode in between. Now, when we install our diode, there is a label on there that say out and two inputs. Our out will always go towards the taillight. So we will slide that on. And then our input from our vehicle wire harness will go on one of the tabs. It does not matter which one. 2:05

Have somebody else hold the brake pedal. OK, that looks like a dark green wire with a white stripe. Do the same thing as before. Cut it in half and add our diode. Alright, we are going to take our wires, the yellow and brown, and we are going to pull them up from the bottom up here and connect those up to our diodes. And we will use a zip-tie to hold it in place. Then we will go ahead and shorten our wire to match up to our diodes. OK, we added our terminals to the wires. Now the yellow wire is going to be our brake and turn signal. So that will go to our diode that went to our brake signal. And then our other diode will be the running light circuit. So the brown wire will be running lights. All we have to do now is just bundle everything together. And then just reinstall the taillight and we will move over to the passenger side and do the same thing once more. 2:56

The white wire with purple stripe will be the running light circuit. And our brake signal looks like it is going to be the white wire with a light green stripe. We will go ahead and pull our green and brown wire up. We will zip-tie it off and cut it to length. Our green wire will go to our brake signal circuit. And our brown wire will go to our running light circuit. Alright, and then we will just bundle everything back up and reinstall the taillight. OK, with that that will finish our install of part number 48955.


Customer Reviews

Tail Light Isolating Diodes Qty 4 - 48955

Average Customer Rating:  ratingratingratingratingrating4.7 out of 5 stars   (26 Customer Reviews)




- 48955

ratingratingratingratingrating by: Jerry L.08/04/2011

Is this review helpful?


I RECEIVED THE DIODES TODAY AND INSTALLED THEM AND EVERYTHING WORKS FINE. MY VEHICLE IS A 1996 GEO TRACKER 4 DOOR. GREAT FOR TOWING. THANKS FOR YOUR HELP. 21111



- 48955

ratingratingratingratingrating by: Frank R03/24/2014

Is this review helpful?


Good product that met my expectations. Easy to install and fairly intuitive. I was thinking about purchasing the high-power Roadmaster diodes (at twice the cost) but am glad I bought these--can't tell the difference in light output. Fast shipping from e-trailer.121870



- 48955

ratingratingratingratingrating by: Jim11/18/2013

Is this review helpful?


My husband ordered these but he doesn't do the computer thing so all I can say is he came in the house about 15 minutes after installing these and was very happy that it all went together so quickly and easily. And it all worked like it should when he finished. Husband happy=happy house!107731



- 48955

ratingratingratingratingrating by: Lin Owen09/16/2013

Is this review helpful?


Order was pretty much as expected and the product was received in six days. I was given a way to track the shipment but when I tried to do it and clicked on track command the screen just sat there and stared at me. I finally called and got the info. Product is installed and performing as expected.100070



- 48955

ratingratingratingratingrating by: John M09/04/2013

Is this review helpful?


Not much to say about these except that they do exactly what they are supposed to do. They are a bit smaller than ones that I have used in the past which is nice for fitting in small spaces. It was an easy install on my 2006 Scion Xa98215



- 48955

ratingratingratingratingrating by: John A08/26/2013

Is this review helpful?


I received the diodes this AM & installed them a couple hours later. Checked them out & they work as advertized. Everything went fine with the order except I was never given any tracking info. It was shipped the day I ordered & I received it a week later. I was beginning to wonder if it was shipped or I would receive it. John97084



- 48955

ratingratingratingratingrating by: Jim02/06/2013

Is this review helpful?


not good quality control .installing the diodes on a honda CRV. No room in taillight housing so had to remove inside trim and find supply harness and installed there. Checked and everthing, ok. Hooked up to motorhome an re checked one light would not work. removed trim one more time. replaced connectors re check the discovered when wiggling wires light would blink. One tab on diode had a intermitant contact inside diode. waiting for a relacement?65139


Comments

You replaced the bad diode contact on wiring tap had intermitant contact everything is ok and has worked flawlessly for a year. Thanks for the good service.

comment by: Jim - 2/10/2014


2761



- 48955

ratingratingratingratingrating by: Guy L.05/12/2011

Is this review helpful?


Excellent choice doing the job well. Quick and simple transaction shipped rapidly.13687



- 48955

ratingratingratingratingrating by: Frank02/19/2014

Is this review helpful?


Works as specified. Packaged as needed for standard project ( no extra unneeded stuff). 116932



- 48955

ratingratingratingratingrating by: Andy B.01/28/2014

Is this review helpful?


Seems to be Quality Product. 115048



- 48955

ratingratingratingratingrating by: Tolby C07/23/2013

Is this review helpful?


Very good product exactly as it was described was easy to install|||||||||||||||||||||||||||||||||| Thanks91172



- 48955

ratingratingratingratingrating by: James02/28/2013

Is this review helpful?


Product was as advertised. Delivery prompt. Quality as advertised.68115



- 48955

ratingratingratingratingrating by: Thomas02/18/2013

Is this review helpful?


This order I placed for the diode kits came in only 3 days in great shape and the right stuff! You can't ask for a better company to deal with! I will order from Etrailer again!66770



- 48955

ratingratingratingratingrating by: Ronald02/02/2013

Is this review helpful?


Arrived as promised, in good condition. 64843



- 48955

ratingratingratingratingrating by: Freddie01/27/2013

Is this review helpful?


as always quick shipping,as advertised,good value & a great helpful staff.64263



- 48955

ratingratingratingratingrating by: Ed H07/24/2012

Is this review helpful?


did the job well. delivered on time great job.49189



- 48955

ratingratingratingratingrating by: iggy05/19/2012

Is this review helpful?


Best deal around when you need more than 4 isolating diodes. I used 7 with a spare backup. Can't beat the price41021



- 48955

ratingratingratingratingrating by: Gil J02/21/2012

Is this review helpful?


Performs as expected. Great service, quick delivery!32094



- 48955

ratingratingratingratingrating by: doug. s.01/04/2012

Is this review helpful?


great product at a very good price. Very fast shipping. Thanks!29071



- 48955

ratingratingratingratingrating by: George10/07/2011

Is this review helpful?


suoer product and great help when i went to order25231



- 48955

ratingratingratingratingrating by: Kathleen D.08/03/2011

Is this review helpful?


Needed in addition to std wiring kit for use on 5 wire system. Great value. KWD20981



- 48955

ratingratingratingratingrating by: 4895505/17/2011

Is this review helpful?


as discribed WORKS GREAT Thank you 14606



- 48955

ratingratingratingratingrating by: Stephen C05/09/2011

Is this review helpful?


Quick ship, the diodes were exactly as depicted (and exactly what I was expecting). Good folks to do business with.13114



- 48955

ratingratingratingratingrating by: David04/10/2011

Is this review helpful?


Works the way it should. It controls the tail lights of the towed car. Glad there was also a video on installing it.11451



- 48955

ratingratingratingratingrating by: Rich M.03/25/2011

Is this review helpful?


Great little item for towing as well as other little automotive & motorcycle projects. The etrailer team was fast to respond to my order and I had it within a couple of days. I plan to do more business with a company like this!10339



- 48955

ratingratingratingratingrating by: Nick F03/01/2011

Is this review helpful?


Simple to fit and good value. 8186
